SCORPION G3-600 User manual

G3-600
600 YARD LASER RANGEFINDER USER MANUAL
Thank you for your purchase!
Our new Scorpion G3-600. This is our
third generation of range nders and has
incorporated many new features. Please read
the instructions thoroughly.
Before beginning, ensure the factory-supplied
CR2 battery has been installed correctly, by
removing all clear packaging and following the
+/- indicators on the unit.
Instructions
To change units and measuring mode
Select display unit (factory default display unit
is Meters)
1. Press the RANGE button to start up,
and conrm the normal power supply and
display of the liquid crystal.
2. Press the MENU button and hold for
more than 2 seconds to activate the unit
switch. (YD to M) or (Mto YD).
3. After the MENU button is released, you
can switch and keep the Settings.
Feature Selection
1. Single ranging mode: no mode
conversion, press RANGE to measure.
2. Default mode: ranging + Angle +
horizontal distance, press the MENU
button, the mode will be switched in the
following order ( ).
HUNT MODE / AC
SCAN MODE
After the MENU button is released, toggle and
keep the Settings, press the RANGE key for
measurement/range.
What’s in the box?
The unit, hang rope, lens cloth.
Eective Range
Our new G3-600 will perform to at least a
range of 600 yards on most non-reective
targets.
The measuring range of this series of
rangenders is dened under the following
conditions:
1. Measuring the target’s reective surfaces
are perpendicular to the laser.
2. The weather for measuring should be
sunny but not under direct sunlight.
3. Generally, the maximum ranges for
G3 Rangenders are determined under
perfect conditions. The maximum range
can be aected by poor air quality with
things like rain, snow, dust and smoke.
Bright sunshine will also reduce the laser
signal and may produce inconsistent
readings.
4. Under good conditions size, shape and
colour may inuence the unit’s ranging
ability.
1 2
1
2

Main Product Features
1. The product has a 6x optical viewing
system.
2. The product’s waterproof ability
meets up with the class of IP54 (Not for
underwater use).
3. The product has an automatic shutdown
function (8 seconds if unattended).
Precautions
Do not stare at the laser beam for a long
time.
The product’s safety meets up with FDA
Class 1 on vision, which means that under
that condition of ordinary use, there is no
risk of staring at the laser. However, like
any other laser device, proper precautions
should be taken during the operation. It
is recommended to not stare at the laser
emission hole while operating. Using other
optical instruments together with this product
may injure the eyes.
Do not measure the sun.
Measuring the sun through this product may
cause permanent eye injury.
Do not target directly at the sun.
The internal components of the lens system
will get permanent damage when the lens is
placed directly under the sunlight, even for a
short time.
Do not place the eyepiece under direct
sunlight.
Placing the eyepiece under direct sunlight may
damage the internal display.
Do not store or use the product in extreme
temperature conditions.
The temperature range for using the product
is 25°F to 140° F (-4°C to 50°C). Do not
store or use the product beyond the above
temperature conditions.
Change Units and the Measuring Mode
Select display unit (factory default display unit
is meters)
1. Press the RANGE button to start up,
and conrm the normal power supply and
display of the liquid crystal.
2. Press the MENU button and hold for
more than 2 seconds to activate the unit
switch. (YD to M) or (M to YD)
3. After the MENU button is released, you
can switch and keep the Settings.
Feature Selection
1. Single ranging mode: no mode
conversion, press RANGE to measure.
2. Ranging + Angle measurement + height
measurement + scanning mode: press the
MENU button, the mode will be switched in
the following order.
Outline instructions
1. Install lithium batteries (refer to the
operating instruction for more details).
2. This product can be used by users with
or without glasses.
3. Turn the eyepiece for a clear image.
5. Automatic shutdown after 8 seconds if
unattended.
Battery Instructions
3v, CR2 lithium battery
Replace Battery
Open the battery lid by turning it
counterclockwise, remove the old battery
and replace it with the new battery. Make
sure that you insert the new battery in the
right direction (otherwise, the product will
not work). Close the battery lid by turning it
clockwise.
Battery Service Life
Continuous operation times: 5000 times. The
gure will change due to dierent conditions
in terms of reectivity of measured objects
and the working temperatures.

Battery Cautions
1. If handled improperly, the battery
may cause leakage leading to equipment
corrosion or clothing stain.
2. The battery should be installed with the
“+,-” poles in the right direction, as labelled.
3. Please take out the battery if it runs out
or if not using it for a long time.
4. Please replace the battery with the same
type.
5. Please don’t put the battery together
with metal such as keys and coins, for it
may cause overheating or short circuit the
battery.
6. Please don’t charge the lithium battery
or it may result in leakage or damage to
the equipment.
7. Don’t store the lithium battery in
extreme temperatures.
Safe Use
Please read the entire online manual for
safety considerations before using this
product to avoid potential injury. Please
place this manual where it is easy to refer to.
Product packaging and waste products should
be treated or recycled properly, following the
local laws.
Warnings
•Do not look at the laser beam while using
the product.
•Do not press the measuring button and
MENU button at the same time when
aiming the lens at an object or checking the
optical system. Removing and replacing the
battery will reset the unit.
•Do not use other additional optical units
to operate the product, to avoid the risk of
eye damage.
• Do not disassemble the product,
otherwise, the product will not be
warranted by the manufacturer.
• Please remove the battery immediately
and stop using the product if it falls onto
the ground and generates an abnormal
sound.
•Please keep the product away from
children. Don’t put it on a high and uneven
place to prevent it from being damaged if it
falls on the ground.
•Do not place it in cars, under direct
sunlight, in an environment with intense
UV radiation, or near a heat source,
otherwise, the product will be damaged.
•If the product is used under rapid-
changing temperatures, the lens surface
will be covered by fog. Please don’t use the
product before the fog evaporates.
•With an unclear exterior lens, please use
a soft and clean cloth to clean it up. Never
touch the lens with ngertips to protect the
lm on its surface.
•Considering service life, it is suggested
not to measure objects within 20 meters
too often, or measure objects with high
reectivity too close or too often.

11-846 Marion Street, Winnipeg, MB. R2J 0K4 | 1 [phone] | www.scorpionoutdoors.com
RANGE Button
Power On
Objective Lens
Distance Read Out (Yards or Meters)
Battery Life Indicator
Reticle Angle
Indicator
Laser Aperture
Battery Lid
Focus Ring
Eyepiece
MENU Button
G3-600
600 YARD LASER RANGEFINDER USER MANUAL
Operating Range
-4°C to 40°C
