Workshop Manual
Ateca 2017 ➤
León 2013 ➤
León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection,
4 V, exhaust gas turbocharger, timing chain, EA 888
III. Gen)
Engine ID CJSA CJXA CJXE CJSB CJXH CJXC CJX
G
DNU
C
DNU
E
Edition 10.2018
Service
Service Department. Technical Information

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
List of Workshop Manual Repair Groups
Repair Group
00 - Technical data
10 - Removing and installing engine
13 - Crankshaft group
15 - Cylinder head, valve gear
17 - Lubrication
19 - Cooling
21 - Turbocharging/supercharging
24 - Mixture preparation - injection
26 - Exhaust system
28 - Ignition system
Technical information should always be available to the foremen and mechanics, because their
careful and constant adherence to the instructions is essential to ensure vehicle road-worthiness and
safety. In addition, the normal basic safety precautions for working on motor vehicles must, as a
matter of course, be observed.
Service
All rights reserved.
No reproduction without prior agreement from publisher.
Copyright © 2018 Seat S.A D4B802C0BB7

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
Contents
00 - Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1 Security standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Safety precautions when working on fuel supply system . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Safety precautions for working on vehicles with start-stop system. . . . . . . . . . . . . . . . . . . 1
1.3 Safety precautions during road tests in which testing and measuring equipment is used . . 2
1.4 Safety precautions when working on ignition system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.5 Safety precautions when working on the cooling system . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.6 Safety precautions when working on exhaust system . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Engine identification number/engine data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Repair instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Cleaning rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Foreign particles in engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3 Contact corrosion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.4 Routing and attachment of pipes, hoses and wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.5 Installing radiators and condensers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.6 Vacuum system: checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
10 - Removing and installing engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1 Removing and installing the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1 Engine removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.2 Separating engine and gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
1.3 Separating engine and gearbox - models with automatic gearbox . . . . . . . . . . . . . . . . . . 36
1.4 Securing engine to engine and gearbox support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
1.5 Installing engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
2 Assembly bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
2.1 Installation overview - assembly mountings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
2.2 Removing and installing engine mountings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
2.3 Removing and installing gearbox mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
2.4 Removing and installing pendulum support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
2.5 Supporting engine in installation position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
2.6 Adjusting assembly mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
2.7 Checking adjustment of assembly mountings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
3 Engine cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
3.1 Removing and installing engine cover panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
13 - Crankshaft group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
1 Cylinder block (pulley end) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
1.1 Exploded view - cylinder block (pulley end) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
1.2 Removing and installing poly V-belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
1.3 Removing and installing tensioner for poly V-belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
1.4 Removing and installing vibration damper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
1.5 Removing and installing ancillary bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
1.6 Removing and installing engine support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
1.7 Renewing seal for vibration damper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
2 Cylinder block, gearbox end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
2.1 Exploded view - cylinder block, gearbox end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
2.2 Removing and installing flywheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
2.3 Removing and installing sealing flange (gearbox end) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
3 Crankshaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
3.1 Assembly overview - crankshaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
3.2 Crankshaft dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
Contents i

