Schlumbohm EndoPilot User manual

Schlumbohm
Schlumbohm
609 2x01- v07 All data is subject to change. Misprints, errors, innovations and changes excepted.
DE
DE Gebrauchsanweisung Gebrauchsanweisung
EN
EN User Manual User Manual
FR
FR Mode d’emploi Mode d’emploi
IT
IT Modo di uso Modo di uso
PL
PL Podr cznik Podr cznik
ES
ES Modo oe Utilizacion Modo oe Utilizacion
GR
GR Ο∆ΗΓΙΕΣ ΧΡΗΣΗΣ ΓΙΑ Ο∆ΗΓΙΕΣ ΧΡΗΣΗΣ ΓΙΑ
EndoPilot

1
1a 1b 1c 1d
4a
4b
4c
11a
11b
11d
11c
23
4
6
5
7 8
910
11
12
13
14

EndoPilot
*related to the additional module “CoPilot” - 1 - 609 2201 v12 www.schlumbohm.de
Description of the individual components
Picture Component Description
1 Control-Unit
Ref.-No: 109 2010
Control unit with touch screen, incl. 4 connecting sockets (1a, 1b,
1c, 1d) and tripod nut on the backside
2 Power Supply
Ref.-No: 109 232.1
AC/DC converter with Euro-prime plug
Input: 100 – 240 V/AC Output: 12 V/DC 1,25 A
3 Foot Switch
Ref.-No: 109 233.4
Start/stop, cable-connected foot switch with connection to the
power supply
4 Apex-cable set
Ref.-No: 109 2311
4a – Measuring cable with plug Ref.-No: 109 2312
4b – Cable with file clamp Ref.-No: 109 2313
4c – Lip clip Ref.-No: 109 2314
5 Contra-angle
Ref.-No: 109 0126
For the Apex-measuring / fully isolated/ transmission 1:1, with ISO-
E fitting
6 Motor
Ref.-No: 109 0112
Motor with Apex-measuring contact, LED performance display and
ISO-E connection
7 D-Pack Heating Tip
Ref.-No: 109 0152 - ...56 Heating Tips - 5 different sizes are available
8 D-Pack
Ref.-No: 109 0151 DownPack handpiece with LED display
9 BackFill Needle
Ref.-No: 109 0149
The Gun Needle Starter Set encloses 3X25ga und 3X 23ga
Different sizes are available
10 Heat insulator
Ref.-No: 109 0143 Offers protection from thermal damaging
11
-
BackFill Gun
Ref.-No: 109 0141
(Backfill cable)
Ref.-No: 509 0142
For the thermo-plastic filling of the root canal
(cable: no illustration)
11a – Release button
11b – Piston
11c – Lever
11d – Cylinder with knurled knob
12 Multi-tool
Ref.-No: 109 0147 For forming as well as screwing on and off the BackFill Needles
13 Guttapercha
Ref.-No: 109 0142
Pellets made of Guttapercha for the BackFill Gun
Gutta Percha Bar encloses 100 Pellets
14 Cleaning Set
Ref.-No: 109 0148
Brushes for the cleaning of the BackFill Gun
The Cleaning Set encloses 2 brushes
19 Base with equipment Holder
Ref.-No: 109 2306 Tray for the entire equipment (see illustration on page 2)
- Protective Foil
Ref.-No: 109 2397
Foil for protection of the display (optional, no illustration)
Can be ordered from the manufacturer
- Wireless foot switch
Ref.-No: 109 2360
Special accessories: wireless foot switch with one pedal (single)
incl. receiver module
(optional, no illustration )

19
15
23
18
16
21
17
22
20
19a
15d
15e
15c
15a
15b

EndoPilot
*related to the additional module “CoPilot” - 3 - 609 2201 v12 www.schlumbohm.de
Supplementary module CoPilot *
Picture Component Description
15
Additional module
CoPilot
Ref.-No: 109 32.07
Control unit incl. 4 connecting sockets (15a -15d), connecting plug to
the EndoPilot (15e) and integrated battery as well as wireless module
15a – Update – Connection
15b – Power supply – Connection in combination with
15c – Additional connection DownPack
15d – Ultrasonic handpiece - connection
16 Ultrasonic handpiece
Ref.-No: 109 3102
With Satelec® compatible screw thread
EMS ® compatible version also available on request
17 Rinsing adapter
Ref.-No: 109 3132
Adapter for standard syringe for the cleaning of the ultrasonic
handpiece
18 Handpiece cable
Ref.-No: 109 3122 Highly flexible connection with handpiece plug
19 Base CoPilot
Ref.-No: 109 2306
Rack for the handpieces with double holder (19a) Ref.-No: 109 2309
for ultrasonic handpiece and motor
(3 countersink screws for the mounting at the device casing are
attached)
20 Wireless twin foot switch
Ref.-No: 109 2351
Pedal I = Start
Pedal II = Select / to select the functions
Incl. 2x 1,5V batteries, type AA
21 Torque wrench
Ref.-No: 109 3112 Mounting tool for ultrasonic tips with torque limiter
22 Adapter cable
Ref.-No: 509 0410
Connecting cable to charge the CoPilot with the power supply of the
EndoPilot
23 Mounting screws
Ref.-No: 360 0413
To mount the CoPilot to the EndoPilot (3x)
Countersunk screw DIN 7991 M4x12

