Constellation® ES
High-capacity storage designed for seamless
enterprise integration
Data Sheet
FIPS 140-2 INSIDE
2TB, 1TB and 500GB •7200 RPM •
3.5-inch form factor •6Gb/s SAS and SATA 6Gb/s
Key Advantages
•Fifth-generation, enterprise, nearline drive designed for 24×7 operation
•Up to 2TB capacity for data-hungry enterprise business applications
•Best-in-class enhanced rotational vibration tolerance ensures unrivalled
performance in high-density applications for continuous data access.
•Enhanced efficiencies with PowerChoice™ host-selectable power options
for unprecedented savings during slow or idle periods
•Seagate RAID Rebuild™ development platform significantly reduces hours
of lost productivity.
•Multi-drive firmware maximized for enterprise system availability
•Robust performance with dual processor and ramp load technologies
(35% average sustained throughput increase over previous generation)
•Provides business sustainability with Seagate Unified Storage architecture
- 6Gb/s SAS performance with error detection and correction
(IOEDC/IOECC) capabilities and PI (Protection Information)
- Self-Encrypting Drive (SED) option cuts IT drive retirement expenses
while securely protecting data and is one of the easiest, most
cost-effective security measures you can implement.1
- FIPS Self-Encrypting Drive option provides all the benefits of SED
and is NIST certified to meet U.S., Canada and U.K. government data
encryption compliance requirements.1, 2
Best-Fit Applications
•High-capacity data center storage
•Mainstream enterprise external storage arrays (SAN, NAS, DAS)
•Enterprise backup and restore—D2D, virtual tape
•Centralized surveillance
•Cloud storage
1 Self-Encrypting Drive (SED) and FIPS Self-Encrypting Drive options require
TCG-compliant host or controller support. Not available in all countries.
2 See FIPS 140-2 Level 2 Certificate at
http://csrc.nist.gov/groups/STM/cmvp/documents/140-1/1401vend.htm.

Constellation®ES
High-capacity storage designed for seamless
enterprise integration
Copyright © 2011 Seagate Technology LLC. All rights reserved. Printed in USA. Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries.
Constellation and PowerChoice are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST,
which does not imply product endorsement by NIST, the U.S., or Canadian governments. All other trademarks or registered trademarks are the property of their respective owners. When referring to drive capacity, one gigabyte, or GB,
equals one billion bytes and one terabyte, or TB, equals one trillion bytes. Your computer’s operating system may use a different standard of measurement and report a lower capacity. In addition, some of the listed capacity is used
for formatting and other functions, and thus will not be available for data storage. The export or re-export of hardware or software containing encryption may be regulated by the U.S. Department of Commerce, Bureau of Industry and
Security (for more information, visit www.bis.doc.gov), and controlled for import and use outside of the U.S. Seagate reserves the right to change, without notice, product offerings or specifications. DS1697.4-1103US, March 2011
seagate.com
1-800-SEAGATE (1-800-732-4283)
Specifications 6Gb/s SAS SATA 6Gb/s SATA 3Gb/s
2TB11TB1500GB12TB11TB1500GB12TB11TB1500GB1
Standard Model ST32000444SS
ST2000NM00015
ST31000424SS
ST1000NM00015
ST3500414SS
ST500NM00015ST2000NM0011 ST1000NM0011 ST500NM0011 ST32000644NS ST31000524NS ST3500514NS
SED 256 Model ST2000NM00212ST1000NM00212ST500NM00212ST2000NM00312ST1000NM00312ST500NM00312
SED 128 Model ST32000445SS2ST31000425SS2ST3500415SS2
SED 128 with FIPS Model ST32000446SS3ST31000426SS3ST3500416SS3
Features
Protection Information Yes5Yes5Yes5——————
Low Halogen Yes Yes Yes Yes Yes Yes Yes Yes Yes
Self-Encrypted Drive (SED) Option Yes Yes Yes Yes Yes Yes ———
