Sea Ray Sundancer 370 Owner's manual

16.1
370 Sundancer®
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
Model Specic
Information
370 Sundancer®

16.2
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
MAXIMUM
0609
IMCI
F
I
N
T
E
R
N
A
T
I
O
N
A
L
C
E
R
T
I
I
C
A
T
I
O
N
Sea
12 1360
Ray
370 SDA
Boats
kg
1. lo a D ca p a c i T Y
Refer to the General Information Sections for a
detailed explanation of Load Capacity.
bu I l d e r ’spl a T e (I n T e r n a T I o n a l )
(fI g . 16.2.1)
BOAT MANUFACTURER MFR’S MODEL
DESIGNATION
MAXIMUM NUMBER
OF PASSENGERS
MAXIMUM LOAD
CAPACITY
Nevercarrymoreweightorpassengersthanindicated
on the certication plate, regardless of weather or
waterconditions.
Theboatcancapsize,swamporsink.
! DANGER
pa s s e n g e r lo c a T I o n s
(fI g . 16.2.2)
Rotatingpropellerscaninjureorkillyou.
Shut off engine when persons are in water near
boat,oronswimplatformorladder.
!DANGER
ACCOMMODATIONDECK
(DECK AREA INTENDED FOR
OCCUPATION DURING NORMAL
OPERATION)
WORKINGDECK
(DECK AREA INTENDED
FOR OCCUPATION DURING
ANCHORING, MOORING AND
EMERGENCY OPERATION ONLY
RearfacingtransomseatsMUST NOT be used while
engineisrunningorboatismoving.
! WARNING
2. pa s s e n g e r lo c a T i o n s
Refer to the General Information Sections for a
detailed explanation of Passenger Locations.
Boatmotioncanbeerratic.
You can fall overboard or be injured by hitting
somethinginorontheboat.
Allpersonsmustbeincockpitareaorcabinandbe
preparedforsuddenboatmovement.
Use front or bow deck area only during anchoring,
mooringoremergencies.
! WARNING
Wetdecksareslippery.
Youcanbeseriouslyinjuredifyouslipandfall.
Wearslipresistantfootwearsecuredtoyourfeetand
holdontorailsorboatstructure.
! WARNING
DONOTSTANDORWALKONTHIS
AREAWHILEUNDERWAY.

