SCHLAPPI ENGINEERING NIBBLER User manual

SCHLAPPI ENGINEERING
The Nibbler is a four bit digital accumulator based on CM S logic. This means that it counts in binary from zero to
fteen, with inputs and outputs for individual bits as well as stepped voltage outputs (digital to analog
converters). It does this with individual logic chips instead of a CPU.
The concept here is that counting in binary (and its expression in bits) is inherently musical, and with slow clock
speeds we can use it to create both rhythms and modulation voltages (or melodies). At audio rate we can
generate subharmonics and modem-like sounds (or noise).
SUBTRACT ADD SWITCH
Determines if the binary word
is added or subtracted to the
output register
ASYNC SYNC SWITCH
Determines if the output is
updated only on a clock pulse
(sync), or every time an input is
received (async)
ADD SWITCHES
These four switches form a binary
word, adding the indicated
amount to the output register at
each clock pulse.
RESET BUTTON
Clears the output register, holding
all outputs at zero while the
button is held if in SYNC mode and
at the value indicated by the
switches if in ASYNC M DE
OFFSET SWITCHES
These two switches set a phase
oset for the related stepped
voltage.
STEPPED OUTPUTS
Stepped voltages made by adding
the 4 gate outputs together with
binary weights
CARRY OUTPUT
Gate output that goes high for one
clock pulse when the accumulator
overows. Can be used to chain
multiple nibblers or as a clock
divider output.
CLOCK INPUT
Input for any gate or trig signal,
generally necessary for operation
QUICKSTART GUIDE - NIBBLER MANUAL ONLINE AT SCHLAPPIENGINEERING.COM
GATE OUTPUTS
UT1, UT2, UT4, UT8 combined
form a binary word and are
thecurrent contents of the output
register. They can be used as clock
dividers or to create rhythms.
SUB INPUT
Reverses the direction of the
counter, X Rs with the related
switch.
SHIFT INPUT
If in SYNC mode then when the
SHIFT is high then on clock pulses
the register shifts up instead of
adding, in ASYNC mode the
register will shift on each pulse.
GATE INPUTS
GATE 1, GATE 2, GATE 4 , GATE 8
add to their respective switches
then are added to the output
register. Can be used without a
clock.
SHIFT DATA
Replaces the input of the shift
register
With no input the top bit (OUT 8)
cycles around and enters from the
bottom.
DATA XOR INPUT
The input will be X R'ed with
whatever is present at the input to
the shift register. nly active when
using the SHIFT input.
RESET INPUT
Resets the register to zero
whenever a signal is received.
Acts as a sync input at audio rates
PR TIPS :
*Black square around a jack
indicates output, all others are inputs
*A clock input is generally required
*Check that at least one ADD switch is up
Lower oset
switch
down
up
down
up
Lower
oset
switch
Upper
oset
switch
Degree
oset
Numerical
oset
down down 0 0
up down 45 2
down up 90 4
up up 180 8

CLOCK DIVIDER
SWITCH P SITI NS SUBTRACT ADD ADD
ASYNC SYNC SYNC
ADD 1 UP
THER SWITCHES D WN
•CL CK signal at CL CK input
•take divider output from CARRY
•With only ADD1 up you will have divide by 16
•only ADD2 will give you divide by 8, ADD 4 will divider by 4
•Push the switches down and raise only ADD 8 for divider by 2
•In generally the ADD switches form the numerator of a divide by 16 calculation
•Try the GATE UTPUTS to get other divisions
PATCHES TO START WITH
STEPPED VOLTAGES
•Start from the CL CK DIVIDER
patch
•Plug the two stepped (sawtooth)
voltages into a pitched input
•Try dierent switch settings for
dierent sequences
TRIANGLE WAVE
•Start from STEPPED V LTAGES
•Patch the CARRY out into SUB input
•This will cause the accumulator to
alternate counting up and down,
resulating in a triangle wave
•Works at LF or audio rate
SHIFT REGISTER NOISE
•Start from AUDI RATE patch
•Patch signals into the SHIFT INPUT
•Try all the other inputs as well
AUDIO RATE (FREQUENCY DIVIDER)
•Start from CL CK DIVIDER patch
•Input audio at CL CK input
•Listen to CARRY or GATE outs for pulse
waves
•Listen to stepped outputs for saw,
triangle, or other waveform outputs
A BIT F THE RY
The Nibbler is at it's core a 4-bit accumulator. That is an adder combined with a register (or memory), this
means on each clock pulse the the accumulator word is added to itself (or the existing contents of the
register). This is a core component of digital oscillators and lters.
