Schwank MonsterFans Style Series User manual

schwankgroup.com/monsterfans
MonsterFans Style Series
Installation Manual

2 3
schwankgroup.com/monsterfans schwankgroup.com/monsterfans
Table Of Contents Overview
Overview .............................................................................................................................................. 3
Components................................................................................................................................. 3
Technical Data.................................................................................................................................... 4
Fusing and Thermal Limiting............................................................................................................... 5
Fuses............................................................................................................................................... 5
Thermal Limiting............................................................................................................................ 5
Safety.................................................................................................................................................... 5
Electrical Safety............................................................................................................................ 5
General Safety ............................................................................................................................. 5
Clearances ................................................................................................................................... 6
Installation Preparation....................................................................................................................... 7
Preparation ................................................................................................................................... 7
Tools Required .............................................................................................................................. 8
Items Included..............................................................................................................................10
Hardware Included......................................................................................................................11
Installation Procedure.........................................................................................................................12
Installation of the Mounting Hardware......................................................................................12
Installing the Motor Assembly .....................................................................................................20
Installing the Blades .....................................................................................................................22
Installing the Optional LED Light Kit ............................................................................................23
Installing the Hub Cover [with Lens]...........................................................................................24
Electrical Installation ...........................................................................................................................25
Wiring the Fan...............................................................................................................................25
Power Wiring – 120/240 VAC 1 Phase Input ..............................................................................26
HMI Control ..........................................................................................................................................28
HMI/CAT 5 Cable Connection ...................................................................................................28
Maintenance.......................................................................................................................................29
Recommended Maintenance Schedule .................................................................................30
LED Light Kit Or
Lens [below]
[5] Blades
[Not Shown]
Motor Assembly
Hub Cover
Mount Assembly
[3 mm] 3/32” Aluminum Crimp
Optional Custom
Lengths Available
See Mounting Applications
[2] [3 mm] 1/8” Cable Clamp Zinc
Note: All bolts are “Grade 5”
[#] = Quantity Supplied
Components
Illustrations may be changed without notice. All dimensions and specications are approximate and
drawings are not to scale. Specications are subject to change without notice.

4 5
schwankgroup.com/monsterfans schwankgroup.com/monsterfans
Fuses
It is recommended that the following fuses for protecting the equipment and subject to local
authority:
For 220-240 VAC use a fast blow fuse rated 5 Amps.
For 110-120 VAC use a fast blow fuse rated 10 Amps.
Thermal Limiting
The Fan System is designed to monitor motor and controller temperatures and, in the event, that
operating temperatures exceed control limits, fan speed will automatically reduce until the system is
within temperature limits. No user intervention is required.
Electrical Safety
Never work on the drive, motor cable or motor when input power is applied. After disconnecting the
input power, always wait for 5 minutes to let the intermediate circuit capacitors discharge before you
start working on the drive, motor or motor cable.
Do not work on the control cables when power is applied to the drive or to the external control
circuits. Externally supplied control circuits may carry dangerous voltage even when the input power
of the drive is switched off.
The Touch Current of the Protective Earthing Conductor could reach up to 9mA AC.
Technical Data Fusing and Thermal Limiting
Safety
Conformity CE Low Voltage [2006/95/EC] & EMC [2004/108/EC]
Directives
EN61000-6-2:2005, EN61000-6-4:2007
IEC 60335-2-80:2015 IEC 60335-1:2015
Approvals UL61800-5-1
CSA C22.2 No113
Input Voltage Phase
Imbalance
≤2%
Input Voltage 110-240 VAC
Input Current 4.6 @ 120VAC, 2.5A @ 240VAC
Input Frequency 50-60Hz
Supported Power Systems TT TN For central ground systems, operation is permitted
without restrictions.
Humidity ≤ 95% Non-condensing
Temperature Range Transport -40°F…+160°F [40°C...+70°C]
Storage -40°F…+160°F [40°C...+70°C]
Operation -40°F…+120°F [40°C...+50°C] [with speed derating
above +104°F]
Installation Altitude 0-13,000 ft [0-4000 m]
above sea level
[with 5%/3000ft current derating above 3000ft]
Earth Leakage Current <=9 mA to PE
Power Conductor Size [Cord] Minimum 16AWG 3 Conductors rated 300VAC, use Copper Conductors
only.
For permanent connection only.
Max. Permissible Control Ca-
ble Length
100 ft un-shielded
Enclosure IP54/ NEMA 3
Protection Measures Against Short circuit, earth fault, phase loss, over voltage, under voltage, motor
stalling, over temperature, motor overload, communication loss
Environment For indoor use only
Thermal Overload Protection Drive provides internal overload protection for the motor
Pollution Degree 2
Overvoltage Category Category lll
Supply Earthing System TN-S
Impulse Voltage 2500V
Working System Voltage 150V
Packaged Fan Weight 98 lbs [44.5 kgs]
Overall Fan Weight
[no mount]
85 lbs [38.5 kgs]
LED Light Kit Weight 1.542 lbs [0.669 kgs]
Warning! Ignoring the following instructions can cause
physical injury or death, or damage to the equipment.
Warning! Only qualied electricians are allowed to install
the drive and connections to the motor!
General Safety
• Installation work and electrical work must be done by qualied person[s] in accordance with all
applicable codes and standards, including re-rated construction.
• The installation is to be in accordance with the National Electrical Code, CSA C22.1, ANSI/NFPA
70, and local codes.
Warning! To reduce the risk of re, electric shock, or injury
to persons, observe the following:

6 7
schwankgroup.com/monsterfans schwankgroup.com/monsterfans
Preparation
• The Fan must be installed with the proper blades to match the fan assembly that are marked to
indicate their suitability with this model.
• No other blades can be substituted.
• Check to see if you have all the tools required for the installation.
• Verify that all fan components were received.
• Check drawings and layouts provided to locate where the Fan is to be installed.
• Ensure work area is safe and that all security, policies and procedures for the facility are met.
• Inspect the lift device or mobile platform.
• Each person installing the Fan must use a safety harness at all times.
• Other safety requirements may be required for installation.
• All workspace safety requirements, lock out procedures and hoarding of construction zone for the
assembly and installation must be met and followed.
• This appliance is not intended for use by persons [including children] with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
supervised or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• The mounting of the suspension system shall be performed by a certied contractor or suitably
qualied persons.
• DO NOT LIFT, CARRY OR HANG FAN BY POWER CABLE. This could possibly cause the safety
disconnect system to disconnect power to the fan.
Clearances
• Open ceiling, center of fan to roof deck for ideal operating performance without compromising
overall fan performance
• Min 12” [304.8 mm] from fan blade’s leading edge to obstruction above or below fan.
• Min 8” [203 mm] from side of fan to any obstruction
• Min oor to fan leading edge height 120” [3050 mm]
Contractor is responsible for verifying all site conditions to include eld dimensions where applicable.
If the contractor elects to make any changes without notifying Schwank Ltd. the contractor is
responsible for the same. All drawings are to be used as general architectural intent unless otherwise
stamped. See Engineer drawings for structural design information. Contractor to ensure that all
building departments and authorities are informed in regard to the work and that all permits are
attained before commencing work.
Installation Preparation
Warning! To reduce the risk of re, electric shock, or injury
to persons, observe the following:
Safety