EndoPilot
+
CoPilot

EndoPilot
*related to the additional module “CoPilot” - 5 - 609 2201 v12 www.schlumbohm.de
Congratulations!
We are glad you have decided to purchase the EndoPilot. You have made a good choice.
For more than 40 years, the family-owned company Schlumbohm®has been successful on the dental industry market.
These long-standing experiences as well as excellent contacts to specialists nationally and internationally permit the
company Schlumbohm®to design outstanding devices, enabling the patient as well as the dentist to achieve an optimal
treatment result.
Each development has, in addition to the self-evident optimal treatment result strived for, the focus on an easy and
convenient handling.
With the EndoPilot®you acquired a product which was developed and tested with utmost care. With regard to function
and usability, it meets even the highest demands.
Attention: the device is available in several extension versions
Depending on the extension version, the device offers various functions:
•EndoPilot Comfort : Endo-Motor and Apexfinder
•EndoPilot Comfort Plus : Endo-Motor and Apexfinder, DownPack and BackFill
•Additional module CoPilot : offers additional ultrasonic, battery-operation and a wireless foot switch
This instruction of use describes the basic device EndoPilot Comfort Plus, from firmware 50 (see Setup chap. 8).
All extra functions of the additional module „CoPilot“ are marked with „* “.
Manufacturer:
Schlumbohm GmbH & Co. KG
Klein Floyen 8-10
D-24616 Brokstedt
Germany
www.schlumbohm.de
[email protected]
Telephone +49-4324 - 8929 - 0
Telefax +49-4324 - 8929 – 29
WEEE-Reg.-Nr. DE 88116129
Edition 04-2013
The manufacturer reserves the right to change indications and data of this operating manual also without prior notice.
Upon request, the operating manual is available in several languages.
This operating manual was prepared with utmost care. However, as mistakes can never be fully excluded, we are always
thankful for each hint. Please contact us directly in such an event. Also, should you have any further questions, please
do not hesitate to contact us.

EndoPilot
*related to the additional module “CoPilot” - 6 - 609 2201 v12 www.schlumbohm.de
Table of contents Page
1. Remarks .................................................................................................................... 7
1.1. Symbols ................................................................................................................................................................ 7
1.2. Proper Usage........................................................................................................................................................ 8
1.2.1. Apexlocator........................................................................................................................................................... 8
1.2.2. Motor..................................................................................................................................................................... 8
1.2.3. DownPack-Handpiece with Heating Tip................................................................................................................ 8
1.2.4. BackFill Gun.......................................................................................................................................................... 8
1.2.5. Ultrasonic Handpiece * ......................................................................................................................................... 8
1.3. General Precautions ............................................................................................................................................. 8
1.3.1. Contra-Indications................................................................................................................................................. 8
1.3.2. General Conditions of Operating........................................................................................................................... 8
2. First Steps............................................................................................................... 10
2.1. Installation........................................................................................................................................................... 10
2.2. Base with Equipment Holder............................................................................................................................... 10
2.3. Connection.......................................................................................................................................................... 10
2.4. Touch-Display ..................................................................................................................................................... 11
2.5. Foot Switch ......................................................................................................................................................... 11
2.6. Switch on, Standby, Switch off, Battery-Operation* ............................................................................................ 12
2.7. Preparation of the Root Canal – Motor and Contra-Angle .................................................................................. 12
2.8. Filling Technique - DownPack (D-Pack) ............................................................................................................. 13
2.9. Filling Technique - BackFill (B-Fill)...................................................................................................................... 13
3. Manual Root Length Measurement ....................................................................... 14
3.1. Advice for an accurate Measurement ................................................................................................................. 15
4. Motor system .......................................................................................................... 15
4.1. Favorites ............................................................................................................................................................. 15
4.2. Selection of a file system .................................................................................................................................... 16
4.3. MyFile System .................................................................................................................................................... 16
4.4. Selection of a sequence / file .............................................................................................................................. 17
4.5. Preparation ......................................................................................................................................................... 17
4.6. File Parameters (F. Data) ................................................................................................................................... 18
4.6.1. Reciprocal Function ............................................................................................................................................ 18
4.6.2. File Management / Selection of a Box ................................................................................................................ 19
4.7. Options ............................................................................................................................................................... 20
4.7.1. Apexlocator – Root Canal Measurement during Preparation.............................................................................. 21
5. Obturation ............................................................................................................... 22
5.1. DownPack........................................................................................................................................................... 22
5.2. BackFill ............................................................................................................................................................... 22
6. Ultrasonic Function* .............................................................................................. 23
6.1. Selection of the Ultrasonic output level*.............................................................................................................. 24
6.2. Selection of Run-Time* ....................................................................................................................................... 24
6.3. Ultrasonic-Instrument-Selection.......................................................................................................................... 24
7. Contra-angle calibration ........................................................................................ 25
8. Setup CoPilot / Wireless foot switch* ................................................................... 25
9. Reset........................................................................................................................ 26
10. Setup / Updates / Tones........................................................................................ 26
11. Maintenance............................................................................................................ 26
12. Trouble Shooting.................................................................................................... 27
13. Error Messages ...................................................................................................... 28
14. Warranty / Liability ................................................................................................. 28
15. Technical Data ........................................................................................................ 28
16. Cleaning, Disinfection, processing of devices .................................................... 28
16.1. procedural instruction part I : Control-Unit, Contra-angle and Motor................................................................. 29
16.2. Procedural Instruction part II: Apex-cable, D-Pack-handpiece and BackFill-gun ............................................... 31
16.3. Procedural Instruction Part III: 1. CoPilot device 2. Ultrasonic cable and 3. Ultrasonic handpiece .................... 33

