Specic
Information
Manual
350 Sundancer®
Manual Part Number: MRP 1944467

350 Sundancer®i
Manual Part Number: MRP 1944467
350 Su n d a n c e r Sp e c i f i c in f o r m a t i o n ma n u a l
Ta b l e o f Co n T e n T s
1. Load Capacity..........................................................1
2. Passenger Locations ...............................................1
3. Safety Label Locations ............................................2
4. Basic Boat Dimensions and Clearances ................. 6
5. Function and Location of Through-Hull Cutouts ...... 7
6. Helm, Gauge & Switch Layout................................8
7. Deck Layout ........................................................... 10
8. Cabin Layout.......................................................... 11
9. Cleats..................................................................... 12
10. Navigation and Anchor Lights..............................12
11. Lighting ................................................................12
12. Bilge Layout .........................................................14
13. Fire Extinguishing System ...................................18
14. Fuel System.........................................................18
A. Gasoline Fuel System..................................... 18
B. Diesel Fuel System (Optional) ........................ 18
15. Water System ......................................................18
16. Aft Facing Transom Seat......................................18
17. Entertainment System ......................................... 19
18. DC to AC Inverter ................................................20
19. Engine Hatch .......................................................20
20. Canvas................................................................. 20
21. Electrical Schematic ............................................ 20
Information in this publication is based upon the latest product specifications available at printing. Sea Ray®
Boats, Inc. reserves the right to make changes at any time, without notice, in the colors, equipment, specifications,
materials and prices of all models, or to discontinue models. Should changes in production models be made, Sea
Ray® is not obligated to make similar changes or modifications to models sold prior to the date of such changes.
Owner’s Manual
350 Sundancer®
Printed in the U.S.A. June 2008
© Sea Ray Boats, Inc. • A Brunswick Company
Sea Ray Boats, Inc. 0 Sea Ray Blvd., Knoxville, TN 37914
For information call 1-800-SRBOATS or fax [phone]
(International 1-314-216-3333)
Internet Address: http://www.searay.com
Note: Not all accessories shown in pictures or described herein are
standard equipment or even available as options.
Options and features are subject to change without notice.
The following are registered trademarks of the Brunswick Corporation: Sea Ray®& The SR Wave Logo

350 Sundancer® ii Manual Part Number: MRP 1944467
THIS PAGE INTENTIONALLY LEFT BLANK

1
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®Manual Part Number: MRP 1944467
1. lo a d Ca p a C i T y
Refer to the General Information Manual for a
detailed explanation of Load Capacity.
B
1360
350 DA
12
Bu i l d e r ’Spl a t e (i n t e r n a t i o n a l )
(fi g . 1.1)
BOAT MANUFACTURER MFR’S MODEL
DESIGNATION
MAXIMUM NUMBER
OF PASSENGERS
MAXIMUM LOAD
CAPACITY
Never carry more weight or passengers than indicated
on the certification plate, regardless of weather or
water conditions.
The boat can capsize, swamp or sink.
! DANGER
pa S S e n g e r lo c a t i o n S
(fi g . 1.2)
Rotating propellers can injure or kill you.
Shut off engine when persons are in water near
boat, or on swim platform or ladder.
!DANGER
ACCOMMODATION DECK
(DECK AREA INTENDED FOR
OCCUPATION DURING NORMAL
OPERATION)
WORKING DECK
(DECK AREA INTENDED
FOR OCCUPATION DURING
ANCHORING, MOORING AND
EMERGENCY OPERATION ONLY
Rear facing transom seats MUST NOT be used while
engine is running or boat is moving.
! WARNING
2. pa s s e n g e r lo C a T i o n s
Refer to the General Information Manual for a
detailed explanation of Passenger Locations.
Boat motion can be erratic.
You can fall overboard or be injured by hitting
something in or on the boat.
All persons must be in cockpit area or cabin and be
prepared for sudden boat movement.
Use front or bow deck area only during anchoring,
mooring or emergencies.
! WARNING
Wet decks are slippery.
You can be seriously injured if you slip and fall.
Wear slip resistant footwear secured to your feet and
hold on to rails or boat structure.
! WARNING
DO NOT STAND OR WALK ON THIS
AREA WHILE UNDERWAY.

