Schiller RYAN 544859A User manual

OP / PARTS MANUAL
MAN 4163392 Rev. A 04-2008
544859A
LAWNAIRE (3-POINT HITCH 36”)
544860A
LAWNAIRE (TOW BEHIND)
544876A
LAWNAIRE (3-POINT HITCH 48”)

2
LAWNAIRE
2
CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of
itsconstituentsareknowntotheState
of California to cause cancer, birth
defects and other reproductive harm.
Californie Proposition 65Avertissement
Leséchappementsdesmoteursdieseletcertains
de leurs composés sont reconnus par l’Etat de
Californie pour être cancérigènes, provoquer
des défauts congénitaux et d’autres dangers en
matière de reproduction.
ADVERTENCIA
AVERTISSEMENT
WARNING
The engine exhaust from this product
containschemicalsknown to the State
of California to cause cancer, birth
defects or other reproductive harm.
California Advertencia
de la Proposicion 65
El estado de California hace saber que
los gases de escape de los motores diesel
y algunos de sus componentes producen
cáncer,defectosdenacimiento yotrosda-
ñosenelprocesodereproducciónhumana.
L’
é missiondumoteur de ce mat é rielcon-
tient des produits chimiques que l’Etat de
Californie consid è re ê tre canc é rig è nes,
provoquer des d é fauts cong é nitaux et
d’autres dangers en mati è re de reproduc-
tion.
ElestadodeCaliforniahacesaberquelos
gasesdeescapedeesteproductocontienen
productosquÍmicosqueproducencáncer,
defectos de nacimiento y otros daños en
el proceso de reproducción humana.
CALIFORNIA
Proposition 65 Warning
Battery posts, terminals, wiring
insulation, and related accessories
contain lead and lead compounds,
chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.
WASH HANDS AFTER HANDLING.

3
LAWNAIRE
6-2007
TABLE OF CONTENTS FIGURES PAGE
SAFETY............................................................................................................................................................2
SET-UP..........................................................................................................................................................3-7
OPERATION.................................................................................................................................................8, 9
SERVICE...................................................................................................................................................10-12
SPECIFICATIONS..........................................................................................................................................13
ACCESSORIES..............................................................................................................................................14
PARTS SECTION...........................................................................................................................................15
HYDRAULIC LIFTACCESSORY........................ FIGURE 1...................................................................16, 17
MANUAL LIFTACCESSORY..............................FIGURE 2...................................................................18, 19
MODEL NO. 544859A.........................................FIGURE 3...................................................................20, 21
MODEL NO. 544876A.........................................FIGURE 4...................................................................22, 23
MODEL NO. 544860A.........................................FIGURE 5...................................................................24, 25
IMPORTANT MESSAGE
Thank you for purchasing this Ryan product. You have purchased a world class product, one of the best de-
signed and built anywhere.
This machine comes with a Technical Manual containing safety, operation, parts and service information. The
useful life and good service you receive from this machine depends to a large extent on how well you read and
understand this manual. Treat your machine properly, lubricate and adjust it as instructed, and it will give you
many years of reliable service.
Your safe use of this Ryan product is one of our prime design objectives. Many safety features are built in, but
we also rely on your good sense and care to achieve accident-free operation. For best protection, study the
manual thoroughly. Learn the proper operation of all controls. Observe all safety precautions. Follow all instruc-
tions and warnings completely. Do not remove or defeat any safety features. Make sure those who operate
this machine are as well informed and careful in its use as you are.
See a Ryan dealer for any service or parts needed. Ryan service ensures that you continue to receive the best
results possible from Ryan’s products. You can trust Ryan replacement parts because they are manufactured
with the same high precision and quality as the original parts.
Ryan designs and builds its equipment to serve many years in a safe and productive manner. For longest life,
use this machine only as directed in the manual, keep it in good repair and follow safety warnings and instruc-
tions. You'll always be glad you did.
Schiller Grounds Care, Inc.
One Bob Cat Lane
Johnson Creek, WI 53038-0469