EndoPilot
*related to the additional module “CoPilot” - 7 - 609 2201 v12 www.schlumbohm.de
1. Remarks
1.1. Symbols
Description of the symbols used in this operating manual.
Symbol Description
The product complies with the requirements of the EU Directive 93/42
Warning: Consult the operating manual!
If the instructions are not followed properly, operation may result in damages of the device or
in the injury of the user or the patient.
Special protection against electric shock (Usage part)
This medical product may not be disposed off in the normal garbage. The national disposal
regulations for electrical and electronic equipment have to be adhered to.
WEEE Directive (Directive 2002/96/EC)
Single use only
contains Guttapercha
contains silver
use before
EU authorized representative
Mechanic processing in the thermo disinfector
Steam sterilisation
Production LOT
Manufacturer

EndoPilot
*related to the additional module “CoPilot” - 8 - 609 2201 v12 www.schlumbohm.de
1.2. Proper Usage
The EndoPilot is an „all-in-one“ device concept for the mechanical root canal treatment.
It is exclusively determined for the usage in dentistry and may not be combined with other devices.
The EndoPilot was especially designed for the endodontic. The EndoSystem is intended for the following usage only:
1.2.1. Apexlocator
By the Apexlocator, the file position in the root canal is determined. This length determination can either be done
manually by using the file clamp (without motor) or parallel to the preparation of the root canal (integrated length
determination with motor).
1.2.2. Motor
Mechanical root canal preparation in combination with the preprogrammed nickel-titanium files with standard settings,
with optional integrated length determination. Basically, the actual parameters of the manufacturer files should be used.
1.2.3. DownPack-Handpiece with Heating Tip
Vertical thermoplastic condensation of Guttapercha in the root canal as well as cutting off of Guttapercha sticks.
1.2.4. BackFill Gun
Final thermoplastic filling of root canals with Guttapercha.
1.2.5. Ultrasonic Handpiece *
*CoPilot: The CoPilot was developed as supplementary module for the EndoPilot. It provides the ultrasonic function for
the execution of professional endodontic treatments.
Possible scope of application: Activation of a rinsing solution in the root canal, revisions, preparations of the canal with
ultrasonic instruments and removal of pins.
In addition, the device is equipped with a battery and a wireless foot switch.
1.3. General Precautions
Please read the operation manual precisely and completely! This is the only way to assure a maximum of security. Most
of the problems in operating and maintenance result from the insufficient attention being paid to basic safety precautions
and the fact that the possibility of accidents is not foreseen.
The user and his team have to be familiar with the device prior to the first usage.
Always use a cofferdam to prevent inhalation or swallowing of small parts!
If you have any questions or note any problems, please contact your supplier immediately.
Do not use the device if your patient or you are having an active implant (pacemaker, etc.)!
*CoPilot: Use safety goggles. Aerosols and germs may be released when using ultrasonic, therefore, please always use
a mask.
1.3.1. Contra-Indications
Using Guttapercha in combination with the Backfill function on patients with a known allergy to latex, silver or copper may
result in allergic reactions. These reactions may cause irritations of eyes, lips and the face. They may also cause
breathing problems. Patients should be instructed to immediately indicate any complaints occurring.
1.3.2. General Conditions of Operating
Operating
•The EndoPilot may only be used by approbated specialists.
•The device parts have to be used sterile, please observe the disinfection- and processing-instruction in the
appendix.
•Prior to usage, please check the device for damages.
•Use the device only for its intended purposes.
•Do not combine the device with other devices, like, for example, Endo-devices from other manufacturers.
•Do not alter the device in any way. Schlumbohm® declines any and all responsibility in case of alteration or
modification of the device.
•*CoPilot: the device may only be used with Satelec®, resp. EMS® compatible ultrasonic tips.

