Scilox BL100 User manual

BL100 User Manual
BL100 Fingerprint Lock User Manual
Version: 1.0
About This Manual
This user manual explains how to operate the BL100 fingerprint deadbolt
and how to navigate through its programming menu options. For the
fingerprint deadbolt installation, see the installation manual.

BL100 User Manual

BL100 User Manual
Thank you for purchasing the Scilox BL-100 fingerprint deadbolt.
Please read the documentation carefully before operating the deadbolt.
This manual describes all possible operations of the fingerprint deadbolt.
Note: The manufacturer, dealers and distributors of the Scilox BL100 will
not be held responsible for any damages caused by incorrect installation or
mishandling of the fingerprint deadbolt. Any such damages will void the
manufacturer’s warranty.
Due to manufacturer’s product updates during the life of the deadbolt, the
manufacturer cannot guarantee 100% consistency of the actual deadbolt as
described by this manual. If the reader discovers inconsistencies in this manual,
please bring them to the attention of the manufacturer so the corrections can be
published in subsequent revisions of the manual. Thank you.

BL100 User Manual
i
IMPORTANT NOTICE
–To ensure optimum performance of the fingerprint deadbolt, please
read the tips below before programming and installing.
1. Keep your fingers clean when operating the deadbolt, so that your fingerprints
can be recognized by the deadbolt’s fingerprint sensor.
2. When you first purchase and operate your new deadbolt, its factory default
setting allows you to unlock the deadbolt with ANY finger.
3. To ensure security, the manufacturer strongly suggests you immediately change
the default master passcode (98989) after initial installation
4. Prior to enrolling ordinary (non-Administrator) users, you must first enroll at least
one “Administrator User”. Administrator Users have the unique ability to
program the deadbolt and add/delete users. Conversely, “Ordinary Users”can
only open the door and have no access to the deadbolt’s programming menu.
5. Each user can register one fingerprint and one PIN (Personal Identification
Number).
6. When opening the door, if you hear the deadbolt alarm beep and see the
indicator light flashing, this indicates the deadbolt’s AA batteries soon need to be
changed with fresh AA batteries.
7. The deadbolt automatically shuts off after 10 seconds of inactivity. This setting
helps conserve battery life.
8. You can register up to 100 users on the deadbolt. 5 can be Administrator Users
(Code: 995-999), and the other 95 will be Ordinary Users (Code: 000-994).
9. To ensure accuracy of the deadbolt’s fingerprint sensor, be sure to keep the
sensor clean.
10. When cleaning the entire deadbolt, exercise caution by not using corrosive
cleaning agents which could damage the deadbolt’s glossy finish. Instead, the
manufacturer recommends periodically cleaning the deadbolt with furniture
polish wax (e.g. Pledge).

BL100 User Manual
ii
11. If after installation you discover the deadbolt’s latch-bolt fails to freely move back
and forth or that the door no longer closes properly, this can normally be
corrected by properly re-aligning the strike plate's position on the door.
12. If at times you discover registered fingerprints or passwords fails to unlock the
deadbolt, use the mechanical key to unlock the deadbolt.
13. While programming the deadbolt, you can cancel out of any operation by
pressing and holding “0” at any time. When cancelling, NO changes will be saved.
Notice:
Remember to record user names along with user ID and codes on the provided
page in the back of this user manual.