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
3.3 Arrangement of the crankshaft bearing shells . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
3.4 Renewing needle bearing in crankshaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
3.5 Measure axial play of crankshaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
3.6 Measure radial play for crankshaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
3.7 Sender wheel: removing and installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
4 Balancing shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
4.1 Assembly overview - balancer shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
4.2 Removing and installing balance shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
4.3 Renewing oil seal for balance shaft (inlet side) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
5 Pistons and conrods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
5.1 Exploded view - pistons and conrods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
5.2 Removing and installing pistons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
5.3 Checking pistons and cylinder bores . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
5.4 Separating parts of new conrod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
5.5 Checking radial clearance of conrod bearings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
5.6 Removing and installing oil spray jets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
15 - Cylinder head, valve gear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
1 Cylinder head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
1.1 Exploded view - cylinder head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
1.2 Removing and installing cylinder head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
1.3 Removing and installing vacuum pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
1.4 Check compression pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
2 Timing chain cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
2.1 Assembly overview - timing chain cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
2.2 Removing and installing timing chain cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
3 Chain drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
3.1 Assembly overview - camshaft timing chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
3.2 Assembly overview - drive chain for balancer shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
3.3 Fitting and removing bearing support module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
3.4 Removing and installing camshaft timing chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
3.5 Removing and installing drive chain for balancer shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
3.6 Checking valve timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
3.7 Checking timing chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
4 Valve gear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
4.1 Assembly overview - valve gear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
4.2 Removing and installing camshaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
4.3 Install ball for forked sleeve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
4.4 Removing and installing camshaft control valve 1 N205 . . . . . . . . . . . . . . . . . . . . . . . . . . 186
4.5 Removing and installing exhaust camshaft control valve 1 N318 . . . . . . . . . . . . . . . . . . . . 187
4.6 Removing and installing actuators for camshaft adjustment . . . . . . . . . . . . . . . . . . . . . . . . 187
4.7 Removing and installing valve stem seals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
5 Inlet and exhaust valves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
5.1 Valve guides: verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
5.2 Valves: checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
5.3 Valve dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
17 - Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
1 Sump, oil pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
1.1 Exploded view - sump/oil pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
1.2 Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
1.3 Removing and installing sump (bottom section) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
1.4 Removing and installing sump (top section) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
1.5 Oil pump: removing and installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
1.6 Removing and installing oil level and oil temperature sender G266 . . . . . . . . . . . . . . . . . . 215
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
ii Contents

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
2 Engine oil radiator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
2.1 Assembly overview - engine oil cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
2.2 Removing and installing engine oil cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
2.3 Removing and installing mechanical switching valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
3 Crankcase breather system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
3.1 Exploded view - crankcase breather system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
3.2 Removing and installing the oil separator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
4 Oil filter/oil pressure switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
4.1 Exploded view - oil filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
4.2 Exploded view - oil pressure switches/oil pressure control . . . . . . . . . . . . . . . . . . . . . . . . 222
4.3 Removing and installing piston cooling jet control valve N522 . . . . . . . . . . . . . . . . . . . . . . 223
4.4 Removing and installing oil pressure switch F1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224
4.5 Removing and installing oil pressure switch for reduced oil pressure F378 . . . . . . . . . . . . 225
4.6 Removing and installing stage 3 oil pressure switch F447 . . . . . . . . . . . . . . . . . . . . . . . . 226
4.7 Checking oil pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
4.8 Removing and installing valve for oil pressure control N428 . . . . . . . . . . . . . . . . . . . . . . . . 231
19 - Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
1 Cooling system/coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
1.1 Connection diagram - coolant hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
1.2 Draining and filling coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239
1.3 Checking cooling system for leaks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244
1.4 Flushing cooling system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247
1.5 Flushing cooling system, quick reference guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
2 Coolant pump/thermostat assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
2.1 Exploded view - coolant pump and thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
2.2 Exploded view - electric coolant pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270
2.3 Exploded view - coolant temperature sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
2.4 Removing and installing toothed belt for coolant pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
2.5 Removing and replacing coolant pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276
2.6 Removing and installing electric coolant pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 277
2.7 Removing and installing coolant shut-off valve N82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278
2.8 Removing and installing coolant valve for gearbox N488 , vehicles with dual clutch
gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
2.9 Removing and installing actuator for engine temperature regulation N493 . . . . . . . . . . . . 282
2.10 Removing and installing coolant temperature sender G62 . . . . . . . . . . . . . . . . . . . . . . . . 284
2.11 Removing and installing coolant temperature sender at radiator outlet G83 . . . . . . . . . . 285
3 Coolant pipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287
3.1 Exploded view - coolant pipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287
3.2 Removing and installing coolant pipe at front of engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287
3.3 Removing and installing coolant pipes (top) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 289
4 Radiator/radiator fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
4.1 Exploded view - radiator/radiator fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
4.2 Exploded view - auxiliary radiator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
4.3 Exploded view - radiator cowl and radiator fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 295
4.4 Removing and positioning radiator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 295
4.5 Removing and installing radiator cowl . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300
4.6 Removing and installing radiator fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302
4.7 Removing and installing auxiliary radiator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 303
21 - Turbocharging/supercharging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307
1 Turbocharger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307
1.1 Exploded view - turbocharger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307
1.2 Turbo compressor: removing and fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 309
1.3 Adjusting charge pressure positioner V465 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 316
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
Contents iii