8 9
schwankgroup.com/monsterfans schwankgroup.com/monsterfans
Glu-Lam Mount
Installation Procedure
Installation of the Mounting Hardware
Note: Consult a structural engineer before installation. Choose one of the following mounting options
for your Fan and follow the corresponding steps. The mounting kits included in the Fan package are
glu-lam, purlin, OWSJ and web truss.
Tools Required
• Level
• Ratchet or impact gun
• 3/8”, 7/16” and 9/16” Imperial socket to t bolt heads and nuts
• 7/16” and 9/16” Imperial wrench to t bolt heads and nuts
• #2 Phillip screwdriver
• Lifting device or scaffolding
• Appropriate personal protective equipment
• Drill [optional]
• Drill bit set up to ½” diameter [optional]
Items Included
• Motor Assembly
• [5] Blades [Optional Color]
• [1] LF/SP Assembly
• [1] Packaged Assembly Hardware
• [1] Packaged HMI Control
• [1] Packaged Wire Harness
• [1] LED Light Kit [Or Lens]
• [1] Hub Cover [Optional Color]
Hardware Included
• Mounting Plate
• [2] Mounting Brackets
• [3] 3/8 x 9” B7 Threaded Rod W/ Nut
• [2] Hex Cap Screw 3/8” X 3”
• [5] 3/8 Nylocks
• [10] 3/8 Flat Washers
• [20] ¼ x 5/8 Serrated Flange Head Cap Screw
• [5] #8-32 x 1 3/8 Machine Screw
• [1] 1/8” Cable Clamp
• [1] Studded Mount Assembly
• [8] ¼ Flat Washers
• [8] ¼ Nylocks
• [4] ¼ x 1 ¼ Hex Cap Screw
• [3] 3/8 x 1 ½ Hex Cap Screw
• [1] Stand Off Ring
Note: Illustrations may be changed without notice. All dimensions and specications are approximate
and drawings are not to scale. Specications are subject to change without notice.
Warning! Use of any other mounting hardware or
technique is strictly prohibited.
Only use mounting hardware/ brackets supplied
by MonsterFans Style Series.
1. From an accessible landmark, on the glu-lam, measure to the centre line of the bottom centered
hole of the 3 mounting holes.
2. Drill the centered bottom mounting hole with a ½” drill bit, so that there will be a minimum of ¾”
[19mm] between the top of the mounting bracket deck and the bottom of the glu-lam.
3. Place the two mounting bracket faces one on each side of the glu-lam with each mounting
bracket bottom deck face inward.
4. Before fastening the mounting brackets install four ¼” x 1-1/4” long hex cap screws with ¼” at
washers into mounting bracket deck facing down.
5. Using a 3/8” X 9” threaded rod with welded nut and 3/8” nylock nut, suspend the mounting
brackets using the center bottom hole only.
Installation Preparation

10 11
schwankgroup.com/monsterfans schwankgroup.com/monsterfans
1. Level the mounting brackets and mark the centre of the top two mounting holes.
Drill the remaining top two mounting holes.
2. Before tightening the structural nuts and bolts, ensure the bracket is plumb and level then
proceed with tightening the mounting brackets to the glu-lam.
3. Fasten studded mount assembly to four ¼” x 1-1/4” long hex cap screws already in place using
four ¼” at washers and four ¼ nylocks.
4. Continue onto page 20 to complete the fan installation.
1. From an accessible landmark, on the rst purlin, measure to the centre line of the bottom
centered hole of the 3 mounting holes.
2. Drill the centered bottom mounting hole with a ½” drill bit, so that there will be a minimum of ¾”
[19mm] between the top of the mounting bracket deck and the bottom of the purlin.
3. Place the two mounting bracket faces together with each bracket bottom deck face outward.
4. Before fastening the mounting brackets install four ¼” x 1 1/4” long hex cap screws with ¼” at
washers into slots in mounting bracket deck facing down.
5. Using a 3/8” X 1-1/2” hex cap screw and 3/8” nylock nut, suspend the mounting brackets using
the center bottom hole only.
6. Level the mounting brackets and mark the centre of the top two mounting holes.
Drill the remaining top two mounting holes.
7. Before tightening the structural nuts and bolts, ensure the bracket is plumb and level then
proceed with tightening the mounting brackets to the purlin.
8. Fasten studded mount assembly to four ¼” x 1-1/4” long hex cap screws already in place using
four ¼” at washers and four ¼ nylocks.
9. Continue onto page 20 to complete the fan installation.
Purlin Mount
Installation ProcedureInstallation Procedure

12 13
schwankgroup.com/monsterfans schwankgroup.com/monsterfans
OWSJ Mount [Open Web Steel Joist] Wood Truss Mount
1. Insert two 3/8” X 9” long thread rod with welded nut through the studded mounting plate pointing
upward. Place the studded mounting plate against bottom face of OWSJ and place through
bottom web of OWSJ directing the threaded rods between the bottom web angles.
2. Place the other mounting plate over top of the bottom web angles and thread two 3/8” nylock
nuts onto threaded rod with welded nuts.
3. Tighten to sandwich assembly to bottom web of the OWSJ.
4. Continue onto page 20 to complete the fan and drop installation.
1. Place round stand-off on top of ange of fan assembly.
2. Ensure power wire, communication wire and safety cable are directed through either a hole on
side of stand-off ring or up through the centre of the studded mount assembly.
3. Lift motor assembly to bottom of the studded mounting assembly at ceiling and position with
round stand-off on fan assembly so the four ¼” studs are inserted through the clearance holes in
the ange of fan assembly.
4. Thread four ¼” nylock nuts on each of the studs to sandwich fan assembly with round stand-off to
the bottom mounting plate of studded mount assembly.
Installation ProcedureInstallation Procedure

