WARNINGS
Please Read Carefully and Fully Understand
This manual is for use by personnel trained in the use and care of compressed air
breathing apparatus, and MUST NOT be used as a self-teaching guide by untrained users.
Failure to understand or adhere to the Contour user instructions may result in injury or
death.
Scott Health and Safety Limited has taken great care to ensure that the information in
this manual is accurate, complete and clear. However, Training and Technical Support
Services will be pleased to clarify any points in the manual and answer questions on
SCOTT breathing apparatus.
The following warnings are in accordance with certifying authority requirements and
apply to the use of breathing apparatus in general:
Breathing apparatus users must be fully trained in the use and care of self-
contained, compressed air breathing apparatus.
Ensure that the selection of the apparatus type is sufficient for the tasks
being undertaken and the hazards likely to be encountered. Please refer to
National Regulations for guidance.
Adequate protection may not be provided in certain highly toxic
atmospheres.
The apparatus must be tested and serviced in accordance with Section 7 -
Scheduled Maintenance and the notes in Section 1 under Training and
Servicing.
The quality of air used to supply and charge breathing apparatus must meet
the requirements of EN 12021 : 1999 or AS/NZS1715 : 1994. See Section 1 for
details.
In Australia and New Zealand, ensure that your selection of respiratory
protective devices conform to the requirements of AS/NZS1715 : 1994.
Ensure that a good seal can be obtained between the face and facemask.
The wearing of beards, side-burns or spectacles may adversely affect the
sealing of a facemask to the wearer's face.
The apparatus is not designed for use underwater.
The harness must not be used as a vehicle seat restraint.
DISCLAIMER
Failure to comply with these instructions or misuse of the apparatus may result in:
death, injury or material damage, and invalidate any warranty or insurance claims.
COPYRIGHT
This manual must not be copied in part or whole, or used for purposes other than its intended
purpose without the written permission of Scott Health and Safety Limited.

CONTOUR
1
1. INTRODUCTION
1.1 ABBREVIATIONS
The following abbreviations are used in
this manual:
AL Airline Attachment
BA Breathing Apparatus
CVR Cylinder Valve Retainer
DCC Decontamination Attachment
DV Demand Valve
HP High Pressure
IRIS Integrated Radio Information
System
m Metres
min Minutes
mg Milligrams
mm Millimetres
MP Medium Pressure
NRV Non Return Valve
PRV Pressure Relief Valve
psi Pounds per Square Inch
RSM Rescue Mask Attachment
1.2 BREATHABLE AIR
Air used to supply or charge breathing air
may be natural or synthetic and must
comply with EN 12021 : 1999 or
AS/NZS1715 : 1994. The composition of
breathable air in accordance with EN
12021 is given in Table 1.
Component Mass %
(Dry Air)
Volume%
(Dry Air)
Oxygen 23.14 20.948
Nitrogen 75.52 78.08
Argon 1.29 0.93
Carbon Dioxide 0.05 0.031 4
Hydrogen 0.000 003 0.000 05
Neon 0.001 270 0.001 818
Helium 0.000 037 0.000 524
Krypton 0.000 330 0.000 114
Xenon 0.000 039 0.000 009
Table 1: Breathable Air - EN 12021
(NOT applicable for Australia or
New Zealand)
There is an increased fire risk when the
oxygen content is above the value shown
above.
The purity/quality of air used to supply
and charge breathing apparatus should
be tested periodically in accordance with
national regulations.
Unless otherwise specified, the
contaminants shall not exceed the
permissible exposure level.
National regulations must be observed.
The mineral oil content shall be such that
the air is without the odour of oil. The
odour threshold is in the region of 0.3
mg/m3.
The water content shall not exceed 50
mg/m3for 200 and 207 bar apparatus and
30 mg/m3for 300 bar apparatus.
For airline apparatus, air must be used
with a dew-point sufficiently low to
prevent internal freezing.
1.3 COMPRESSED AIR
AIRLINE SUPPLIES
Air for use with compressed air airlines
must conform to EN 12021 : 1999 or
AS/NZS1715 : 1994 and must have a
dew point sufficiently low to prevent
internal freezing when apparatus is used
in temperatures below 4°C.
No. of Wearers Airflow (L/min.)
1
2
3
4
300
450
750
900
Table 2
Airline pressure must be between 5.0 and
9.0 bar (70 and 130 psi). Airflow supply
capacity for a single airline is given in
Table 2.
Generally; each additional wearer
requires an extra 150 litres per minute,
each additional pair of wearers requires
300 L/min for one wearer and 450 L/min
for two wearers. All measurements must
be taken at the wearer end of the airline.
Example: for 8 users (4 pairs) the
recommended flow is 4 x (300 + 150) =
1800 litres/minute.

