Schweizer LocControl100 Operating instructions

LocControl100 Page 1 of 28 General operating instructions
10.0296.6600.01 Version N
LocControl100
General operating instructions
(customer-specific aspects are described in a separate document)
Document no. 10.0296.6600.02
Version N
Author: Gerhard Jordi
The contents of this manual are the intellectual property of Schweizer Electronic AG. No user rights to
patents or other property rights are granted to third parties through its acquisition. All rights remain with
Schweizer Electronic. Except with our express permission, this manual may not be copied or duplicated,
either completely or partially, and it may not be communicated or made accessible to third parties.

LocControl100 Page 2 of 28 General operating instructions
10.0296.6600.01 Version N
Contents
0DOCUMENT INFORMATION ..................................................................................................................4
0.1 DOCUMENT OBJECTIVE................................................................................................................................4
0.2 VERSION CONTROL .....................................................................................................................................4
1INTRODUCTION......................................................................................................................................5
1.1 GENERAL REMARKS ....................................................................................................................................5
1.2 ISED RSP-100 NOTICE: ............................................................................................................................6
2PICTOGRAMS .........................................................................................................................................7
3LOCCONTROL100 COMMISSIONING AND MAINTENANCE CONCEPT............................................8
3.1 INTRODUCTION ...........................................................................................................................................8
3.2 COMMISSIONING ENGINEERS’ACTIVITIES:.....................................................................................................8
3.3 MAINTENANCE ENGINEERS’ACTIVITIES:........................................................................................................8
3.4 OPERATOR.................................................................................................................................................8
3.5 MANUFACTURERS.......................................................................................................................................8
3.6 PERSONNEL COMPETENCE..........................................................................................................................8
3.7 QUALIFICATION OVERVIEW...........................................................................................................................9
3.8 THE SERVICE ORGANIZATION.......................................................................................................................9
4DEVICE DESCRIPTION ........................................................................................................................10
4.1 OPERATING PRINCIPLE..............................................................................................................................10
4.2 TRANSMITTER...........................................................................................................................................10
4.3 RECEIVER ................................................................................................................................................10
4.4 RECEIVER →TECHNICAL UNIT INTERFACE..............................................................................................10
5SYSTEM SECURITY..............................................................................................................................11
5.1 ADDRESSING............................................................................................................................................11
5.2 TRANSMISSION SECURITY ON THE RADIO CHANNEL .....................................................................................13
6STANDARDS, GUIDELINES AND COMPANY-INTERNAL REGULATIONS......................................13
6.1 STANDARDS,GUIDELINES AND COMPANY-INTERNAL REGULATION HIERARCHY...............................................13
6.2 OBSERVED STANDARDS ............................................................................................................................13
6.3 RADIO MODULE „MSY“ NOTIFICATIONS.......................................................................................................14
6.4 LOCCONTROL100 RSNOTIFICATIONS........................................................................................................14
7INTENDED USE OF THE RADIO REMOTE CONTROL ......................................................................14
8SAFETY INFORMATION.......................................................................................................................15
8.1 GENERAL SAFETY INFORMATION................................................................................................................15
8.2 GENERAL OPERATING SAFETY GUIDELINES.................................................................................................15
8.3 SAFETY INFORMATION FOR OPERATION......................................................................................................16
8.4 COMPORTMENT IN EMERGENCY SITUATIONS...............................................................................................16
9COMPORTMENT IN CASE OF THUNDERSTORMS...........................................................................16
10 TRANSMITTER......................................................................................................................................17
10.1 TECHNICAL DATA -TRANSMITTER..........................................................................................................17
10.2 CARRYING HARNESS FOR THE SCHWEIZER ELECTRONIC TRANSMITTER MODEL........................................17
10.3 USE OF OPERATOR’S OWN CARRYING HARNESS......................................................................................18
10.4 TRANSMITTER OPERATION WITH TRANSMITTER HOLDER..........................................................................18
11 LITHIUM-ION BATTERIES....................................................................................................................19
11.1 CARE WHEN DEALING WITH LITHIUM-ION BATTERIES (AKKUPACS)............................................................19
11.2 BATTERY EXPIRY DATE..........................................................................................................................19
11.3 DISPOSAL OF BATTERIES.......................................................................................................................19
12 RECEIVER .............................................................................................................................................20
12.1 TECHNICAL DATA -RECEIVER ...............................................................................................................20
13 RECEIVER ANTENNA ..........................................................................................................................20
14 MOUNTING THE RECEIVER, TRANSMITTER HOLDER AND ANTENNA ........................................20
15 MALFUNCTIONS...................................................................................................................................21
15.1 TRANSMITTER MALFUNCTIONS...............................................................................................................21