16.3
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
H
G
!DANGER
Carbon monoxide (CO) can cause brain damage
or death.
Engine and generator exhaust contains odorless
and colorless carbon monoxide gas.
Carbon monoxide will be around the back of the
boat when engines or generators are running.
Move to fresh air, if you feel nausea, headache,
dizziness, or drowsiness. NW-206-05
x
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO CO
CO CO
CO
3. sa f e T Y la b e l lo c a T i o n s
C
D
A
E
G
J
C
D
A
J
B
MRP 1743571 SR-7102
DANGER
!
TRANSOMDOORMUSTBE
CLOSEDANDSECUREWHEN
ENGINEISRUNNING
MRP 1745158 SR-7119B
DANGER
!
NOSMOKING
GASOLINEVAPORSAREEXPLOSIVE
LPGAppliancescanignitegasoline
vaporcausingreorexplosion.Turnoff
allLPGapplianceswhilefueling.
NOTICE
GASOLINERECOMMENDATION
Minimumoctaneratingof87AKI.
Refertotheengineowner’smanualfor
additionalinformation.
TOAVOIDRISKOFSERIOUSINJURYORDEATH
SHUTOFFENGINEWHENNEARSWIMMERS
ORPRIORTOUSINGSWIMPLATFORMAND
BOARDINGLADDER.
MRP 1745519 SR-7214
DANGER
!
sa f e T Y la b e l lo c a T I o n s
(fI g . 16.3.1)
H
MRP 1745162 SR-7124
INSIDE COMPARTMENT
WARNING
!
-DONOTLEAVEBOATUNATTENDEDWITHTHE
 DOCKSIDEWATERHOSECONNECTED.
-DOCKSIDEWATERSHOULDBECONNECTED
 DURINGPERIODSOFHEAVYWATERUSEONLY.
E
LOCATED UNDER ANCHOR HATCH
STAYCLEAROFMOVINGPARTS
MRP # 1746896 SR-7162
DANGER
!
DOORMUSTBECLOSEDANDLATCHED
FORENGINEHATCHLIFTTOBEACTUATED.
MRP # 1907439 SRS-7425
NOTICE
DO NOT STAND ORWALK ON
THIS AREA SERIOUS INJURY
COULDRESULT.
MRP # 1745515 SR-7216
DANGER
!
I
YOU CAN DIE OR BE SERIOUSLY INJURED BY
BREATHING CARBON MONOXIDE
OR BY THE PROPELLERIF YOU
FALL OVERBOARD.
REAR FACING TRANSOM SEATS MUST NOT
BEUSEDWHILEENGINEISRUNNINGOR
BOAT IS MOVING.
WARNING
!
1792393
K
K
MRP 852558 SR-140
FOREANDAFTSUNPADSSHOULDNOT
BEUSEDWHENVESSELISUNDERWAY.
DANGER
!
F
F
RUNNINGBOATWITHDOOROPENCOULD
INDUCE EXHAUST FUMES INTO CABIN.
SEEOWNER’SMANUALFORINSTRUCTIONS
CONCERNING CARBON MONOXIDE.
MRP # 1743548 SR-7285
WARNING
!
MRP # 1743507 SR-7313
WARNING
!
-SECUREDOORWHENCRUISING.
-DONOTSIT,STAND,ORPLACEHEAVY
OBJECTS ON DOOR.
-KEEPCABINDOORCLOSEDWHENENGINES
OR GENERATOR ARE RUNNING.
- DO NOT USE CAUSTIC MATERIALS TO CLEAN.
-WASHWITHMILDSOAPANDWATER.
B
B
B
H
I

16.4
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
MAXIMUM
0609
IMCI
F
I
N
T
E
R
N
A
T
I
O
N
A
L
C
E
R
T
I
I
C
A
T
I
O
N
Sea
12 1360
Ray
370 SDA
Boats
kg
B
MRP 1746224 SR-7218
IMPORTANTSAFETYANDOPERATIONALINFORMATION
!!
!WARNING
Carbon monoxide (CO) can cause brain damage or death.
Engine and generator exhaust contains odorless and colorless carbon monoxide gas.
Signs of carbon monoxide poisoning include nausea, headache, dizziness, drowsiness,
and lack of consciousness.
Get fresh air if anyone shows signs of carbon monoxide poisoning.
See Owner's Manual for information regarding carbon monoxide poisoning.
NW-204-05
x
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
CO CO
CO
CO
CO
CO
CO
CO
CO
CO
sa f e T Y la b e l lo c a T i o n s (co n T i n u e D )
sa f e T Y la b e l lo c a T I o n s
(fI g . 16.4.1)
C
THIS TAG INSTALLED WHEN BOAT IS ORDERED
WITH CE INTERNATIONAL OPTION
NMMA CERTIFICATION TAG
A
B
A
CHECKBATTERYCELLFLUIDLEVEL
APPROXIMATELYEVERY4WEEKS,ANDMORE
OFTENINSUMMERANDHOTZONES.
MRP # 1746895 SR-7139
NOTICE
STAYCLEAROFMOVINGPARTS
WHILEENGINEISRUNNING.
MRP 1745512 SR-7149
DANGER
!
LEAKINGFUELISAFIREANDEXPLOSION
HAZARD.INSPECTSYSTEMREGULARLY.
EXAMINE FUELTANKS FOR LEAKS OR
CORROSIONATLEASTANNUALLY.
MRP 1745513 SR-7151
WARNING
!
DISCHARGEOFOILPROHIBITED
THE FEDERALWATERPOLLUTIONCONTROLACTPROHIBITSTHE
DISCHARGEOFOILOROILYWASTEINTOORUPONTHENAVIGABLE
WATERSOFTHEUNITEDSTATESORTHEWATERSOFTHECONTIGUOUS
IFSUCHDISCHARGECAUSESAFILMORSHEENUPONORA
DISCOLORATIONOFTHESURFACEOFTHEWATERORCAUSESA
SLUDGEOREMULSIONBENEATHTHESURFACEOFTHEWATER.
VIOLATORSARESUBJECTTOAPENALTYOF$5,000.
MRP 1744737 SR-744
C
VISIBILITYFROMTHESEATEDPOSITIONAT
THISHELMSTATIONISLIMITED.
AVOIDSERIOUSINJURYORDEATHFROMCOLLISIONS.
OPERATIONFROMASTANDINGPOSITION
MAYBENECESSARYTOMAINTAINLOOKOUT
ASREQUIREDBYRULESOFTHEROAD.
READOWNERSMANUAL.
!
MRP 1743528 BCM-714
WARNING
PRIORTOTOWINGVESSEL:
CAUTION
!
• LOCKPROPELLERSHAFT(S)TOPREVENT
DAMAGE TO SHAFT SEAL AND TRANSMISSION
BEARINGS.
• CLOSESEACOCKSONNON-OPERATING
 ENGINESTOPREVENTSEAWATERINGESTION.
MRP 1751885 SR-7203
MRP 1745156 SR-7118
NOTICE
THISBOATISEQUIPPEDWITH
ANOPTIONALDIRECTOVERBOARD
DISCHARGEVALVE.DISCHARGING
OFSEWAGEDIRECTLYOVERBOARD
ISFORUSEWHEREAPPROVEDONLY
D
D
E
E

