Schumacher FR01241 User manual

0099001877-01
MODEL / MODELO / MODÈLE :
FR01241
Jump Starter and DC Power Source
Arrancador y fuente de poder de CC
Bloc d’alimentation et aide
démarrage
OWNERS MANUAL / MANUAL DEL USUARIO /
MANUEL D’UTILISATION
PLEASE SAVE THIS OWNERS MANUAL AND READ BEFORE EACH USE.
This manual will explain how to use the jump starter safely and effectively.
Please read and follow these instructions and precautions carefully.
POR FAVOR CONSERVE ESTE MANUAL DEL USUARIO Y LEALO ANTES
DE CADA USO. En este manual le explica cómo utilizar el arrancador de manera
segura y conable. Por favor, lea y siga las siguientes instrucciones y precauciones.
ESSAYER DE GARDER LE MANUEL D’INSTRUCTIONS ET LE LIRE AVANT
CHAQUE UTILISATION. Ce manuel explique comment utiliser l’unité d’une façon
sûre et efcace. S’il vous plaît lisez et suivez ces instructions et précautions.

CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ........................................................................4
PERSONAL SAFETY PRECAUTIONS...........................................................................5
FEATURES .....................................................................................................................5
CHARGING THE INTERNAL BATTERY.........................................................................5
USING THE JUMP STARTER ........................................................................................6
MAINTENANCE AND CARE ..........................................................................................7
TROUBLESHOOTING....................................................................................................7
BEFORE RETURNING FOR REPAIRS..........................................................................8
SPECIFICATIONS ..........................................................................................................8
ACCESSORIES..............................................................................................................8
LIMITED WARRANTY ....................................................................................................8
WARRANTY CARD ......................................................................................................19
CONTENIDOS
INSTRUCCIONES IMPORTANTES DE SEGURIDAD ...................................................9
PRECAUCIONES DE SEGURIDAD PERSONAL ..........................................................9
CARACTERÍSTICAS ....................................................................................................10
PARA CARGAR LA BATERIA INTERNA ......................................................................10
CÓMO UTILIZAR EL ARRANCADOR .......................................................................... 11
MANTENIMIENTO Y CUIDADO...................................................................................12
LOCALIZACIÓN Y SOLUCIÓN DE PROBLEMAS .......................................................12
ANTES DE DEVOLVER A REPARACIONES ...............................................................12
ESPECIFICACIONES...................................................................................................13
ACCESORIOS..............................................................................................................13
GARANTÍA LIMITADA...................................................................................................13
TARJETA DE GARANTÍA .............................................................................................19

TABLE DES MATIÈRES
CONSIGNES DE SÉCURITÉ IMPORTANTES ............................................................14
MESURES DE SÉCURITÉ PERSONNELLE ...............................................................14
CARACTÉRISTIQUES .................................................................................................15
CHARGE DE LA BATTERIE INTERNE ........................................................................15
UTILISATION DE LE DÉMARREUR ............................................................................16
MAINTENANCE ET ENTRETIEN.................................................................................17
DÉPANNAGE................................................................................................................17
AVANT DE RETOURNER POUR LES RÉPARATIONS ...............................................17
SPÉCIFICATIONS ........................................................................................................18
ACCESSOIRES............................................................................................................18
GARANTIE LIMITÉE.....................................................................................................18
CARTE DE GARANTIE ................................................................................................20

