Speakman CPT-1000-TP User manual

INSTRUCTIONS FOR MODELS
92-CPT-1000-TP-02
For additional assistance or service please contact:
SPEAKMAN®Company
400 Anchor Mill Road
New Castle, DE 19720
800-537-2107
[email protected]
www.speakman.com
CPT-1000-TP
CPT-1300-TP
TOOLS AND SUPPLIES
Measuring
Tape
Phillips
Screwdriver
IMPORTANT
• Circular Trim Package shown for reference. While
the appearance of your trim may be different, the
installation steps are the same.
• This Trim Package is intended to mount to the
following Speakman valves. Please verify the model
of your valve prior to installation.
SPEAKMAN® SentinelPro®
CPV-5000 Thermostatic / Balance Pressure Valve
*NOT FOR USE WITH DIVERTER/VOLUME CONTROL MODELS
SPEAKMAN® SentinelPro®
CPV-TP Thermostatic / Balance Pressure Valve
*NOT FOR USE WITH DIVERTER/VOLUME CONTROL MODELS
Additional warranty information can be found at: www.speakman.com
Your new Speakman Product is designed for years of trouble-free performance. Keep it looking new by cleaning it
periodically with a soft cloth. The use of harsh chemicals and abrasives on any of the Speakman custom finish products
may damage the finish and void the product warranty. Please be sure to only use approved cleaners. Please contact
Speakman for any clarification of acceptable cleaners.
WARRANTY
MAINTENANCE
Cover your drain to prevent loss of parts. Be sure to wear eye protection while cutting pipe.
SAFETY TIPS
IMPORTANT
• Be sure to read instructions thoroughly before beginning installation.
• Do not over-tighten any connections or damage may occur.
If installing to a Speakman
CPV-5000 valve:
6
1
STEPS
If installing to a Speakman
CPV-TP valve:
11
7
STEPS
CPV-TP INSTALLATION HARDWARE BAG
1 CPV-5000 INSTALLATION
Clean front surface of wall. Install Valve Mounting Plate ❶to Speakman Valve, using the 8-32 x 1-1/8”
screws ❷provided. Take care to not over tighten mounting screws.
NOTE: The Valve Mounting Plate Assembly (1) should sit flush against the Speakman Valve when
installed correctly.
2 CPV-5000 INSTALLATION
NOTE: The back surface of the Valve Mounting Plate Assembly (1) should sit flush against the wall when
installed correctly.
Secure the Wall Mounting Plate ❶to the Valve Mounting Plate ❷using the 8-32 X 2½” Screws ❸
provided.
The Universal Valve Trim kit includes two Spindle Adapters that allow for both shallow and deep valve
mount installations. Measure the distance between the front lip of the Wall Mounting Plate and the end of
the Valve Spindle as shown below to determine correct selection of Spindle Adapter.
• If the measurement falls between 1-7/8” to 2-1/2”, the Spline Adapter marked “A” is needed
for installation.
• If the measurement falls between 1-3/8” to 1-7/8”, the Spline Adapter marked “B” is needed
for installation.
MEASURE
A
B
3 CPV-5000 INSTALLATION
VERTICAL
LINE
Confirm that the Valve is in the off position. Insert Spline Adapter ❶(Spline Adapter selection
determined in STEP 3) over Valve Spindle ❷. One set of splines on the adapter must be oriented
perfectly vertical when installed, as shown below. Secure the Spline Adapter with the 8-32 X 3/8” Screw
❸provided.
4 CPV-5000 INSTALLATION

RED
BLUE
Orient the Decorative Wall Plate ❶as shown below and insert the RED index button into the top hole of
the Wall Plate, and the BLUE index button into the lower hole. Slide Wall Plate Assembly over Wall
Mounting Plate ❷.
5 CPV-5000 INSTALLATION
Orient the Handle Assembly in a vertical position as shown below. Guide Handle Assembly onto the
Spline Adapter ❸. While holding the Handle ❶stationary in the vertical position, thread the Handle
Escutcheon ❷onto the Wall Mounting Plate ❹. Hand tighten until snug.
NOTE: This style of Valve uses a “Compression Stop”. After Handle Assembly
installation, rotate Handle clockwise to achieve full compression and closure of Valve.
If the Handle does not rest in a vertical position after full compression, repeat Steps 4
and 6 for proper Handle alignment.
6 CPV-5000 INSTALLATION
CPV-TP INSTALLATION
117
STEPS
CPV-TP INSTALLATION HARDWARE BAG
NOTE: The back surface of the Valve Mounting Plate Assembly (1) should sit flush against the wall when
installed correctly.
Clean front surface of wall. Secure the Wall Mounting Plate ❶to the CPV-TP Valve using the longer
screws ❷from the CPV-TP Hardware Bag provided.
7 CPV-TP INSTALLATION
The Universal Valve Trim kit includes three Spindle Adapters that allow for both shallow and deep valve
mount installations. Measure the distance between the front lip of the Wall Mounting Plate and the end of
the Valve Spindle as shown below to determine correct selection of Spindle Adapter.
• If the measurement falls between 2” to 2-3/8”, the Spline Adapter marked “A” is needed
for installation.
• If the measurement falls between 1-1/2” to 2”, the Spline Adapter marked “B” is needed
for installation.
• If the measurement falls between 1-1/4” to 1-1/2”, the Spline Adapter
marked “B” plus “C” Extension is needed for installation.
MEASURE
8 CPV-TP INSTALLATION
A
BC
+
VERTICAL
LINE
Confirm that the Valve is in the off position. Insert Spline Adapter(s) ❶(Spline Adapter selection
determined in STEP 8) over Valve Spindle ❷. One set of splines on the adapter must be oriented
perfectly vertical when installed, as shown below. Secure the Spline Adapter with the Screw ❸from the
CPV-TP Hardware Bag provided.
9 CPV-TP INSTALLATION
RED
BLUE
Orient the Decorative Wall Plate ❶as shown below and insert the RED index button into the top hole of
the Wall Plate, and the BLUE index button into the lower hole. Slide Wall Plate Assembly over Wall
Mounting Plate ❷.
10 CPV-TP INSTALLATION
Orient the Handle Assembly in a vertical position as shown below. Guide Handle Assembly onto the Spline
Adapter ❸. While holding the Handle ❶stationary in the vertical position, thread the Handle Escutcheon
❷onto the Wall Mounting Plate ❹. Hand tighten until snug.
NOTE: After Handle Assembly installation, rotate Handle counterclockwise to
achieve full closure of Valve. If the Handle does not rest in a vertical position, repeat
Steps 9 and 11 for proper Handle alignment.
11 CPV-TP INSTALLATION

ROUGH-IN DIMENSIONS: CPT-1000-TP
•Dimensions are subject to change without notice.
71
4
"
186mm
2"
51mm
41
2
"
114mm
31
2
"
89mm
1"
25mm
ROUGH-IN DIMENSIONS: CPT-1300-TP
•Dimensions are subject to change without notice.
71
4
"
186mm
71
4
"
186mm
21
4
"
56mm
31
2
"
89mm
45
8
"
117mm
11
8
"
28mm
REPAIR PARTS
•RPG10-0118
REPAIR PARTS USED WITH CPV-TP
