Schwaiger Home 4 You ZHS20 User manual

Network inclusion of the sensor
Put the Gateway into inclusion mode.
Remove the protective battery cover, press the networking button
for 2 seconds until the green LED starts to flash fast.
USER MANUAL ZHS20
Congratulations and thank you for purchasing the Schwaiger ZHS20 product.
Below you will find useful operating guidelines.
SMOKE SENSOR
ZHS20
BDA_ZHS20_a
Please pay attention to the fact that during network inclusion, the
distance between sensor and Gateway may not exceed 0.5 m.
3. Networking button
Press the networking button (with-
in the hole) for 2 seconds until the
green LED starts to flash fast, then
let go. The device will be detected
and included into the network.
4. Installation
of the Smoke Sensor
Select a place for installation.
5. Screw the bracket to
the ceiling OR remove the
protective cover from the
adhesive pad and stick
the bracket to the ceiling.
6. Attach the sensor to
the bracket by turning
it clockwise.
This is a smart smoke sensor which is based on the ZigBee Wireless Network-
ing technology. It has a very low power consumption which makes for longer
battery life. As soon as the sensor detects smoke, the alarm signal will sound
and the red LED will start to flash.
Network inclusion
1. Remove the protective battery cover.
To do so, remove the sensor from the
bracket by turning it counter-clockwise.
2. Put the Gateway into inclusion mode
7. Network removal of the device
Put the Gateway into removal mode by choosing „Home setup“ in the main
menu and then click on „Add device“ (See images on the left). Then reset the
device to default settings.
8. Reset to default settings (Reset)
Press the networking button for 5 seconds until the green LED starts to flash
slowly.
Note: For network inclusion, the sensor must always be in the factory state.
MANUFACTURER INFORMATION
Dear Customer,
should you require technical advice and
your retailer could not help please contact
our technical support.
Schwaiger GmbH
Würzburger Straße 17
90579 Langenzenn
Hotline: [phone]
www.schwaiger.de
[e-mail]

LED indicator of devices
Network inclusion Press the networking button for 2
seconds until the green LED starts to
flash
(two times per second)
Network removal / Reset The green LED flashes 6 times
(once per second)
Technical data
Working voltage DC 3 V (1xCR123A battery)
Static current ≤ 10 µA
Alarm current ≤ 60 mA
Noise level 85 dB
Working environment -10°C ~ +50°C
Frequency range 2.4 GHz
Range about 15 m (depending on building
structure)
Dimension 60 x 60 x 49.2 mm
Important information
• This smoke sensor is only suitable for smoke detection. It cannot detect gas,
heat or flames and cannot prevent or put out fires.
• This smoke sensor is not suitable for use in places with high humidity (e.g.
bathrooms) or kitchens.
• Correct functioning of the smoke sensor should be checked regularly.
• The smoke sensor should be cleaned regularly in order to prevent malfunc-
tion due to dust and dirt.
• Smoke sensors have to be replaced after 10 years of use.
• In case that the smoke sensor does not function correctly, do not try to
repair it yourself. Please contact the manufacturer.
Status information
Status LED indicator Alarm signal
Normal function Red LED flashes every 53
seconds
No
Test mode Red LED flashes Fast peeping
Smoke detected Red LED flashes Fast peeping
Low battery Red LED flashes once Peeps once every
53 seconds
Malfunction Red LED flashes twice
every 53 seconds
Peeps twice every
53 seconds
Test mode
It is recommended to check correct functioning of the sensor at least once a week. To
do so, please press and hold the button Test for 3 seconds until the alarm signal sounds.
Never check correct functioning of the sensor by holding it over a flame.
Replacing the battery
Under normal conditions, battery power can last up to 3 years. However, batteries
should still be replaced regularly, at the very least when the sensor indicates low bat-
tery. Upon replacing the battery, please make sure to position it correctly.
Problem Possible cause Solution
The alarm is triggered even though there is no
smoke
The sensor is dirty or covered in dust Clean the sensor carefully using warm water and a
soft brush
The device peeps twice at regular intervals Low battery Replace the battery
The alarm tone does not sound or is very weak Low battery Replace the battery
The alarm does not sound upon pressing the Test
button
Battery is not positioned correctly in the bracket or
is positioned the wrong way
Position the battery correctly paying attention to
the + and - poles
Low battery Replace the battery
The device is not available in the network Low battery Replace the battery
The distance between the smoke sensor and the
Gateway is too large for wireless networking
1. Install a repeater
2. Position the Gateway closer to the sensor
Network inclusion of the smoke sensor failed The sensor is still connected to another network Please carry out a reset
The Gateway has not been put into inclusion mode Put the Gateway into inclusion mode
Choosing a Suitable Location
For complete coverage in residential units, Smoke Sensors should be installed in all
rooms, halls, storage areas, basements and attics in each family living unit. Minimum
coverage is one sensor on each floor and one in each sleeping area.
1. Install Smoke Sensor as close to the center of ceiling as possible. If this is not practi-
cal, put the sensor on the ceiling, no closer than 6inches(15 cm) from any wall or
corner and no closer than 12inches(30 cm) from any lamp or other object.
2. If some of your rooms have sloped, peaked, or gabled ceilings, try to mount sensors
3 feet(0.9 meter) measure horizontally from the highest point of ceiling.
Nuisance alarms take place when Smoke Sensors are installed where they will
no work properly. To avoid nuisance alarms, do not install Smoke Sensors in
the following situations:
• Combustion particles are the by-products of something that is burning. Thus,
in or near areas where combustion particles are present you do not install
the Smoke Sensors to avoid nuisance alarms, such as kitchens with few
windows or poor ventilation, garages where there may be vehicle exhaust,
near furnaces, hot water heaters, and space heaters.
• Do not install Smoke Sensors less than 20 feet (6 meters) away from places
where combustion particles are normally present, like kitchens. If a 20-foot
distance is not possible, try to install the alarm as far away from the combus-
tion particles as possible, preferably on the wall. To prevent nuisance alarm
alarms, provide good ventilation in such places.
• In very dusty or dirty areas, dirt and dust can build up on the alarm’s sen-
sing chamber, to make it overly sensitive. Additionally, dust or dirt can block
openings to the sensing chamber and keep the alarm from sensing smoke.
• Near fluorescent lights, electrical “noise” from fluorescent lights may cause
nuisance alarms. Install Smoke Sensor at least 5 feet(1.5 meters) from such
lights.
• If used in rooms and buildings whose structure is made up of a lot of metal
and concrete, the wireless signal range of the smoke sensor may suffer
significantly.
Disposal information
This product contains batteries. Please refer to the applicable disposal regu-
lations for batteries. It is an electrical device. They can be disposed of free of
charge at specified disposal sites.
EC Declaration of Conformity
This device corresponds to the relevant EU directives. With the CE sign the
Schwaiger GmbH ensures, that the product is conformed to these basic
standards and directives. The conformity explanation can be found under the
following address: http://www.schwaiger.de/downloads