2
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®
Manual Part Number: MRP 1944467
H
G
!DANGER
Carbon monoxide (CO) can cause brain damage
or death.
Engine and generator exhaust contains odorless
and colorless carbon monoxide gas.
Carbon monoxide will be around the back of the
boat when engines or generators are running.
Move to fresh air, if you feel nausea, headache,
dizziness, or drowsiness. NW-206-05
x
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO CO
CO
3. sa f e T y la b e l lo C a T i o n s
C
D
A
E
G
J
C
D
A
J
B
MRP 1743571 SR-7102
DANGER
!
TRANSOM DOOR MUST BE
CLOSED AND SECURE WHEN
ENGINE IS RUNNING
MRP 1745158 SR-7119B
DANGER
!
NO SMOKING
GASOLINE VAPORS ARE EXPLOSIVE
LPG Appliances can ignite gasoline
vapor causing fire or explosion.Turn off
all LPG appliances while fueling.
NOTICE
GASOLINE RECOMMENDATION
Minimum octane rating of 87 AKI.
Refer to the engine owner’s manual for
additional information.
TO AVOID RISK OF SERIOUS INJURY OR DEATH
SHUT OFF ENGINE WHEN NEAR SWIMMERS
OR PRIOR TO USING SWIM PLATFORM AND
BOARDING LADDER.
MRP 1745519 SR-7214
DANGER
!
Sa f e t y la B e l lo c a t i o n S
(fi g . 2.1)
H
MRP 1745162 SR-7124
INSIDE COMPARTMENT
WARNING
!
- DO NOT LEAVE BOAT UNATTENDED WITH THE
DOCKSIDE WATER HOSE CONNECTED.
- DOCKSIDE WATER SHOULD BE CONNECTED
DURING PERIODS OF HEAVY WATER USE ONLY.
E
LOCATED UNDER ANCHOR HATCH
STAY CLEAR OF MOVING PARTS
MRP # 1746896 SR-7162
DANGER
!
DOOR MUST BE CLOSED AND LATCHED
FOR ENGINE HATCH LIFT TO BE ACTUATED.
MRP # 1907439 SRS-7425
NOTICE
DO NOT STAND OR WALK ON
THIS AREA SERIOUS INJURY
COULD RESULT.
MRP # 1745515 SR-7216
DANGER
!
I
YOU CAN DIE OR BE SERIOUSLY INJURED BY
BREATHING CARBON MONOXIDE
OR BY THE PROPELLER IF YOU
FALL OVERBOARD.
REAR FACING TRANSOM SEATS MUST NOT
BE USED WHILE ENGINE IS RUNNING OR
BOAT IS MOVING.
WARNING
!
1792393
K
K
MRP 852558 SR-140
FORE AND AFT SUN PADS SHOULD NOT
BE USED WHEN VESSEL IS UNDER WAY.
DANGER
!
F
F
RUNNING BOAT WITH DOOR OPEN COULD
INDUCE EXHAUST FUMES INTO CABIN.
SEE OWNER’S MANUAL FOR INSTRUCTIONS
CONCERNING CARBON MONOXIDE.
MRP # 1743548 SR-7285
WARNING
!
MRP # 1743507 SR-7313
WARNING
!
- SECURE DOOR WHEN CRUISING.
- DO NOT SIT, STAND, OR PLACE HEAVY
OBJECTS ON DOOR.
- KEEP CABIN DOOR CLOSED WHEN ENGINES
OR GENERATOR ARE RUNNING.
- DO NOT USE CAUSTIC MATERIALS TO CLEAN.
- WASH WITH MILD SOAP AND WATER.
B
B
B
H
I