4
LAWNAIRE
MODEL NUMBER: This number appears on
sales literature, technical manuals and price lists.
SERIAL NUMBER: This number appears only
on your mower. It contains the model number
followed consecutively by the serial number. Use
this number when ordering parts or seeking war-
ranty information.
NOTICE !!!
Unauthorized modications may present extreme
safety hazards to operators and bystanders and
could also result in product damage.
Schiller Grounds Care, Inc. strongly warns against,
rejects and disclaims any modications, add-on
accessories or product alterations that are not
designed,developed,testedandapprovedbySchiller
GroundsCare, Inc.'sEngineeringDepartment. Any
Schiller Grounds Care, Inc. product that is altered,
modied or changed in any manner not specically
authorized after original manufacture–including the
additionof“after-market”accessoriesorcomponent
parts not specically approved by Schiller Grounds
Care, Inc.–will result in the Schiller Grounds Care,
Inc. Warranty being voided.
Any and all liability for personal injury and/or
property damage caused by any unauthorized
modications, add-on accessories or products not
approved by Schiller Grounds Care, Inc. will be
considered the responsibility of the individual(s) or
company designing and/or making such changes.
Schiller Grounds Care, Inc. will vigorously pursue
full indemnification and costs from any party
responsibleforsuchunauthorizedpost-manufacture
modications and/or accessories should personal
injury and/or property damage result.
This symbol means:
ATTENTION!
BECOME ALERT!
Your safety and the safety of others is involved.
Signal word denitions:
The signal words below are used to identify levels
of hazard seriousness. These words appear in this
manualandonthesafetylabelsattachedtoSchiller
Grounds Care, Inc. machines. For your safety and
thesafetyofothers,read andfollow theinformation
given with these signal words and/or the symbol
shown above.
DANGER indicates an imminently hazardous
situationwhich,ifnotavoided, WILL resultindeath
or serious injury.
WARNING indicates a potentially hazardous
situation which, if not avoided, COULD result in
death or serious injury.
CAUTIONindicatesapotentiallyhazardoussituation
which,ifnotavoided,MAY resultinminorormoderate
injury. It may also be used to alert against unsafe
practices or property damage.
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which, if
not avoided, MAY result in property damage.
SAFETY

5
LAWNAIRE SET-UP
SET-UP
MODEL 544859A, 3-POINT HITCH 36"
MODEL 544876A, 3-POINT HITCH 48"
Banding is under tension and may snap back
when cut. Wear eye protection and stay clear
when cutting the band.
Use caution when installing the knives and
tines. These items are sharp and should be
handled with care.
Use an appropriate jackstand to support the
aerator any time it is serviced or repaired.
1. Remove and discard banding holding the aerator
to the pallet.
2. Attach tractor to aerator and lift off pallet. For
category 1 hitches, use the bushing (Part No.
829987) and the hitch pins.
3. Place jackstands at each end of tine wheel axles
and lower aerator onto stands. Aerator wheels
need to be approximately 5 to 6 inches (127 to
152 mm) above the ground.
4. With tractor engine off, install the appropriate
tools for your needs. Figure 1 shows coring
tines mounted to the aerating wheels (8 tines per
wheel). When using coring tines, the nipple on
the inside of the tine clamp (Part No. 515198)
must be placed into the hole on the sides of the
tine. Refer to Parts List, Pages 21 and 23 for
knife blade installation.
NOTE: To assure equal tine spacing, note the
position of the tines in Figure 1. The middle wheels
have the tines mounted on the inner side, the outside
wheels have the tines mounted on the outer side.
See Accessories (Page 14) for optional attachments.
5. Lubricate aerating wheels with lithium based
lubricant until lubricant can be seen at wheel
bushings. Check aerating wheels for free
rotation.
FIGURE 1
Tine Spacing