LocControl100 Page 3 of 28 General operating instructions
10.0296.6600.01 Version N
15.2 RECEIVER MALFUNCTIONS.....................................................................................................................21
15.3 BATTERY CHARGER MALFUNCTIONS.......................................................................................................21
15.4 RADIO MALFUNCTIONS BY EXTERNAL INFLUENCES ..................................................................................21
16 OPERATING DATA ...............................................................................................................................22
16.1 DATA ACQUISITION................................................................................................................................22
16.2 OPERATING DATA READOUT ..................................................................................................................22
17 OPENING THE LOCCONTROL100 TRANSMITTER AND RECEIVER...............................................22
18 MAINTENANCE OF THE LOCCONTROL100 SYSTEM ......................................................................23
19 LOCCONTROL100 SAFETY TEST EVERY THREE YEARS ..............................................................23
20 SERIAL NUMBER MANAGEMENT AND TRACEABILITY..................................................................24
21 DISPOSAL .............................................................................................................................................24
22 LIMITED MANUFACTURERS GUARANTEE.......................................................................................25
22.1 GUARANTEE DECLARATION ...................................................................................................................25
22.2 EXCLUSIONS FROM THE MANUFACTURER’S GUARANTEE..........................................................................25
22.3 GUARANTEE CLAIMS .............................................................................................................................26
22.4 GUARANTEE EXCLUSIVITY .....................................................................................................................26
22.5 LIMITATION OF LIABILITY........................................................................................................................27
22.6 APPLICABLE LAW AND COURT OF JURISDICTION ......................................................................................27
23 FURTHER USER INFORMATION.........................................................................................................28
23.1 FCC INTERFERENCE STATEMENT,PART 15.105(B) ...............................................................................28
23.2 FCC PART 15.21 WARNING..................................................................................................................28
23.3 FCC PART 15.19(A)STATEMENT..........................................................................................................28
23.4 FCC/ISED RF EXPOSURE GUIDANCE STATEMENT................................................................................28

LocControl100 Page 4 of 28 General operating instructions
10.0296.6600.01 Version N
0 Document information
0.1 Document objective
This document describes the general operation of the LocControl100 radio remote control for railways and
railway vehicles.
This manual does not cover customer-specific aspects, which are covered in separate documents.
0.2 Version control
V.
Status
Who
When
Changes to the previous version
A
Replaced
PEK
16.03.2008
Follows the Version
B
Replaced
GJO
01.07.2008
C
Replaced
GJO
16.07.2008
D
Replaced
GJO
28.07.2008
E
Replaced
RBU
03.11.2009
F
Replaced
RBU
14.12.2009
G
Replaced
RBU
18.01.2010
H
Replaced
RBU
27.01.2010
N
Active
MRA
25.11.2015
Chapter 6.3/6.4 added
Status: Draft Document in draft stage.
ReplacedThis document is no longer valid and has been replaced by one or more others.
Obsolete Document is no longer valid and has not been replaced.
Review Document is frozen in order to carry out a review.
Active Document has been released.

LocControl100 Page 5 of 28 General operating instructions
10.0296.6600.01 Version N
1 Introduction
1.1 General remarks
LocControl100 transmitter
German Railways (DB) execution
19-inch rack execution for German Railways
LocControl100 receiver
IP65 housing execution
Swiss Federal Railways SBB
The illustrations in the user handbook are sample
photographs.
Customer-specific executions may appear different.
The LocControl100 radio remote control for shunting
locomotives, railway vehicles and similar vehicles has
been developed according to both the latest technical
knowledge and the latest version of European standard
EN 50239.
During the construction and manufacture of this device,
attention was paid to the relevant regulations
concerning the safety of persons and things.

LocControl100 Page 6 of 28 General operating instructions
10.0296.6600.01 Version N
1.2 ISED RSP-100 Notice:
“This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.”
“Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
1) l’appareil ne doit pas produire de brouillage;
2) l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.”

