Seada SD-MV-CM61 User manual
S h o w i n g t h e Wo r l d
SD-MV-CM61
4K@60 6X1 Multiviewer with Audio Switching
All Rights Reserved
Version: 02
SD-MV-CM61 4K@60 6X1 Multiviewer
Catalogue
1. Introduction ...........................................................................................................2
2. Feature ...................................................................................................................2
3. Specifications .........................................................................................................3
4. Operation Controls and Functions..........................................................................4
4.1 Front Panel.........................................................................................................4
4.2 Rear Panel ..........................................................................................................5
5. Setup......................................................................................................................6
5.1 Wiring Diagram.........................................................................................6
6. Operating ...............................................................................................................7
6.1 Standby Mode and Work Mode .........................................................................7
6.2 Screen layout Configuration...............................................................................8
6.2.1 Single Window .......................................................................................10
6.2.2 Double Windows....................................................................................11
6.2.3 Triple Windows.......................................................................................13
6.2.4 Quadruple Windows ..............................................................................14
6.3 Output Resolution............................................................................................16
6.4 Audio Setting..........................................................................................17
6.4.1 Audio Input Select..................................................................................17
6.4.2 Audio Outputs........................................................................................18
6.5 Advanced Settings ...........................................................................................19
6.5.1 RS232 Setting.........................................................................................19
6.5.2 IP Obtain ................................................................................................19
6.5.3 WEB Control...........................................................................................20
6.6 Firmware Update..............................................................................................36
6.7 Auto Layout .....................................................................................................37
7. Command List ......................................................................................................39
SD-MV-CM61 4K@60 6X1 Multiviewer
1. Introduction
SD-MV-CM61 is a standard alone Multiview controller, which could accept up to 6 inputs
and combine any 4 onto a multiple-window layout display at the same time. It supports
HDCP, up to 4K@60 input and 4K@60 output.
It also has built-in audio switching with de-embedding in 6X1 mode, 1 SPDIF output and
1 analog output for audio processing.
2. Feature
⚫Multiple inputs: 4 x HDMI, 2 x DisplayPort.
⚫Up to 4 sources on a single screen with up to 4K 60Hz input and output.
⚫Support various resolutions, up to 3840 x 2160 @60Hz.
⚫Support up to 32 layouts including 16 pre-defined layouts and 16 customizable
layouts.
⚫HDCP 2.2 & 1.4 compliant.
⚫Fast input switching
⚫Built-in audio switching with de-embedding in 6X1 mode.
⚫User-friendly Web GUI.
⚫Support various control methods: Front panel, LAN (Web GUI, TCP)
and RS232
⚫Support in application programming (IAP) through Web GUI (LAN) & USB port.
⚫1 U Height, 19” width standard enclosure, rack mountable design.
SD-MV-CM61 4K@60 6X1 Multiviewer
3. Specifications
Video
Input Interface
4 × HDMI IN, 2 x DP IN
Input Specification
HDMI：HDMI 2.0a
DisplayPort: DP1.2a
HDCP: HDMI 2.0, DP 1.4
Input Resolution
Up to 3840 x 2160@60Hz
Input Electrical Level
0.5-1.0 V peak to peak value
Output Interface
1 x HDMI OUT
Output Specification
HDMI 2.0
Output Resolution
Up to 3840 x 2160@60Hz
Output Impedance
100 Ω
DDC Signal
1.2 V peak to peak value
Audio
Input Interface
6 x 3.5mm stereo jack
Output Interface
1 x 3.5mm stereo jack
1 x optical fiber terminal
General
Power Supply
110~240V AC
Power Dissipation
15W
Control Mode
RS232，LAN
Work Temperature
0°C to 35°C (32°F to 95°F)
10% to 90%, no condensation
Storing Temperature
-20°C to 70°C (-4°F to 140°F)
10% to 90%, no condensation
Product size
(L x W x H)
440mm x 272mm x 43.5mm
Product Weight
3.16kg
SD-MV-CM61 4K@60 6X1 Multiviewer
4. Operation Controls and Functions
4.1 Front Panel
ID
Name
Description
1
Input Buttons and
Indicators
Press the buttons 1~6 to select the corresponding
video or audio input. The indicators mean the
corresponding status of the video or audio input.
2
Audio Selection
Button and Indicator
Press this button, then the indicator lights up,
meaning switching between audio outputs.
3
Layout Button and
Indicator
Press this button and the input button 1~6 to select
the first 1-6 default layout
4
Video Window Mode
Button and Indicator
Video window mode selection: single window,
double windows, triple windows, and quadruple
windows. The indicators show which mode is on.
5
Lock
Press this button and indicator lighting up meaning
all the buttons at front panel are locked until
pressing this button again to unlock it.
