Sealey POWER TOOLS Generation Series User manual

pWARNING! Ensure Health & Safety, local authority and general workshop practice regulations are adhered to when using this equipment.
pWARNING! Disconnect the hammer from the air supply before changing accessories, servicing or performing any maintenance.
3Keep the hammer clean and maintain it in good condition.
3Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty (use an authorised service agent).
3Keep the work area clean and uncluttered. Ensure that there is adequate lighting.
3Ensure chisels are correctly rated for the job. DO NOT use damaged or suspect chisels.
pWARNING! Wear approved safety eye or face protection, ear defenders and, if dust is generated, respiratory protection.
3Keep hands and body clear of the work when operating the hammer.
3Maintain correct balance and footing. Ensure that the floor is not slippery and wear non-slip shoes.
3Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and contain and/or tie back long hair.
3Keep children and unauthorised persons away from the work area.
3Secure unstable workpiece with a clamp, vice or other adequate holding device.
3Avoid unintentional starting.
pWARNING! Ensure that the correct air pressure is maintained and not exceeded.
3Keep air hose away from heat, oil and sharp edges. Check air hose for wear before each use and ensure that all connections are secure.
7DO NOT use the hammer for a task it is not designed to perform.
7DO NOT operate the hammer if any parts are damaged or missing as this may cause failure and/or
personal injury.
pWARNING! DO NOT chisel into any materials containing asbestos.
7DO NOT switch the hammer on whilst the chisel is in contact with the workpiece.
7DO NOT carry the by the hose, or yank the hose from the air supply.
7DO NOT hold the workpiece by hand. Use clamps or a vice (not
included) to secure the workpiece. Available from your Sealey dealer.
7DO NOT allow untrained persons to operate the hammer.
7DO NOT operate the hammer when you are tired or under the
influence of alcohol, drugs or intoxicating medication.
7DO NOT use hammer where there is flammable liquid, solid or gas
such as paint solvent, including waste wiping or cleaning rags etc.
7DO NOT leave the hammer operating unattended.
7DO NOT carry the hammer with your finger on the trigger.
7DO NOT direct air from the air hose at yourself or others.
3When work is complete ensure that the air supply is turned off.
3When not in use disconnect from the air supply and store in a safe, dry, childproof area.
3. AIR SUPPLY
1. SAFETY INSTRUCTIONS
GSA11 - 1 - 31204
2. INTRODUCTION & SPECIFICATION
INSTRUCTIONS FOR:
LONG STROKE G3 AIR
HAMMER
MODEL: GSA11
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used
according to these instructions and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS, AND
CAUTIONS. USE THIS PRODUCT CORRECTLY, AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO
MA
Y CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY.
Chisel Shank Size: . . . . . . . . . . . . . . . . . . . . . . . . . .0.401 Parker Taper
Speed: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3600bpm
Air Consumption: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5cfm
Operating Pressure: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90psi
Air Inlet Size: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1/4BSP
Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.3kg
Third generation, RWTUV approved air hammer. Handle exhaust reduces noise emission and contoured, soft grip allows added comfort and control. Kit includes
spring retainer, taper punch, long bladed panel cutter, weld buster, panel cutter and cold chisel. Supplied in carry-case.
3.1 Air Supply
Recommended hook-up procedure is shown in fig 1.
3.1.1 Ensure tool air valve (or trigger) is in "off" position before connecting to the air supply.
3.1.2 You will require an air pressure of 90psi, and an air flow according to specification.
3.1.3 pWARNING! Ensure the air supply is clean and does not exceed 90psi while operating the tool. Too high an air pressure and unclean air will shorten the
product life due to excessive wear, and may be dangerous causing damage and/or personal injury.
3.1.4 Drain the compressor air tank daily. Water in the air line will damage the tool.
3.1.5 Clean compressor air inlet filter weekly.
3.1.6 Line pressure should be increased to compensate for unusually long air hoses (over 8 metres). The minimum hose diameter should be 1/4 I.D. and fittings
must have the same inside dimensions.
3.1.7 Keep hose away from heat, oil and sharp edges. Check hose for wear, and make certain that all connections are secure.
3.2 Couplings.
Vibration may cause failure if a quick change coupling is connected directly to the tool.
To overcome this, connect a leader hose to the tool. A quick change coupling may then be used to connect the leader hose to the air line recoil hose. See
fig 1 & 2 (overleaf).
