SCHOLTES tip 744 dd l User manual

Operating Instructions
Contents
Installation, 24-25
Positioning
Electrical connection
Description of the appliance, 26
Control panel
Start-up and use, 27-30
Switching on the hob
Switching on the cooking zones
Medium unction
Booster unction
Switching o the cooking zones
Programming the cooking duration
Timer
Control panel lock
Switching o the hob
 emo mode
Practical advice on using the appliance
Sa ety devices
Practical cooking advice
Precautions and tips, 31
General sa ety
isposal
Care and maintenance, 32
Switching the appliance o
Cleaning the appliance
isassembling the hob
Technical description of the models, 33
TIP 642 DD B
TIP 642 DD L
TIP 644 DD L
TIP 744 DD L
HOB
Italiano, 1
GB
Espanol, 34
ES
eutsch, 34
DE
Français, 12 English,23
ITFR
B

24
B
Installation
 Be ore operating your new appliance please read this
instruction booklet care ully. It contains important
in ormation concerning the sa e operation, installation and
maintenance o the appliance.
 Please keep these operating instructions or uture
re erence. Pass them on to any new owners o the
appliance.
Positioning
 Keep all packaging material out o the reach o children.
It may present a choking or su ocation hazard (see
Precautions and tips).
 The appliance must be installed by a quali ied
pro essional in accordance with the instructions provided.
Incorrect installation may cause harm to people and
animals or may damage property.
Built-in appliance
Use a suitable cabinet to ensure that the appliance
unctions properly.
The supporting sur ace must be heat-resistant up to a
temperature o approximately 100°C.
I the appliance is to be installed above an oven, the
oven must be equipped with a orced ventilation
cooling system.
Avoid installing the hob above a dishwasher: i this
cannot be avoided, place a waterproo separation
device between the two appliances.
epending on the hob you want to install, the cabinet
must have the ollowing dimensions (see figure):
560 +/- 1
490 +/- 1
48
590
520
690
520
560 +/- 1
490 +/- 1
48
Ventilation
To allow adequate ventilation and to avoid overheating of the
surrounding surfaces the hob should be positioned as follows:
At a minimum distance of 40 mm from the back panel
or any other vertical surfaces.
So that a minimum distance of 20 mm is maintained
between the installation cavity and the cabinet
underneath.
Kitchen cabinets adjacent to the appliance and taller
than the top of the hob must be at least 600 mm from
the edge of the hob.
FRONT SIDE
OF HOB
SUPPORTING
SURFACE
30
40
UNDERSIDE
OF HOB
5 mm
min. 20 mm
min. 20 mm
min. 40 mm
COMPARTMENT
5 mm
min. 40 mm
FAN-ASSISTED
OVEN