6
Standby button and
indicator
⚫Switches between standby and working mode.
⚫When this device is switched to the standby
mode, the indicator lights up.
When this device is switched to working mode, the
indicator will be off.
7
Power Indicator
Indicates when the units have power.
SD-MV-CM61 4K@60 6X1 Multiviewer
4.2 Rear Panel
ID
Name
Description
1
Power Socket
Turn the power ON or OFF using this switch. Connect
to an 110/220 AC Power electrical outlet.
2
Optical output
Connect the optical output port to the digital audio
input port of your amplifier
3
Stereo audio output
2 channel analog audio output. Connect to multimedia
system using cable with a 3.5mm jack
4
HDMI output
Connect to a display with HDMI cable
5
Analog audio input
1~6
2 channel stereo analog audio input, Connect a 3.5mm
mini-stereo cable from the Line Out jack on the audio
source to this jack.
6
HDMI input 1~4
Connect video sources to these inputs using HDMI
cables.
7
DisplayPort input
1~2
Connect video sources to these inputs using
DisplayPort cables.
8
USB Port
Upgrading service port
9
IP Cont.
Connect to a PC/laptop/3rd controller via a network
cable for TCP/IP controlling
10
RS-232
Connect to a PC/laptop/3rd controller via a serial cable
for serial commands controlling
SD-MV-CM61 4K@60 6X1 Multiviewer
5. Setup
1. Connect HDMI sources to the input ports (HDMI 1 - HDMI 4), Connect
DisplayPort sources to the input ports (DISPLAYPORT 5 - DISPLAYPORT 6) on
the SD-MV-CM61
2. Connect any analog audio inputs to 3.5mm jack sockets on SD-MV-CM61 if
needed.
3. Connect a screen or any video receiver to the HDMI Output port on SD-MV-
CM61. Make sure the HDMI output resolution is right for the receiver.
4. Connect the audio outputs of SD-MV-CM61 to any speakers or amplifiers if
needed.
5. Connect an RS-232 cable from the RS-232 port on SD-MV-CM61to the RS-232
connector on the serial controller for controlling if needed.
6. Connect an Ethernet cable from the LAN port on the SD-MV-CM61 to a Local
Area Network (LAN) for controlling if needed.
7. Connect the AC power cord to the SD-MV-CM61 and connect the plug to an
available electrical outlet.
5.1 Wiring Diagram
SD-MV-CM61 4K@60 6X1 Multiviewer
6. Operating
6.1 Standby Mode and Work Mode
The “PWR” LED next to the Standby button, on the front panel, indicates the power
state of the SD-MV-CM61. This indicator will be red and remain illuminated if the
power is being supplied to the SD-MV-CM61. If this indicator does not illuminate,
check the connection between the power receptacle on the SD-MV-CM61 and the AC
outlet.
The Standby button could be pressed to enter into Standby mode at any time. When
Standby mode is activated, all front panel back-lit LED indicators are off, except the
Standby indicator and the PWR indicators, until pressing the standby button again to
wake up the unit. There are three ways to wake up the device: pressing Standby button
or using Web GUI or RS232 commands.
SD-MV-CM61 4K@60 6X1 Multiviewer
6.2 Screen layout Configuration
SD-MV-CM61 offers four layout modes: Quadruple Windows, Triple Windows, Double
Windows, and Single Window. The screen configuration is shown as follows.
Press the combination key (LAYOUT + Input 1~6) in the Key Button of the SD-MV-CM61,
corresponding to the four modes above. For example, if you want to use the mode of
quadruple windows, press the button to which LAYOUT + Input 4 is displayed or the
button in the remote, the button indicator on the panel lights up, the picture output to
the display device through HDMI shows quadruple windows, meanwhile, video 1~4
indicators will light up.
SD-MV-CM61 4K@60 6X1 Multiviewer
SD-MV-CM61 can display up to four sources. When multiple sources are displayed on
the screen, each source is regarded as a single window, and each window is defined as
an input. However, we want to define the operation in the single window to introduce
the basic operation before introduction to the operation in multiple windows. In the
following example, six video sources (each of them is displayed as a single picture) are
connected to SD-MV-CM61. When SD-MV-CM61 is delivered from the factory, the
default settings are loaded automatically. (See below)
SD-MV-CM61 4K@60 6X1 Multiviewer
6.2.1 Single Window
1) Use the LAYOUT + input 1 button on the front panel to set to the single window
mode, Video 1 button indicator lights up, input 1 indicator lights up.
2) HDMI output configures the HDMI1 input, the window is shown as follows.
3) If you want to switch to the signal of DisplayPort5.
Method 1: directly press the INPUTS 5 button on the front panel.