3
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®Manual Part Number: MRP 1944467
B
MRP 1746224 SR-7218
IMPORTANT SAFETY AND OPERATIONAL INFORMATION
!!
!WARNING
Carbon monoxide (CO) can cause brain damage or death.
Engine and generator exhaust contains odorless and colorless carbon monoxide gas.
Signs of carbon monoxide poisoning include nausea, headache, dizziness, drowsiness,
and lack of consciousness.
Get fresh air if anyone shows signs of carbon monoxide poisoning.
See Owner's Manual for information regarding carbon monoxide poisoning.
NW-204-05
x
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO CO
CO
CO
CO
CO
CO
CO
CO
CO
sa f e T y la b e l lo C a T i o n s (Co n T i n u e d )
Sa f e t y la B e l lo c a t i o n S
(fi g . 3.1)
C
B
1360
350 DA
12
THIS TAG INSTALLED WHEN BOAT IS ORDERED
WITH CE INTERNATIONAL OPTION
NMMA CERTIFICATION TAG
A
B
A
CHECK BATTERY CELL FLUID LEVEL
APPROXIMATELY EVERY 4 WEEKS, AND MORE
OFTEN IN SUMMER AND HOT ZONES.
MRP # 1746895 SR-7139
NOTICE
STAY CLEAR OF MOVING PARTS
WHILE ENGINE IS RUNNING.
MRP 1745512 SR-7149
DANGER
!
LEAKING FUEL IS A FIRE AND EXPLOSION
HAZARD. INSPECT SYSTEM REGULARLY.
EXAMINE FUEL TANKS FOR LEAKS OR
CORROSION AT LEAST ANNUALLY.
MRP 1745513 SR-7151
WARNING
!
DISCHARGE OF OIL PROHIBITED
THE FEDERAL WATER POLLUTION CONTROL ACT PROHIBITS THE
DISCHARGE OF OIL OR OILY WASTE INTO OR UPON THE NAVIGABLE
WATERS OF THE UNITED STATES OR THE WATERS OF THE CONTIGUOUS
IF SUCH DISCHARGE CAUSES A FILM OR SHEEN UPON OR A
DISCOLORATION OF THE SURFACE OF THE WATER OR CAUSES A
SLUDGE OR EMULSION BENEATH THE SURFACE OF THE WATER.
VIOLATORS ARE SUBJECT TO A PENALTY OF $5,000.
MRP 1744737 SR-744
C
VISIBILITY FROM THE SEATED POSITION AT
THIS HELM STATION IS LIMITED.
AVOID SERIOUS INJURY OR DEATH FROM COLLISIONS.
OPERATION FROM A STANDING POSITION
MAY BE NECESSARY TO MAINTAIN LOOKOUT
AS REQUIRED BY RULES OF THE ROAD.
READ OWNERS MANUAL.
!
MRP 1743528 BCM-714
WARNING
PRIOR TO TOWING VESSEL:
CAUTION
!
• LOCK PROPELLER SHAFT(S) TO PREVENT
DAMAGE TO SHAFT SEAL AND TRANSMISSION
BEARINGS.
• CLOSE SEACOCKS ON NON-OPERATING
ENGINES TO PREVENT SEA WATER INGESTION.
MRP 1751885 SR-7203
MRP 1745156 SR-7118
NOTICE
THIS BOAT IS EQUIPPED WITH
AN OPTIONAL DIRECT OVERBOARD
DISCHARGE VALVE. DISCHARGING
OF SEWAGE DIRECTLY OVERBOARD
IS FOR USE WHERE APPROVED ONLY
D
D
E
E