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
2 Supercharger air system: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 319
2.1 Assembly overview - charge air system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 319
2.2 Exploded view - hose connections for charge air system . . . . . . . . . . . . . . . . . . . . . . . . . . 321
2.3 Charged air cooler: removing and fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 321
2.4 Removing and installing charge pressure sender G31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 326
2.5 Checking charge air system for leaks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
2.6 Removing and installing air intake pipe between turbocharger and charge air cooler . . . . 329
24 - Mixture preparation - injection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331
1 Injection system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331
1.1 Overview of fitting locations - injection system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331
2 Injectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 343
2.1 Assembly overview - fuel rail with injectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 343
2.2 Removing and installing fuel rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 345
2.3 Injectors: removing and installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 346
2.4 Renewing seals on injectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 350
2.5 Cleaning injectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 353
3 Air cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 355
3.1 Exploded view - air cleaner housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 355
3.2 Air filter housing: removing and fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 356
4 Suction hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 358
4.1 Exploded view - intake manifold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 358
4.2 Removing and installing intake manifold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 359
4.3 Throttle valve control unit GX3 : removing and fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 365
4.4 Cleaning throttle valve module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 367
5 Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 368
5.1 Assembly overview - actuator for structure-borne sound and control unit for structure-borne
sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 368
5.2 Removing and installing fuel pressure sensor G247 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 369
5.3 Checking fuel pressure sender G247 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 371
5.4 Removing and installing fuel pressure sender for low pressure G410 . . . . . . . . . . . . . . . . 373
5.5 Remove and install intake manifold sender GX9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 374
5.6 Pressure differential sender for particulate filter G1037 . . . . . . . . . . . . . . . . . . . . . . . . . . 375
6 Engine control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 376
6.1 Removing and installing engine control unit J623 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 376
7 High-pressure pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 380
7.1 Exploded view - high-pressure pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 380
7.2 High-pressure pump: removing and fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 381
7.3 Removing and installing high-pressure pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 384
8 Lambda probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 387
8.1 Exploded view - Lambda probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 387
8.2 Removing and installing Lambda probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 388
26 - Exhaust system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 391
1 Exhaust pipes/silencers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 391
1.1 Exploded view - silencers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 391
1.2 Removing and installing rear silencer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 401
1.3 Removing and installing centre silencer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 404
1.4 Removing and installing front silencer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 405
1.5 Disconnecting exhaust pipes/silencers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 408
1.6 Align exhaust system to be free of stress . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 411
1.7 Aligning tailpipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 412
1.8 Check exhaust system for leaks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 412
2 Emission control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 414
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
iv Contents

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
2.1 Assembly overview - emission control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 414
2.2 Removing and installing catalytic converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 420
2.3 Removing and installing holder of pressure differential sender for particulate filter G1037
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 442
2.4 Removing and installing exhaust flap control unit J883 / J945 . . . . . . . . . . . . . . . . . . . . . . 443
3 Exhaust gas temperature regulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 445
3.1 Assembly overview - exhaust gas temperature regulation . . . . . . . . . . . . . . . . . . . . . . . . . . 445
3.2 Removing and installing parts of exhaust gas temperature regulation . . . . . . . . . . . . . . . . 446
28 - Ignition system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 451
1 Ignition system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 451
1.1 Assembly overview - ignition system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 451
1.2 Ignition coils with output stage: removing and fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 452
1.3 Removing and installing knock sensor 1 G61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 454
1.4 Removing and installing Hall sender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 455
1.5 Removing and installing engine speed sensor G28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 456
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
Contents v