16.5
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
MRP 1747493 SR-7135
LEAVINGWINDOWOPENCOULD
INDUCEEXHAUSTFUMES
INTOCABINRESULTINGINSEVERE
PERSONALINJURYORDEATH
DANGER
!
NOTICE
EXHAUST FAN MUST BE ON
WHEN USING COOKING
APPLIANCES
MRP #1745124 SR-7106
A
A
MRP 1743616 SR-7154
UNPLUGSHOREPOWERAND
TURNOFFGENERATOR
BEFORE REMOVINGCOVER
DANGER
!
LOCATED ON ALL AC JUNCTION BOXES
B
B
DONOTUSEAFTSUNSHADEINTHEDEPLOYED
POSITIONATSPEEDSINEXCESSOF10MPH.
MRP # 1894013 SR-7418
NOTICE
C
C
DONOTCLIMBUPONORSTORE
EQUIPMENTONHARDTOP
! DANGER
MRP 1765879 SR-7198
D
D
DANGER
!
In all gasoline powered boats, engine and generator exhaust
systems produce colorless and odorless carbon monoxide gas
(“CO”). Direct prolonged exposure can result in CO poisoning
whichmaybe harmfulor fatal.Topreventexcess exposureand
reduce the possibility of accumulations of CO in the cabin and
cockpitoftheboat,theoperatorshouldinsureadequateventilation
ineach thecabin and cockpitareas,throughutilization of cabin
hatches,cabindoors,cabinwindows,cockpitwindshieldwindows
andsidewindshield ventstoincreaseair movementthrough the
cabinandcockpitareas.Thefollowingconditionstendtoincrease
the accumulation of CO in and about the boat and require the
operator’sparticularattention:
1. Operation at slow speeds or dead in the water.
2. Operationwithahighbowangleattitude.
3. Theutilizationofcanvastops,sidecurtainsandback
curtains.
4. Contributingclimaticconditions,suchasaheadwind.
5. Operationofenginesand/orgeneratorinconned
spacesoratdockside.
6. Anyblockageofhullexhaustoutlets.
Indications of excessive exposure to CO concentrations may
includenausea,dizzinessanddrowsiness.
MRP 1746899 SR-7126
!WARNING
Carbon monoxide (CO) can cause brain damage or death.
Carbon monoxide can be present in the cabin.
Signs of carbon monoxide poisoning include nausea, headache,
dizziness, drowsiness, and lack of consciousness.
Get fresh air if anyone shows signs of carbon monoxide poisoning.
Get fresh air is carbon monoxide detector alarm sounds.
Carbon monoxide detoctor must be functioning at all times.
NW-205-05
x
CO
CO
CO
CO
CO CO
CO
CO
CO CO
CO
CO
CO
CO
CO
CO
CO CO
CO
CO
CO
CO
CO
CO
CO
CO
CO
MRP 1747493 SR-7135
LEAVINGWINDOWOPENCOULD
INDUCEEXHAUSTFUMES
INTOCABINRESULTINGINSEVERE
PERSONALINJURYORDEATH
DANGER
!
E
sa f e T Y la b e l lo c a T i o n s (co n T i n u e D )
sa f e T Y la b e l lo c a T I o n s
(fI g . 16.5.1)
E

