Introduction
The Relio R4 is a solid-state 1U rackmount computer designed for applications requiring high reliability, I/O
expansion, scalable processing and a long product lifecycle. The R4’s fanless and cable-less structure
ensures extensive durability for long-term usage. The R4 differs from traditional industrial computer
systems in that it is built using the PICMG COM Express architecture. Sealevel has partnered with the
leading COM Express module manufacturers to ensure our customers benefit from the best in the industry.
This manual will focus on the higher level features of the R4 computer system.
The R4 is compatible with Basic and Compact form factor Type 6 pin out COM Express modules. COM
Express is a widely supported implementation of Computer on Module (COM) design. The COM Express
architecture reduces the complexity, cost and time required for custom computer system design by
combining the processing, memory, video, Ethernet and USB functionality in a small, highly-integrated
module. COM Express modules install on a carrier board that provides the application specific I/O and
external connectors best suited for the system requirements.
Sealevel COM Express carrier boards leverage the company’s years as a leader in I/O and communication
products to provide carrier board and full system solutions in the fastest time possible. Common I/O
features include serial, analog and digital I/O. Sealevel’s extensive library of proven I/O circuits can be
included as required to meet the specific I/O count, voltage ranges and connector types.
Features
The following features are included and installed on the Relio R4 models.
Fanless and Cable-less design
2 expansion slots for digital and analog SeaRAQ I/O modules
1 DisplayPort Compatible Video Output
2 Gigabit Ethernet Ports
2 RS-232 Serial Ports
1 RS-485 Serial Port
5 USB 2.0 Ports
1 Audio Line Input
1 Audio Line Output
Power and SATA Activity LED Indicators
Half-length PCI Express Mini Card Expansion
Accepts 1 removable 2.5” SATA Disk Drive
Supports Wake-on-LAN
18-36 VDC Input
©Sealevel Systems, Inc. R4 Manual 4
SL9260 06/2015

COM EXPRESS MODULE/RAM CONFIGURATION OPTIONS
Part Number COM Express Module COM Express Module Description RAM
R41004 TCA/N2800 Type 6 Compact Module with Intel
Atom N2800 Cedarview CPU
4GB
DDR3 1333 Non-ECC
R43008 IB-i3-3217UE Type 6 Standard Module with Intel
Core i3 3217UE Ivy Bridge CPU
8GB
DDR3 1333 Non-ECC
R47008 IB-i7-3517UE Type 6 Standard Module with Intel
Core i7 3517UE Ivy Bridge CPU
8GB
DDR3 1333 Non-ECC
©Sealevel Systems, Inc. R4 Manual 5
SL9260 06/2015

Before You Get Started
WHAT’S INCLUDED
The R4 is shipped with the following items. If any of these items are missing or damaged, please contact
Sealevel at 864.843.4343 for a replacement.
•R4 Computer System
•TR144-US AC/DC Power Supply – Desktop 100VAC-240VAC input, 24V 2.7A output w/AC power
cable
ADVISORY CONVENTIONS
Warning - The highest level of importance used to stress a condition where damage could result to
the product or the user could suffer serious injury.
Important– The middle level of importance used to highlight information that might not seem
obvious or a situation that could cause the product to fail.
Note
– The lowest level of importance used to provide background information, additional tips, or
other non-critical facts that will not affect the use of the product.
©Sealevel Systems, Inc. R4 Manual 6
SL9260 06/2015

OPTIONAL ITEMS
Depending upon your application, you are likely to find one or more of the following items useful with the
R4. All items can be purchased from our website (www.sealevel.com)or by calling our sales team at
[phone].
DB9 Female to DB9 Male Extension Cable, 72” Length (Item# CA127)
The CA127 is a standard DB9F to DB9M serial extension
cable. Extend a DB9 cable or locate a piece of hardware
where it is needed with this six-foot (72-inch) cable. The
connectors are pinned one-to-one so the cable is
compatible with any device or cable with DB9
connectors. The cable is fully shielded against
interference and the connectors are molded to provide
strain relief. Dual metal thumbscrews secure the cable
connections and prevent accidental disconnection.
DB9 Female to DB25 Male Standard RS-232 Modem Cable, 72” Length
(Item# CA177)
The CA177 is a standard AT-style RS-232 modem cable
with a DB9 female connector on one end and a DB25
male connector on the other end. Simply connect the
DB9 female connector to the DB9 serial port on the R4,
and then connect the DB25 male connector to your
RS232 serial modem or other compatible RS-232 serial
device. The six foot cable is fully shielded with dual
thumbscrews at each connector. The molded connectors
integrate strain relief to prevent damage to the cable or
connectors. All DB9 modem control signals are
implemented and the cable is pinned to EIA-232
standards.
Terminal Blocks
DB9 Female to 9 Screw Terminal Block (Item# TB05)
The TB05 terminal block breaks out a DB9 connector to
9 screw terminals to simplify field wiring of serial
connections. It is ideal for RS-422 and RS-485 networks,
yet it will work with any DB9 serial connection, including
RS-232. The TB05 includes holes for board or panel
mounting. The TB05 is designed to connect directly to
the R4 DB9 serial ports or any cable with a DB9M
connector.
©Sealevel Systems, Inc. R4 Manual 7
SL9260 06/2015

