INSTRUCTIONS FOR
JOBSITE BOX 5 DRAWER 915MM HEAVY DUTY
MODEL NO: PTB91505
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using these units.
9Locate the units in a suitable work area.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use the box on level and solid surface capable of withstanding its weight.
9Keep the box clean and tidy in accordance with good workshop practice.
9Keep children and unauthorised persons away from the work area.
8DO NOT use this box for any purpose other than that for which it is designed.
8DO NOT place the box in a damp or wet location or an area where there is condensation.
8DO NOT clean the box with any solvents which may damage the surfaces or the protective coating.
8DO NOT move the box with the drawers out. To avoid tipping, open one drawer at a time and close and secure all drawers and close lid
whilst moving.
8DO NOT step on the drawers.
2. INTRODUCTION
Manufactured from 1.2mm steel, this jobsite box features a lockable front panel which opens in unison with the lid, supported by two gas struts
for smooth operation. The box features ve ball bearing runner drawers (each with 45kg capacity) along with an open storage space ideal for
larger tools and quick access. Heavy duty handles on either side of the jobsite box aid positioning. Welded feet on the base of the box enable
use with either a forklift or pallet truck to move around the work area. The feet are supplied with pre-drilled holes adding the option to secure in
place. Suitable for secure storage of tools on site, in vehicles, workshops or even at home. The jobsite box also doubles up as a bench.
3. SPECIFICATION
Model no: ............................................................. PTB91505
Overall size (W x D x H):.........................915 x 505 x 705mm
Small drawer (x4): .....................................720 x 400 x 45mm
Large drawer (x1):...................................720 x 400 x 120mm
4. OPERATION
4.1. Remove drawers
4.1.1. Pull drawer out until it is almost fully extended. Push up one release lever, while pulling down the other. Hold the levers in these
positions and pull the drawer out until it is released from the drawer slide.
4.2. Replace drawers
4.2.1. Extend the drawer slides from the tool chest/cabinet.
4.2.2. Insert the brackets on each side of the drawer into the slots in the chest/cabinet slides, being careful that they are properly positioned.
4.2.3. Once properly inserted, completely close the drawer to set the slides in their proper positions.
Refer to
Instruction
Manual
PTB91505 | Issue 2 08/11/16
Original Language Version
© Jack Sealey Limited
