©2006 SCOSCHE INDUSTRIES, INC. SI 07/06 - AU2380B (3000003)
If you have any further questions, call our toll free technical help line at: 1-800-621-3695x3
AU2380B
2000-UP SELECT AUDI A6
ALL-IN-ONE, SINGLE DIN & DOUBLE-DIN KIT
LIABILITY DISCLAIMER
This instruction booklet is based on carefully documented data and research of automobile dash disassembly, wire
harness/codes and information pertaining to installation of this kit (AU2380B) in 2000-Up Select Audi A6 Vehicles.
Scosche Industries, Inc. can not be held responsible for discrepancies/inconsistencies that may occur due to the
automobile manufacturing changes or options, or damage that may occur in the automobile during the installation of
components while using this booklet.
INTRODUCTION / PRELIMINARY
Thank you for purchasing the Scosche AU2380B Kit. This Kit was manufactured with the highest of quality
standards.
CAUTION: DISCONNECT YOUR VEHICLE'S NEGATIVE BATTERY TERMINAL BEFORE THE
INSTALLATION TO HELP PREVENT ELECTRICAL DAMAGE. WE RECOMMEND THE USE OF A
VOLT/OHM METER OVER A TEST LIGHT TO CHECK WIRING. A TEST LIGHT OR GROUNDED
WIRE PROBE CAN CAUSE DAMAGE TO THE VEHICLE'S COMPUTER AND/OR DIAGNOSTIC
SYSTEMS. AVOID ALL FACTORY AIR BAG WIRING - AIR BAGS CAN ACCIDENTALLY DEPLOY
CAUSING SERIOUS INJURY OR DEATH.
NOTES:
• See your vehicle's instructions for any special tools your installation might require.
• Read all instructions accompanying your car stereo/cassette player for proper wiring and mounting
instructions.
FACTORY WIRING CODES
CAR STEREO CONNECTORS
PROVIDE EASY CONNECTION OF YOUR CAR
STEREO TO FACTORY WIRING HARNESS.
VW03B
2002-UP Volkswagen and BMW
5742 L & R
SINGLE-DIN
ISO BRACKETS
5933
MOUNTING
PANEL
5984
SINGLE-DIN
TRIM RING
6068 L & R
SINGLE-DIN
ISO BRACKETS
5985
SINGLE-DIN
TRIM RING
5986
POCKET
RADIO DISASSEMBLY
Using European radio removal tools (4), slide in to the (4) slots on the factory radio. Pull out, disconnect
and remove

A. ATTACHING THE POCKET:
Align the pocket to the lower edge of the opening in the
panel. Then slide in, as shown, until pocket snaps into
place. The front of pocket should rest flush to the front
of panel.
POCKET ASSEMBLY
RADIO’S
SLEEVE
DIN RADIO
MOUNTING THE RADIO (2 SINGLE DIN / DBL DIN)
A. DIN-ISO / DBL DIN MOUNT:
1. Snap the L/R brackets to the 5933 Kit Panel.
2. Align, position and bolt the aftermarket two IS0-DIN or one
Double DIN head unit to the 6068 brackets. Use hardware
supplied with radio to secure the mounting brackets.
ISO DIN
RADIO
BEND TABS
OUTWARD
2
MOUNTING THE RADIO
B. DIN INSTALLATION:
1. For DIN mount application, slide into
radio opening.
B. ISO DIN MOUNT:
1. Snap the Left/Right brackets to the 5951
kit panel.
2. Align, position, and bolt the aftermarket
two ISO-DIN.
CAUTION:
REAR SUPPORT AVAILABLE SEPARATELY.
REAR SUPPORTING THE RADIO ADDS TO THE
INSTALLATION’S STRUCTURAL INTEGRITY.
CAUTION:
REAR SUPPORT AVAILABLE SEPARATELY.
REAR SUPPORTING THE RADIO ADDS TO THE
INSTALLATION’S STRUCTURAL INTEGRITY.