4
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®
Manual Part Number: MRP 1944467
MRP 1747493 SR-7135
LEAVING WINDOW OPEN COULD
INDUCE EXHAUST FUMES
INTO CABIN RESULTING IN SEVERE
PERSONAL INJURY OR DEATH
DANGER
!
NOTICE
EXHAUST FAN MUST BE ON
WHEN USING COOKING
APPLIANCES
MRP #1745124 SR-7106
A
A
MRP 1743616 SR-7154
UNPLUG SHORE POWER AND
TURN OFF GENERATOR
BEFORE REMOVING COVER
DANGER
!
LOCATED ON ALL AC JUNCTION BOXES
B
B
DO NOT USE AFT SUNSHADE IN THE DEPLOYED
POSITION AT SPEEDS IN EXCESS OF 10 MPH.
MRP # 1894013 SR-7418
NOTICE
C
C
DO NOT CLIMB UPON OR STORE
EQUIPMENT ON HARDTOP
! DANGER
MRP 1765879 SR-7198
D
D
DANGER
!
In all gasoline powered boats, engine and generator exhaust
systems produce colorless and odorless carbon monoxide gas
(“CO”). Direct prolonged exposure can result in CO poisoning
which may be harmful or fatal. To prevent excess exposure and
reduce the possibility of accumulations of CO in the cabin and
cockpit of the boat, the operator should insure adequate ventilation
in each the cabin and cockpit areas, through utilization of cabin
hatches, cabin doors, cabin windows, cockpit windshield windows
and side windshield vents to increase air movement through the
cabin and cockpit areas. The following conditions tend to increase
the accumulation of CO in and about the boat and require the
operator’s particular attention:
1. Operation at slow speeds or dead in the water.
2. Operation with a high bow angle attitude.
3. The utilization of canvas tops, side curtains and back
curtains.
4. Contributing climatic conditions, such as a head wind.
5. Operation of engines and/or generator in confined
spaces or at dockside.
6. Any blockage of hull exhaust outlets.
Indications of excessive exposure to CO concentrations may
include nausea, dizziness and drowsiness.
MRP 1746899 SR-7126
!WARNING
Carbon monoxide (CO) can cause brain damage or death.
Carbon monoxide can be present in the cabin.
Signs of carbon monoxide poisoning include nausea, headache,
dizziness, drowsiness, and lack of consciousness.
Get fresh air if anyone shows signs of carbon monoxide poisoning.
Get fresh air is carbon monoxide detector alarm sounds.
Carbon monoxide detoctor must be functioning at all times.
NW-205-05
x
CO
CO
CO
CO
CO CO
CO
CO
CO CO
CO
CO
CO
CO
CO
CO
CO CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
MRP 1747493 SR-7135
LEAVING WINDOW OPEN COULD
INDUCE EXHAUST FUMES
INTO CABIN RESULTING IN SEVERE
PERSONAL INJURY OR DEATH
DANGER
!
E
sa f e T y la b e l lo C a T i o n s (Co n T i n u e d )
Sa f e t y la B e l lo c a t i o n S
(fi g . 4.1)
E

5
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®Manual Part Number: MRP 1944467
LOCATED ON INSIDE OF GALLEY CABINET DOOR
Save Our Seas
It is illegal to dump plastic trash anywhere into the ocean or navigable
waters of the United States. Violation of these requirements may result
in civil penalty up to $25,000, a fine of $50,000 and imprisonment for up
to five years.
PLASTIC - Includes but is
not limited to: plastic bags,
styrofoam cups and lids, six-
pack holders, stirrers, straws,
milk jugs, egg cartons, syn-
thetic fishing nets, ropes, lines,
and bio or photo degradable
plastics.
GARBAGE - Means paper,
rags, glass, metal, crockery
(generated in living spaces
aboard the vessel-what we
normally call trash), and all
kinds of food, maintenance and
cargo-associated waste.
“Garbage” does not include
fresh fish or fish parts, dishwa-
ter, and gray water.
DUNNAGE- Material used to
block and brace cargo, and is
considered a cargo associated
waste.
DISHWATER- Means the liquid
residue from the manual or au-
tomatic washing of dishes and
cooking utensils which, have
been pre-cleaned to the extent
that any food particles adher-
ing to them would not normally
interfere with the operation of
automatic dishwashers.
GRAYWATER - Means drain-
age from a dishwasher, shower,
laundry, bath, and washbasin,
and does not include drainage
from toilets, urinals, hospitals,
and cargo spaces.
(and in U.S. Lakes, Rivers,
Bays and Sounds)
PLASTICS
DUNNAGE, LINING AND PACKING
MATERIALS THAT FLOAT
ANY GARBAGE EXCEPT DISHWATER/
GRAYWATER/FRESH FISH PARTS
PLASTICS
DUNNAGE, LINNING AND PACKING
MATERIALS THAT FLOAT
ANY GARBAGE NOT GROUND TO LESS
THAN ONE SQUARE INCH
PLASTICS
DUNNAGE, LINING AND PACKING
MATERIALS THAT FLOAT
PLASTICS
3 TO 12 MILES
INSIDE 3 MILES
12 TO 25 MILES
12 TO 25 MILES
sa f e T y la b e l lo C a T i o n s (Co n T i n u e d )
Sa f e t y la B e l lo c a t i o n S
(fi g . 5.1)