LocControl100 Page 7 of 28 General operating instructions
10.0296.6600.01 Version N
2 Pictograms
In order to improve user understanding, these operating instructions use the following pictograms.
This explanatory note gives useful advice and tips for better operation, performance improvement and
reliability of the radio remote control.
This explanatory note draws attention to potentially dangerous situations and indicates that mishandling
could result in severe damage to the radio remote control, the locomotive or the general railway
infrastructure.
Whenever work is being carried out, attention must be paid to this safety warning, as well as to the
applicable safety regulations at the workplace.
This advice draws attention to dangers in the fields of electrical engineering and electronics.
Work on electrical and electronic assemblies and LocControl100 components should only be carried out
by a fully-qualified electrical engineer having a training certificate from the Schweizer Electronic Group.
It is imperative that this information be heeded before the radio remote control is used.

LocControl100 Page 8 of 28 General operating instructions
10.0296.6600.01 Version N
3 LocControl100 commissioning and maintenance concept
3.1 Introduction
Carrying out commissioning and maintenance work on LocControl100 devices are subject to CENELEC
regulations and may only be performed by organizations and/or persons who fulfil the provisions defined in
this document.
Commissioning and maintenance work is under the control of Schweizer Electronic AG.
The commissioning and maintenance concept determines how the commissioning and maintenance work on
LocControl100 devices and system components has to be carried out.
The commissioning and maintenance concept comprises following activities:
3.2 Commissioning engineers’ activities:
Typical commissioning engineers’ activities are:
▪Cleaning work and function controls of LocControl100 sealed transmitters and receivers
▪LocControl100 RS mounting and commissioning, including acceptance of locomotives
▪Reading LocControl100 RS operating data from USB interfaces
3.3 Maintenance engineers’ activities:
Typical maintenance engineers’ activities are:
▪Reading LocControl100 RS operating data from USB interfaces
▪Replacement of “non-serial-number-managed” parts on LocControl100 RS transmitters and
receivers
▪Carrying out LocControl100 RS function and final tests
▪Affixing device seals to LocControl100 RS transmitters and receivers
▪LocControl100 RS mounting and commissioning, including locomotive acceptance test
The LocControl100 commissioning and maintenance concept concerns all system components.
3.4 Operator
Operators are companies that operate radio remote controlled locomotives and carry out commissioning
work on radio remote control systems using their own personnel. Operators are responsible for the
qualitative formation of their personnel (commissioning and maintenance engineers I) and adhere to
Schweizer Electronic’s standards and directives.
.
3.5 Manufacturers
Manufacturers are companies that manufacture radio remote controlled locomotives and carry out the
installation of radio remote control systems and commissioning work using their own personnel.
Manufacturers are responsible for the qualitative formation of their personnel (commissioning and
maintenance engineers I) and adhere to Schweizer Electronic’s standards and directives.
Training of their project planners and assembly mechanics.
3.6 Personnel competence
Commissioning and maintenance work on LocControl100 system components should only be carried out by
qualified and trained personnel.

LocControl100 Page 9 of 28 General operating instructions
10.0296.6600.01 Version N
Only qualified persons who have successfully completed the appropriate Schweizer Electronic training
courses should maintain the LocControl100.
→See chapter 22.2 Exclusions from the manufacturer’s guarantee
Training offers are regularly published or, on customer request, individually arranged by Schweizer
Electronic. Schweizer Electronic monitors participants and issues a certificate to those who successfully
complete their formation.
3.7 Qualification overview
Function
Qualified for the
following activities
Responsible for
training
Support for
training
Schweizer Electronic
certificate description
Operative
May work with
LocControl100 RS
Operator
Schweizer
Electronic
Commissioning
engineer
May mount
LocControl100 RS
transmitters and
receivers on
locomotives, carry out
commissioning and
acceptance tests as well
as carry out activities
according to the
“Commissioning” training
stage
Schweizer
Electronic
Commissioning engineer
for the mounting and
commissioning of
LocControl100 RS
according to the
“commissioning” training
stage
Commissioning
engineer I
May carry out
commissioning and
maintenance activities on
LocControl100
transmitters and
receivers according to
the “Maintenance 1”
training stage
Schweizer
Electronic
Maintenance engineer I
for LocControl100 RS
maintenance according
to the “maintenance”
training stage
Commissioning
engineer II
May carry out
commissioning and
maintenance activities on
LocControl100 according
to the “Maintenance II”
training stage
Schweizer
Electronic
Schweizer Electronic
personnel
3.8 The service organization
As the manufacturer of the LocControl100, Schweizer Electronic possesses the necessary prerequisites for
supporting LocControl100 RS partners. A service organization is available for authorized partners and
supports these in both technical and logistics areas.
Please consult our homepage www.schweizer-electronic.ch for the current service organization.