BL100 User Manual
iii
Table of Contents
1 Operating Instructions ......................................................................- 1 -
1.1 Introduction to Fingerprint Deadbolt Functions....................- 1 -
1.2 Front and Rear Views.............................................................- 2 -
1.3 Precautions ............................................................................- 4 -
1.4 User Privileges........................................................................- 4 -
1.5 Finger Placement...................................................................- 5 -
2. Basic Operation................................................................................- 6 -
2.1 Change Master Pass Code (MPC)...........................................- 6 -
2.2 Enroll an Administrator User..................................................- 7 -
2.2.1 Enroll Administrator User’s Fingerprint ......................- 7 -
2.2.2 Enroll Administrator User’s PIN Code .........................- 8 -
2.3 Enroll an Ordinary User..........................................................- 8 -
2.3.1 Enroll an Ordinary User’s Fingerprint .........................- 9 -
2.3.2 Enroll an Ordinary User’s PIN Code.......................... - 10 -
2.4 User Verification.................................................................. - 11 -
2.4.1 Fingerprint Verification............................................ - 11 -
2.4.2 PIN Code Verification............................................... - 11 -
2.5 Delete a User....................................................................... - 12 -
2.5.1 Delete a User............................................................ - 12 -
2.5.2 Delete All Ordinary Users......................................... - 12 -
2.6 Enable / Disable a User....................................................... - 13 -
2.7 Reset Deadbolt to Factory Default Settings ........................ - 14 -
3 Other Functions ............................................................................. - 15 -
3.1 Routine Operation Indications............................................ - 15 -
3.2 Deadbolt Initialization......................................................... - 16 -
3.3 Unlock the Non-lock Status Alarm.......................................- 17 -
3.4 Automatic Menu Program Exit and System Power-off ........- 17 -

BL100 User Manual
iv
3.5 Using External Power...........................................................- 17 -
3.6 Unlocking Deadbolt with Mechanical Key .......................... - 19 -
3.7 Battery “Low Voltage”Warning...........................................- 20 -
4. Appendix....................................................................................... - 21 -
4.1 Technical Specifications ...................................................... - 21 -
Warranty........................................................................................... - 22 -
Support ............................................................................................. - 23 -
User Codes........................................................................................ - 24 -

BL100 User Manual
1
1 Operating Instructions
1.1 Introduction to Fingerprint Deadbolt Functions
1. By leveraging the perfect combination of biometrics and cryptography,
the Scilox BL100 fingerprint dead-bolt ensures door-security through its
fingerprint and PIN unlocking feature.
2. The deadbolt is very intuitive and user friendly. Indicator sounds and
lights help guide the user.
3. Enroll both “ordinary” users and “Administrator” users. Ordinary Users
only have door access, while Administrator Users can program the
deadbolt and add/delete users.
4. Administrator Users can quickly and easily delete users whose door access
rights have been revoked.
5. Deadbolt can recognize users by either Fingerprint or PIN code
verification.
6. Upon total AA battery failure, the deadbolt can still operate temporarily
by connecting a 9V battery to the deadbolt’s 9V battery external
connector.
7. Non-lock Alarm: When the deadbolt’s latch-bolt fails to pop out and
secure the door, the deadbolt’s deadbolt will make a short, sharp
alarming sound which will last one minute unless the alarm is
de-activated manually by locking or unlocking the deadbolt.

BL100 User Manual
2
1.2 Front and Rear Views
①Fingerprint sensor: You can only register or match fingerprints by placing your
finger on the fingerprint sensor when the green light in the fingerprint sensor
window is turned on; otherwise nothing will happen when you place your finger on
the fingerprint sensor.
②Lock/Unlock Button: Besides locking and unlocking the deadbolt, this button
can be used to open the deadbolt’s program menu. Press and hold this button for 3
seconds until it beeps to enter the program menu.
1. Fingerprint Sensor
6. Battery cover
2. Lock/Unlock button
3. Numerical Keypad
4. Key Hole/cover
5. Emergency 9V external
battery connector
7. Mounting Screw Holes
8. Lock lever

BL100 User Manual
3
③Numerical Keypad: Used to enter a user’s PIN code or user ID.
④Key Hole/cover: You can use the included mechanical key for emergency door
opening. The key hole also has a detachable cover, to help hide the keyhole from
unauthorized users.
⑤9V External battery connector: External battery connector to be used with a
9-volt battery when internal batteries do not operate.
LED Indicators:
The deadbolt’s lock/unlock button and keypad change color to further help the user
operate the deadbolt.
The general rule:
Successful = 1 Long Beep, flashes green
Failed = 2 Short Beeps, flashes red
Verify State: Fingerprint sensor flashes green every second
Management Mode: Keypad LED flashes blue every second
All deadbolt LED indicators should respond as above. If not, please contact
your local dealer/distributor or visit our website at www.scilox.com.