6
LAWNAIRE
SET-UP
SET-UP
MODEL 544860A, TOW BEHIND
Banding is under tension and may snap back when cut. Wear eye protection and stay clear when
cutting the band.
DO NOT use tractor hydraulics to hold up aerator for servicing. Hydraulic lines may rupture
causing the unit to fall suddenly.
Use caution when installing the knives and tines. These items are sharp and should be handled
with care.
1. Remove and discard banding holding aerator to pallet.
2. Locate and mark the center on the front side of the frame (Part No. 4163369.7). Mark the center of the
hitch assembly (Part No. 4163370.2 in a location which can be seen when mounting it to the frame.
3. Using the center marks for alignment, mount the hitch assembly and clamping plate (Part No. 547741) to
the frame. The hitch assembly will mount on the bottom side of the frame for small tractors, and on the
top side of the frame for larger tractors.
NOTE: Install the manual lift accessory or the hydraulic lift accessory to the aerator before installing the tines
or knife blades. An electric lift kit is also available (Part No. 4131949) which contains set-up instructions
When used on a Bobcat or Bunton ZT200 mower, Hitch Kit (Part No. 970315) is also available to provide a
hook-up point on the mower. Refer to the following installation instructions for the proper application of the
hydraulic or manual lift accessory.
If the hydraulic lift accessory is used, secure the hitch and clamping plate using (3) 3/8-16 X 2-1/2"
screws, lockwashers and nuts. Mount the hose support (Part No. 521905) onto the right front hole of the
clamping plate. Secure, using a 3/8-16 X 3" screw, large atwasher, lockwasher and nut. (The hardware
for each accessory is included in the appropriate accessory kit).
If the manual lift accessory is used, secure the hitch and clamping plate to the frame with (4)
3/8-16 X 2-1/2" screws, lockwashers and nuts.
4. Attach tractor to the aerator and carefully pull aerator off the pallet. Stop tractor engine.

7
LAWNAIRE
Escaping hydraulic oil under pressure can have sufcient force to penetrate the skin, causing
serious injury.
If a leak is suspected, use a piece of cardboard or wood, not your hands, to check for leaks.
If injured by escaping uid, see a doctor at once. Serious infection or reaction can develop if
proper medical treatment is not administered immediately.
Do not use a unit with a leaking hydraulic system. See your authorized Ryan dealer for necessary
repairs.
NOTE: This lift accessory is designed to be used with a hydraulic system providing 700 p.s.i. (4,824kPa) or
1500 p.s.i. (10,341kPa) working pressure. It may work on systems providing lower pressures, but will raise
the aerator much slower.
Properly support the aerator, using jackstands, for removal of the right side transport wheel and
leg assembly. For safe removal, the wheel and leg need to be at least 2 inches (50mm) above the
ground and move freely in order to remove it from the axle shaft.
1. Remove the spirol pin, and the wheel and leg assembly from the right side of the axle shaft and retain for
later use.
2. Install the cylinder mounting brackets (Part No. 522090) onto the right wheel leg assembly, using (4)
7/16-14 X 1" screws, lockwashers and nuts. See Figure 2, Page 6.
3. Install the woodruff key (Part No. 64164-35) into the keyway on the axle shaft, and slide the wheel and leg
assembly back onto the axle. Secure with the spirol pin removed in Step 1.
4. Remove the (4) 7/16-14 X 1-3/4" screws securing the right frame arm (Part No. 521883) and cover to the
frame (Part No. 545645). Retain hardware for later use.
5. Mount the cylinder pivot bracket (Part No. 545649) onto the frame arm using the original hardware. See
Parts List, Page 17.
6. Install the hydraulic cylinder (Part No. 545787) in the appropriate holes on the cylinder pivot bracket and
the wheel leg assembly, or the cylinder pivot bracket and the cylinder mounting brackets. See Figures 2
and 3, Page 6.
SETUP
HYDRAULIC LIFT ACCESSORY
PART NO. 545711

8
LAWNAIRE
SETUP
NOTE: For tractors with 700 p.s.i. (4,824 kPa), in-
stall the hydraulic cylinder using the front holes in the
cylinder pivot bracket, and the holes of the cylinder
mounting brackets. Figure 2.
For tractors with 1500 p.s.i. (10,341 kPa), install the
hydraulic cylinder using the rear holes in the pivot
mounting bracket, and the holes in the wheel and leg
assembly. Figure 3.
FIGURE 2
(For Tractors With 700 p.s.i. Hydraulics)
1. Cylinder Mounting Bracket
2. Wheel and Leg Assembly
3. Front Hole Position on Pivot Bracket
FIGURE 3
(For Tractors With 1500 p.s.i. Hydraulics)
1. Rear Hole Position on Pivot Bracket
2. Wheel and Leg Assembly
NOTE: The operator is responsible for acquiring the
proper hoses and/or ttings that attach the hydrau-
lic cylinder to the tractor directly to the cylinder, or
the operator may install hydraulic ttings onto the
cylinder.
For proper connection to the cylinder, use hoses or
ttings with a 3/8-18 NPT. Fittings can be obtained
from any local tractor dealer, or can be ordered
through your Ryan dealer. See Parts List on Page
17 for appropriate ttings.
7. Install hydraulic hoses (not included with set)
from tractor to cylinder, passing through the hose
support. Raise and lower aerator to make sure
hydraulic oil is circulated through entire system.
Check for any loose or leaking connections
and tighten or replace as necessary. Fill tractor
hydraulic reservoir if necessary.