25
GB
Fixing
The appliance must be installed on a perfectly level
supporting surface.
Any deformities caused by improper fixing could affect
the features and operation of the hob.
The thickness of the supporting surface should be taken
into account when choosing the length of the screws for the
fixing hooks:
30 mm thick: 23 mm screws
40 mm thick: 13 mm screws
Fix the hob as follows:
1. Use short flat-bottomed screws to fix the 4 alignment
springs in the holes provided at the central point of each
side of the hob.
2. Place the hob in the cavity, make sure it is in a central
position and push down on the whole perimeter until the
hob is stuck to the supporting surface.
3. For hobs with raised sides: After inserting the hob into
its cavity, insert the 4 fixing hooks (each has its own pin)
into the lower edges of the hob, using the long pointed
screws to fix them in place, until the glass is stuck to the
supporting surface.
 The screws or the alignment springs must remain
accessible.
 In order to adhere to sa ety standards, the appliance
must not come into contact with electrical parts once it
has been installed.
 All parts which ensure the sa e operation o the
appliance must not be removable without the aid o a tool.
Electrical connection
 The electrical connection or the hob and or any built-in
oven must be carried out separately, both or sa ety
purposes and to make extracting the oven easier.
Single-phase connection
The hob is equipped with a pre-connected electricity
supply cable, which is designed or single-phase
connection. Connect the wires in accordance with the
instructions given in the ollowing table and diagrams:
Voltage and
mains frequency Electrical cable Wire connection
220-240V 1+N ~
50 Hz
: yellow/green;
N: the two blue wires
together
L: brown and black
together
Other types of connection
I the mains supply corresponds with one o the ollowing:
Voltage and mains requency
 400V - 2+N ~ 50 Hz
 220-240V 3 ~ 50 Hz
 400V 3 - N ~ 50 Hz
 400V - 2+2N ~ 50 Hz
Separate the wires and connect them in accordance with
the instructions given in the ollowing table and diagrams:
Voltage and
mains frequency Electrical cable Wire connection
400V - 2+N ~
50 Hz
220-240V 3 ~
50Hz
400V 3-N~ 50Hz
: yellow/green;
N: the two blue wires together
L1: black
L2: brown
400V - 2+2N ~
50 Hz
: yellow/green;
N1: blue
N2: blue
L1: black
L2: brown
Connecting the electricity supply cable to the mains
I the appliance is being connected directly to the
electricity mains an omnipolar switch must be installed
with a minimum opening o 3 mm between contacts.
 The installer must ensure that the correct electrical
connection has been made and that it is ully compliant
with sa ety regulations.
Be ore connecting the appliance to the power supply,
make sure that:
The appliance is earthed and the plug is compliant with
the law.
The socket can withstand the maximum power o the
appliance, which is indicated on the data plate located
on the appliance itsel .
The voltage alls within the range o values indicated on
the data plate.
The socket is compatible with the plug o the
appliance. I the socket is incompatible with the plug,
ask an authorised technician to replace it. o not use
extension cords or multiple sockets.
 Once the appliance has been installed, the power
supply cable and the electrical socket must be easily
accessible.
 The cable must not be bent or compressed.
 The cable must be checked regularly and replaced by
authorised technicians only.
 The manufacturer declines any liability should these
safety measures not be observed.
 o not remove or replace the power supply cable or any
reason. Its removal or replacement will void the warranty
and the CE marking. INESIT does not assume liability
or accidents or damage arising rom replacement/
removal o the original power supply cable. Replacement
can only be accepted when carried out by personnel
authorised by INESIT and using an original spare part.

26
GB
Description of the
appliance
Control panel
INCREASE POWER button switches on the
hotplate and controls the power (see tart-up and
use).
REDUCE POWER button controls the power and
switches o the hotplate (see tart-up and use).
COOKIN ZONE indicator represents the
corresponding cooking zone.
POWER indicator provides a visual display or the
current heat level.
ON/OFF button switches the appliance on and o .
ON/OFF indicator light shows whether the
appliance is on or o .
PRORAMME TIMER* button controls the
cooking programme times (see tart-up and use).
PRORAMME TIMER* display shows which
programme has been selected (see tart-up and
use).
COOKIN ZONE PRORAMMED* indicator lights
show which cooking zones are being used during
a cooking programme (see tart-up and use).
CONTROL PANEL LOCK button prevents
accidental changes to the hob settings (see tart-
up and use).
CONTROL PANEL LOCK indicator light shows
the control panel has been locked (see tart-up
and use).
BOOSTER* button activates the booster unction -
3000 W - o the cooking zone (see tart-up and
use).
BOOSTER* indicator light shows that the booster
unction has been activated.
TIMER* indicator light shows that the timer has
been activated
MEDIUM* button switches the cooking zone on at
medium power level 8 (see tart-up and use).
INCREASE TIME* button increases the cooking
duration while the timer is running or while a set
programme is underway (see tart-up and use).
DECREASE TIME* button decreases the cooking
duration while the timer is running or while a set
programme is underway (see tart-up and use).
The control panel described in this manual is only a representative example: it may not exactly match the panel
on your appliance.
* Only available in certain models.
ON/OFF indicator light
CONTROLS LOCKED
indicator light
CONTROL PANEL LOCK
button
INCREASE TIME*
button
COOKING ZONE PROGRAMMED*
indicator light
PROGRAMME TIMER*
display
PROGRAMME TIMER
button
DECREASE TIME*
button
POWER and
RESIDUAL HEAT
indicators
ON/OFF button
COOKING ZONE
indicator
TIMER*
indicator light
m edium mm ediumedium
b oo st er bb oo ostost erer
m edium mm ediumedium
b oo st er bb oo ostost erer
m edium mm ediumedium m edium mm ediumedium
b oo st er bb oo ostost erer b oo st er bb oo ostost erer
BOOSTER*
button
MEDIUM*
button
BOOSTER*
indicator light
INCREASE POWER
button
DECREASE POWER
button