EndoPilot
*related to the additional module “CoPilot” - 9 - 609 2201 v12 www.schlumbohm.de
Conditions of the Location
•The device may not get in contact with liquids or be installed in damp places.
•Do not expose the device to direct or indirect heat sources.
•The use of the device in a place with free oxygen, explosive or flammable gases and fluids is not admitted.
•In order not to influence to correct length determination, the EndoPilot should not be installed near devices
emitting electro-magnetic radiation.
•Do not cover the device with cloth or foils. Inflammable materials may be damaged or even ignited upon
unintended activation of the DownPack function.
•*CoPilot: Regarding the usage of several wireless foot switches: The signal is transmitted encoded; this
technique enables a safe synchronization of foot switch and receiving module. It also prevents from an
unintended usage of one device with the foot switch of another device. For the simultaneous usage of several
devices in a confined space (e.g. training sessions), different transmitting frequencies are additionally available,
please contact us if needed.
•*CoPilot: Do not use any mobile phones or other devices with a strong electro-magnetic radiation near the
device. In some cases, this may cause a disturbance of the wireless foot switch’s function.
Device Parts and Accessories
•The power supply has a safety-relevant function. Use only the permitted original medical-power-supply supplied
with the device!
•Follow the manufacturer’s instructions for use and disposal of the endodontic files.
•The accuracy of the length determination, the torque and the speed is only ensured when using the EndoPilot
1:1 contra-angle.
•In case of abnormal or unusual canal morphology (blocked or fractured canal), an exact length determination
may not always be possible.
•The tolerance of torque and speed is 10%.
•The DownPack-handpiece and the BackFill Gun become hot; there is a risk of burns, of damaging the
surroundings and of fire.
•In order to avoid the induction of separate source voltage, the hand pieces shall not be put down on electrically
conducting surfaces.
•Guttapercha is a natural rubber, which may cause allergic reactions (latex-cross-allergy).
•*CoPilot: do not use any deformed or worn instruments.
At first, always use a very low ultrasonic power level and increase the energy only if necessary.
The ultrasonic device is intended for intermittent (interrupted) usage. In order to avoid a heating to the extent
possible, the usage at maximum output level should be limited to 2 minutes and at minimum power level to 4
minutes.
•*CoPilot: Please note that the ultrasonic instruments heat up during usage, therefore, please provide, if
necessary, for adequate, external cooling.
Compatibility
•Endo Files: All commercially available NiTi-Endo-Files with standard ISO shaft can be used..
The values for speed, torque and the operation mode must follow the data from the file-manufacturer.
The manufacturer of the instruments may change the values. Prior to the usage please check if the selected
values are conform with the current data from the manufacturer.
•DownPack Heating Tips: Only use the original tips which are available from the manufacturer.
•BackFill Needles: Only use the original needles which are available from the manufacturer.
•*CoPilot Ultrasonic-Tips: All commercially available instruments with Satelec® or EMS® compatible thread can
be used. (Depending on your ultrasonic handpiece, also EMS ® compatible instruments)
General
•Store this operating manual and all information at the device.
•Keep the documents for this device for the entire product shelf-life.
•The user is obliged to report all incidents according to MDD 93/42/EWG as well as any indications of risks to the
manufacturer.

EndoPilot
*related to the additional module “CoPilot” - 10 - 609 2201 v12 www.schlumbohm.de
2. First Steps
2.1. Installation
At first, please compare the components delivered with the attached shipping documents and the corresponding serial-
resp. LOT-numbers. Please check if the display-glass is damaged (1).
Please note that all components are delivered unsterile and not disinfected (s. chap.16).
Following conditions should be considered when installing the device:
•The space for the device must be horizontal.
•The device may not be installed in damp places.
•Do not expose the device to direct or indirect heating. Direct sunlight has to be avoided.
•The temperature in the environment should not be below 15°C and not above 40°C.
•The device shall not be installed near free oxygen, flammable gas-mixtures or liquids.
•In order not to influence the correct length determination, the EndoPilot should not be installed near devices
emitting electro-magnetic radiation.
Place the foot switch in such a way that it will be easy to use.
•*CoPilot: If you would like to use two devices with wireless foot switch simultaneously and close to each other,
please contact the manufacturer; different transmission modules are available.
•*CoPilot: please take care that the foot switch may not be activated unintentionally.
•Place the machine so that the power supply cable can be pulled out of the unit if necessary.
2.2. Base with Equipment Holder
The base offers a secure stand for the device and the operating tools. Thanks to the recessed grip in the upper part, the
stand can be transported single-handedly. The surfaces are easy to clean and skid-proof feet ensure optimal stability.
For the mounting of the base as well as the arrangements of the hand pieces, please read the mounting instructions
(delivered separately) for the base! The EndoPilot is connected to the stand by the tripod-screw.
*CoPilot: a double holder is mounted on the base for the ultrasonic handpiece and motor. If you expand the device with
the supplementary module CoPilot, the base has to be connected with the casing of the supplementary module. To do
so, remove (if present) the rubber feet of the base and screw the base on the CoPilot-casing (use the screws provided by
all means (23)).
Please note that the base has to be suitable for the mounting on the CoPilot-casing. (older bases have no opening for
the CoPilot-cable).
Attention! If you mount the whole device on to a table or cart, please make sure by all means that the selected screws
(3x Type M4 with 4 mm diameter) will not be screwed deeper than 5 mm into the ground plate of the CoPilot. In any
case, check the length in advance. The device may be damaged if the screwing is too deep. Tighten the screws not to
hard.
2.3. Connection
All connections are to be plugged in and may not be screwed! Please make sure that the notch of the plug fits into the
notch of the socket. The „Push and Pull“-connections for the hand pieces and the foot switch (3) are colour-coded (the
numbers refer to the pictures on the inner coverpage):
Illustration 1 Connection Use
1a red BackFill Gun (11) / also to be used for Updates
1b black
Foot Switch (3) / connect the power supply directly with
the foot switch
1c blue
1. Motor (6) or 2. DownPack handpiece (8)
Alternative: Switch module for automatic switch between Motor and DownPack
1d green Apex-cable (4a), connection to the patient (Lip Clip) (4c)