Configuration/Organization
Bytes per Sector 512, 520, 528 512, 520, 528 512, 520, 528 512 512 512 512 512 512
Reliability/Data Integrity
Power-On Hours (annual) 8760 8760 8760 8760 8760 8760 8760 8760 8760
Mean Time Between Failures (MTBF,
hours) 1.2 million 1.2 million 1.2 million 1.2 million 1.2 million 1.2 million 1.2 million 1.2 million 1.2 million
Reliability Rating at Full 24x7 Operation
(AFR) 0.73% 0.73% 0.73% 0.73% 0.73% 0.73% 0.73% 0.73% 0.73%
Nonrecoverable Read Errors per Bits Read 1 sector per 10E15 1 sector per 10E15 1 sector per 10E15 1 sector per 10E15 1 sector per 10E15 1 sector per 10E15 1 sector per 10E15 1 sector per 10E15 1 sector per 10E15
IOEDC (I/O Error Dectection Code) Reads/Writes Reads/Writes Reads/Writes Reads/Writes Reads/Writes Reads/Writes Reads/Writes Reads/Writes Reads/Writes
IOECC (I/O Error Correction Code) Reads/Writes Reads/Writes Reads/Writes Writes Writes Writes Writes Writes Writes
Load/Unload Cycles (at 40°C) 300,000 300,000 300,000 300,000 300,000 300,000 300,000 300,000 300,000
Interface Ports Dual Dual Dual Single Single Single Single Single Single
Limited Warranty (years) 555555555
Performance
Spindle Speed (RPM) 7200 7200 7200 7200 7200 7200 7200 7200 7200
Seek Time, Average Read/Write (ms) 8.5/9.5 8.5/9.5 8.5/9.5 8.5/9.5 8.5/9.5 8.5/9.5 8.5/9.5 8.5/9.5 8.5/9.5
Max Sustained Transfer Rate (MB/s) 150 150 150 140 150 150 140 140 140
Cache, Multisegmented (MB) Up to 64 Up to 64 Up to 64 64 64 64 64 32 32
Interface Access Speed (Gb/s) 6.0, 3.0, 1.5 6.0, 3.0, 1.5 6.0, 3.0, 1.5 6.0, 3.0, 1.5 6.0, 3.0, 1.5 6.0, 3.0, 1.5 3.0, 1.5 3.0, 1.5 3.0, 1.5
Rotational Vibration @ 1500Hz (rad/s²) 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5
Power Management
Power Supply Requirements +12V and +5V +12V and +5V +12V and +5V +12V and +5V +12V and +5V +12V and +5V +12V and +5V +12V and +5V +12V and +5V
Idle (W) 7.26 5.41 4.67 6.39 4.61 3.74 6.39 4.61 3.74
Typical Operating Power (W)
Random Read
Random Write
10.43
10.15
8.04
7.2 8
7.89
7.18
9.03
7.8 0
7.42
6.21
6.47
5.31
9.03
7.8 0
7.42
6.21
6.47
5.31
PowerChoice™ Option (W) As low as 1.39 As low as 1.34 As low as 1.44 As low as 0.53 As low as 0.57 As low as 0.55 As low as 0.53 As low as 0.57 As low as 0.55
Environmental
Operating Temperature Range (˚C) 5 to 60 5 to 60 5 to 60 5 to 60 5 to 60 5 to 60 5 to 60 5 to 60 5 to 60
Vibration (Gs)
Operating: 5 to 500Hz
Nonoperating: 10 to 500Hz
0.5
2.0
0.5
2.0
0.5
2.0
0.25
4.9
0.25
4.9
0.25
4.9
0.25
4.9
0.25
4.9
0.25
4.9
Shock (Gs)
Operating, 2ms
Nonoperating: 1ms and 2ms
70
300
70
350
70
350
70
300
70
350
70
350
70
300
70
350
70
350
Physical
Height (in/mm)41.028 / 26.10 1.028 /2 6.10 1.028/26.10 1.028 / 26.10 1.028 /2 6.10 1.028/26.10 1.028 / 26.10 1.028 /26.10 1.028/26.10
Width (in/mm)44.010/101.85 4.010/101.85 4.010/101.85 4.010 /101.85 4.010/101.85 4.010/101.85 4.010/101.85 4.010/101.85 4.010/101.85
Depth (in/mm)45.787/147.00 5.787/147.00 5.787/147.00 5.787/147.00 5.787/147.00 5.787/147.00 5.787/147.00 5.787/147.00 5.787/147.00
Weight (lb/g) 1.57/710 1.41/640 1.34/ 610 1.57/710 1.411/6 40 1.345/610 1.57/710 1.411/640 1.345/610
Carton Unit Quantity 20 20 20 20 20 20 20 20 20
Cartons per Pallet 40 40 40 40 40 40 40 40 40
Cartons per Layer 888888888
1 One gigabyte, or GB, equals one billion bytes and one terabyte, or TB, equals one trillion bytes when referring to drive capacity.
2 Self-Encrypting Drive model. Requires TCG-compliant host or controller support. Not available in all countries.
3 FIPS Self-Encrypting Drive model. Requires TCG-compliant host or controller support. Not available in all countries.
4 These base deck dimensions conform to the Small Form Factor Standard (SFF-8301) found at www.sffcommittee.org. For connector-related dimensions, see SFF-8323.
5 Protection Information included