16.6
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
LOCATED ON INSIDE OF GALLEY CABINET DOOR
Save Our Seas
It is illegal todumpplastictrashanywhereintotheoceanornavigable
watersoftheUnitedStates.Violationoftheserequirementsmayresult
incivilpenaltyupto$25,000,aneof$50,000andimprisonmentforup
toveyears.
PLASTIC - Includes but is
not limited to: plastic bags,
styrofoam cups and lids, six-
pack holders, stirrers, straws,
milk jugs, egg cartons, syn-
thetic fishing nets, ropes, lines,
and bio or photo degradable
plastics.
GARBAGE - Means paper,
rags, glass, metal, crockery
(generated in living spaces
aboard the vessel-what we
normally call trash), and all
kinds of food, maintenance and
cargo-associated waste.
“Garbage” does not include
fresh fish or fish parts, dishwa-
ter, and gray water.
DUNNAGE- Material used to
block and brace cargo, and is
considered a cargo associated
waste.
DISHWATER- Means the liquid
residue from the manual or au-
tomatic washing of dishes and
cooking utensils which, have
been pre-cleaned to the extent
that any food particles adher-
ing to them would not normally
interfere with the operation of
automatic dishwashers.
GRAYWATER - Means drain-
age from a dishwasher, shower,
laundry, bath, and washbasin,
and does not include drainage
from toilets, urinals, hospitals,
and cargo spaces.
(and in U.S. Lakes, Rivers,
Bays and Sounds)
PLASTICS
DUNNAGE, LINING AND PACKING
MATERIALS THAT FLOAT
ANY GARBAGE EXCEPT DISHWATER/
GRAYWATER/FRESH FISH PARTS
PLASTICS
DUNNAGE, LINNING AND PACKING
MATERIALS THAT FLOAT
ANY GARBAGE NOT GROUND TO LESS
THAN ONE SQUARE INCH
PLASTICS
DUNNAGE, LINING AND PACKING
MATERIALS THAT FLOAT
PLASTICS
3 TO 12 MILES
INSIDE 3 MILES
12 TO 25 MILES
12 TO 25 MILES
sa f e T Y la b e l lo c a T i o n s (co n T i n u e D )
sa f e T Y la b e l lo c a T I o n s
(fI g . 16.6.1)

16.7
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
(D)
4. ba s i c bo a T Di M e n s i o n s a n D cl e a r a n c e s
bo a T dI m e n s I o n s a n d cl e a r a n c e s
(fI g . 16.7.1)
(A) Overall Length
With Std. Swim Platform......... 37' 6" 11.43 m
(B) Beam (Width)........................... 12' 0" 3.66 m
(C) Draft (V-Drive........................... 39"* 99 cm*
Draft (Stern Drive Down) ............... 37"* 94 cm*
Draft (Stern Drive Up).................... 27in.* 69 cm*
* MINIMUM WATER DEPTH TO PREVENT RUNNING AGROUND
Dry Weight..................................... 18,100 lbs. 8,200 kg.
Fuel Capacity................................. 225 gal. 851 liters
Usable Fuel ................................... 202 gal. 765 liters
Fresh Water Capacity .................... 50 gal. 189 liters
Holding Tank.................................. 28 gal. 106 liters
Dead Rise...................................... 21°
370 Sundancer®SpecificationS HeigHt dimenSionS
(D) Keel to Top of Mast Light ...............16' 1½" 4.91 m
(E) Waterline to Top of Mast Light........13' 7½" 4.15 m
(F) Waterline to Top of Spoiler .............10' 5½" 3.19 m
(G) Waterline to Top of Windshield ......7' 9" 2.36 m
(A)
WATERLINE
KEEL
(C)
(B)
(E)(F)(G)
NOTE - DIMENSIONS CAN VARY DEPENDING ON LOAD AND RUNNING CONDITIONS.
NOTE: DIMENSIONS CAN VARY DEPENDING ON LOAD
AND RUNNING CONDITIONS