BL100 User Manual
4
1.3 Precautions
1. User must change Master Pass Code (MPC) upon initial installation of the
deadbolt (See Change MPC section on pg 6). User must have at least one
“Administrator User”enrolled before adding any “Ordinary Users”. If you don't
change the MPC, you can't use any deadbolt functions. And if you don't enroll an
“Administrator User”you can't add any “Ordinary Users”.
2. Do not remove batteries when matching, registering/adding or deleting
fingerprints or PIN codes; the sudden power-loss may result in loss of data. Prior to
removing the batteries, make sure the deadbolt is not in the middle of a program
operation (i.e. registering a user, deleting fingerprints, etc.).
3. It is recommended to replace the deadbolt AA batteries at least once every six
months. Further delay risks damage to the deadbolt due to battery leakage or
corrosion. Do not use poor-quality batteries.
1.4 User Privileges
The user privileges are classified into two types: Administrator Users and Ordinary
Users.
Administrator User: Refers to users who have access to all operations like program
settings and registering users.
Ordinary User: Refers to all users other than the Administrator Users. Ordinary
Users only have door access privileges.

BL100 User Manual
- 5 -
1.5 Finger Placement
Recommended finger selection: The index finger, middle finger or the ring finger is
recommended; the thumb and little finger are not recommended (because they are
usually clumsy when pressing on the fingerprint sensor).
1. Proper finger placement
2. Improper finger placement
Off-center
Not flat on the surface
Off-center
The finger must be placed flat and
centered on the fingerprint sensor.
Please be sure to use proper finger placement when registering and verifying your
users’ fingerprints. Improper finger placement on the sensor is the primary cause
for perceived problems with the deadbolt. The fingerprint sensor is extremely
accurate. Proper finger placement will ensure users have a very favorable and
positive experience with the deadbolt.
Sideways

BL100 User Manual
- 6 -
(1) User must change master pass code when they first install the deadbolt, otherwise
you can't register Administrator Users.
(2) User must have registered at least one Administrator User before enrolling any
Ordinary Users.
(3) All deadbolt operations must be completed within 10 seconds or deadbolt will
time-out.
2. Basic Operation
2.1 Change Master Pass Code (MPC)
Notice:
To change MPC, follow the procedures shown:
1. Press button to start lock, which will then enter the “Verify State”. The
LED flashes green.
2. Press and hold the button until you hear 1 long beep and the keypad’s
green LED changes to blue. Enter the default MPC "98989", and then press
- button to enter the “Management Mode”.
3. Press "5" key on the deadbolt and enter the new 5 digit MPC, then press the -
button to confirm. Enter the new MPC once again, then press the .
button to confirm. Once you hear 1 long beep and the LED flashes
green, you have successfully changed the MPC code.

BL100 User Manual
- 7 -
2.2 Enroll an Administrator User
The deadbolt has two kinds of users: “Administrator User”and “Ordinary User”. If
the deadbolt has no Administrator User, then you can’t enroll Ordinary Users. You
must at least enroll one Administrator User before enrolling any Ordinary Users. To
enroll an Administrator User, enter Management Mode by following below:
1. Press button to start deadbolt, and then enter the “Verify State”.
2. Press and hold the button until you hear 1 long beep, enter the 5 digit
MPC, and then press button to enter the “Management Mode”.
3. Press "9" on the deadbolt to enter the “Enroll Administrator User”mode.
The next step is to register fingerprint(s) and PIN code for administrator.
2.2.1 Enroll an Administrator User’s Fingerprint
Note: Steps 1-3 are above.
4. After you enter the “Enroll Administrator User”mode, enter a 3 digit user
ID, and then press button to confirm.
Note: The Administrator User's ID must be between "995" and "999".
5. Press finger on the fingerprint sensor properly (For details, see 1.5 Finger
Placement), and remove once you hear a beep, repeat 2 additional times
(total 3 three times), until you hear one long beep and LED turns green.
Note: During the fingerprint registration process, if the fingerprint sensor
successfully registers the fingerprints, the button will turn green. If not, try
repeating the registration process with a different finger.