EndoPilot
*related to the additional module “CoPilot” - 11 - 609 2201 v12 www.schlumbohm.de
*CoPilot
When using the additional module CoPilot, the cable foot switch of the EndoPilot basic device is obsolete!
The „Push and Pull“-connections for the handpieces are colour-coded resp. coded by additional symbols like with the
EndoPilot:
Illustration Connection Use
1a red
BackFill Gun (11)/ in addition, for updates of the
EndoPilot control unit
1b black
Connection to the supplementary module CoPilot via
Connecting cable (15e)
1c blue 1. Motor (6)
1d green Apex cable (4a), connection to the patient (Lip clip)(4c)
15a red
For updates of the CoPilot device. Optional: Connection for a peristaltic pump.
Always cover this socket with the delivered cap
15b black Power supply (2) with power supply adapter cable (22)
15c blue DownPack – handpiece (8)
15d grey Ultrasonic handpiece cable (18) and ultrasonic handpiece (16)
Please make sure when connecting the ultrasonic handpiece to the ultrasonic cable that the handpiece is not twisted
during connection.
If you want to utilize your EndoPilot device with the supplementary module CoPilot, please read all sections in the
operating manual marked with „*“ and execute the steps as described in „Setup CoPilot“. In order to realize the
combination with the CoPilot module, the EndoPilot control unit must have the current software (Firmware v43 or higher)
(please see data in the menu „Setup“). If older firmware is installed on your EndoPilot control unit, the device first has to
be updated with current software.
For older models, a hardware update may be necessary.
2.4. Touch-Display
Prior to the first use, pull off the protection foil. All functions of the EndoPilot are activated by the comfortable Touch-
Display. The Touch-Display allows an intuitive and self-explanatory handling. The display is operated directly with a soft
finger touch. It is of course also possible wearing gloves. Alternatively, a small stick with a rounded plastic tip may also
be used. For protection from scratches and dirt, we recommend our crystal-clear display protection foil. It can be orders
as an accessory.
By no means may the display be operated with any metal objects (danger of breakage of glass)!
With the -button, you always return to the Start Menu. With the – button, you always return to the previous
menu.
2.5. Foot Switch
Functions of the foot switch (also foot switch single):
•Start/stop of the motor, the ultrasonic or heating of the DownPack
•Saving of the measured root length (s. chapter 3)
•Activate the EndoPilot from the sleep-mode
Functions of the wireless twin foot switch*:
•Pedal ”START” as described above
•Pedal “SELECT“ long pressing: select function (ultrasonic or motor)
short pressing: choosing the next file within the file sequence
In order to change the batteries (2 pieces 1,5V Type AAA), please open the battery compartment on the bottom plate of
the foot switch. Remove old batteries. Insert new batteries, paying attention to the correct pole direction. Push the battery
compartment back into its place in the casing. Put the ground plate back in and tighten the screws. Dispose of the old
batteries as per regulation. Do only use brand name batteries. Use only batteries of the same type.
Caution! Remove the batteries if you do not use the foot switch for a longer period of time.
To ensure an uninterrupted usage, spare batteries should always be available.
In case of need, the EndoPilot can be used with the help of the standard cable foot switch at any time (socket 15b)!
The connection of the power supply to the cable foot switch is possible, but not necessary as long as the battery is
charged,

