Schoolhouse Leo Mirror User manual

Leo Mirror
NOTE:
Leave cardboard strip between frame and glass until
installation is complete.
REQUIRED TOOLS:
Phillips Head Screwdriver
3/16˝ Drill Bit, Electric Drill (for Masonry Installation only)
INCLUDED HARDWARE:
INSTALLATION INSTRUCTIONS
1. If you have a Round Mirror or are orienting your
Rectangular Mirror vertically, skip to step 2. If you
prefer to hang your mirror horizontally, follow the
directions below.
a. Remove Mirror Bracket with a Phillips Head
Screwdriver from back of mirror.
schoolhouse.com
1
b. Reinstall the Mirror Bracket into the two thread-
ed inserts on the long side of the mirror back
using two #8-32 x 1/2˝ Machine Screws, two #8
flat washers and a Phillips Head Screwdriver.
1 3/8"Anchorless Screw (x3) Level (x1)
#8 Flat Washer (x2)
#8-32 x 1/2" Phillips
Machine Screw (x2)
Wall Bracket (x1)
Mirror Bracket (x1)

2. Install first Anchorless Screw through the middle
large hole of the Wall Bracket using Phillips Head
Screwdriver.
NOTE: For installation in masonry drill 3/16˝ pilot hole.
3. Slide Level into track in Wall Bracket.
092118
schoolhouse.com
2
4. Once bracket is level, mark center of remaining two
large holes with a pencil. Use tip of Anchorless Screw
to create an indent at each pencil mark. This will ease
installation and help the Wall Bracket remain level. In-
stall and tighten the remaining two Anchorless Screws
using Phillips Head Screwdriver.
5. Lift Mirror onto Wall Bracket. Mirror placement can be
adjusted slightly left or right without tipping.
WallMirror
6. Remove cardboard strip between frame and glass.