• 4 •
THIS UNIT CONTAINS A SEALED, NON-SPILLABLE
LEAD-ACID BATTERY. MUST BE DISPOSED OF PROPERLY.
WARNING: Possible explosion hazard. Contact with battery acid may
cause severe burns and blindness. Keep out of reach of children.
ESTA UNIDAD CONTIENE UNA BATERÍA SELLADA DE ÁCIDO-PLOMO
NO DERRAMABLE QUE DEBE DESECHARSE APROPIADAMENTE.
ADVERTENCIA: Posible riesgo de una explosión. El contacto con una batería de ácido
puede causar quemaduras y ceguera. Manténgase alejado de los niños.
CET APPAREIL CONTIENT UNE BATTERIE SCELLÉE SANS ÉCOULEMENT AU
PLOMB-ACIDE. LA BATTERIE DOIT ÊTRE JETÉE ADÉQUATEMENT.
AVERTISSEMENT : Risque d’explosion possible. Le contact avec l’acide des batteries
peut causer de graves brûlures et la cécité. Conserver hors de portée des enfants.
1. IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS.
WARNING – RISK OF EXPLOSIVE GASES
WORKING IN THE VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS.
BATTERIES GENERATE EXPLOSIVE GASES DURING NORMAL OPERATION.
IT IS IMPORTANT THAT YOU FOLLOW THESE INSTRUCTIONS EACH TIME
YOU USE THE JUMP STARTER.
To reduce the risk of battery explosion, follow these instructions and those published by
the battery manufacturer and the manufacturer of any equipment you intend to use in the
vicinity of a battery. Review cautionary marking on these products and on the engine.
• Keep out of reach of children.
• Do not disassemble the jump starter.
Take it to a qualied service professional
if service or repair is required. Incorrect
assembly may result in re or electrical
shock.
• Do not use the jump starter to jump a
vehicle while charging the internal battery.
• Do not recharge the jump starter with a
damaged extension cord.
• The jump starter gets hot during charging
and must have proper ventilation.
• Do not set the jump starter on ammable
materials, such as carpeting, upholstery,
paper, cardboard, etc.
• Place the jump starter as far away from
the battery being jumped as the cables
will permit.
• Do not expose the jump starter to rain
or snow.
• Never place the jump starter directly
above battery being jumped.
• To prevent arcing, never allow the clamps
to touch together or to contact the same
piece of metal.
• Use of an attachment not recommended
or sold by Schumacher®Electric
Corporation may result in damage to the
unit or personal injury.
• Never operate the jump starter if it is
damaged.
• If someone else uses the jump starter,
ensure they are well informed on how
to use it safely, and have read and
understood the operating instructions.
• The jump starter is NOT designed to be
installed as a replacement for a vehicle
battery.
• Use ONLY on vehicles, boats and garden
tractors powered with a 12V DC battery
system.
• If the engine fails to start after the
recommended number of attempts,
disconnect the unit and look for other
problems that may need to be corrected.
• Use the jump starter for jump starting
lead-acid batteries only. Do not use for dry
cell batteries that are commonly used with
home appliances.

• 5 •
2. PERSONAL SAFETY PRECAUTIONS
• Wear complete eye protection and
protective clothing when working
near lead-acid batteries. Always have
someone nearby for help.
• Have plenty of fresh water, soap and
baking soda nearby for use, in case
battery acid contacts your eyes, skin, or
clothing. Wash immediately with soap
and water and seek medical attention.
• If battery acid comes in contact with eyes,
ush eyes immediately for a minimum 10
minutes and get medical attention.
• Neutralize any acid spills thoroughly with
baking soda before attempting to clean up.
• Remove all personal metal items from your
body, such as rings, bracelets, necklaces
and watches. A battery can produce a short
circuit current high enough to weld a ring to
metal, causing a severe burn.
• Never smoke or allow a spark or ame in
the vicinity of the battery or engine.
3. FEATURES
6
4
3
5
7
8
1
2
1. USB port
2. Rotary switch for USB and jump starter
3. Built-in work light
4. Battery status indicators
5. Battery status button
6. 12V DC power outlet
7. Worklight ON/OFF switch
8. Battery clamps
4. CHARGING THE INTERNAL BATTERY
IMPORTANT!
CHARGE IMMEDIATELY AFTER
PURCHASE, AFTER EACH USE AND
EVERY 30 DAYS, TO KEEP THE
INTERNAL BATTERY FULLY CHARGED
AND PROLONG BATTERY LIFE.
CHECKING THE LEVEL OF THE
INTERNAL BATTERY
Press the Battery Status button on
the front of the unit. The LED lights will
indicate the current charge level as
follows:
RED – less than 20% of full charge;
immediately charge the unit.
YELLOW/ORANGE – 20-80% of full
charge.
GREEN – more than 80% of full charge.
CHARGING THE INTERNAL BATTERY
Charge the internal battery for the
jump starter using an extension cord (not
included).
NOTE: Use of an improper extension
cord could result in a risk of re and
electric shock.
1. To charge, ip the AC connector on
the back of the unit DOWN and plug in
an 18 AWG or larger extension cord.
2. Plug the extension cord into a 120VAC
electrical wall outlet.
3. While the jump starter is charging, the
RED LED will be on. Complete charging
may take up to 72 hours. When the
RED LED turns off, the jump starter is
ready to use.
4. When the internal battery is fully
charged, the charger will automatically
go into maintain mode and maintain
the battery at full charge without
damaging it. When in maintain mode,
the GREEN LED will pulse, as long
as there is an AC cord connected to
the charging port.
5. Charge the jump starter as soon as
possible after use.
CHARGING THE INTERNAL BATTERY
WHILE DRIVING
You may also charge the internal battery
while driving, using a male-to-male
charger cable (part number 94500109 –
not included).