Risk of Hand Arm Vibration Injury
Long Stroke G3 Air Hammer Model No. GSA11 when operated in accordance with these instructions and tested in accordance with EN 28662-2: 1994 results in
the following vibration emission declared in accordance with
BS EN12096: 1996.
Measured vibration emission value: . . . . . . . . . . .20m/s² Uncertainty: . . . . . . .8m/s²
These values are suitable for comparison with emission levels of other tools that have been subject to the same test.
This tool may cause hand-arm vibration syndrome if its use is inadequately managed.
Recommended Measures to reduce risk of hand-arm vibration syndrome:
This tool should not be used by an individual regularly for more than 15.3 minutes in any 8 hour period.
This duration of use should be reduced if the individual is exposed to hand-arm vibration from other sources.

Note: Numbers in brackets refer to item numbers in the parts list.
The air hammer is designed primarily for use on vehicle bodywork. We do not recommend any other use. Ensure you read, understand and follow the safety
instructions in Section 1.
4.1 Attach the retaining spring (21) by screwing it onto the cylinder (18).
4.2 Insert the chisel using the hooked end of the spring to hold the chisel in place.
4.3 Attached the tool to the air supply (see Section 3).
4.4 To operate the hammer, squeeze the trigger (11).
pWARNING! Disconnect the hammer from the air supply before changing chisels, servicing or performing any maintenance.
5.1 Keep the hammer oiled for optimum performance. Lubricate with a good grade of air tool oil such as Sealey ATO/500 or ATO/1000. If there is no oiler in
the air system then a teaspoon of oil can be poured into the air inlet of the hammer, or into the hose at the nearest connection to the air supply. Then run
the hammer for a short time.
Note: The following external factors may cause loss of power and effect hammer performance:
The air supply: reduced compressor output, excessive drain on the air line, moisture or restrictions in air pipes or the use of hose connectors having too small a bore.
Correct as necessary.
The hammer: grit or gum deposits in the tool. Correct by cleaning the air strainer and flushing out the tool with gum solvent oil or an equal mixture of SAE No.10
oil and kerosene. If, despite taking action as above, the tool function is still impaired, contact your local Sealey service agent.
4. OPERATING INSTRUCTIONS
5. MAINTENANCE
GSA11 - 1 - 31204
ITEM PART NO. DESCRIPTION
01. GSA11.01 HOUSING
02. GSA01.05 SPRING PIN
03. GSA01.08 VALVE SEAT
04. GSA01.09 THROTTLE VALVE
05. GSA11.05 VALVE SPRING
06. GSA11.06 EXHAUST DEFLECTOR
07. GSA01.12 AIR INLET
08. GSA11.08 PLASTIC GRIP
09. GSA11.09 BUSHING
10. GSA11.10 TRIGGER SHAFT
11. GSA01.06 TRIGGER
12. GSA11.12 LOWER VALVE
13. GSA11.13 CHECK VALVE
14. GSA11.14 VALVE PIN (A)
15. GSA11.15 FRONT END PLATE
16. GSA11.16 GASKET
17. GSA11.17 PISTON
18. GSA11.18 ROUND CYLINDER
19. GSA11.19 BUSHING
20. GSA11.20 PLASTIC COVER
21. GSA11.21 SPRING RETAINER
Issue No: 1
Issue Date: 31204
fig 1
fig 2
Declaration of Conformity We, the sole importer into the UK, declare that the product listed here is in conformity with the following standards and directives.
The construction file for this product is held by the Manufacturer and may be inspected, by a
national authority, upon request to Jack Sealey Ltd. For Jack Sealey Ltd.
Sole importer into the UK
of Sealey Power Tools
Signed by Mark Sweetman 3rd December 2004
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts
without prior notice. IMPORTANT
: No liability is accepted for incorrect use of this equipment. WARRANTY: Guarantee is 12 months from
purchase date, proof of which will be required for any claim. INFORMATION: For a copy of our latest catalogue and promotions call us on
01284 757525 and leave your full name and address, including postcode.
www.sealey.co.uk
01284 757500 01284 703534 [e-mail]
Web email
Sole UK Distributor, Sealey Group, Bury St. Edmunds, Suffolk.
LONG STROKE G3 AIR HAMMER
Model: GSA11
98/37/EC Machinery Directive
93/68/EEC CE Marking Directive
6. PARTS LIST