14 15
schwankgroup.com/monsterfans schwankgroup.com/monsterfans
5. Ensure wires are not compromised and tighten ¼” nylock nuts to secure the motor assembly to
the studded mounting assembly.
6. Anchor the safety cable, allowing ¾” [19mm] of slack cable, and secure to solid point of the glu-
lam, purlin, OWSJ, wood truss or building structure using supplied cable clamps.
7. The power cable must be secured to a solid point of the glu-lam, purlin, OWSJ, wood truss or
building structure. The power cable is to be fastened so there is absolutely no slack in line, in order
to allow the safety disconnect to function as designed. [see “Electrical Installation” section of
manual.
8. Install all ve blades [see “Blade Installation” section of manual].
9. Install Light Kit [see “Light Kit Installation” section of manual].
10. Install Hub Cover [see “Hub Cover Installation” section of manual].
1. Using 3/8” socket fasten blade to hub plate on the bottom of the motor assembly.
2. Insert four ¼” x 5/8” serrated ange hex cap screws through all four holes in blade.
3. Thread hex cap screw into hub plate until blade is fastened tightly.
4. Repeat rst 3 steps for each of the remaining blades.
5. Turn fan by hand to ensure that there are no obstructions with the blades.
Installation Procedure Installing the Optional LED Light Kit
Installing the Blades
Caution! to reduce the risk of re, electric shock,
or injury to persons, disconnect the electrical
supply circuit to the fan before installing light kit.
The light kit is pre-assembled for visual understanding of assembly, and will need to be disassembled
to install.
1. Remove light kit from box
2. Using a Phillips screwdriver, remove the four - #6 x 3/8 screws and the two electrical box clips
to free the LED panel light from the electrical box. Inside, there will be three #8 x 3/8 pan head
machine screws.
3. Direct the LED power wire on the bottom of the motor assembly through the electrical box.
Mount the electrical box to the bottom of the motor assembly using the three #8 x 3/8 pan head
machine screws ensuring wiring is not compromised.
4. Plug the LED panel light into the power wire.
5. Install the four - #6 x 3/8 screws and the two electrical box clips to secure the LED panel light to
the electrical box in the same manner it was packaged.

16 17
schwankgroup.com/monsterfans schwankgroup.com/monsterfans
Wiring the Fan
A means of disconnect must be incorporated in the xed wiring in accordance with electrical codes
and standards.
DO NOT LIFT, CARRY, OR HANG FAN BY POWER CABLE. This could possibly cause the safety
disconnect system to disconnect power to the fan.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
For compliance with EMC standards the LF/SP Assembly must be installed as directed in the
installation manual. The EMC requirements apply to the nal installation in its entirety, not to the
individual components used. As every installation is different, the recommended installation should
follow these guidelines as a minimum.
Note: The use of the LF/SP Assembly is mandatory and will apply to Fan [CE]. However, for Fan [UL/
CSA] the LF/SP Assembly is additional optional equipment and is available upon request.
Electrical Installation
Installing the Hub Cover [with Lens]
1. Take hub cover [with optional lens if applicable], and place over the center hub and blade
proles. Align the hole pattern up with clearance holes on each of the ve blades.
2. Fasten hub cover with insert to fan assembly by threading ve #8-32 X 1-3/8” long machine screws
through the clearance hole into each blade and tighten to secure.
3. Turn fan by hand to ensure that there are no obstructions with the hub cover.
1. Ensure all local electrical codes are met.
2. The motor is to be eld-wired to a separate dedicated branch circuit.
3. The power cable must be secured to a solid point of the glu-lam, purlin, OWSJ, wood truss or
building structure. The power cable is to be fastened so there is absolutely no slack in line, in order
to allow the safety disconnect to function as designed.
4. The location of the input power [line] is labelled on the enclosure and should be drilled to
accommodate the appropriate gauge of wire required in accordance with the electrical codes
and standards.
5. The input power [line] will be wired into the LF/SP assembly as shown in the following illustration.
6. The outgoing power [load] that is coming out of the LF/SP Assembly and going to the fan must
also be wired as shown in the following illustration.
Power Wiring – 120/240 VAC 1 Phase Input
Installing the Optional LED Light Kit