DB9 Female to 5 Screw Terminal Block (RS-485) (Item# TB34)
The TB34 terminal block adapter offers a simple solution
for connecting RS485 field wiring to the R4’s serial port
3. The terminal block is compatible with 2-wire and
4wire RS485 networks. A pair of thumbscrews secures
the adapter to the DB9 male connector and prevents
accidental disconnection.
CAT5 Patch Cable, 7’ In Length (Part# CA246)
Standard 7' CAT5 Unshielded Twisted Ethernet Pair Patch
Cable (RJ45) with blue jacket.
CAT5 Patch Cable, 10' In Length (Part# CA247)
Standard 10’ CAT5 Unshielded Twisted Pair Ethernet
Patch Cable (RJ45) with blue jacket.
6 Channel Isolated RTD Analog Inputs (Part# 6511)
The SeaRAQ 6511 analog expansion board is
specifically designed to interface RTDs
(Resistance Temperature Detectors). RTDs offer a
wide temperature measurement range, good
accuracy, repeatability, and long-term stability
well-suited to industrial applications.
6 Channel Isolated Thermocouple Inputs (Part# 6512)
The SeaRAQ 6512 analog expansion board is
specifically designed to interface inexpensive
thermocouples. To simplify temperature
calibration in the field, cold junction
compensation is provided on the board.
16 Channel Isolated DC Digital Inputs (3-30 VDC) (Part# 8510)
The SeaRAQ 8510 expansion board adds 16
channels of isolated digital inputs designed for
3-30 VDC. The inputs are compatible with TTL
signal levels.
©Sealevel Systems, Inc. R4 Manual 8
SL9260 06/2015

16 Channel Isolated AC Digital Inputs (0-132 VAC) (Part# 8511)
The SeaRAQ 8511 expansion board adds 16
channels of isolated digital inputs rated for 0-
132 VAC.
16 Isolated Digital Inputs 4 Form C Relay Outputs (Part# 8512)
The SeaRAQ 8512 expansion board adds 16
channels of isolated digital inputs rated for
24VDC and 4 Form C Relays.
16 Channel Isolated Relay Outputs (Part# 8520)
The SeaRAQ 8520 expansion board adds 16
isolated relay outputs rated for 5-250 VAC and 5-
30 VDC. The Form A relays are organized into
four banks of four relays, with each bank sharing
a common. The relays support a maximum
current load of 2A per relay (4A maximum per
bank). The SPST relays are normally open and
close when energized.
8 Channel Isolated Relay Outputs (Part# 8521)
The SeaRAQ 8521 expansion board adds 8
isolated relay outputs rated for 5-250 VAC and 5-
30 VDC. The Form A relays each have a discrete
common and support a maximum 4A current
load. The SPST relays are normally open and
close when energized.
8 Channel-to-Channel Isolated Analog Inputs (Part# 6510)
The SeaRAQ 6510 provides eight general
purpose 16-bit A/D channels that can be
individually configured for 4-20 mA current loop,
0-5V or 0-10V voltage inputs.
8 Channel-to-Channel Isolated Analog Outputs (Part# 6520)
The SeaRAQ 6520 expansion board adds eight 4-
20 mA current loop transmitter outputs and is
ideal for interfacing a wide variety of industrial
process control and test equipment that use 4-20
mA signaling.
©Sealevel Systems, Inc. R4 Manual 9
SL9260 06/2015

Specifications
MECHANICAL DIMENSIONS
Depth 8.00 inches (12.32 cm)
Width 19.00 inches (48.26 cm)
Height 1.75 inches (4.45 cm)
ENVIRONMENTAL SPECIFICATIONS
Specification Operating Storage
Temperature Range -40 to 50 ºC (-40 to 185 ºF)1-40 to 85 ºC (-40 to 221 ºF)
Humidity Range 10 to 90% R.H. Non-Condensing 10 to 90% R.H. Non-Condensing
OPERATING TEMPERATURE RANGE
Part Number COM Express Module Operating Temperature
Range Comment
R41004 TCA/N2800 0 - 50 °C
Requires Industrial Temperature SSD
for operating temperatures above 35 °C
with no airflow or conduction.
-20C to 50 °C optional. Contact Sales
R43008 IB-i3-3217UE -40 - 50 °C Requires Industrial Temperature SSD
R47008 IB-i7-3517UE -40 - 50 °C Requires Industrial Temperature SSD
The R47004 and R47008 can operate with no airflow at 50 °C as long as the steady-state CPU usage does
not exceed 50%. If CPU usage is sustained at a workload greater than 50%, the CPU will throttle itself back
to keep its internal temperature in a safe range.
If the application environment requires the computer to operate at 50 °C with steady state CPU usage
greater than 50%, some additional cooling must be used to ensure safe operation of the electronics.
1Operating temperature is dependent on particular model. See the Operating Temperature Range section
for model capabilities.
©Sealevel Systems, Inc. R4 Manual 10
SL9260 06/2015