LocControl100 Page 10 of 28 General operating instructions
10.0296.6600.01 Version N
4 Device description
4.1 Operating principle
Operating principle of the LocControl100 radio remote control
4.2 Transmitter
Operatives can give instructions by means of the transmitter’s command controls.
The command controls are:
▪“Manual stop” palm button
▪Switches
▪Buttons
▪Combined switch-buttons
▪Traction/Brake switch (joystick), uniaxial or biaxial
These commands are converted into radio telegrams in the transmitter (control unit).
These radio telegrams are then sent via a secure, monitored and encrypted radio link to a unique radio remote control
receiver dedicated to the transmitter.
4.3 Receiver
The receiver, mounted on a locomotive (or similar vehicle), converts the radio signals received into commands, which it
passes on to the technical unit (locomotive computer) in the form of electrical signals.
With the LocControl100, it is also possible to send return messages from the technical unit via the receiver to the
transmitter. This is called bidirectional radio traffic.
4.4 Receiver →technical unit interface
The interface between the LocControl100 radio remote control and the technical unit is the output of the LocControl100
receiver.
Up to this interface, Schweizer Electronic assumes technical safety responsibility for the product.
The “technical radio part” of the LocControl100 radio control ends at this interface.

LocControl100 Page 11 of 28 General operating instructions
10.0296.6600.01 Version N
5 System security
The transmitter and receiver electronics each consist of a bi-processor system.
Monitoring electronics compares all telegrams received for their validity and only executes the commands received if
there is compliance (valent –antivalent) of both computers’ evaluation.
All the requirements of EN 50239, in particular safety-relevant functions, have been fulfilled for all safety-relevant order
issuance possibilities.
The LocControl100 is suitable for uses of software security performance level 3 (EN 50128) and SIL3 (EN 50129).
5.1 Addressing
Every installation is assigned a unique built-in address. This address is allocated by Schweizer
Electronic once worldwide.
The addressing is memorized in the receiver and inscribed on the receiver’s front panel.
A transmitter can be dedicated to a receiver (of a locomotive), by equipping the transmitter with a closed
RFID slot.
Execution with closed RFID slot

LocControl100 Page 12 of 28 General operating instructions
10.0296.6600.01 Version N
RFID key with engraved radio identification number (addressing)
A transmitter with an open RFID slot can be variably dedicated to a receiver (a locomotive) by plugging
the transmitter’s corresponding RFID key, which belongs to the receiver of the locomotive to be
controlled, into the RFID slot. This therefore ensures that a particular locomotive can be controlled with a
transmitter of the same project.
Execution with open RFID slot
Addressing ensures the unique assignment of transmitter remote controls to receiver remote controls
when operating several radio remote controls at the same frequency.

LocControl100 Page 13 of 28 General operating instructions
10.0296.6600.01 Version N
5.2 Transmission security on the radio channel
In order to ensure validity and security with regard to telegram interference over the radio channel, the
following measures are met:
- Telegram security according to EN 60870-5-1
- Telegram transmission (incl. encryption) according to EN50159-2
- Monitoring of configured telegram length
- Telegram security by relative and absolute time monitoring
6 Standards, guidelines and company-internal regulations
6.1 Standards, guidelines and company-internal regulation hierarchy
The hierarchy of documents which describe and regulate the function and use of radio remote controls for the remote
control of railway vehicles is defined as follows:
Hierarchy
Documents
Highest level
EN 50239 standard and referenced standards
Subordinated level
Guidelines, such as
BGR 122 Operation of radio controls on railways
VDV-211 Conditions for the design of radio control installations on railways
Lowest level
In-house directives, such as operating manuals, working directives and other documents
6.2 Observed standards
→European standard EN 50239 concerning the security requirements of radio remote controls for locomotives,
including all referenced standards
→Telegram security according to EN 60870-5-1
→Telegram transmission according to EN50159-2
→Software security performance level 3 according to EN 50128 and SIL 3 according to EN 50129
→Radio standard EN 300-113

