SciCan SANAO 200 L User manual

SANAO
Handpiece
Instructions for use
EN
DE
FR
CS / IT / NL / …
via: www.scican.uk.com/downloads
200 L
40 / 40 L
10 / 10 L
PSO
PSI
40 ST
Rx only
www.scican.com www.micro-mega.com
SANAO
Copyright 2016 SycoTec. All rights reserved.
Doc. No. 2.002.1189 - Rev. 2016-04
=== Ende der Liste für Te xtmarke Titel ===

Page 2 SANAO EN
Pos: 4 /9 26-SycoTec /zz_La youtmod ule/Titelrü ckseite SciC an H andstück @ 9\ mo d_136249 0317268_ 6.doc @ 7 1424 @ @ 1
Exclusively distributed by:
SANAO and STATMATIC are trademarks of SciCan Ltd.
All other trademarks referred to in this handbook are the
property of their respective owner.
SciCan GmbH
Wangener Strasse 78
88299 Leutkirch, GERMANY
Telephone: [phone]
Fax: [phone]
SciCan Ltd.
1440 Don Mills Road
Toronto, ON M3B 3P9, CANADA
Telephone: [phone]
Fax: [phone]
Free of charge: [phone]
E-mail: [email protected]
SciCan Medtech AG
Alpenstrasse 16
6300 Zug, SWITZERLAND
Telephone: [phone]
Fax: [phone]
SciCan Inc.
701 Technology Drive
Canonsburg, PA 15317, USA
Telephone: [phone]
Fax: [phone]
MICRO-MEGA®SA
5-12 rue du Tunnel - BP 1353
25006 BESANCON Cedex
FRANCE
TEL: [phone]
FAX: [phone]
[email protected]
Produced by:
SycoTec GmbH & Co. KG
Wangener Strasse 78
88299 Leutkirch
GERMANY
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
0124

Table of Contents
Page 3 SANAO EN
Pos: 6 /926-Syco Tec/zz_La youtmodule/In haltsverzeich nis @ 8 \mod_134096 2731143_6.d oc@ 60687 @ @ 1
1Important Information.......................................................................................................................................................................................5
Symbols used..................................................................................................................................................................................................5
Safety measures..............................................................................................................................................................................................7
General warnings ............................................................................................................................................................................................ 8
Warnings for reprocessing (cleaning –disinfection –care –sterilization) .....................................................................................................10
Intended use –purpose.................................................................................................................................................................................11
Target group .................................................................................................................................................................................................. 12
2Technical data ...............................................................................................................................................................................................13
3Reprocessing methods.................................................................................................................................................................................. 18
Preparation at the location of use .................................................................................................................................................................. 18
Cleaning ........................................................................................................................................................................................................18
Sterilization in accordance with ISO 17665 ...................................................................................................................................................20
Storage.......................................................................................................................................................................................................... 23
4Installation and Commissioning.....................................................................................................................................................................24
Cooling media supply ....................................................................................................................................................................................24
5Operation....................................................................................................................................................................................................... 25
Connecting the handpiece............................................................................................................................................................................. 26
Removing handpiece..................................................................................................................................................................................... 27
Inserting cutters or diamond grinders ............................................................................................................................................................ 28
Removing cutters or diamond grinders..........................................................................................................................................................30

Table of Contents
Page 4 SANAO EN
Inserting rubber cups or polishing brushes (PSI / PSO) ................................................................................................................................31
Removing the rubber cups or polishing brushes (PSI / PSO) ........................................................................................................................ 32
6Maintenance and repair.................................................................................................................................................................................33
Care products and maintenance systems......................................................................................................................................................33
Care with maintenance systems: STATMATIC / STATMATIC PLUS............................................................................................................34
Care with dental care spray........................................................................................................................................................................... 35
7Guarantee...................................................................................................................................................................................................... 36
=== Ende der Liste für Te xtmarke Verzeichnis ===
Pos: 8 /9 26-SycoTec /1_Wich tige Hi n weise/2 _Sehr geehrt er A nwender (Handst ückeu ndT urbine) @ 8\mod_13408084 70182_6.doc @ 60191 @ 1 @ 1
Im

1Important Information
Page 5 SANAO EN
1Important Information
Dear user,
we hope that you enjoy using your new quality product. In order to ensure that you use the product correctly, efficiently and safely, please
adhere to the following information.
Pos: 9/ 926-SycoTec/1 _Wichtige Hin weise/2_Verwendete S ymbole( Handstücke u ndT urbine) @ 8\mo d_134080934752 9_6.doc @ 60210 @ 2 @ 1
Symbols used
In the manual/on the product
On the packaging
Situation which can result in injury or danger to persons, when the
instructions are not followed.
Handle with care
Important information for users and technicians
Keep dry
Instructions for disposal
Maximum stacking load
Steam-sterilizable up to 135 °C (275 °F)
Temperature range
CE marking
Humidity

