Scosche PSM31001 User manual

BASE-CLAMPS
HOW IT WORKS:
STEP 1
Select the right size clamp
(Various sizes sold
separately)
STEP2
Select the base & ring
clamp that coincides with
what you need to mount
2A. Use protective film to
prevent any paint
damage 28.
STEP3
Lock it in place
The self locking clamp design
allows for easy for easy one
person installation. Simply slip the
clamp over tube and lock in your
base, secure using the stainless
mounting hardware and you are
ready to Mount Up and Move Out.
NOTE: Ring clamps 2" & over in size may
require pre-stretching to help spread the
clamp over the tube. (Use Protective film
when mounting)
Register your product online at
www.scosche.com/register
PSM31001
CAMERA/ GoPro
®
MOUNT BASE
PARTS INCLUDED
(1) Camera Base Adjustment Mount
(1) 1/4" -20 Screw Mount
(1) GoPro• Mount
TOOLS REQUIRED (Not Included}
3/16" Hex (Allen) Key, Except where noted
• Ring Clamps
NOT Included
For complete warranty details, please visit us at
www.scosche.com
or call [phone]
*VARIOUS RING CLAMP SIZES SOLD SEPARATELY W/ HARDWARE
PSC21006
PSC21007
PSC21009
PSC21010
PSC21011
PSC21012
BaseClamp 1.5" Tube Clamp
BaseClamp 1.625" Tube Clamp
BaseClamp 1.75" Tube Clamp
BaseClamp 1.85" Tube Clamp
BaseClamp 1.875" Tube Clamp
BaseClamp 2" Tube Clamp

DEVICE SETUP GUIDE
MOUNTING ADAPTER for GoPro®
Requires Go Pro ® camera with waterproof case (not included).
1. Attach ball adapter to the mounting base as show below.
2. Place the camera case onto the adapter so that the two
mounting brackets on the case fit between the (3) mounting
brackets on the adapter as shown (A). Make sure the holes
on both sets of brackets are aligned.
3. Insert the threaded end of the clamping arm into the
bracket holes (B), and thread into the threaded nut
at the opposite end and tighten until snug (C).
Loosen the arm to adjust the angle of the camera.
1/4" THREADED MOUNTING ADAPTER
for devices with a 1/4" threaded mount
1. Attach the ball adapter to the mounting base as shown on the
following page.
2. Screw the 1/4" threaded mounting adapter directly into the 1/4"
mounting hole on device.
PSM31001
Camera/GoPro® Mount Base
STEP 1
Choose a mounting location (D).
STEP2
Mount base to the appropriate sized clamp ring for the vehicle (E*).
Note: Do not exceed 200 inch-pounds
STEP3
Position the base into location by clicking clamp rings into the base.
Then use a 3/16" hex key to fasten the screw & nut (F) included with
the ring clamp*. Continue until
clamp is tight and does not move.
Note: Do not exceed 200
inch-pounds
STEP4
Tighten/Loosen the ball and hinge
joint
using the mounted turn knob (G) on
the
mount base.
Note: Use the knob to
loosen, tighten or switch-out the
1/4" -20 screw mount {I)
or the GoPro® mount (H).
Clamp Removal:
In-order to remove the tube clamp from location, the clamp must
first be tightened to allow base removal. Once tightened, loosen
the clamp and carefully squeeze clamp to remove from the
location.
Note: Use protective film to help avoid damage to the paint. 'Various
ring clamp sizes available (sold separately w/ hardware