27
GB
Start-up and use
 The glue applied on the gaskets leaves traces o grease
on the glass. Be ore using the appliance, we recommend
you remove these with a special non-abrasive cleaning
product. uring the irst ew hours o use there may be a
smell o rubber which will disappear very quickly.
 A ew seconds a ter the hob is connected to the
electricity supply, a buzzer will sound. The hob may now
be switched on.
Types of noise during normal hob operation:
Buzz: due to the vibration o the metallic parts that
make up the induction element and the pot; it is
generated by the electromagnetic ield required or
heating and increases as the power o the induction
element increases.
Soft whistle: heard when the pot placed on the
heating zone is empty; the noise disappears once ood
or water is placed into the pot.
Crackle: produced by the vibration o materials on the
bottom o the pot due to the low o parasitic currents
caused by electromagnetic ields (induction); can be
more or less intense depending on the material making
up the bottom o the pot, and decreases as the pot
dimensions increase.
Loud whistle: heard when two induction elements o
the same group unction simultaneously at maximum
power and/or when the booster unction is set on the
larger element while the other is auto-adjusted. Noise is
reduced by decreasing the power level o the auto-
adjusted induction element; pot bottom layers made o
di erent kinds o materials are among the main causes
o this noise.
Fan noise: a an is necessary to ensure the hob
unctions correctly and to sa eguard the electronic unit
rom possible overheating. The an unctions at
maximum power when the large induction element is at
maximum power or when the booster unction is on; in
all other cases, it works at average power depending on
the temperature detected. Furthermore, the an may
continue to work even a ter switching the hob o , i the
temperature detected is high.
The types o noise listed above are due to induction
technology and are not necessarily operational aults.
Switching on the hob
To switch the hob on, press and hold the button or
approximately one second.
Switching on the cooking zones
To begin using a cooking zone, set the desired power
level using the - and +.
Press and hold the + button or approximately 2
seconds: the cooking zone will immediately begin
operating at its maximum power level (16).
Press and hold the - button or approximately 2
seconds: the cooking zone will operate at power level 2
(slow cooking unction).
Medium function*
Press the
m
m
edium mm ediumedium
button to switch on the cooking zone at
medium power level 8.
Booster function*
The booster unction or some o the cooking zones may
be used to shorten heating-up times. It may be activated
by pressing the
b
b
oosterbbooostosterer
button. The indicator light directly
above the button will illuminate. This unction boosts the
power to 2000 W or 3000 W, depending on the size o the
corresponding cooking zone.
It stops automatically a ter 4 minutes. While the booster
or one o the cooking zones is active, the corresponding
ront or rear cooking zone will operate at a reduced power
level (e.g. i the booster or the rear le t-hand hotplate has
been activated, the power level o the ront le t-hand
hotplate will be reduced). For urther in ormation, please
re er to the Technical description of the models.
Switching off the cooking zones
To switch o a cooking zone:
Press the - button: the power o the cooking zone will
progressively decrease until it is switched o .
Alternatively, the - and + buttons may be pressed
simultaneously: this immediately returns the power
setting to 0 and the cooking zone switches o .
Programming the cooking duration
 I the and buttons are pressed or an extended
period o time, the timer scrolls quickly through the minute
values in the corresponding direction.
 All the cooking zones may be programmed
* Only available in certain models.