16.8
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
5. fu n c T i o n a n D lo c a T i o n o f Th r o u g h -hu l l cu T o u T s
po r T TH r o u g H -Hu l l cu T o u T s
(fI g . 16.8.1)
bI l g e TH r o u g H -Hu l l cu T o u T s
(fI g . 16.8.3) Tr a n s o m TH r o u g H -Hu l l cu T o u T s
(fI g . 16.8.4)
sT a r b o a r d TH r o u g H -Hu l l cu T o u T s
(fI g . 16.8.2)
HULL WINDOW HEAD PORTLIGHT WATER TANK
VENT
POWER VENT FUEL VENT PORT STORAGE
TUB DRAIN WASTE VENT
MANUAL BILGE
PUMP (CE OPT)
ENGINE EXHAUST
BYPASS
WATER HEATER
VENT
A/C DISCHARGE
COMMON DRAIN
BILGE PUMP
COCKPIT WETBAR/
ETS MODULE DRAIN
FUEL VENT
VACUUM VENT
(OPT)
PORTLIGHT
(INTERNATIONAL OPT) HULL WINDOW
GENERATOR
EXHAUST
ENGINE EXHAUST
BYPASS
A/C PICKUP
PORT RUDDER
STBD RUDDER
STBD ENGINE
EXHAUST
MACERAT OR
(OPT)
PORT ENGINE
EXHAUST PORT SHAFT LOG
STBD SHAFT LO G
STBD ENGINE
SEACOCK
PORT ENGINE
SEACOCK
SPEED
TRANSDUCER
(OPT)
DEPTH
TRANSDUCER
(OPT)
GENERA T OR
PICKUP (OPT)
STERN THRUSTER
(OPT) GARBOARD
DRAIN
ZINC PLAT E

16.9
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
6. he l M , ga u g e & sW i T c h la Y o u T
He l m
(fI g . 16.9.1)
* OPTIONAL EQUIPMENT
VHF RADIO
INSTRUMENT PANEL
COMPASS
VHF RADIO
SPEAKER
NAVIGATION
ELECTRONICS*
AUTO PILOT*
AIR SENSOR
SPOT LIGHT
CONTROL*
ENGINE SYSTEMS
DISPLAY
COMPONENT BOARD &
FUSE BLOCK ACCESS
STBD SWITCH
PANEL
IGNITION SWITCH
PANEL
BOW THRUSTER
CONTROL
PORT SWITCH
PANEL
STEREO REMOTE
THROTTLE & SHIFT
CONTROLS

16.10
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
co n T r o l sT a T I o n po r T sW I T c H pa d
(fI g . 16.10.1)
co n T r o l sT a T I o n sT a r b o a r d sW I T c H pa d
(fI g . 16.10.2)

16.11
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
7. De c k la Y o u T
de c k la Y o u T
(fI g . 16.11.1)
SWIM LADDER W/
OPTIONAL PLATFORM
PORT DASH/
STORAGE
AFT SEAT
(W/ STORAGE BELOW)
FOLDOUT
AFT FACING
TRANSOM SEAT
SPOT LIGHT (OPT)
PORT NAV LIGHT
WINDLASS FOOT
SWITCHES
COCKPIT TABLE
CABIN ENTRY
DOOR
SKY LIGHT
ANCHOR DAVIT
PORT SWIVEL SEAT
TRANSOM
STORAGE
12V RECEPTACLE (IN
SIDE PANEL STORAGE)
CONTROL STATION
ROPE LOCKER
(WINDLASS)
STARBOARD NAV LIGHT
WET BAR
FUEL FILL
SWIM PLATFORM
(OPT)
GRILL (OPT)
PIVOTING
HELM SEAT
TRANSOM
WALK-THRU
HORN
DECK HATCH
(EMERGENCY EXIT)
ENGINE HATCH
STANDARD SWIM
LADDER
SWIM PLATFORM
(STANDARD)