6
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®
Manual Part Number: MRP 1944467
(D)
4. ba s i C bo a T di m e n s i o n s a n d Cl e a r a n C e s
Bo a t di m e n S i o n S a n d cl e a r a n c e S
(fi g . 6.1)
(A) Overall Length
With Std. Swim Platform......... 37' 6" 11.43 m
(B) Beam (Width)........................... 12' 0" 3.66 m
(C) Draft (V-Drive ........................... 39"* 99 cm*
Draft (Stern Drive Down) ............... 37"* 94 cm*
Draft (Stern Drive Up).................... 27in.* 69 cm*
* MINIMUM WATER DEPTH TO PREVENT RUNNING AGROUND
Dry Weight..................................... 18,100 lbs. 8,200 kg.
Fuel Capacity................................. 225 gal. 851 liters
Usable Fuel ................................... 202 gal. 765 liters
Fresh Water Capacity .................... 50 gal. 189 liters
Holding Tank.................................. 28 gal. 106 liters
Dead Rise...................................... 21°
350 Sundancer®SpecificationS HeigHt dimenSionS
(D) Keel to Top of Mast Light ...............16' 1½" 4.91 m
(E) Waterline to Top of Mast Light........13' 7½" 4.15 m
(F) Waterline to Top of Spoiler .............10' 5½" 3.19 m
(G) Waterline to Top of Windshield ......7' 9" 2.36 m
(A)
WATERLINE
KEEL
(C)
(B)
(E)(F)(G)
NOTE - DIMENSIONS CAN VARY DEPENDING ON LOAD AND RUNNING CONDITIONS.
NOTE: DIMENSIONS CAN VARY DEPENDING ON LOAD
AND RUNNING CONDITIONS

7
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®Manual Part Number: MRP 1944467
5. fu n C T i o n a n d lo C a T i o n o f Th r o u g h -hu l l Cu T o u T s
po r t th r o u g h -hu l l cu t o u t S
(fi g . 7.1)
Bi l g e th r o u g h -hu l l cu t o u t S
(fi g . 7.3) tr a n S o m th r o u g h -hu l l cu t o u t S
(fi g . 7.4)
St a r B o a r d th r o u g h -hu l l cu t o u t S
(fi g . 7.2)
HULL WINDOW HEAD PORTLIGHT WATER TANK
VENT
POWER VENT FUEL VENT PORT STORAGE
TUB DRAIN WASTE VENT
MANUAL BILGE
PUMP (CE OPT)
ENGINE EXHAUST
BYPASS
WATER HEATER
VENT
A/C DISCHARGE
COMMON DRAIN
BILGE PUMP
COCKPIT WETBAR/
ETS MODULE DRAIN
FUEL VENT
VACUUM VENT
(OPT)
PORTLIGHT
(INTERNATIONAL OPT )
HULL WINDOW
GENERATOR
EXHAUST
ENGINE EXHAUST
BYPASS
A/C PICKUP
PORT RUDDER
STBD RUDDER
STBD ENGINE
EXHAUST
MACERAT OR
(OPT)
PORT ENGINE
EXHAUST PORT SHAFT LOG
STBD SHAFT LO G
STBD ENGINE
SEACOCK
PORT ENGINE
SEACOCK
SPEED
TRANSDUCER
(OPT)
DEPTH
TRANSDUCER
(OPT)
GENERA T OR
PICKUP (OPT)
STERN THRUSTER
(OPT) GARBOARD
DRAIN
ZINC PLAT E

8
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®
Manual Part Number: MRP 1944467
6. he l m , ga u g e & sw i T C h la y o u T
he l m
(fi g . 8.1)
* OPTIONAL EQUIPMENT
VHF RADIO
INSTRUMENT PANEL
COMPASS
VHF RADIO
SPEAKER
NAVIGATION
ELECTRONICS*
AUTO PILOT*
AIR SENSOR
SPOT LIGHT
CONTROL*
ENGINE SYSTEMS
DISPLAY
COMPONENT BOARD &
FUSE BLOCK ACCESS
STBD SWITCH
PANEL
IGNITION SWITCH
PANEL
BOW THRUSTER
CONTROL
PORT SWITCH
PANEL
STEREO REMOTE
THROTTLE & SHIFT
CONTROLS