Method 2: first press Video 1 button on the front panel,
the 1 button indicator on the panel turns solid on, 2~6 button indicators are blinking
(If an indicator is solid on, it means the source currently selected; If an indicator is
SD-MV-CM61 4K@60 6X1 Multiviewer
blinking, it means the source which can be selected), press the INPUTS 5 button on
the front panel.
4) The input 5 button indicator lights up, the panel status is shown as follows.
5) HDMI output picture is changed to the signal of DisplayPort5.
6.2.2 Double Windows
1) Use the LAYOUT + input 2 button on the front panel to set to the mode of double
windows, Video 1 and 2 button indicators on the front panel light on.
2) HDMI output port outputs the mode of double windows. Window 1 is configured to
HDMI1 input (HDMI1 is the factory default. It will show the last configurate being
used); Window 2 is configured to HDMI2 input (HDMI2 is the factory default. It will
show the last configurate being used). The windows are shown as follows.
SD-MV-CM61 4K@60 6X1 Multiviewer
3) For example, if you want to switch INPUT 5 to Window 1.
Method 1: directly press the INPUTS 5 button on the front panel, the Video 1 and 2
button indicators blink (indicates that the two buttons can be selected), press the
Video 1 button on the front panel to select Window 1.
Method 2: first press the Video 1 button on the front panel, the 1 button indicator
on the panel turns solid on, 2~6 button indicators are blinking (If an indicator is solid
on, it means the source currently selected; If an indicator is blinking, it means this
source can be selected), press the INPUTS 5 button on the front panel.
4) Windows 2 can select DisplayPort6 using the same method.
5) When the INPUTS indicators are off, the panel status is shown as follows.
6) HDMI output picture is changed to the status below.
SD-MV-CM61 4K@60 6X1 Multiviewer
6.2.3 Triple Windows
1) Use the LAYOUT + input 3 button on the front panel to set to the mode of triple
windows, Video 1, 2 and 3 button indicators on the front panel light up.
2) HDMI output port outputs the mode of triple windows. Window 1 is configured to
HDMI1 input (HDMI1 is the factory default. If any changes are made, use the last
configuration); Window 2 is configured to HDMI2 input (HDMI2 is the factory default.
It will show the last configurate being used); Window 3 is configured to HDMI3 input
(HDMI3 is the factory default. It will show the last configurate being used). The
windows are shown as follows.
3) For example, if you want to switch to Window 1, and if you want to switch the signal
of DisplayPort5.
Method 1: directly press the INPUTS 5 button on the front panel, the Video 1 and 2
button indicators blink (indicates the two buttons can be selected), press the Video
1 button on the front panel to select Window 1.
Method 2: first press the Video 1 button on the front panel, the 1 button indicator
on the panel turns solid on, 2~6 button indicators are blinking (If an indicator is solid
on, it means the source currently selected; If an indicator is blinking, it means this
source can be selected), press the INPUTS 1 button on the front panel.
4) In the same methods, Window 2 can select DisplayPort5, and Window 3 can select
HDMI1.
5) When the INPUTS indicators are off, the panel status is shown as follows.
SD-MV-CM61 4K@60 6X1 Multiviewer
6) HDMI output picture is changed to the following status.
6.2.4 Quadruple Windows
1) Use the LAYOUT + input 4 button on the front panel to set to the mode of quadruple
windows, Video 1, 2, 3 and 4 button indicators on the front panel light up.
2) HDMI output port outputs the mode of quadruple windows. Window 1 is configured
to HDMI1 input (HDMI1 is the factory default. It will show the last configurate being
used); Window 2 is configured to HDMI2 input (HDMI2 is the factory default. It will
show the last configurate being used); Window 3 is configured to HDMI3 input
(HDMI3 is the factory default. It will show the last configurate being used); Window
4 is configured to HDMI4 input (HDMI4 is the factory default. It will show the last
configurate being used). The windows are shown as follows.
SD-MV-CM61 4K@60 6X1 Multiviewer
3) For example, if you want to switch to Window 1, and if you want to switch the signal
of DisplayPort5.
Method 1: directly press the INPUTS 5 button on the front panel, the Video 1 and 2
button indicators blink (indicates the two buttons can be selected), press the Video
1 button on the front panel to select Window 1.
Method 2: first press the Video 1 button on the front panel, the 1 button indicator
on the panel turns solid on, 2~6 button indicators are blinking (If an indicator is solid
on, it means the source currently selected; If an indicator is blinking, it means this
source can be selected), press the INPUTS 1 button on the front panel.
4) In the same methods, Window 2 can select DisplayPort6, Window 3 can select
HDMI2, and Window 4 can select HDMI1.
5) When the INPUTS indicators are off, the panel status is shown as follows.