9
LAWNAIRE SETUP
MANUAL LIFT ACCESSORY
PART NO. 545654 (For Tow Behind Lawnaire Model 544860A)
1. Remove the (2) 3/8-16 X 1-1/2" screws, securing the rear part of the cover to frame arm, on right side of
aerator. Retain hardware for later use.
2. Install right stop assembly (Part No. 545675) to unit as shown in Illustration on Page 18. Secure stop with
the original hardware.
3. Using the same procedure, install the left side stop (Part No. 645655).
4. Place the spring (Part No. 521880) between the uprights on the wheel leg. Insert the lock pin into the
holes, passing lock pin through both leg uprights.
5. Pull the spring back and insert a cotter pin (Part No. 307976) through the hole in the lock pin. The cotter
pin will be positioned between the spring and the leg upright. Repeat procedure on other side of unit.
6. To raise aerator, insert the lifting handle (Part No. 521892) into the tube on the wheel leg. Raise handle
lowering wheel leg into a vertical position. Lock the locking pin into the hole on the stop bracket. Repeat
on other side of unit.
7. To lower aerator, insert the lifting handle into the tube on the wheel leg. Push handle forward to relieve
pressure on the locking pin. Pull pin out and raise the wheel, lowering the aerator. Repeat on opposite
side of unit.
8. Replace lifting handle in tongue for storage. Insert pin (Part No. 521918) to secure lifting handle.

10
LAWNAIRE
OPERATION
MODEL 544859A, 3-POINT HITCH 36"
MODEL 544876A, 3-POINT HITCH 48"
Before operating the aerator, check area to be aerated, and remove any objects which may
present a safety hazard or damage the aerator (rocks, cans, etc.)
To prevent injury, do not operate aerator without cover in place. Do not make adjustments or
perform any maintenance while tractor engine is running.
Do not leave tractor unattended without stopping the engine and lowering the aerator.
NOTE: Failure to lubricate aerating wheels can cause damage to axle, bushings and wheels.
Never cross hard objects or surfaces (sidewalks, driveways, stepping stones, etc.) with tines down.
Do not back up when tines are in the ground or damage to the tines and clamps may occur.
For maximum performance, a double set of tines may be mounted onto the aerating wheels. A longer
screw is required for this application. To obtain this screw, order Part No. 311213.
1. Position the tractor and aerator where you wish to begin aerating.
2. With tractor in motion, lower aerator and begin aerating.
3. After completion of job, clean and service the aerator according to the following service instructions.
TRANSPORT OF TOW BEHIND
LAWNAIRE MODEL 544860A
1. With transport wheels lowered and locked into place, tow the aerator to and from job sites with aerator
properly hitched to tractor drawbar. Maximum towing speed should not exceed 10 MPH (16 km/h).

11
LAWNAIRE
AERATING
LAWNAIRE MODEL 544860A
This unit is not designed nor meant to be towed at speeds in excess of 10 MPH (16 Km/h).
Towing at excessive speeds will cause damage to frame and/or wheels. This type of damage will
not be repaired under the terms of the warranty.
Before operating the aerator, check area to be aerated and remove any objects which may present
a safety hazard or damage the aerator (rocks, cans, etc.).
To prevent injury, do not operate aerator without cover in place. Do not make adjustments or
perform any maintenance while tractor engine is running.
Do not leave tractor unattended without stopping the engine.
NOTE: Failure to lubricate aerating wheels can cause damage to axle, bushings and wheels.
Never cross hard objects or surfaces (sidewalks, driveways, stepping stones, etc.) with tines down.
Aerator should be raised completely out of the ground to avoid turf damage while turning.
Do not back up when tines are in the ground or damage to the tines and clamps may occur.
For maximum performance, a double set of tines may be mounted onto the aerating wheels. A longer
screw is required for this application. To obtain this screw, order Part No. 311213.
1. Position tractor and aerator where you wish to begin aerating. On models with hydraulic lift, lower unit
and begin aerating. On models with manual lift, use the lift handle (as stated in Step 7 on Page 7) to
lower the aerator to the ground.
2. Tow Lawnaire over area to be aerated.
3. After completion of job, clean and service the aerator according to the following service instructions.
OPERATION