EndoPilot
*related to the additional module “CoPilot” - 12 - 609 2201 v12 www.schlumbohm.de
2.6. Switch on, Standby, Switch off, Battery-Operation*
Connect the foot switch (3) with the power supply (2). Put the power supply into the socket (green LED in the power
supply has to light up). Now, the plug of the foot switch has to be plugged into the black connection (1b) of the EndoPilot.
If the device is not being used for some time, it automatically switches to the sleep-mode. The display light is turned off.
The device is turned on again by a short step on the foot switch or touch of the touch-display. The menu displayed as
last will be displayed again.
In order to avoid waste of electricity in the standby-mode, the EndoPilot should be disconnected if it will not be used for a
longer period.
*CoPilot:
When expanding the device with the „CoPilot“ module, the cable foot switch (3) of the EndoPilot basic device becomes
obsolete. For charging, the power supply has to be connected to the CoPilot with the help of the adapter cable (22). The
device can be switched on with the switch on the front of the device. If the charge drops to 10% of the capacity, the
CoPilot must be loaded. Otherwise, the unit turns off to avoid a total discharge of the battery and destruction.
Charge the battery periodically, the LED at the front of the device shows the charging level (red LED means charging is
necessary). If the battery is fully charged (constant green LED), the power supply may be plugged off.
The display switches off after several minutes of idling. By touching the display or by pressure on the wireless foot
switch, the display will switch on again. The supplementary module CoPilot will completely switch off after 10, 20 or 40
minutes of idling, it can only be re-activated by the switch at the front of the device. (The turn-off time can be selected via
the menu).
2.7. Preparation of the Root Canal – Motor and Contra-Angle
The EndoPilot contra-angle (5) is mounted on the motor (6). Use only contra-angles with 1:1 gear. The integrated Apex
length measurement (s. chapter 4.7.1.) via the contra-angle (during the preparation) does only work in connection with
the original-EndoPilot contra-angle.
If the contra-angle was changed or sterilized, it is necessary to run the calibration-process under the menu item
C a li b ra t i o n . Contra-angles may only be changed upon standstill of the motor (s. chapter 7).
Operating Remarks:
Before starting the device, please check if the motor is tightly snapped into the contra-angle.
Do not put any pressure on the push-button of the contra-angle because this may cause frictions
or mismeasurements!
Depending on the shape of the root canal, the Endo-files are bent and stressed during usage. The device reduces the
risk of file-breakage; however, this danger cannot be eliminated completely. Please ensure that you know the allowed
torques value of the instruments. Select the correct file. Never use deformed or damaged files!
The menu offers a variety of settings. The device permits to individually change all parameters like speed, torque and
operation mode, etc.. Parameters, which deviate from the manufacturers settings may lead to file
fractures and other damages. The company Schlumbohm®will not be liable for damages deriving from operations
deviating from the manufacturers settings.
To avoid file-breakage, please pay attention to the following points:
•Never use pressure to insert the file or to move it forward.
•Nickel-titanium files also break due to material fatigue. Only prepare as many canals as allowed by the
manufacturer of the files.
•In order to use NiTi-instruments effectively, experience and practice are indispensible.
•Practice on extracted teeth or Endo-plastic blocks.
LED Motor: GREEN: The torque is below 80% of admissible load
RED : The torque is above 80% of admissible load

EndoPilot
*related to the additional module “CoPilot” - 13 - 609 2201 v12 www.schlumbohm.de
2.8. Filling Technique - DownPack (D-Pack)
The DownPack handpiece (8) shares the blue connection with the motor (6).
(*CoPilot: if expanding the device by the „CoPilot“ module, the DownPack handpiece is always connected to the blue
notch (15c) of the CoPilot)
Do not put the DownPack handpiece down on electrically conducting surfaces, this could lead to induction of separate
source voltage.
Do not connect the DownPack handpiece at the same time with the Apex-cable. Put down the handpieces only on the
EndoPilot tripod or a temperature-resistant tray. Please keep in mind that the tip becomes very hot.
Operating the heating tip:
Open the tongs by two turns of the nut and insert the heating tip (7) (always insert the piston to mechanical stop). The tip
is fixed by screwing the nut tight.
Before using it, make sure that the heating tip is firmly fixed. A twisting tip can cause injuries.
If necessary, the multi-tool (12) may be used to loosen the nut.
Please pay attention to limited life expectancy of the heating tip which differs depending upon the frequency of use,
stress and deforming.
Check the heating tip before each use on its function and on its good mechanic condition. Use of excessive force may
lead to breaking and to injuries caused by slipping.
Never use heating tips from other manufacturers!
Do not use the DownPack handpiece simultaneously with the Apex cable.
Due to the continued induction of heat into the point of treatment, a warming up of the tooth and the surrounding tissue
may occur.
Provide for sufficient waiting times and act carefully. An exaggerated heating may change of the characteristics of the
filling material.
LED DownPack:
Red blinking: DownPack is operating, heating procedure is running (Usage s. chapter 5.1).
2.9. Filling Technique - BackFill (B-Fill)
Connect the BackFill Gun (11) with the delivered cable to the red connection (1a) at the device. The BackFill needle (9)
must be tightened with the key (12) to prevent leakage of gutta-percha at the screwing connection.
Form the needle between the forming rolls of the multi-tool. Always be careful that the needle is not being bent or torn
out of the screwing base. Avoid bending back and forth.
Please always use a Heat insulator (10), which should only be put on shortly before usage in order to avoid burns.
Press the release (11a) and pull the piston (11b) a bit backwards.
Then always insert only 1 pellet Guttapercha (13) at a time in the upper opening of the Gun. If the Gun is already heated,
do so quickly in order to avoid the inner parts to agglutinate.
By using the lever (11c), you push the Guttapercha into the heating chamber with the help of the piston (11b) and later
on through the needle. Make sure that the small screw and the seal at the end of the piston (11b) is in place and
tightened securely.
As long as the set temperature has not been reached and the Guttapercha is still rigid, do not press too hard as that may
damage the Gun.
If the heating times are longer, the outer parts of the Gun will also be warmed up. Check the temperature of the
protection cap (10).
Do not touch the patient’s lips or mucous membrane with the needle.
During the filling process, the needle should be able to rise with the filling material.
Do not put the BackFill Gun on electrically conducting surfaces; this could catch external voltage.
Do not use the BackFill Gun simultaneously with the Apex cable.
Put down the BackFill Gun only on the EndoPilot tripod or on a temperature-resistant tray.
Use of excessive force may break the needle and cause injuries. Please take care that the Gun is cleaned and prepared
before each use. Use a new needle each time as well as a new Guttapercha-pellet for each treatment. After the usage
and as long as the handpiece is still hot, press all remains of Guttapercha out of the Gun. Only use the original
Guttapercha-pellets.
For remarks on dismantling, please see preparation instructions (s.chap.16)!