CONTOUR
2
An airline flow tester is available from
Scott Health and Safety Limited under
Article Number 1035978.
Compressed air airlines used with
Contour must be SCOTT products,
approved to EN 139 or AS/NZS1716 :
2003.
Ensure that hoses used in an explosive or
flammable atmosphere are marked:
ANTI-STATIC
EN 139
AS/NZS1716
BREATHING AIR
Cost effective PVC hoses may be used in
other atmospheres.
Scott Health and Safety Limited
manufacture a range of anti-static and
PVC hoses, in lengths ranging from 15m
to 60m. Our Customer Services
Department will be pleased to provide
details on price and delivery.
1.4 APPARATUS DURATION
All durations quoted are nominal, based
on an Average Wearer Consumption
Rate of 40 L/min and FULLY CHARGED
cylinders. Actual Wearer Consumption
rates vary due to many factors, such as:
•Workload: high work rates increase
consumption rates.
•Weight of apparatus and use of
heavy or restrictive clothing.
•Work environments with extremes
of heat or cold.
•Physical fitness of the wearer.
•Other factors include emotional
stress and fatigue.
•Supplying cylinder air to a
resuscitator or rescue second mask
(RSM).
It is important that all wearers are aware
of these factors and take account of them
when assessing cylinder duration.
1.5 TRAINING
Personnel who use self-contained,
compressed air breathing apparatus must
be fully trained in accordance with these
instructions and national regulations.
These instructions cannot replace an
accredited training course run by fully
qualified instructors in the proper and
safe use of SCOTT breathing apparatus.
Please contact Training and Technical
Support Services or your distributor for
training course details.
1.6 SERVICING
Contour must be serviced at scheduled
intervals by personnel who have
completed a formal training course and
hold a current certificate for the servicing
and repair of SCOTT breathing
apparatus. Details of the servicing
schedule are contained in the SCOTT
Contour Service Manual, copies of which
can only be obtained by registered
holders of a current certificate.
Your distributor or Training and
Technical Support Services will be
pleased to provide training course details
and quotes for service contracts. Please
see above for contact details.
1.7 SPARE PARTS AND
ACCESSORIES
Customer Services provide an efficient,
friendly, customer contact point for
ordering new apparatus, spare parts and
accessories. The team can also provide
general information on SCOTT products.

CONTOUR
3
1.8 WARRANTY
The products manufactured at our
factories in Skelmersdale and Vaasa
carry a warranty of 12 months (unless
stated otherwise) for parts, labour and
return to site. The warranty period runs
from the date of purchase by the end
user.
These products are warranted to be free
from defects in materials and
workmanship at the time of delivery.
SCOTT will be under no liability for any
defect arising from wilful damage,
negligence, abnormal working conditions,
failure to follow the original
manufacturer’s instructions, misuse or
unauthorised alteration or repair.
Evidence of purchase date will need to be
provided for any claims arising during the
warranty period. All warranty claims must
be directed through SCOTT Customer
Services and in accordance with our
sales return procedure.
1.9 NOTIFIED BODIES
Inspec International Limited (0194)
56 Leslie Hough Way,
Salford,
Greater Manchester,
M6 6AJ,
England.
BSI Product Services (0086)
Kitemark House,
Maylands Avenue,
Hemel Hempstead,
HP2 4SQ,
England.
SAI Global
286 Sussex Street,
Sydney,
NSW 2000,
Australia.
Lic. No 1214.
2. APPARATUS
DESCRIPTION
2.1 GENERAL
Contour is an open circuit, self-contained
compressed air Breathing Apparatus (BA)
for use by fire-fighters and in industrial
applications, where a high level of
respiratory protection is required.
Standard versions of Contour feature a
mechanical pressure gauge and whistle
mounted on the left-hand shoulder strap.
Versions specifically intended for use by
fire-fighters are available which
incorporate the IRIS data-
communications system.
All safety-critical components on the
Contour Set, (for example the reducer
valve and demand valve etc), are
individually identified by a unique serial
number and date of manufacture.
Contour is approved to European
Standards EN 137 : 1993, EN 137 : 2006
Class 1 (self-contained breathing
apparatus) and EN 139 : 1995 (self-
contained breathing apparatus with airline
attachment). Contour is 'CE' marked in
accordance with EC Directive
EC/686/1986.
Contour is approved to Australian/New
Zealand Standard AS/NZS1716 : 2003.
Contour is also approved for use at sea
by:
Lloyds Inspectorate, in accordance with
SOLAS regulation 17 and the 1980
Merchant Shipping Act.
Please call Scott Health and Safety
Limited for further apparatus approval
details.
This manual contains user instructions for
single cylinder, twin cylinder (Duo)
versions, and versions for use with
compressed air airlines. Duo models are
not normally provided with airline
attachments.