9
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®Manual Part Number: MRP 1944467
co n t r o l St a t i o n po r t Sw i t c h pa d
(fi g . 9.1)
co n t r o l St a t i o n St a r B o a r d Sw i t c h pa d
(fi g . 9.2)

10
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®
Manual Part Number: MRP 1944467
7. de C k la y o u T
de c k la y o u t
(fi g . 10.1)
SWIM LADDER W/
OPTIONAL PLATFORM
PORT DASH/
STORAGE
AFT SEAT
(W/ STORAGE BELOW)
FOLDOUT
AFT FACING
TRANSOM SEAT
SPOT LIGHT (OPT)
PORT NAV LIGHT
WINDLASS FOOT
SWITCHES
COCKPIT TABLE
CABIN ENTRY
DOOR
SKY LIGHT
ANCHOR DAVIT
PORT SWIVEL SEAT
TRANSOM
STORAGE
12V RECEPTACLE (IN
SIDE PANEL STORAGE)
CONTROL STATION
ROPE LOCKER
(WINDLASS)
STARBOARD NAV LIGHT
WET BAR
FUEL FILL
SWIM PLATFORM
(OPT)
GRILL (OPT)
PIVOTING
HELM SEAT
TRANSOM
WALK-THRU
HORN
DECK HATCH
(EMERGENCY EXIT)
ENGINE HATCH
STANDARD SWIM
LADDER
SWIM PLATFORM
(STANDARD)

11
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®Manual Part Number: MRP 1944467
8. Ca b i n la y o u T
ca B i n la y o u t
(fi g . 11.1)
V-BERTH
GALLEY SINK
STOVE
MICROWAVE
HEAD SINK
HEAD / SHOWER
V-BERTH PRIVACY
CURTAQIN
REMOVABLE
SALON TABLE
CONVERTABLE
SOFA / BERTH
MDP CABINET
MID-BERTH PRIVACY
CURTAIN
MID-BERTH
CONVERTABLE SOFA

12
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®
Manual Part Number: MRP 1944467
9. Cl e a T s
Cleats must not be used for lifting the boat; they
are intended for docking or mooring use only.
cl e a t lo c a t i o n S
(fi g . 12.1)
11. li g h T i n g
See General Information Manual for a detailed
explanation of the lighting.
*
*
*
*
*
*
*
*
10. na v i g a T i o n a n d an C h o r li g h T s
See General Information Manual for a detailed
explanation of the anchor lights.
NAVIGATION
LIGHT SWITCH
ANCHOR LIGHT
SWITCH
na v i g a t i o n a n d an c h o r li g h t S
(fi g . 12.2)
MAST LIGHT
PORT & STBD
NAVIGATION
LIGHTS
PORT SWITCH
PANEL
ALL-ROUND/
ANCHOR LIGHT
CLEAT
CLEAT
CLEAT CLEAT
CLEAT
CLEAT

13
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®Manual Part Number: MRP 1944467
li g h t i n g la y o u t
(fi g . 13.1)
li g h T i n g (Co n T i n u e d )
E
AA
A
A
A
A
A
BB
BB
BB
BB
CC
C
C
C
C
C
C
C
D
E
E
BULB REPLACEMENT
BULB# GE2641L
12V R 10W
G
PORT & STBD
NAV. LIGHTS
STERN NAV. /
ANCHOR LIGHT
BULB REPLACEMENT
FUSE TYPE BULB
#12V10WPERKO
H
RECTANGLE LIGHT
(IN BILGE AREA)
BULB
REPLACEMENT
BULB#CEC1141
I
COCKPIT LIGHT
BULB REPLACEMENT
FUSE TYPE BULB
#12V10WPERKO #70-0
F
G
H
F
G
F
F
F
F
FF
READING LIGHT
BULB REPLACEMENT
HALOGEN 12V 10W
BI-PRONG
A
LED LIGHT - NO
REPLACEMENT BULB
LED LIGHTS
B
EYEBALL LIGHT
BULB REPLACEMENT
XENON HALOGEN
G4 12V/10W
C
SHOWER LIGHT
BULB REPLACEMENT
XENON “XH” MINIATURE
HALOGEN BI-PIN, 24V/10W
D
LED LIGHT - NO
REPLACEMENT BULB
LED STEP LIGHT
E