LocControl100 Page 14 of 28 General operating instructions
10.0296.6600.01 Version N
6.3 Radio module „MSY“ notifications
Overview-table for placing on the market of radio module from RF Data according to article 6(4) to the
directive 1999/5/EG.
Country
Organisation
Register-Number
issued
Austria
Office for broadcasting and
telecommunication-installations
BMFIT-640.825/0817-III/BFT/2009
10.12.2009
Germany
Bundesnetzagentur, Saarbrücken
7910801
06.01.2010
Switzerland
BAKOM
none
19.01.2010
Belgium
BIPT
none
24.02.2010
France
Agence Nationale des Fréquences
ANFR/DTCS/RTTE/17601-10/LL
29.01.2010
6.4 LocControl100 RS notifications
Overview-table for placing on the market of LocControl100 RS according to article 6(4) to the directive
1999/5/EG.
Country
Organisation
Register-Number
issued
Austria
Office for broadcasting and
telecommunication-installations
BMVIT-640.825/0817-III/BFT/2009
10.12.2009
Germany
Bundesnetzagentur, Saarbrücken
7910801
06.01.2010
Switzerland
BAKOM
Belgium
BIPT
7 Intended use of the radio remote control
Radio remote control is intended for use with rail-based vehicles in shunting operations and on railway
sections.
Any other use may only be made with the agreement of Schweizer Electronic.
Schweizer Electronic cannot be held responsible for damages caused by non-intended use.
The intended use also includes the observation of this “LocControl100 General Operating Instructions”
user manual as well as the provisions and directions contained therein.

LocControl100 Page 15 of 28 General operating instructions
10.0296.6600.01 Version N
8 Safety information
8.1 General safety information
LocControl100 is a technically sophisticated product. Nevertheless, danger can arise from the product if
it is operated or repaired by insufficiently trained persons, or if it is not used as intended. Schweizer
Electronic therefore strongly urges you to familiarize yourself with the operating manual as well as the
instructions provided with the product, and to adhere strictly with the provisions provided therein.
Before delivery, the radio control was tested on the test bench and packed in perfect condition. The test
data is preserved by Schweizer Electronic and Schweizer Electronic’s authorized service stations
throughout the whole of the device’s lifespan.
All the specified measures and indications relating to operating safety, points of general safety and
accident prevention which were implemented or observed before, during or after a start-up, must be
strictly complied with by the operator and his employees.
The manufacturer accepts no responsibility whatsoever for the safety, reliability or performance of the
radio remote control if repairs or other interventions to the radio remote control have been carried out by
non-authorized persons.
Within his organization, the operator must ensure that the equipment is safeguarded against
unauthorized handling or manipulation.
8.2 General operating safety guidelines
All legal and operating regulations must be observed before every start-up of the radio remote control.
Operatives must make sure of the proper and safe operating condition of LocControl100 before every
start-up. Before starting work or at the change of a shift, it is imperative to
- check the transmitter for any external damage
- check the battery/ies for any external damage
- check the condition of the carrying harness
Before starting work or at the change of a shift, it is imperative to carry out the prescribed safety test, in
particular to check the brake and emergency stop functions.
The operative must ensure that the RFID key in the transmitter belongs to the receiver of the locomotive
he intends to control.
The receiver identification number of the locomotive to be controlled must be the same as the number
engraved on the RFID key.
If this is not the case, or if there is the possibility of a mix-up, the operative must not activate the radio
remote control.
If any damage is observed, the transmitter should not be employed.
Before starting work or at the change of a shift, it is imperative to carry out the prescribed safety test, in
particular to check the brake and emergency stop functions.

LocControl100 Page 16 of 28 General operating instructions
10.0296.6600.01 Version N
The LocControl100 must be taken out of service immediately if any functional failings or irregularities are
observed.
It is imperative that irregularities are reported to the designated operational office immediately.
8.3 Safety information for operation
The safety information for operating is given in the “LocControl100 customer-specific operating
instructions”, since this can vary according to the system execution.
8.4 Comportment in emergency situations
In case of any malfunction during the course of operation or in all cases where movement of the
locomotive or vehicle results in a dangerous situation, the transmitter must be set to safe mode by
activating the “Manual stop” switch.
In addition, if the locomotive is at standstill after a manual stop, the transmitter must be switched off by
means of the key switch (if available) or by removing the battery.
The operator together with his operating personnel must thoroughly exercise reaction behaviour in
emergency situations.
Due to special local conditions or particular applications, situations may arise that were unknown at the
time of writing this operating manual. In such cases, special measures relating to safety may be
introduced by the operator.
9 Comportment in case of thunderstorms
The usual safety precautions with respect to comportment during thunderstorms must be respected
when such storms are approaching. The closeness of the storm should be estimated.
→ Do not stand out in the open
→ Do not stand under high masts or trees
→ Do not stand close to open water
No work should be carried out using the LocControl100 in the centre of storms where there is severe
danger of lightning.
This means
→ vehicle operation using the radio remote control should be discontinued
→ no mounting or repair work should be carried out on vehicles standing in the open.