18 19
schwankgroup.com/monsterfans schwankgroup.com/monsterfans
Input: 120/240V 2.9/1.45A 1 PH
50/60Hz LED: 25W
Electrical Installation HMI Control
HMI/CAT 5 Cable Connection
75ft of Cat 5 cable is supplied to connect the HMI to the fan. This is a simple “plug and play”
application once the cable is ran. Level and install HMI within reach of the 75ft CAT 5 cable using
supplied fasteners. It is recommended the fan remain in line of site of the HMI.
HMI Control
The bottom left button toggles ‘Light’ to ‘Fan’ depending on what functionality you are looking to set
or adjust. When the screen says ‘Fan’, the remaining buttons on the keypad are controlling just the
fan. When the screen says ‘Light’, the remaining buttons on the keypad are controlling just the light.
The centre button is the on/off control. This button controls both the fan & light, however; they are
controlled separately depending on which functionality the interface is showing.
The top left button only works when the interface is controlling the ‘Fan’. This button is for forward and
reverse functionality of the fan as indicated by the left and right arrows.
The up and down buttons on the right of the control adjust the speed of the fan or the brightness of
the light depending on which functionality the interface is showing. The value is displayed 0%-100%
and is adjusted in increments if 5%. 100% displayed for the fan is equivalent to full speed and 100%
displayed for the light is full brightness. The control will remember the last speed & light values and will
automatically resume those settings once the fan is turned back on.
Note: The Fan System is designed to monitor motor and controller temperatures and in the event
that operating temperatures exceed control limits, fan speed will reduce until the system is within
temperature limits. No user intervention is needed.

20 21
schwankgroup.com/monsterfans schwankgroup.com/monsterfans
Maintenance Maintenance
Warning! Risk of shock!
If unusual oscillating movement is observed, immediately
stop using the ceiling fan and contact the manufacturer,
its service agent or suitably qualied persons.
Terminals:
Power Terminal: 3A, 300V, 10-30 AWG Torque = 0.5-0.6 Nm [0.37-0.44 ft-lb]
I/O Terminal: 17.5A, 300V, 12-30 AWG Torque = 0.6-0.8 Nm [0.44-0.59 ft-lb]
Power Cord:
Minimum 16AWG 3 Conductors rated 300VAC, use Copper Conductors only. For permanent
connection only.
Warning! Risk of shock!
Only qualied personnel to remove drive cover! There is no
adjustments or replacement parts for the use!
1. No maintenance shall be done on the fan, mount or guy wires while it is in operation or powered.
2. No maintenance shall be done on the fan controller while powered unless the task involves
reprogramming or troubleshooting the electrical system.
3. No maintenance shall be done within a 6m [20ft] horizontal radius of the fan and 1.2m [4ft] below
and none above the blade level while it is in operation.
4. While doing maintenance on the fan, mount, or guy wires, a safety barrier shall be erected at a
radius of 6m of the centre of the fan.
5. The fan controller shall be locked out while maintenance is ongoing on the fan, mount, or guy
wires.
6. All personnel working on the fan, mount, or guy wires, shall wear the appropriate personal safety
equipment as mandated by local, provincial, and national regulations.
7. A risk assessment shall be performed before any maintenance is done on the fan, mount, guy
wires and fan controller.
8. A tailboard meeting shall be performed before any work is done. A checklist shall be completed
and shall include any emergency contacts for the area.
Initial Six Months
• Check for hot spots
• Re-tighten all loose electrical connections
• Check all nuts/bolts/clamps [missing/loose/damaged]
• Physical check of safety cable, re-tightening of clamps if required
Repeat Every Eighteen Months Thereafter
Recommended Maintenance Schedule
Maintenance Schedule

Toll Free: 1-877-446-3727
1-706-554-6191
[email protected]
schwankgroup.com/monsterfans
USA
2 Schwank Way,
Waynesboro, GA
30830
Canada
5285 Bradco Blvd.,
Mississauga, ON
L4W 2A6