12
LAWNAIRE
SERVICE
DO NOT use tractor hydraulics to support the aerator while servicing. Hydraulic lines may rupture
causing unit to fall suddenly.
When replacement parts are required, use genuine Ryan parts or parts with equivalant
characteristics including type, strength and material. Failure to do so may result in product
malfunction and possible injury to the operator and/or bystanders.
LUBRICATION
1. Wipe off lubrication ttings before and after lubrication of aerating wheels. Lawnaire Model 544859A has
six lubrication ttings; Lawnaire Models 544860A and 544876A have eight lubrication ttings.
2. Lubricate aerating wheels after every four hours of use. Use a standard lithium based grease.
3. Lubricate aerating wheels daily (Model 544860)
4. Transport wheel bearings should be repacked yearly using a good grade wheel bearing lubricant.

13
LAWNAIRE SERVICE
STORAGE INSTRUCTIONS
Thoroughly clean all tines, inside and out, after aerating is completed. A light coating of oil sprayed onto the
tines or blades will help prevent rust and ensure proper coring the next time the unit is put into service.
Unit should be stored on boards to protect tines or blades from rust and damage. Store in a dry location.
Lubrication before long storage periods will help prevent moisture build-up in the lubrication cavities.
When bringing unit out of storage, check for loose hardware and damaged parts. Tighten and replace as
needed.
FOR MODELS EQUIPPED WITH HYDRAULIC LIFT ACCESSORY
Check hydraulic cylinder for leaks and replace seal kit if needed. To obtain seal kit, order Part No. 884597.
Check the hydraulic hose connections for tightness and check the hoses for any wear or damage. Tighten
and replace as necessary.
NOTE: Proper storage and maintenance will extend the usage and performance of the unit.
TINE WHEEL REPLACEMENT
MODELS 544859A & 544876A
1. Attach aerator to tractor for stability.
2. Raise unit and place jackstands under frame assembly. Lower unit on frame making sure tines are not
touching the oor.
3. Remove spirol pin (Part No. 64176-09) from axle, on side closest to wheel to be repaired.
4. Pull axle out until the tine wheel to be replaced or serviced is free. Note location of spacers as the tine
wheels are removed.
5. Replace or service the appropriate tine wheel.
6. Remove any surface rust from axle shaft to prevent damage to seals.
7. Apply a lithium based lubricant to the axle shaft and to the lip of the seals before reassembling. Assemble
in the reverse order of removal.
8. Replace spirol pin with new pin, Part No. 64176-09.

14
LAWNAIRE
TINE WHEEL REPLACEMENT
MODEL 544860A
1. Attach aerator to tractor for stability.
2. Raise unit and place jackstands under each frame arm and lower aerator, keeping the transport wheels
and the tine wheels off the oor.
3. If aerator has the hydraulic lift accessory, disconnect the hydraulic cylinder from the wheel leg assembly.
4. Remove spirol pin, wheel leg assembly and key from axle shaft, on side closest to wheel to be repaired.
(Units with hydraulic lift will have a key at each end of axle shaft.)
5. Pull axle out until tine wheel to be replaced or serviced is free. Note the location of spacers as tine
wheels are removed.
6. Remove any surface rust from the axle shaft to prevent damage to the seals.
7. Apply a lithium based lubricant to the axle shaft and to the lip of the seals before reassembling. Assemble
in the reverse order of removal.
8. Replace spirol pin with new pin, Part No. 64176-09.
SERVICE