14
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®
Manual Part Number: MRP 1944467
A/C UNIT
FRESH WATER
TANK
FUEL TANKS
EMERGENCY
HIGH WATER
BILGE PUMP
TRIM TABS
PUMPBILGE BLOWER
PORT ENGINE
BATTERIES
GENERATOR
FUEL FILTER
TRANSDUCER
GENERATOR
(OPT)
GENERATOR
SEACOCK (OPT)
GENERATOR
STRAINER (OPT)
GENERATOR
MUFFLER (OPT)
PORT POWER
TRIM PUMP
A/C SEACOCK
FLOAT SWITCHES
GENERATOR
BATTERY
Bi l g e la y o u t (ga S St e r n dr i v e )
(fi g . 14.1)
PORT ENGINE
BATTERIES
A/C
STRAINER
FRESH WATER
PUMP
WASTE WATER
HOLDING TANK
WASTE VENT FILTER
MACERATOR (OPT)
VACUUM
GENERATOR
WASTE DISCHARGE
SEACOCK (OPT)
WATER HEATER
PORT POWER
TRIM PUMP
A/C PUMP
BILGE BLOWER
BILGE PUMP
12. bi l g e la y o u T

15
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®Manual Part Number: MRP 1944467
A/C UNIT
FRESH WATER
TANK
FUEL TANKS
EMERGENCY
HIGH WATER
BILGE PUMP
TRIM TABS
PUMPBILGE BLOWER
PORT ENGINE
BATTERIES
GENERATOR
FUEL FILTER
TRANSDUCER
GENERATOR
(OPT)
GENERATOR
SEACOCK (OPT)
GENERATOR
STRAINER (OPT)
GENERATOR
MUFFLER (OPT)
PORT POWER
TRIM PUMP
A/C SEACOCK
FLOAT SWITCHES
GENERATOR
BATTERY
Bi l g e la y o u t (di e S e l St e r n dr i v e )
(fi g . 15.1)
PORT ENGINE
BATTERIES
A/C
STRAINER
FRESH WATER
PUMP
WASTE WATER
HOLDING TANK
WASTE VENT FILTER
MACERATOR (OPT)
VACUUM
GENERATOR
WASTE DISCHARGE
SEACOCK (OPT)
WATER HEATER
PORT POWER
TRIM PUMP
A/C PUMP
BILGE BLOWER
BILGE PUMP

16
350 Su n d a n c e r ®ow n e r S ma n u a l
350 Sundancer®
Manual Part Number: MRP 1944467
A/C UNIT
FRESH WATER
TANK
FRESH WATER
PUMP
WASTE WATER
HOLDING TANK
WASTE VENT FILTER
MACERATOR (OPT)
VACUUM
GENERATOR
A/C PUMP
FUEL TANKS
EMERGENCY
HIGH WATER
BILGE PUMP
WASTE DISCHARGE
SEACOCK (OPT)
BILGE PUMPBILGE BLOWERS
PORT ENGINE
BATTERIES
PORT ENGINE
RAW WATER
STRAINER
PORT ENGINE
RAW WATER
SEACOCK
WATER HEATER
PORT ENGINE
BATTERIES
PORT ENGINE
RAW WATER
STRAINER
PORT ENGINE
RAW WATER
SEACOCK
GENERATOR
FUEL FILTER
AUTO PILOT
PUMP
EMERGENCY
HIGH WATER
FLOAT SWITCH
TRANSDUCERS
GENERATOR
(OPT)
GENERATOR
SEACOCK (OPT)
GENERATOR
STRAINER (OPT)
GENERATOR
MUFFLER (OPT)
PORT ENGINE
MUFFLER
STBD ENGINE
MUFFLER
A/C SEACOCK
FLOAT SWITCH
A/C STRAINER
GENERATOR
BATTERY
Bi l g e la y o u t (ga S v-dr i v e )
(fi g . 16.1)