6) HDMI output picture is changed to the following status.
SD-MV-CM61 4K@60 6X1 Multiviewer
6.3 Output Resolution
HDMI output resolutions support multiple modes with the indicator indication.
1) Auto
2) 3840 x 2160 @60Hz
3) 3840 x 2160 @30Hz
4) 3840 x 2160 @24Hz
5) 1920 x 1200 @60Hz
6) 1920 x 1080 @ 60Hz
7) 1920 x 1080 @ 50Hz
8) 1600 x 1200 @ 60Hz
9) 1680 x 1050 @ 60HZ
10) 1600 x 900 @ 60Hz_R
11) 1400 x 1050 @60Hz
12) 1440 x 900 @60Hz
13) 1360 x 768 @60Hz
14) 1280 x 1024 @60Hz
15) 1280 x 720 @60Hz
16) 1280 x 800 @60Hz_R
17) 1280 x 768 @60Hz
18) 1280 x 720 @50Hz
19) 1024 x 768 @60Hz
20) 800 x 600 @60Hz
Auto means that it outputs the HDMI resolutions based on the EDID information read
from the display device.
Operation method: press the Resolution buttons on the panel to switch between different
HDMI output resolutions. When a resolution is selected, the corresponding indicator
lights up. When selecting a resolution, HDMI output is switched to this resolution.
SD-MV-CM61 4K@60 6X1 Multiviewer
6.4 Audio Setting
6.4.1 Audio Input Select
When selecting the video input, the audio also has six inputs. When the video input is
selected as HDMI or DisplayPort, the audio input will be from either HDMI digital audio
or analog stereo audio via the 3.5mm earphone jack of the audio input, according to the
priority rule as below
⚫Auto: HDMI embedded audio > External stereo audio
⚫External: External stereo audio input
⚫Internal: HDMI embedded audio
When “Auto” is selected
1. When both HDMI or DisplayPort input and analog stereo audio input have active
audio, the audio input select is from HDMI or DisplayPort digital audio
2. When only HDMI or DisplayPort input have active audio, the audio input select is
from HDMI or Display digital audio
3. When only analog stereo audio input has active audio, the audio input select is
from the 3.5mm earphone jack of the audio input
When “External” is selected, the audio input select is from the 3.5mm earphone jack of
the audio input.
When “Internal” is selected, the audio input select is from the HDMI or DisplayPort digital
audio.
SD-MV-CM61 4K@60 6X1 Multiviewer
Operations for audio switching:
Method 1:
(1). Press “Audio Button” (in front buttons), the corresponding button backlit
indicator lights up, which means the audio output is selected. The Inputs indicator of
the corresponding audio source turns solid on, the other indicators blink.
(2). Press “Inputs Button” (in front buttons), the audio is switched to this channel. At
the same time, other inputs indicator all off.
(3). In the status mentioned in Step (2), if no further operation is performed within 5
seconds, it exists from this status.
Method 2:
(1). Press “Inputs Button” (in front buttons), the corresponding indicator lights up,
which means the audio input is selected. The “Audio Selection Button” blinks to be
ready for selecting.
(2). Press “Audio Button” (in front buttons), the input selected audio in step#1 is
switched to program audio output channel. At the same time, Inputs indicator and
audio indicator are off.
(3). In the status mentioned in Step (2), if no further operation is performed within 5
seconds, it exists from this status.
Note:
(1). Press audio button (the Inputs indicator of the corresponding audio source
turns solid on, the other indicators blink) to confirm the current audio selected
channel
(2). HDMI and DisplayPort have a 3.5mm earphone jack of stereo audio, if HDMI or
DisplayPort input signal with audio format, voice output is the digital audio signal, if
the signal without audio format, then automatically switch to 3.5 earphone
input analog stereo.
6.4.2 Audio Outputs
There are three methods of audio output:
(1). HDMI output
(2). Optical output
SD-MV-CM61 4K@60 6X1 Multiviewer
(3). Analog output, 2 channels for audio output
6.5 Advanced Settings
6.5.1 RS232 Setting
Connect to RXD, TXD, GND only
RS-232 Settings:
Description
Setting
Baud rate
115200
Data bits
8
Parity
None
Stop bits
1
Hardware flow control
None
For more information about serial command lines, see the chapter of commands.
6.5.2 IP Obtain
SD-MV-CM61 supports IP control, WEB GUI、TCP and so on. The default IP address is
192.168.1.200, port:23.
If users have modified the IP address and lost it. users can obtain the IP address and port
number via the information from the on-screen display (OSD). Either single window or
multiple window display, users could press any input button to see the IP address and
port number on main screen.
Table of contents
Other Seada Monitor manuals