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
vi Contents

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
00 – Technical data
1 Security standards
(ERL003849; Edition 10.2018)
⇒ “1.1 Safety precautions when working on fuel supply system”,
page 1
⇒ “1.2 Safety precautions for working on vehicles with start-stop
system.”, page 1
⇒ “1.3 Safety precautions during road tests in which testing and
measuring equipment is used”, page 2
⇒ “1.4 Safety precautions when working on ignition system”, page
2
⇒ “1.5 Safety precautions when working on the cooling system”,
page 2
⇒ “1.6 Safety precautions when working on exhaust system”,
page 3
1.1 Safety precautions when working on fuel supply system
Risk of injury due to highly-pressurised fuel.
The fuel system is pressurised. Injury possible due to fuel which
may spurt out.
Before opening the fuel system:
– Wear safety goggles.
– Wear protection gloves.
– Release pressure: place clean cloth around connection and
carefully open connection.
Risk of fire due to escaping fuel
If the battery is connected, the door contact switch will activate
the fuel pump when the door is opened. Escaping fuel may ignite
and cause a fire.
– Disconnect the fuel pump from the power supply before open‐
ing the fuel system.
1.2 Safety precautions for working on vehicles with start-stop system.
Risk of injury due to unexpected engine start-up
In the case of vehicles with activated Start/Stop system, the en‐
gine may start up unexpectedly. The status of the Start/Stop
system is indicated by a message in the dash panel insert.
– Deactivate Start/Stop system by switching off the ignition.
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
1. Security standards 1

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
1.3 Safety precautions during road tests in which testing and measuring equip‐
ment is used
Risk of injury due to unsecured test and measuring equipment.
If the front passenger airbag deploys in the event of an accident,
the test and measuring devices being tossed around become
hazardous projectiles.
– Secure the test and measuring devices on the rear seat using
a seat belt.
or
– A second person should operate the test and measuring de‐
vices on the rear seat.
1.4 Safety precautions when working on ignition system
Risk of injury due to electric shock
The ignition system is under high-voltage when the engine is run‐
ning. Touching the ignition system may result in an electric shock.
– Do not touch or disconnect ignition cables when the engine is
running or being turned at starter speed.
Risk of damage to components
If the engine is washed while running and if electric cables are
connected or disconnected, components may become damaged.
– Switch off the ignition before connecting or disconnecting elec‐
tric cables.
– Also, switch off the ignition before washing the engine.
1.5 Safety precautions when working on the cooling system
Risk of scalding by hot coolant
The cooling system is under pressure when the engine is hot. Hot
steam/hot coolant can escape - risk of scalding.
– Wear protection gloves.
– Wear safety goggles.
– Reduce excess pressure by covering cap of coolant expan‐
sion tank with cloths and opening it carefully.
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
2 Rep. gr.00 - Technical data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
1.6 Safety precautions when working on ex‐
haust system
CAUTION
Risk of poisoning due to chemical substances
Exhaust gas temperature senders may contain chemical sub‐
stances. There is a risk of poisoning or injuries to respiratory
system.
– Never open an exhaust gas temperature sender by cutting,
sawing or any other means.
CAUTION
Risk of injury due to hot condensate and particles in the exhaust
system.
The exhaust system could contain hot condensate and/or par‐
ticles. There is a risk of injury to the eyes, skin and respiratory
system, as well as poisoning.
– Always wear protective gloves and eye protection when cut‐
ting the exhaust system.
– When cutting, use an extraction system or otherwise ensure
sufficient ventilation.
There is a danger of the damper element becoming damaged.
Do not allow the decoupling element to kink by more than 10°.
Do not subject the decoupling element to tensile force.
Do not damage wire mesh on decoupling element.
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
1. Security standards 3

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
4 Rep. gr.00 - Technical data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
2 Identification
⇒ “2.1 Engine identification number/engine data”, page 5
2.1 Engine identification number/engine da‐
ta
Engine number
The engine code is also stamped on the cylinder block behind the
oil filter.
In addition, there is a sticker on the right of the timing chain cover
with “engine code” and “serial number”.
The first 3 digits denote the mechanical design of the engine and
are stamped on the engine. The fourth digit shows the engine
output and torque and varies according to engine control unit. The
four-character engine code can be found on the identification
plate as well as on the vehicle data sticker. It can also be read
from the engine control unit.
Note
Installation location of vehicle data plate ⇒ Maintenance ; Booklet
501 ; Vehicle data plate .
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
2. Identification 5