LocControl100 Page 17 of 28 General operating instructions
10.0296.6600.01 Version N
10Transmitter
10.1 Technical Data - Transmitter
The general technical data and characteristics of the transmitter can be found in the attached LocControl100
data sheet. This data is subject to modification at any time.
Project-specific parameters and transmitter characteristics can be found in the project documentation.
10.2 Carrying harness for the Schweizer Electronic transmitter model
For carrying the transmitter around when working, a carrying harness made of lightweight, weather-
resistant plastic material with quick-release fasteners and easily adjustable straps is available in various
sizes.
The transmitter is hooked to the two quick-release fasteners.
Thanks to the carrying harness, dropping the remote operating device will be prevented, irrespective of
the kind of movement or tilting.
The harness construction is so designed that safe operation of the tilt switch is ensured.
Carrying harness for the Schweizer Electronic radio remote control transmitter

LocControl100 Page 18 of 28 General operating instructions
10.0296.6600.01 Version N
10.3 Use of operator’s own carrying harness
The use of an operator’s own carrying harness can be dangerous.
If an unsuitable carrying harness is used, the tilt monitoring function could possibly be impaired or even
no longer function at all.
If either the LocControl100 purchaser or operator intends to use a different carrying harness to the
standard one delivered by the Schweizer Electronic Group, the purchaser and/or operator is obliged,
without being asked, to have written approval for the carrying harness from the Schweizer Electronic
Group.
Schweizer Electronic will give approval for the proposed carrying harness in writing. Verbal approval will
not be valid.
If, according to the assessment of Schweizer Electronic, the carrying harness is not perfectly safe
technically or not fit for purpose, Schweizer Electronic cannot give its approval.
If the purchaser or the operator uses a carrying harness that has not been approved by the Schweizer
Electronic Group in writing, then all claims under the guarantee as well as claims for compensation
against the Schweizer Electronic Group lapse.
10.4 Transmitter operation with transmitter holder
If the transmitter should be operated with a transmitter holder, operation is described in the relevant
customer-specific operating manual.

LocControl100 Page 19 of 28 General operating instructions
10.0296.6600.01 Version N
11Lithium-ion batteries
11.1 Care when dealing with lithium-ion batteries (AkkuPacs)
ATTENTION: In order to avoid any danger of fire or explosion with lithium-ion batteries, please
observe the following warning:
Do not dismantle, make holes in, or short-circuit batteries.
Do not throw batteries into a fire or water. Do not expose batteries to temperatures above 60°C.
Batteries should only be charged using the charging device provided.
11.2 Battery expiry date
Lithium-ion batteries are subject to aging. An expiry date is shown on the battery. Batteries
should not be used after this expiry date even if they are judged to be still usable.
11.3 Disposal of batteries
Lithium-ion batteries should be appropriately disposed of according to applicable local
guidelines.
If the operator is not in a position to dispose of batteries in a proper manner, he must return
them to Schweizer Electronic at his own cost.

LocControl100 Page 20 of 28 General operating instructions
10.0296.6600.01 Version N
12Receiver
12.1 Technical Data - Receiver
The general technical data and characteristics of the receiver can be found in the attached LocControl100
data sheet.
This data is subject to modification at any time.
Project-specific parameters and receiver characteristics can be found in the project documentation.
13Receiver antenna
The following antenna types are available
for use with the receiver:
Article number
Frequency band
Antenna gain
VWE1766
410 –470 MHz
0 dB
VWE1620
410 –430 MHz
2 dB
VWE1768
450 –470 MHz
2 dB
For antennas up to 2dBi the minimum distance to a human body is 20cm.
For antennas up to 6dBi the minimum distance to a human body is 31cm.
ATTENTION: Antennas with more than 6dBi are not allowed to be used.
14Mounting the receiver, transmitter holder and antenna
The mounting of LocControl100 components, such as the transmitter holder, receiver, signal feeder to the
receiver, antenna and the antenna cable between the antenna and the receiver should only be carried out
by a qualified specialist who has completed training with Schweizer Electronic and is consequently in
possession of a certificate.
All the necessary documentation and instructions for installation will be given to participants in writing
during training.