28
GB
simultaneously, or a duration between 1 and 99 minutes.
1. Select the cooking zone using the corresponding
selector button.
2. Adjust the temperature.
3. Press the programming button.
4. Set the cooking duration using the and buttons.
5. Con irm by pressing the button.
The timer begins counting down immediately. A buzzer
sounds or approximately 1 minute and the cooking zone
switches o when the set programme has inished.
Repeat the above procedure or each hotplate you wish to
programme.
Using multiple programmes and the display
I one or more hotplates are programmed, the display will
show the data or the hotplate with the least time
remaining, and the light corresponding to the position o
the hotplate will lash. The lights corresponding to the
other hotplates programmed will be switched on.
To display the time remaining or the other programmed
hotplates, press the button repeatedly. The times
remaining or each hotplate will be shown in a clockwise
order, beginning with the ront le t hotplate.
Changing the programme
1. Press the button repeatedly until the duration you
wish to change is shown.
2. Use the buttons to set the new duration.
3. Con irm by pressing the button.
To cancel a programme, ollow the above instructions. At
step 2, press the button: the duration decreases
progressively until it reaches 0 and switches o . The
programme resets and the display exits programming
mode.
Timer
The hob must be switched on.
The timer can be used to set a duration up to 99 minutes.
1. Press the programming button until the timer
indicator light is illuminated.
2. Set the desired duration using the and buttons.
3. Con irm by pressing the button.
The timer begins counting down immediately. When the
time has elapsed, a buzzer will sound ( or one minute).
Control panel lock
When the hob is switched on, it is possible to lock the
oven controls in order to avoid accidental changes being
made to the settings (by children, during cleaning, etc.).
Press the button to lock the control panel: the
indicator light above the button will switch on.
To use any o the controls (e.g. to stop cooking), you must
switch o this unction. Press the button or a ew
moments, the indicator light will switch o and the lock
unction will be removed.
Switching off the hob
Press the button to switch the appliance o .
I the control panel lock has been activated, the controls
will continue to be locked even a ter the hob is switched
on again. In order to switch the hob on again, you must
irst remove the lock unction.
Demo mode
It is possible to set the hob to a demonstration mode
where all the controls work normally but the heating
elements do not switch on. To activate the demo mode
the hob must be switched on, with all the hotplates
switched o .
Press and hold the + and buttons simultaneously
or 6 seconds. When the 6 seconds have elapsed, the
ON/OFF and CONTROLS LOCKE indicator lights will
lash or one second. Release the + and buttons
and press the button;
The display will show the text E and MO and the hob
will be switched o .
When the hob is switched on again it will be set to the
demo mode.
To exit this mode, ollow the procedure described above.
The display will show the text E and OF and the hob will
be switched o . When it is next switched on, the hob will
unction normally.
Practical ad ice on using the
appliance
 Use cookware made rom materials which are compatible
with the induction principle ( erromagnetic material). We
especially recommend pans made rom: cast iron, coated

29
GB
steel or special stainless steel adapted or induction. Use
a magnet to test the compatibility o the cookware.
*
SUITABLE UNSUITABLE
Cast iron
Enamelled steel
Special stainless steel
Copper,
Aluminium, Glass, Earthenware,
Ceramic, non magnetic Stainless steel
In addition, to obtain the best results rom your hob:
Use pans with a thick, lat base in order to ully utilise
the cooking zone.
Always use pans with a diameter which is large enough
to cover the hotplate ully, in order to use all the
available heat.
Make sure that the base o the cookware is always
clean and dry, in order to ully utilise and extend the li e
o both the cooking zones and the cookware.
Avoid using the same cookware which has been used
on gas burners: the heat concentration on gas burners
may distort the base o the pan, causing it not to
adhere correctly.
Safety deices
Pan sensor
Each cooking zone is equipped with a pan sensor device.
The hotplate only emits heat when a pan with suitable
measurements or the cooking zone is placed on it. I the
power level indicator display lashes, this may be because:
An incompatible pan
A pan whose diameter is too small
The pan has been removed rom the hotplate.
Overheating protection
I the electronic elements overheat, the hob switches o
automatically and F appears on the display, ollowed by a
lashing number. When the temperature has reached a
suitable level, this message disappears and the hob may
be used again.
Safety switch
The appliance has a sa ety switch which automatically
switches the cooking zones o a ter they have been in
operation or a certain amount o time at a particular
power level. When the sa ety switch has been triggered,
the display shows 0.
For example: the rear right-hand hotplate is set to 5 and
will switch o a ter 7 and a hal hours o continuous
operation, while the ront le t-hand hotplate is set to 2 and
will switch o a ter 9 and a hal hours.
Power level Maximum operating time in hour
1 10
2 9,5
3 9
4 8,5
5 7,5
6 7
7 6,5
8 6
9 5,5
10 5
11 4
12 3,5
13 3
14 2,5
15 2
16 1
Buzzer
This can also indicate several irregularities:
An object (a pan, cutlery, etc.) has been placed on the
control panel or more than 10 seconds.
Something has been spilt on the control panel.
A button has been pressed or too long. All o the
above situations may cause the buzzer to sound.
Remove the cause o the mal unction to stop the
buzzer. I the cause o the problem is not removed, the
buzzer will keep sounding and the hob will switch o .

