Sea-Dog Boat Hook Spinner User manual

BOAT HOOK
SPINNER
Assembly Instrucons

CONTENTS
TOOLS NEEDED
BOAT HOOK SPINNER Assembly Instrucons
Spinner Top (1) Spinner Base (1)
Panel (3)
>Top
>Boom
Lazy Susan (1)
Self-Drilling
Screws (16)
(Phillips Bit)
(Phillips)
or

Flip
1 3
5
2
Spinner Base
>Top
>Boom
Place panels in spinner
base with top side up
Align medium sized holes on Lazy
Susan Side “B” to pre-drilled holes
on Spinner Base
Rotate Side “A” 90° to access
remaining attachment points.
Spinner Top
Attach Spinner Top
& Bottom
(x6)
Aach by screwing the self-drilling
screws through the holes in the top
& boom and into the panels.
(You will create new holes in the panels)
Spinner Base
A
B
Large holes provide through access
to fastening holes
Use MEDIUM sized fastening holes
Large
Small
Medium
Side A
4Fasten first
two points with
through holes
Spin
90°
Side A
(x2)

Part Number Size Pre Loaded Qty. Reorder Qty.
491012-1 48" 4
491013-1 72" 3
491021-1 24"-36" 4
491024-1 48"-96" 6
491034-1 36"-96" 4
491036-1 56"-144" 4
Boat Hook Spinner Reorder Sheet