BL100 User Manual
- 8 -
2.2.2 Enroll an Administrator User PIN code
Note: Steps 1-3 are same as before (2.2)
4. After you enter the “Enroll Administrator User”mode, enter the 3 digit
user ID, press button to confirm.
5. Enter a 4 digit user PIN code and press button to confirm, and
then enter the same 4 digit user PIN code once again and press .
button to confirm, you will hear one long beep and LED turns green (if it
fails to register –it will give 2 short beeps and LED will flash red instead).
Note:
(1) If the deadbolt fails to register a finger, it will give 2 short beeps and the .
will flash red. If you are unable to register, you can try again for two more times.
(2) If the deadbolt registers a finger successfully, the deadbolt will automatically
exit the “Enroll Administrator User”mode.
(3) You can press and hold "0" key to cancel operation and exit at any time.
(4) If you want to enroll more Administrator Users, then repeat steps 1-5.
Note:
(1) If PIN code does not match, the deadbolt will fail registration. In this case, you
will need to follow step 1 to 5 again.
(2) If successful, the deadbolt will automatically exit the “Enroll Administrator
User”mode.
(3) You can press and hold "0" key to cancel operation and exit anytime.
(4) If you want to enroll more Administrator Users, then repeat the step 1-5.

BL100 User Manual
- 9 -
2.3 Enroll an Ordinary User
Note: You must change the MPC and enroll an Administrator User first;
otherwise you can't enroll any Ordinary Users.
2.3.1 Enroll an Ordinary User’s Fingerprint
1. Press button to start the deadbolt and enter the “Verify State”.
2. There are two methods to enter the “Management Mode”:
(1) Press and hold the button until you hear 1 long beep, enter the
5-digit MPC, and then press button to enter the “Management
Mode”.
OR
(2) Verify the registered Administrator's PIN code or fingerprint (please see2.4
User Verification) to enter the “Management Mode”.
3. Press "1" to enter the Enroll Ordinary User's Fingerprint Mode.
4. Enter a 3 digit User ID, then press button to confirm.
Note: The Ordinary Users' ID must be between "001" and "994".
5. Place finger on the fingerprint sensor properly (For details, see 1.5 Finger
Placement), and repeat it three times, until you hear one long beep and LED flashes
green.
Note:
(1) If deadbolt fails to register, the deadbolt will give 2 short beeps and the LED
will flash red. If the deadbolt failed to register, you can try again for two more
times.
(2) If the deadbolt registers successfully, it will automatically exit the Enroll
Administrator User mode.
(3) You can press and hold "0" key to cancel operation and exit anytime.
(4) If you want to enroll more Administrator Users, then repeat steps 1-5.

BL100 User Manual
- 10 -
2.3.2 Enroll an Ordinary User’s PIN Code
1. Press button to start the deadbolt and enter the “Verify State”.
2. Enter the “Management Mode”, (see step 2 in 2.3.1 Enroll an Ordinary User’s
Fingerprint).
3. Press "2" on the deadbolt to enter the “Enroll Ordinary User's PIN Code”mode.
4. Enter a 3 digit User ID, and press button to confirm.
Note: The Ordinary Users' ID must between "001" and "994".
5. Enter a 4 digit user PIN, press key to confirm. Enter the same 4 digit user
PIN once again and press key to confirm until you hear one long beep and
the LED flashes green. The keypad’s blue LED will turn off. If it fails to register - it
will give 2 short beeps and the LED will flash red.
Note:
(1) If PIN code does not match, the deadbolt will fail registration. In this case, you
will need to follow step 1 to 5 again.
(2) If successful, the deadbolt will automatically exit the “Enroll Administrator User
Mode”.
(3) You can press and hold "0" key to cancel operation and exit anytime.
(4) If you want to enroll more Ordinary Users, then repeat the step 1-5.