30
GB
Practical cooking advice
¡§
¡S
Pressure cooking
Pressure cooker
Frying
Very high-flame cooking
¡¢
¡£
Grilling Boiling
High-flame
cooking
¡
¡¡
¡O
Crêpes Cooking on a high flame and browning
(roasts, steaks, escalopes, fish fillets,
fried eggs)
ª

Fast thickening (liquid juices)
Boiling water (pasta, rice, vegetables)
Milk
¶
§
Slow thickening (dense juices)
S
Medium-flame cooking
¢
Bain-marie cooking Pressure cooking after whistle
£
Low-flame
cooking

Low-flame cooking
(stews)
-{}-
Reheating dishes
Very low-
flame
cooking
¡
Chocolate sauce Keeping food hot

31
GB
Precautions and tips
 This appliance has been designed and manu actured in
compliance with international sa ety standards. The
ollowing warnings are provided or sa ety reasons and
must be read care ully.
This appliance con orms to the ollowing European
Economic Community directives:
- 2006/95/EEC dated 12/12/06 (Low Voltage) and
subsequent amendments;
-89/336/EEC dated 03/05/89 (Electromagnetic
Compatibility) and subsequent amendments;
- 93/68/EEC dated 22/07/93 and subsequent amendments.
General safety
 Make sure that the air inlet behind the an grille is never
obstructed. The built-in hob should, in act, be provided
with suitable ventilation or the cooling o the electronic
components used in the appliance.
 We advise against the installation o an induction hob
above an under-the-counter re rigerator (heat) or above a
washing machine (vibrations). In act, there would be
insu icient space or the ventilation o electronic
components.
The appliance was designed or domestic use inside the
home and is not intended or commercial or industrial
use.
The appliance must not be installed outdoors, even in
covered areas. It is extremely dangerous to leave the
appliance exposed to rain and storms.
o not touch the appliance when bare oot or with wet
or damp hands and eet.
The appliance must be used by adults only or the
preparation o ood, in accordance with the instructions
provided in this booklet. o not use the hob as a
worktop or chopping board.
The glass ceramic hob is resistant to mechanical
shocks, but it may crack (or even break) i hit with a
sharp object such as a tool. I this happens,
disconnect the appliance rom the electricity mains
immediately and contact a Service Centre.
Ensure that power supply cables o other electrical
appliances do not come into contact with the hot parts
o the hob.
Remember that the cooking zones remain relatively hot
or at least thirty minutes a ter they have been switched
o. An indicator light provides a warning when residual
heat is present (see tart-up and use).
Keep any object which could melt away rom the hob,
or example plastic and aluminium objects, or products
with a high sugar content. Be especially care ul when
using plastic ilm and aluminium oil or packaging: i
placed on sur aces which are still hot, they may cause
serious damage to the hob.
Always make sure that pan handles are turned towards
the centre o the hob in order to avoid accidental
burns.
When unplugging the appliance, always pull the plug
rom the mains socket; do not pull on the cable.
Never per orm any cleaning or maintenance work
without having disconnected the appliance rom the
electricity mains.
The appliance should not be operated by people
(including children) with reduced physical, sensory or
mental capacities, by inexperienced individuals or by
anyone who is not amiliar with the product. These
individuals should, at the very least, be supervised by
someone who assumes responsibility or their sa ety or
receive preliminary instructions relating to the operation
o the appliance.
For the attention of wearers of pacemakers or
other active implants:
The hob complies with all current standards on
electromagnetic inter erence.
Your induction hob is there ore per ectly in keeping with
legal requirements (89/336/CEE directives). It is
designed not to create inter erence on any other
electrical apparatus being used on condition that the
apparatus in question also complies with this
legislation.
Your induction hob generates short-range magnetic
ields.
To avoid any inter erence between your induction hob
and a pacemaker, the latter must be designed to
comply with relevant regulations.
In this respect, we can only guarantee our own product
con ormity. Please consult the pacemaker manu acturer
or your doctor concerning its con ormity or any possible
incompatibility.
o not let children play with the appliance.
Disposal
When disposing o packaging material: observe local
legislation so that the packaging may be reused.
The European irective 2002/96/EC relating to Waste
Electrical and Electronic Equipment (WEEE) states that
household appliances should not be disposed o using
the normal solid urban waste cycle. Exhausted
appliances should be collected separately in order to
optimise the cost o re-using and recycling the materials
inside the machine, while preventing potential damage
to the atmosphere and to public health. The crossed-
out dustbin is marked on all products to remind the
owner o their obligations regarding separated waste
collection.
For urther in ormation relating to the correct disposal o
exhausted household appliances, owners may contact
the public service provided or their local dealer.