16.12
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
8. ca b i n la Y o u T
ca b I n la Y o u T
(fI g . 16.12.1)
V-BERTH
GALLEY SINK
STOVE
MICROWAVE
HEAD SINK
HEAD / SHOWER
V-BERTH PRIVACY
CURTAQIN
REMOVABLE
SALON TABLE
CONVERTABLE
SOFA / BERTH
MDP CABINET
MID-BERTH PRIVACY
CURTAIN
MID-BERTH
CONVERTABLE SOFA

16.13
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
9. cl e a T s
Cleatsmustnotbeusedforliftingtheboat; they
are intended for docking or mooring use only.
cl e a T lo c a T I o n s
(fI g . 16.13.1)
11. li g h T i n g
See General Information Sections for a detailed
explanation of the lighting.
*
*
*
*
*
*
*
*
10. na v i g a T i o n a n D an c h o r li g h T s
See General Information Sections for a detailed
explanation of the anchor lights.
NAVIGATION
LIGHT SWITCH
ANCHOR LIGHT
SWITCH
na v I g a T I o n a n d an c H o r lI g H T s
(fI g . 16.13.2)
MAST LIGHT
PORT & STBD
NAVIGATION
LIGHTS
PORT SWITCH
PANEL
ALL-ROUND/
ANCHOR LIGHT
CLEAT
CLEAT
CLEAT CLEAT
CLEAT
CLEAT

16.14
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
lI g H T I n g la Y o u T
(fI g . 16.14.1)
li g h T i n g (co n T i n u e D )
E
AA
A
A
A
A
A
BB
BB
BB
BB
CC
C
C
C
C
C
C
C
D
E
E
BULB REPLACEMENT
BULB# GE2641L
12V R 10W
G
PORT&STBD
NAV.LIGHTS
STERNNAV./
ANCHORLIGHT
BULB REPLACEMENT
FUSE TYPE BULB
#12V10WPERKO
H
RECTANGLELIGHT
(INBILGEAREA)
BULB
REPLACEMENT
BULB#CEC1141
I
COCKPITLIGHT
BULB REPLACEMENT
FUSE TYPE BULB
#12V10WPERKO #70-0
F
G
H
F
G
F
F
F
F
FF
READINGLIGHT
BULB REPLACEMENT
HALOGEN 12V 10W
BI-PRONG
A
LED LIGHT - NO
REPLACEMENT BULB
LEDLIGHTS
B
EYEBALLLIGHT
BULB REPLACEMENT
XENON HALOGEN
G4 12V/10W
C
SHOWERLIGHT
BULB REPLACEMENT
XENON “XH” MINIATURE
HALOGEN BI-PIN, 24V/10W
D
LED LIGHT - NO
REPLACEMENT BULB
LEDSTEPLIGHT
E

16.15
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
A/C UNIT
FRESH WATER
TANK
FUEL TANKS
EMERGENCY
HIGH WATER
BILGE PUMP
TRIM TABS
PUMPBILGE BLOWER
PORT ENGINE
BATTERIES
GENERATOR
FUEL FILTER
TRANSDUCER
GENERATOR
(OPT)
GENERATOR
SEACOCK (OPT)
GENERATOR
STRAINER (OPT)
GENERATOR
MUFFLER (OPT)
PORT POWER
TRIM PUMP
A/C SEACOCK
FLOAT SWITCHES
GENERATOR
BATTERY
bI l g e la Y o u T (ga s sT e r n dr I v e )
(fI g . 16.15.1)
PORT ENGINE
BATTERIES
A/C
STRAINER
FRESH WATER
PUMP
WASTE WATER
HOLDING TANK
WASTE VENT FILTER
MACERATOR (OPT)
VACUUM
GENERATOR
WASTE DISCHARGE
SEACOCK (OPT)
WATER HEATER
PORT POWER
TRIM PUMP
A/C PUMP
BILGE BLOWER
BILGE PUMP
12. bi l g e la Y o u T

