WiSilica lumos CONTROLS Catron V User manual

Wireless 5 Button Remote
Catron V
Catron V
www.lumoscontrols.com

Product Overview
Specifications
Features
Catron V is a battery-powered switch that controls ON/OFF,
intensity, and Correlated Color Temperature of an individual or
group of luminaires. This five-button switch device operates on
a 3V coin cell battery and is designed for maximum longevity.
It is part of Lumos Controls ecosystem, which includes
controllers, sensors, switches, modules, drivers, gateways, and
analytical dashboards. The device can be configured,
commissioned, and controlled from any mobile device
super-quick and can connect to the Lumos Controls cloud for
data analytics.
The ecosystem is DLC (Design Lights Consortium) qualified,
making it eligible for utility companies' energy conservation
incentive programs and rebates.
Controls ON/OFF, intensity, and CCT of an individual or
a group of luminaires.
BLE4.2 based non-flooding intelligent communication.
Easy installation with a wall bracket and a magnet
attached back of the remote.
Specifications Value
Input voltage 3VDC CR2032 coin cell battery
Electrical
Remarks
Specifications Remarks
Value
Frequency range 2402-2480 MHz
Max output power 7 dBm
Receive sensitivity -92dBm
Connection distance
(device to device)
Bluetooth
Vary depending
on the installation
environment
45m (147ft)
Specifications RemarksValue
Ambient temperature 0 to 50°C
(32 to 122°F)
Storage temperature
Environmental
Non-condensing
Relative humidity 95%
-10 to 60°C
(14 to 140°F )
Specifications Remarks
Value
Dimension
(105 X 40 X 12mm)
L X B X H
(Dimensions of only
remote)
Weight
4.1 X 1.6 X 0.47in
30g(1.05oz)
Mechanical
02

Device Dimension
Device Controls
Long press the ON and
OFF button
simultaneously for 10
seconds to activate
commissioning mode
A LED would lit up when
the device is under the
commissioning mode
ON and OFF buttons
can be used to perform
ON-OFF operations
Commissioning
ON
OFF
ON/OFF Operation
Case material: 5VA PC
Remote dimensions Wall bracket dimensions
03
1.25in(32mm)
2.59in
(66mm)
0.35in(9mm)
4.13in(105mm)
1.57in(40mm) 0.47in(12mm)
0.15in(4mm)
Catron V

04
Smart Ecosystem
Gateway
Internet
Connectivity
45m is the device to device communication distance ideally with clear LoS
Mesh
Network
Radiar AF10
Control
Device
Sensor
Switch
Catron V
45m is the device to device communication distance ideally with clear LoS
Catron V
Intensity(dimming) of
the luminaires can be
controlled using these
intensity up and down
buttons
A single click on the Up
and Down buttons will
increase or decrease
the intensity by 10%
CCT operation can be performed
by clicking the CCT mode button
The device will persist in CCT
mode only for 10 seconds after
the click
While in the CCT mode the CCT
up and down buttons can be
used to increase or decrease
the CCT by 10%
Intensity
Down
Intensity
Up
CCT Down
CCT Mode
CCT Up
Intensity Operation CCT Operation

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by
WiSilica Inc. is under license. Other trademarks and trade names are those of their respective owners.
All Rights Reserved WiSilica Inc
www.lumoscontrols.com
23282 Mill creek Dr #340
Laguna Hills, CA 92653 USA
[phone]
Ver 1.0 Apr 2022
05
Ordering Information
Product Name Product Description Communication Voltage Rating Functionality
WSC5B BLE4.2
Catron V Wireless
Battery-powered
5 Button Remote
CR-2032 3V
coin cell battery
Product Code
ON/OFF, Dimming,
Tuning
Certifications Details
CE Article 3, RED 2014/53/EU
EMC test standards
ETSI EN 301 489-1 V2.2.3(2019-11)
ETSI EN 301 489-17 V3.2.4(2020-09)
EN 55032: 2015/A11:2020
EN 55035: 2017+A11 :2020
RoHS2.0 RoHS Directive (EU) 2015/863 amending Annex II to Directive 2011/65/EU
FCC ID: 2AKG3-875050
Radio test standard
ETSI EN 300 328 V2.2.2 (2019-07)
Health test standard:
EN 50663: 2017
Safety test standard
IEC 62368-1:2014+A11: 2017
Items included in the package box
Catron V Wall bracket ScrewsUser guide
Bluetooth Declaration ID: D039950