32
GB
Care and maintenance
Switching the appliance off
isconnect your appliance rom the electricity
supply be ore carrying out any work on it.
Cleaning the appliance
 o not use abrasive or corrosive detergents ( or
example, products in spray cans or cleaning
barbecues and ovens), stain removers, anti-rust
products, powder detergents or sponges with
abrasive sur aces: these may scratch the sur ace
beyond repair.
Never use steam cleaners or pressure cleaners on
the appliance.
It is usually su icient simply to wash the hob
using a damp sponge and dry it with absorbent
kitchen towel.
I the hob is particularly dirty, rub it with a special
glass ceramic cleaning product, then rinse well
and dry thoroughly.
To remove more stubborn dirt, use the scraper
provided. Remove spills as soon as possible,
without waiting or the appliance to cool, to avoid
residues orming crusty deposits. You can obtain
excellent results by using a rust-proo steel wire
sponge - speci ically designed or glass ceramic
sur aces - soaked in soapy water.
 The scraper provided is sharp: be care ul when
using it.
I any plastic or sugary substances are
accidentally melted on the hob, remove them
immediately with the scraper, while the sur ace is
still hot.
Once it is clean, the hob may be treated with a
special protective maintenance product: the
invisible ilm le t by this product protects the
sur ace rom drips during cooking. This
maintenance task should be carried out while the
appliance is warm (not hot) or cold.
Always remember to rinse the appliance well with
clean water and dry it thoroughly: residues can
become encrusted during subsequent cooking
processes.
Stainless steel frame (only in models with outer
rame)
Stainless steel can be marked by hard water which
has been le t on the sur ace or a long time, or by
cleaning products containing phosphorus.
Ater cleaning, it is advisable to rinse the sur ace
well and dry it thoroughly. I water is spilt on the
sur ace, dry it quickly and thoroughly.
Some hobs have an aluminium rame which is
similar to stainless steel. o not use any cleaning or
degreasing products which are not suitable or use
with aluminium.
Disassembling the hob
I it is necessary to disassemble the hob:
1. Loosen the screws ixing the alignment springs on
each side.
2. Loosen the screws holding the ixing hooks in
each corner.
3. Take the hob out o its installation cavity.
o not attempt to repair the appliance yoursel . I
the appliance breaks down, contact a Service
Centre.

33
GB
Technical description of
the models
The induction system is the quickest existing way o cooking. Unlike traditional hotplates where the cooking
zone heats up, with the induction system heat is generated directly inside pans which have erromagnetic
bases.
Hobs TIP 642 DD B
TIP 642 DD L
TIP 644 DD L
TIP 744 DD L
Cooking zone Power (W) Power (W)
Back Left I 1400  600 i ront le t* I 1400  600 i ront le t*
Back Right I 2200  B 3000* I 2200  B 3000* - 1600 i ront right*
Front Left I 2200  B 3000* I 2200  B 3000* - 1600 i back le t*
Front Right I 1400  600 i back right* I 1400  B 2000*  600 i back right*
Total power 7200 7200
Key:
I = single induction cooking zone
I = double-diameter induction cooking zone
B = booster: the power o the cooking zone may be boosted to 3000 W
*= the maximum power level is limited while the booster is activated or the relevant rear cooking zone (see
tart-up and use).