16.16
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
A/C UNIT
FRESH WATER
TANK
FUEL TANKS
EMERGENCY
HIGH WATER
BILGE PUMP
TRIM TABS
PUMPBILGE BLOWER
PORT ENGINE
BATTERIES
GENERATOR
FUEL FILTER
TRANSDUCER
GENERATOR
(OPT)
GENERATOR
SEACOCK (OPT)
GENERATOR
STRAINER (OPT)
GENERATOR
MUFFLER (OPT)
PORT POWER
TRIM PUMP
A/C SEACOCK
FLOAT SWITCHES
GENERATOR
BATTERY
bI l g e la Y o u T (dI e s e l sT e r n dr I v e )
(fI g . 16.16.1)
PORT ENGINE
BATTERIES
A/C
STRAINER
FRESH WATER
PUMP
WASTE WATER
HOLDING TANK
WASTE VENT FILTER
MACERATOR (OPT)
VACUUM
GENERATOR
WASTE DISCHARGE
SEACOCK (OPT)
WATER HEATER
PORT POWER
TRIM PUMP
A/C PUMP
BILGE BLOWER
BILGE PUMP

16.17
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
A/C UNIT
FRESH WATER
TANK
FRESH WATER
PUMP
WASTE WATER
HOLDING TANK
WASTE VENT FILTER
MACERATOR (OPT)
VACUUM
GENERATOR
A/C PUMP
FUEL TANKS
EMERGENCY
HIGH WATER
BILGE PUMP
WASTE DISCHARGE
SEACOCK (OPT)
BILGE PUMPBILGE BLOWERS
PORT ENGINE
BATTERIES
PORT ENGINE
RAW WATER
STRAINER
PORT ENGINE
RAW WATER
SEACOCK
WATER HEATER
PORT ENGINE
BATTERIES
PORT ENGINE
RAW WATER
STRAINER
PORT ENGINE
RAW WATER
SEACOCK
GENERATOR
FUEL FILTER
AUTO PILOT
PUMP
EMERGENCY
HIGH WATER
FLOAT SWITCH
TRANSDUCERS
GENERATOR
(OPT)
GENERATOR
SEACOCK (OPT)
GENERATOR
STRAINER (OPT)
GENERATOR
MUFFLER (OPT)
PORT ENGINE
MUFFLER
STBD ENGINE
MUFFLER
A/C SEACOCK
FLOAT SWITCH
A/C STRAINER
GENERATOR
BATTERY
bI l g e la Y o u T (ga s v-dr I v e )
(fI g . 16.17.1)

16.18
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
A/C UNIT
FRESH WATER
TANK
FRESH WATER
PUMP
WASTE WATER
HOLDING TANK
WASTE VENT FILTER
MACERATOR (OPT)
VACUUM
GENERATOR
A/C PUMP
FUEL TANKS
EMERGENCY
HIGH WATER
BILGE PUMP
WASTE DISCHARGE
SEACOCK (OPT)
BILGE PUMPBILGE BLOWERS
PORT ENGINE
BATTERIES
PORT ENGINE
RAW WATER
STRAINER
PORT ENGINE
RAW WATER
SEACOCK
WATER HEATER
PORT ENGINE
BATTERIES
PORT ENGINE
RAW WATER
STRAINER
PORT ENGINE
RAW WATER
SEACOCK
GENERATOR
FUEL FILTER
AUTO PILOT
PUMP
EMERGENCY
HIGH WATER
FLOAT SWITCH
GENERATOR
(OPT)
GENERATOR
SEACOCK (OPT)
GENERATOR
STRAINER (OPT)
GENERATOR
MUFFLER (OPT)
PORT ENGINE
MUFFLER
STBD ENGINE
MUFFLER
A/C SEACOCK
FLOAT SWITCH
A/C STRAINER
GENERATOR
BATTERY
bI l g e la Y o u T (dI e s e l v-dr I v e )
(fI g . 16.18.1)
TRANSDUCER