EndoPilot
*related to the additional module “CoPilot” - 14 - 609 2201 v12 www.schlumbohm.de
3. - 6. Functions Start Menu
3 Manual root length measurement
4 Motor system for NiTi files
6 Ultrasonic function
5.2 BackFill-Gun
5.1 DownPack hand piece
Next menu
3. Manual Root Length Measurement
In this menu, you can probe the canal manually, that means by a file lead by hand.
For this purpose, the lip clip (4c) as well as the file clamp (4b) are used.
The horizontal line determines the position in the root canal where the "Auto-stop"-function
is reached when using the mechanic preparation. The setting can be stored either
directly at the display by moving the line (short tip of the finger) or also comfortably
by pushing the foot switch.
With this function, it is, for example, possible to transfer an X-ray verified position
of a pilot instrument onto the screen.
The setting of the line is stored until the device is switched off.
If the device is switched on again, the line is re-set to a standard value.
Parallel to the graphic display, a value (here 34) is also shown, this is the length
of the line in the display, however NO indication of millimetres. This number is only for a
better orientation.
Do not put the measuring cables on electrically conducting surfaces, this could lead to
induction of separate source voltages.
ATTENTION: If the file gets in touch with the lip clip, this will cause a short-circuit.
With this short-circuit, you may test the function of the display and the Apexlocator.

EndoPilot
*related to the additional module “CoPilot” - 15 - 609 2201 v12 www.schlumbohm.de
3.1. Advice for an accurate Measurement
Put on the lip clip (4c) in the cheek pouch of the patient (the side which is opposite to the operating area).
Before you start the length measurement, the root canal should be rinsed with NaCl-solution and then be dried (for
example with a cotton-pellet), in order to avoid leakage current and, as a consequence, incorrect measurements.
It is recommended to wear protective gloves during the measurement in order to isolate the measuring current.
For the manual measurement, the file has to be connected with the file clamp below the shaft and shall be inserted
slowly into the root canal.
Please keep in mind that, principally, mismeasurements may occur during the electronic canal measurement caused by
variable disturbances (conductive fillings, cracks in the tooth, etc.)
The results should always be compared with an x-ray photo.
4. Motor system
When selecting the motor system, you will reach the Favorites menue.
4.1Favorites
System ‘ProTaper’ chosen as example for a favorite
(can be deleted again with X )
Space for an other system
(press file file symbol)
4.3 MyFile System
4.2 Selection of a file system
4.1. Favorites
The menu favorites offers the possibility to select from a wide range of pre-programmed file systems 3 favoured file
systems.
This offers the advantage of immediate access to the file systems used most of the times and saves the repeated
selection from the whole assortment of file systems.
The favoured file system is selected by pressing the file symbol .
Via the symbol X the selection can be deleted easily and can then be selected anew.
This menu does not have to be used.
If you do not want to select any favorites, choose the menu item „all file systems“ (Chapter 4.2)
Here, a system can be chosen directly from the alphabetical list of file systems.

EndoPilot
*related to the additional module “CoPilot” - 16 - 609 2201 v12 www.schlumbohm.de
4.2. Selection of a file system
If you have selected the menu item „all file systems, the menu opens with all available file systems.
First, you will get to page 1, additional file systems follow on the next pages.
By a short touch on the desired file (s. right e.g. ProTaper , resp. ProFile ), you will get to
the respective file system.
Within the selected file system, a touch of the headline with the system name will lead back to
the menu favorites.
With the key, you will get back to the Start Menu.
4.3. MyFile System
The device offers a special function with the M y F i l e Sy s t e m .
With the MyFile-system, individual file sequences, independent of the manufacturer, can be
defined. To do so, files will be selected from the extensive file library and then be stored one
after the other (Hybrid-technique).
The system can be accessed in the menu „favorites“ or from every file menu oft the file
systems. In the MyFile system, 5 different sequences with each 10 files can be stored
individually.
By touching M y F i l e Sy s t e m in the menu „favorites“ (see illustration Chapter 4), you can
choose from the following:
My Sequence 1 to My Sequence 5
With these namings, the own sequences can be differentiated easily.
In each of these areas, up to 10 files can be stored.
In the menu to the right, for example, the menu item „My Sequence 1“ was selected.
By touching the file symbol on the right, the alphabetical overview oft the file systems opens.
Again by touching, the desired system will be selected, then the file can be selected (in this
illustration, the file ProTaper F2 has been selected). Behind each entry, a X appears on the
right. Via this field, the selection can be deleted easily.
In one sequence, the same file may also be used several times. This may be reasonable if the
same file shall be used with different settings.
By touching on the desired file, in this case “PT F2 25/08”, the user reaches the file menu
“preparation” (Chapter 4.5). In this menu, the EndoMotor can be started by using the foot
switch.
In the menu preparation 4.5, the file parameters (Chapter 4.6) can be set freely via the key
F . D a t a . The data will be stored in the MyFile-System. The pre-programmed file data (Data
from the file manufacturer) in the basic file system under a l l fi l e s ys t e m s .
Remain unchanged. They will not be overwritten by the individually changed data.