CONTOUR
4
Contour is marked in accordance with
EN 137 : 2003 and AS/NZS1716 : 2003.
An explanation of those markings is given
below:
Key Meaning
A = Symbol - refer to User Instructions
B = Product brand name
C = Product model/designation
D = Apparatus description
E = Standards to which apparatus is certified
F = Number of Approval Body
G = Serial number of apparatus
H = Date of manufacture
I = Contact details of manufacturer
2.2 HARNESS
Contour is available with a flame-
retardant polyamide/ polyester or a
KevlarTM/NomexTM harness (identified by
a -K in the unit part number). Buckles are
of black nylon or stainless steel. Press-
studs are of brass or nickel plated brass.
On KevlarTM versions the pneumatics and
hoses are attached to the harness by
loops closed by press-studs. On EN
versions the loops do not open.
For wearer comfort, a lumbar pad (fitted
as standard), or a full back pad (fitted as
an option) is provided. Both are fabricated
from flame-retardant material and packed
with flame retardant, closed cell foam.
The lumbar pad is held in place by four
press-studs. The full length pad is held by
press studs and the harness straps.
A chest-strap is available as an option.
2.3 CYLINDER BAND
Contour can be configured for use with
one or two (Duo), 200, 207 or 300 bar,
steel or fully wrapped aluminium carbon
fibre composite cylinders (see Table 3).
Cylinders are secured to the light-weight
back-plate by a webbing cylinder band
and a cylinder valve retainer (CVR). A
conversion kit is available for converting
single cylinder apparatus to Duo.
The webbing cylinder band is closed by a
cam lock buckle with a latch that prevents
accidental opening. The band can be
adjusted to accept the range of cylinders
listed in Table 3. The cam-lock buckle
facilitates replacement of similar size
cylinders without cylinder band
adjustment.
Contour Duo cylinder bands can be
easily altered by the wearer (no tools
required) to mount a single cylinder,
centrally on the back-plate.

CONTOUR
5
Cylinders Water
Capacity
(litres)
Charging
Pressure
(bar)
Free air
Volume
(litres)
Nominal
Duration
(mins)
Warning
Period
(mins)
Total
Duration
(mins)
Cylinder
Charged
Weight
(kg)
Weight of
Contour with
Cylinder (kg)
Single Duo
CYL-1200 6.0 200 1200 22 8 30 8.8 11.8 -
CYL-HWG-
1200 6.0 207 1200 22 8 30 7.2 10.2 -
CYL-FWC-
1300 4.7 300 1300 25 7 32 5.0 8.0 -
CYL-1640 6.0 300 1640 33 8 41 12.5 15.5 -
CYL-HWG-
1640 6.0 300 1640 33 8 41 10.0 13.0 -
CYL-FWC-
1640 6.0 300 1640 33 8 41 6.3 9.3 15.6
CYL-1800 9.0 200 1800 33 12 45 13.0 16.0 -
CYL-HWG-
1800 9.0 207 1800 33 12 45 11.2 14.2 -
CYL-FWC-
1800 9.0 207 1800 33 12 45 6.75 9.75 16.5
CYL-FWC-
1860 6.8 300 1860 37 9 46 6.75 9.75 16.5
CYL-FWC-
2460 9.0 300 2460 50 12 62 8.8 11.8 -
Note:
Only cylinders in shaded areas are suitable for use with Contour Duo in twin cylinder
configuration. The total apparatus weight must not exceed 18 kg when fully-charged; (ref: EN
137, Clause 5.4 and AS/NZS1716 : 2003).
Table 3: Cylinders approved for use with Contour apparatus
Table 4 identifies the cylinder material code and the cylinder specification.
Code Material Specification
No Code Steel (e.g.: CYL-1200) CE Marked (EU)
Work Cover (Australia & New Zealand)
HWG Hoop Wrapped Glass Fibre (e.g.: CYL-HWG-1200) HSE-AL-HW1 (EU)
Work Cover (Australia & New Zealand)
FWC Fully Wrapped Carbon (e.g.: CYL-FWC-1300) CE Marked (EU)
Work Cover (Australia & New Zealand)
Table 4: Cylinder Codes and Specifications
Durations are nominal and based on an Average Wearer Consumption Rate of 40 L/min and
are for fully charged cylinders.
Total Duration = Cylinder Free Air Capacity
Average Wearer Consumption Rate
Nominal Duration =Total Duration minus the Warning Period.
Warning Period = Whistle Operating Pressure
Average Wearer Consumption Rate