1Important Information
Page 6 SANAO EN
In the manual/on the product
On the packaging
Thermodisinfectable
Atmospheric pressure
Manufacturer
Quantity
Observe instructions for use
Follow instructions for use!
Pos: 10 /926-SycoTec/ 1_Wichtige Hinweis e/3_Wichtige Hin weise (Handstüc keun dT urbine) @ 8\mod_ 1340810704372 _6.doc @ 60229 @ @ 1
Product subject to technical modifications and design deviations.
No retrofit warranty on existing devices.
The manufacturer does not accept any responsibility for damages caused by:
•external effects (poor quality of media, impact damage, cleaning and care with unsuitable products or faulty installation)
•use of wrong information
•unintended use
•improper repairs

1Important Information
Page 7 SANAO EN
Repair and maintenance, except for the activities described in these instructions for use, must only be performed by qualified professionals.
•Changes made by third parties render the approval null and void.
•Use original parts and spare parts only.
The guarantee becomes ineffective if defects or their consequences are caused by manipulation or modification of the product by the
customer or third parties not authorized by us.
Disposal of devices and accessories after use:
Based on EC directive (WEEE 2012/19/EU) on waste electrical and electronic equipment, we hereby inform you that this product is
subject to the aforementioned directive and must be disposed of through special channels. Contact the manufacturer or dental supply
shop for further information.
Pos: 11 / 926-SycoT ec/1_Wichtig e Hin weise/ 4.1_Sicherheits maßnah men ( Handstüc ke) @ 8\mod_134 1407599776 _6.doc @ 61129 @ 2 @ 1
Safety measures
WARNING! Risks when using handpieces with electrical micro-motors!
Electrical micro-motors generate significantly more energy than conventional air turbines and air motors. Due to the high torques and
speeds, poorly serviced, damaged or misused handpieces may lead to overheating which could inflict severe burns on the patient.
Please observe the following.

1Important Information
Page 8 SANAO EN
Carefully follow the maintenance instructions.
Inspect the handpiece for external damage before each use.
Run a test with the handpiece before each use. Especially pay attention to unusual overheating, conspicuous noises and vibrations.
If a handpiece is found to be faulty, its use must be discontinued immediately.
Never lift cheeks or tongues with the handpiece.
The following people are authorized to perform repair and maintenance works on our products:
Our technicians
Technicians who have been specially trained by us
Pos: 12 / 926-SycoT ec/1_Wic htige Hinw eise/ 4.2_Allge meine War nhinweise (H ands tücke - Variable) @ 8\mod_13419 04697811 _6.doc @ 622 21 @ 2 @ 1
General warnings
Ensure that all of the rotation instruments used are in a perfectly-functioning condition.
Ensure that the handpiece is securely engaged with the motor coupling and that the rotation instrument is fastened correctly before starting
the handpiece.
Use a motor that is in a perfectly-functioning condition.
Avoid using a handpiece that is unusually warm.

1Important Information
Page 9 SANAO EN
It is recommended that appropriate protective gloves and goggles be worn when working with the handpiece and the rotation instruments.
Use a rubber dam during patient procedures.
During a long treatment period, clean and check the instrument every ten minutes.
The handpiece may only be disassembled by an approved retailer or the manufacturer.
Do not press the push-button of the handpiece during operation.
Adjust the rotational speed of the motor to the handpiece used.
Do not use rotation instruments (cutter, grinder) which are blunt, bent or damaged.
Use SANAO 200 L handpieces exclusively with spray cooling.
Should a problem arise with the handpiece, consult our customer service department.
Discontinue using the handpiece in the event of damage, overheating, unusual operating noises, excessive vibrations, an excessive lateral
run-out of the instrument or an inadequate fixation of the instrument. In order to prevent further damage, consult our customer service
department or your local retailer of this product.

1Important Information
Page 10 SANAO EN
Warnings for reprocessing (cleaning –disinfection –care –sterilization)
Clean and sterilize the handpiece prior to the first use and after each patient operation and prior to disposal.
Remove the rotation instruments (drills, files, burs) before reprocessing.
Only use disinfecting cleaning products that are designed for disinfecting dental handpieces and contra-angles. Do not use setting cleaning
agents.
Adhere to the concentrations and immersion periods recommended by the manufacturer of the pre-disinfection product.
Do not use vinegar to clean the spray heads.
Open the sterilization pouches directly before use.
Excessive use of the cleaning products (dental care spray, cleaning and disinfection products) may possibly lead to the permeation of
these products into the motor and may impair its functionality. The instructions for care for the respective product must be observed.
If the handpiece will not be used for a long period of time, clean it as per the instructions after its last use and store it in a dry location.
Observe the national guidelines and provisions for the processing of medical products.