EndoPilot
*related to the additional module “CoPilot” - 17 - 609 2201 v12 www.schlumbohm.de
File alarm
!
Reset the counte
r
4.4. Selection of a sequence / file
4.2 File system
4.4 Sequence / File
After selecting the file system, the system overview opens.
The general structure is the same for all systems, it differs,
however, by particularities and sequences of the individual file
system resp. manufacturer.
With ProFile (see illustration), for example, the sequence is
selected first and in the next step the file.
The file system ProTaper Next does not offer this sequence
selection. A file selection is offered directly.
In the selected file system, a touching of the headline with the system name (in our illustration P r o F i l e resp.
ProTaper Next) leads back to the menu „favorites“. With the key, you can return to the Start Menu.
4.5. Preparation
In the preparation menu, the EndoMotor is operated via the foot switch. The upper line shows the selected file.
Underneath, the speed and torque values of the file are shown.
The Apex screen is always displayed which enables a manual probing with the help of the file clamp. Please note that
the file clamp has to be put down on an isolated surface as otherwise it may cause mistakes in the root canal
measurements with the contra-angle.
The settings which are valid for the entire preparation can be selected in the menu O p t i o n s (chapter 4.7 ).
With the F. D a t a -key, you reach the sub-menu file parameters. It offers the possibility to change the individual
parameters for the selected file (Chapter 4.6 file parameters).
Selected file,
back to file sequence
(see chapter 4.4.)
Preparation line
(see chapter 3.)
Go to next or previous Box selection + Wear indicator
file of the sequence (File Management – only
visible after selection of a limit)

EndoPilot
*related to the additional module “CoPilot” - 18 - 609 2201 v12 www.schlumbohm.de
4.6. File Parameters (F. Data)
The menu offers a variety of settings. The device permits to individually change all parameters like speed,
torque and operation mode, etc.. Parameters, which deviate from the manufacturers settings may lead to file
fractures and other damages. The company Schlumbohm will not be liable for damages deriving from
operations deviating from the manufacturers settings.
File indicator
Operation Mode selectable
(Twist on/off-anti clockwise-reciprocal )
Speed-value of the file
Torque value of the file
Wear-values of the file in the selected box
Selected wear limit (up to 25) for the file alarm
In the menu Operation Mode, Twist, anti-clockwise rotation and reciprocal can be selected.
The speed- and torque-values may be changed after selecting R P M or N c m by the + and - -keys which are then
displayed. The individual key RPM Reset or Nc m R e s e t between the . + and - -key resets the values to the
factory settings (according to the recommendation of the file manufacturer).
In the menu function R e s e t (s. chap.9), all values of the files can be reset to the factory settings at once.
Please note:
Keep in mind that the file manufacturers provide themselves the right to change and adjust the instrument parameters.
The data stored in this device were determined with utmost care according to manufacturer's recommendations. Future
changes may be individually adjusted by the user or by running an update.
4.6.1. Reciprocal Function
General:
With the reciprocal technique which was already known in the 80’s as Balanced-Force-technique, an endo-instrument is
set into a cyclic right-left-movement. The instrument is pulled rhythmically from the canal by the user in order to remove
chips. The advantage of this technique is the significant time-saving.
Often, less files than usual are used for the preparation. In practice, NiTi-instruments, originally only intended for fully-
rotating operation as well as special instruments especially determined for the reciprocal operation are currently being
used.
Other than the known, rigid drive mechanisms, the EndoPilot offers a free selection of the parameters. The movement
can be adjusted by the user according to the canal and the instrument. As there are currently no data published by the
file manufacturers, it is necessary that the user determines the parameters suitable for him and his file system. In
concrete, this can be done for testing purposes by preparing training blocks. The pre-selected values should in any case
be adjusted.
It has to be pointed out that experience and training are prerequisites for this technique.
The user should obtain experiences on extracted teeth. It has to be assumed that the use of different file systems will
lead to different results. In order to avoid a deforming of the file, the same values should always be used for left and right
rotation. The pause offers an intermittent operation and reduces the impulse load on the file.