CONTOUR
6
2.4 THE PNEUMATIC
SYSTEM
The pneumatic system has two pressure
reduction stages: air from the cylinder is
reduced to a medium-pressure (MP) of
between 5.5 and 11 bar by the reducer.
The second pressure reduction is
performed in the facemask Demand
Valve (DV).
Air from the cylinder passes through a
sintered bronze particle filter in the
cylinder connector, which protects the
pneumatic system, then through a short
length of High Pressure (HP) braided
hose to the reducer inlet manifold.
2.5 REDUCER
The reducer is a simple, self-regulating,
spring and piston device, which requires
no adjustment. It has a pressure relief
valve (PRV) that protects the MP system
from over-pressurisation.
Air from the reducer is connected through
a reinforced chlorinated polyethylene
hose to the facemask-mounted DV, which
regulates the air supplied to the wearer.
2.6 GAUGE AND WHISTLE
A high-pressure hose from the reducer
inlet manifold connects air, at cylinder
pressure, to a warning whistle and
pressure gauge mounted on the Contour
shoulder strap.
On standard versions, the warning whistle
and pressure gauge are mounted on the
left-hand shoulder strap.
On versions fitted with the IRIS data-
communications system, the warning
whistle and pressure gauge are
incorporated within the IRIS unit.
The warning whistle sounds when
pressure in the cylinder falls to 55 bar (±5
bar).
The duration of the air remaining in the
cylinder, from the start of the warning
whistle, is listed for each cylinder type
under Warning Period in Table 3.
The pressure gauge dial is photo
luminescent to aid use in low light levels.
The lens is impact resistant
polycarbonate. A rubber shroud protects
the gauge.
Should the gauge, whistle or hose
become damaged, a restrictor in the
reducer limits air-loss to less than 25
litres per minute.
2.7 DEMAND VALVE
The DV operates in conjunction with the
facemask spring-loaded exhale valve to
maintain a positive pressure within the
facemask.
The DV has a servo-assisted tilting
diaphragm mechanism that responds to
pressure changes within the facemask to
regulate the flow of air to the mask,
ensuring that pressure within the mask
remains safely above ambient.
The DV has a reset button that enables
wearers to close the air-flow through the
DV, allowing the facemask to be removed
during test procedures and at the end of a
task without loss of cylinder air.

CONTOUR
7
When the apparatus is donned the DV is
normally “reset” (closed), and is opened
(activated) when the wearer takes a first
breath.
The DV has a supplementary flow device
(bypass), that the wearer can open using
the bypass knob.
When the bypass is used the unregulated
flow of air through the DV reduces
cylinder duration.
The DV is connected to the facemask by
a Quick-Fit (QF) bayonet fitting with a
spring-loaded locking catch to prevent
accidental disconnection.
2.8 OPTIONAL
ATTACHMENTS
The options available are:
•Decontamination attachment (DCC)
- facilitates airline connection into a
gas-tight chemical suit, permitting
the wearer to breathe from an
airline during extended
decontamination procedures.
•Rescue mask attachment (RSM) -
permits the wearer to supply a
rescue mask or an air powered
resuscitator from own cylinder air.
This reduces the duration of the
cylinder supply.
•Airline attachment (AL) - permits
Contour to be used with an airline.
The cylinder provides emergency
backup.
Note:
Air for use with airlines must conform to
Breathable Air as detailed in Section 1.
2.9 FACEMASKS
Contour is approved for use with: Vision
3, PanaSeal, PanaVisor and Promask
PP full facemasks, all of which conform to
EN 136, Class 3 and AS/NZS1716 :
2003.
All are available with five point, fully
adjustable web or net head-harnesses
and neck-straps.
An inner mask minimises CO2dead
space and visor misting. A speech
diaphragm is fitted.
PanaSeal is suitable for medium and
smaller face sizes; PanaVisor is suitable
for medium to larger face sizes. Vision 3
is available in three sizes: small, medium
and medium/large which cover most face
sizes. Promask PP is available in two
sizes: small/medium and medium/large.
Vision 3 is moulded in grey silicone,
while PanaSeal and PanaVisor are of
non-dermatitic, black neoprene or blue
silicone. Promask PP is moulded in
hypo-allergenic, black ProcompTM with a
soft silicone inner mask.
The polycarbonate visors conform to EN
166 Grade B for medium impact-
resistance and AS/NZS 1337 : 1992 for
high-impact resistance.
Versions of the above masks are also
available with helmet attachment clamps
fitted. Please contact Customer Services
for further information.
Vision 3 Facemask with Web Harness
PanaSeal/PanaVisor Facemask with
Net Harness