BL100 User Manual
- 11 -
2.4 User Verification
The users can use fingerprint or PIN code verification to unlock the deadbolt.
2.4.1 Fingerprint Verification
1. Press button to start the deadbolt and enter the “Verify State”. The
fingerprint sensor is in a “Ready State”.
2. Press finger on the fingerprint sensor properly (For detail, please see 1.5 Finger
Placement), until you hear one long beep.
(1) If verification is successful, the deadbolt will sound a long beep and
deadbolt will unlock, the button will flash green for 3 seconds,
the fingerprint sensor will flash green for 5 seconds.
(2) If verification failed, the deadbolt will sound two short beeps, the .
button will flash red for 3 seconds, and then the green LED will flash. The
user can use their fingerprint to verify again until verification is successful.
2.4.2 PIN Code Verification
1. Press button to start the deadbolt and enter the “Verify State”.
2. Enter the programmed 4-digit PIN code and press button to confirm.
(1) If verification is successful, the deadbolt will sound a long beep and unlock,
the button will flash green for 3 seconds, the fingerprint sensor
will flash green for 5 seconds.
(2) If verification failed, the deadbolt will sound two short beeps, the .
button will flash red for 3 seconds, and then the LED will flash green.
The user can use PIN code to verify again until verification is successful.
Note: After successful verification, the deadbolt is unlocked. Press -
button again to lock and power off the deadbolt.

BL100 User Manual
- 12 -
2.5 Delete User
2.5.1 Delete a user
1. Press button to start the deadbolt and enter the “Verify State”.
2. Enter the “Management Mode”, please see step 2 in 2.3.1 Enroll an Ordinary
User’s Fingerprint.
3. Press "3" on the deadbolt to enter “Delete User mode”.
4. Enter the User's ID which you want to delete, and then press button to
confirm. Enter the user ID again, and press key to confirm. The deadbolt
will sound a long beep, and the key will flash green.
5. After deleting the user, you can restart the deadbolt and verify the deleted user's
fingerprint or password again to assure the user has been deleted.
Note: The Administrator can't delete their self or the most recent
administrator.
2.5.2 Delete All Ordinary Users
1. Press button to start the deadbolt and enter the “Verify State”.
2. Enter the “Management Mode”, (see step 2 in 2.3.1 Enroll an Ordinary User’s
Fingerprint).
3. Press "6" on the deadbolt to enter “Delete All Ordinary Users”mode.
4. Enter "000" and press button to confirm, then enter "000" again and
press button to confirm. The deadbolt will sound a long beep, the -
button will flash green.
Note: The operation can only delete Ordinary Users. If you want to delete
administrators, you must reset the system, for detail, (see 2.7 Reset Deadbolt to
Factory Default Settings).

BL100 User Manual
- 13 -
2.6 Enable / Disable a User
1. Press button to start the deadbolt and enter the “Verify State”.
2. Enter the “Management Mode”, (see step 2 in 2.3.1 Enroll an Ordinary User’s
Fingerprint).
3. Press "4" on the deadbolt to enter “Enable/Disable User Mode”.
4. Enter the user ID which you want to enable or disable, press button to
confirm, enter the user ID again and press button to confirm. The deadbolt
will sound a long beep and the button will flash green.
Note:
(1) You can only enable or disable Ordinary Users.
(2) The disabled user can no longer unlock the deadbolt.