15
LAWNAIRE
SPECIFICATIONS
Aerating Depth:
Up to 5" (127 mm), depending on soil condi-
tions.
Model 544876A: Up to 4" (102 mm)
Aerating Pattern:
6" X 6" (152 mm X 152 mm)
Aerating Width:
36" (914 mm)
Model 544876A: 48" (1,219 mm)
Chassis:
1-1/2" sq. X 3/16" wall tube.
Dimensions:
Model 544859A:
Width 35" (889 mm)
Height 34-1/2" (876 mm)
Length 27-3/4" (705 mm)
Model 544876A:
Width 46" (1,368 mm)
Height 34-1/2" (876 mm)
Length 31" (787 mm)
Model 544860A:
Width 46" (1,168 mm)
Height 31" (787 mm)
Length 68-1/2" (1,740 mm)
SPECIFICATIONS
Hitch:
Model 544859A: Mounted; 3-point hitch
Model 544876A: 3-point hitch category "1"
Model 544860A: Tow Behind; pin and clevis
hitch.
Lubrication:
Pressure ttings. Refer to the service sec-
tion on Page 10.
Tines:
See accessories section, Page 14.
Tires:
Model 544860A: 4.10/3.50-4, 2 ply pneu-
matic w/ball bearings.
Model 544860A: 10.25 X 3.25
semi-pneumatic. (SN1111111111 & up)
Tire Pressure:
Model 544860A: 40 p.s.i. (276 kPa)
Weight:
Model 544859A: 475 lbs. (215 kg)
Model 544876A: 675 lbs. (306 kg)
Model 544860A: 500 lbs. (227 kg)
Wheels:
Aerating; Cast iron with sintered bronze
bushing.

16
LAWNAIRE
515196 - 1/2" Coring Tine
522361 - 3/4" Coring Tine, Thin Wall
515197 - 3/4" Coring Tine, Thick Wall
These tines are for use with aeration programs in
the Spring and Fall. Soil cores up to 4" (102mm)
in length can be removed with minimal surface
disturbance.
(Single Knife Part Numbers)
521155 - Deep Slicing Knife
515193 - Shallow Slicing Knife
Slicing knives are used for aeration and renovation
programs during all seasons. Slicing knives control
thatch by cutting through grass runners and also
have the advantage of no surface clean up after
aerating. Knives are especially helpful in that they
do not place buried seeds of noxious weeds on the
surface where they can germinate.
Slicing knives are especially recommended for ath-
letic elds. Slicing allows moisture, air and fertilizer
to be absorbed while not creating hazardous playing
conditions for athletes.
520404 - Aerating Tine
These tines are for turf building and Fall renovation
programs. These tines will thoroughly open up the
soil by penetrating deep into the ground bringing up
large amounts of soil, which then becomes top dress-
ing.
ACCESSORIES

17
LAWNAIRE PARTS SECTION
PARTS
SECTION

18
LAWNAIRE
FIGURE 1
HYDRAULIC LIFT ACCESSORY

19
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
LAWNAIRE FIGURE 1
1-1 64006-03 LOCKWASHER 3/8 4
1-2 64123-82 SCREW-3/8-16 X 2-1/2 3
1-3 64006-06 LOCKWASHER-7/16 4
1-4 304364 NUT-7/16-14 4
1-5 64025-05 NUT-3/8-16 4
1-6 64123-39 SCREW-7/16-14 X 1 4
1-7 64123-75 SCREW-3/8-16 X 3 1
1-8 521905 SUPPORT-HOSE 1
1-9 522090.7 BRKT-CYLINDER MOUNT 2
1-10 545649.7 PIVOT-CYLINDER 1
1-11 2703422 PIN-LOCK 2
1-12 545787 CYLINDER-HYDRAULIC 1
1-13 547741 PLATE-CLAMPING 1
(INCLUDES ITEM 14)
1-14 521921 DECAL-INSTRUCTION 1
1-15 64168-5 PIN-HAIR 2
1-16 548390 FITTING-90 DEG. HYD 3/8-18 2
1-17 64164-35 KEY-WOODRUFF 1/4 X 2-1/8 1
1-18 64163-53 WASHER-SPECIAL 1
1-19 * 884597 SEAL KIT-HYD CYLINDER A/R
* NOT ILLUSTRATED
HYDRAULIC LIFT ACCESSORY

20
LAWNAIRE
FIGURE 2
MANUAL LIFT ACCESSORY
