Seasons Sentry UMB-889201B Guide

E
Assembly, Care and Use Manual
9ft Wind Resistant Airow
TM
Market Umbrella
ITEM # UMB-889201T
UMB-889201B
UMB-889201N
For assistance with assembly or installation, parts or problem resolution, please
do not return to place of purchase, call customer service at:
ATLeisure LLC
1-855-880-7205 (English Only)
8:00am-5:00pm, Mondayto Friday, Eastern Standard TIme
www.atleisure.com • Email: [e-mail]
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY

Contents
23
Preparation .............................................3
Package Contents .......................................3
Set-Up and Operation ....................................4
Care and Maintenence ....................................5
Warnings and Cautions....................................5
Warranty ................................................6
Replacement Parts .......................................7
E
Fiberglass ribs can ex up and down, allowing the air to ow easily around the umbrella.
This helps prevent the canopy from trapping the wind and causing unwanted movement.

23E
Before beginning product assembly, make sure all contents are present. Compare parts
with package contents list and diagram. If any part is missing or damaged, do not attempt
to assemble the product or return to the place of purchase. Contact our customer service
toll free at 1-855-880-7205 for replacement parts or further instructions.
Estimated Assembly Time: 10 minutes
No tools required for assembly.
Preparation
Package Contents
PART DESCRIPTION PICTURE QTY(PC)
AUmbrella Frame
with Canopy
1
BBottom Pole 1
CFinial 1

4E5
CAUTION: If the crank becomes too hard to turn while opening the canopy,
check to see if the rope has come off the pulley. If you continue to turn the
crank, the rope or crank handle could break.
Set-Up and Operation
Step 2: Insert the bottom
pole into the upper pole while
pressing the snap button on the
upper pole until the snap button
locks into position.
Step 4: TO CLOSE UMBRELLA -
The umbrella main pole must
be in the upright position, then
continue to crank counter-
clockwise or opposite direc-
tion to close umbrella. Use tie
straps to secure canopy.
Step 1: Attach the nial on the
umbrella top (if unattached)
by screwing the nial into the
threaded screw-in adapter. Twist
until secure, but do not over
tighten.
Step 3: TO OPEN UMBRELLA - Turn
crank handle clockwise until canopy is
fully open.
TO TILT UMBRELLA - Once umbrella
is open, to operate the EZ Tilt function,
continue to turn crank handle clockwise
with a bit more effort and it will begin to
automatically tilt.
TO UNDO TILT - Turn crank handle in
opposite direction or counterclockwise
and it will automatically come back to
original upright position.
CAUTION: Do not use sharp tools or equipment such as a knife or scissors
when removing the protective material, as it may damage the product.

4
Warnings and Cautions
Care and Maintenance
E
5
See the enclosed Sunbrella® care and cleaning insert for canopy maintenance.
WARNING: Do not use this umbrella during periods of high winds and rain. Failure to
do so may result in personal injury and/or damage.
CAUTION: Assemble and use umbrella on at ground.
DANGER: Keep children out of the assembly area during assembly.
INFORMATION: Recommend inserting the umbrella into an umbrella base (not
included) to secure umbrella in an upright position.
INFORMATION: Close the umbrella and use the canopy ties when umbrella is
not in use.
INFORMATION: Schematics in this manual are for assembly and operation
illustration only. They may differ from the umbrella’s actual appearance.
WARNING: Read the entire instructions before beginning and follow the steps
outlined. Failure to assemble and install as instructed could result in the umbrella
tipping over causing personal injury and/or property damage.

Warranty
This product is covered under a manufacturer’s 2-year warranty from date of purchase
against defects in materials and workmanship. This warranty does not cover damage
due to neglect, abuse or weather related damage. For full warranty disclosure, email us
at customerser[email protected], call toll free at 1-855-880-7205 or send mail to:
Atleisure, LLC
Customer Service Dept.
1040 Boulevard SE Ste. B
Atlanta GA 30312.
NOT COVERED UNDER WARRANTY
This warranty excludes the following: acts of nature (i.e. wind, re or freeze); damage
caused by improper assembly, accident, disaster, misuse, abuse, negligence and
discoloration or fading of the nish as a result of exposure to the elements. Product
not intended for commercial use. This warranty gives you specic rights, and you
may also have other rights which may vary from state to state.
If you are within your warranty, to le a claim you must have your receipt and pictures
of your damaged umbrella and send to ATLeisure at:
[e-mail]
or by mail to:
Atleisure, LLC
Customer Service Dept.
1040 Boulevard SE Ste. B
Atlanta GA 30312.
Filing a Claim
6 7

DESCRIPTION PICTURE RE-ORDER NO.
Finial FNL-38PC-BRZ-T
Bottom Pole
(Snap in 38mm) BMP-38ASN-BRZ-T
Canopy CAN-9MAF8RBS-T-
BE,RD,NB
Replacement Parts
6 7
For replacement parts, call our customer service department at 1-855-880-7205,
8:00am-5:00pm., EST, Monday-Friday.
Made in China
U.S. Patent Pending

www.atleisure.com
ATLANTA, GEORGIA, USA
Customer Service Toll Free 1-855-880-7205
Monday through Friday from 8am-5pm
(Eastern Standard Time)