16.19
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
14. fu e l sY s T e M
a. ga s o l i n e fu e l sY s T e M
The gasoline fuel system on your 370SDA consists
of 2 fuel tanks with a combined capacity of 225 gal.
(851 liter), fuel tank vents, electronic shutoff valves,
ultrasonic sending units, engine fuel supply lines
and fuel fills (generator fuel supply line and fuel
filter included in generator option).
b. Di e s e l fu e l sY s T e M (op T i o n a l )
The diesel fuel system consists of 2 fuel tanks with
a combined capacity of 225 gal. (851 liter), fuel tank
vents, engine fuel supply and return lines, fuel filters
and fuel fills (generator fuel supply and return lines
and filters included in generator option).
16. af T fa c i n g Tr a n s o M se a T
The foldaway aft facing transom seat is intended
for use only when the engine is not running and the
boat is not underway.
Youcandieorbeseriouslyinjuredbybreathingcarbon
monoxideorbythepropellerifyoufalloverboard.
Rear facing transom seats must not be used while
engineisrunningorboatismoving.
! WARNING
15. Wa T e r sY s T e M
The fresh water system on the 370SDA consists of
a 50 gal. (189 liter) tank, 12v water pump, 120v 6
gal. (22.5 liter) water heater, 3 faucets (galley, head
compartment and cockpit wet bar), cockpit shower
(hot and cold) and a fresh water washdown spigot.
Refer to the General Information Sections for a
detailed explanation of the water system.
13. fi r e ex T i n g u i s h i n g sY s T e M
Your 370SDA has an automatic fire extinguisher
system installed standard. Refer to the General
Information Sections for a detailed explanation of
the automatic fire extinguisher system.
fu e l sY s T e m (ga s sT e r n dr I v e W/ ge n e r a T o r op T sH o W n )
(fI g . 16.19.1)
FUEL TANKS
FUEL TANK VENT
FUEL TANK VENT
FUEL FILL
FUEL FILL
ENGINE FUEL SUPPLY
GENERATOR FUEL
SUPPLY
GENERATOR ELECTRIC
SHUTOFF VALVE
GENERATOR
FUEL FILTER
ENGINE ELECTRIC
SHUTOFF VALVE
ENGINE ELECTRIC
SHUTOFF VALVE

16.20
370 su n d a n c e r ®sp e c I f I c In f o r m a T I o n
370 Sundancer®
fu e l sY s T e m (dI e s e l sT e r n dr I v e W/ ge n e r a T o r op T sH o W n )
(fI g . 16.20.1)
FUEL TANKS
FUEL TANK VENT
FUEL TANK VENT
FUEL FILL
FUEL FILL
ENGINE FUEL SUPPLY
ENGINE FUEL RETURN
GENERATOR FUEL
SUPPLY
GENERATOR FUEL
RETURN
GENERATOR
FUEL FILTER
ENGINE FUEL
FILTER
ENGINE FUEL
FILTER
17. en T e r T a i n M e n T sY s T e M
The standard entertainment system on your
370SDA consists of a 12V AM/FM single CD &
satellite radio receiver, a remote MP3 port, amplifier,
speakers (2 Cabin, 4 Cockpit, 2 transom), digital
cockpit remote control, flat screen TV, DVD player
and a game system input port. An addition stereo
remote on the transom is available.
An optional Premium Cockpit Sound System is
available (in addition to the cabin stereo). It includes
upgraded speakers, subwoofer, amplifier and
transom stereo remote.
An optional removable TV with dedicated storage
is available in the cockpit. An optional TV with DVD
player and game system port is optionally available
in the V-Berth and Mid-Stateroom.
sa l o n sT a r b o a r d ca b I n e T
(fI g . 16.20.2)
FWD
STBD
PORT
Cabinet door removed for clarity
ENTERTAINMENT
SYSTEM
A/V INPUT MP3 PORT MDP CABINET