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
Codes CJSA CJSB CJXA CJXE
Exhaust
emis‐
sion
stand‐
ard
EU 6 EU6 EU6 EU6
Dis‐
place
ment
l 1.8 1.8 2.0 2.0
En‐
gine
out‐
put
k
W
a
t
r
p
m
132/5100 …
6200
132/4500
… 6200
206/5700 …
6200
195/5350
… 6600
Tor‐
que
N
m
a
t
r
p
m
250/1250 …
5000
280/1350
… 4500
380/1750 …
5600
350/1700
… 5300
Cylin‐
der
bore
∅
∅
m
m
82.5 82.5 82.5 82.5
Strok
e
m
m
84.2 84.2 92.8 92.8
Com‐
press‐
ion
9.6:1 9.6:1 9.3:1 9.3:1
ROZ 95 95 981) 981)
Injection
system/
ignition
system
Direct injec‐
tion and in‐
take mani‐
fold injection
Direct injec‐
tion and in‐
take mani‐
fold injec‐
tion
Direct injec‐
tion and in‐
take mani‐
fold injection
Direct injec‐
tion and in‐
take mani‐
fold injec‐
tion
Firing
order
1-3-4-2 1-3-4-2 1-3-4-2 1-3-4-2
Charg‐
ing
Turbocharg‐
er
Turbo‐
charger
Turbocharg‐
er
Turbo‐
charger
Cam‐
shaft
timing
adjust‐
ment
yes yes yes yes
Secon‐
dary air
injection
no no no no
Valves
per cyl‐
inder
4 4 4 4
Par‐
ticu‐
late
filter
no no no no
Oil pres‐
sure
control
yes yes yes yes
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
6 Rep. gr.00 - Technical data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
Codes CJSA CJSB CJXA CJXE
•1) Unleaded petrol RON 95 can also be used, though power
is reduced
Code CJXC CJXH CJXG
Exhaust
emission
standard
6 EU6 EU6
Dis‐
place
ment
l 2.0 2.0 2.0
En‐
gine
out‐
put
k
W
at
rp
m
221/5500 … 62
00
213/5900 … 64
00
228/5800 to
6500
Tor‐
que
N
m
at
rp
m
380/1800 … 55
00
350/1700 … 58
00
380/1850 to
5700
Cyl‐
inder
bore
∅
∅
m
m
82.5 82.5 82.5
Strok
e
m
m
92.8 92.8 92.8
Com‐
pression
9.3:1 9.3:1 9.3:1
ROZ 981) 981) 981)
Injection
system/
ignition
system
Direct injection
and intake
manifold injec‐
tion
Direct injection
and intake
manifold injec‐
tion
Direct injection
and intake
manifold injec‐
tion
Firing or‐
der
1-3-4-2 1-3-4-2 1-3-4-2
Charging Turbocharger Turbocharger Turbocharger
Cam‐
shaft tim‐
ing ad‐
justment
yes yes yes
Secon‐
dary air
injection
no no no
Valves
per cylin‐
der
4 4 4
Par‐
ticu‐
late
filter
no no no
Oil pres‐
sure
control
yes yes yes
•1) Unleaded petrol RON 95 can also be used, though power
is reduced
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
2. Identification 7

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
Code DNUC DNUE
Exhaust
emission
standard
6 EU6
Dis‐
place‐
ment
l 2.0 2.0
Engine
output
k
W
at
rp
m
213/5400 to 6500 221/5300 to 6500
Engine
torque
N
m
at
rp
m
380/1950 to 5300 400/2000 to 5200
Cylinder
bore ∅
∅
m
m
82.5 82.5
Stroke m
m
92.8 92.8
Compres‐
sion
9.3:1 9.3:1
ROZ 98 98
Ignition/in‐
jection sys‐
tem
Direct injection and in‐
take manifold injection
Direct injection and intake
manifold injection
Firing order 1-3-4-2 1-3-4-2
Charging Turbocharger Turbocharger
Camshaft
timing ad‐
justment
yes yes
Secondary
air injection
no no
Valves per
cylinder
4 4
Particu‐
late filter
yes yes
Oil pres‐
sure control
yes yes
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
8 Rep. gr.00 - Technical data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
3 Repair instructions
⇒ “3.1 Cleaning rules”, page 9
⇒ “3.2 Foreign particles in engine”, page 9
⇒ “3.3 Contact corrosion”, page 9
⇒ “3.4 Routing and attachment of pipes, hoses and wiring”, page
9
⇒ “3.5 Installing radiators and condensers”, page 10
⇒ “3.6 Vacuum system: checking”, page 10
3.1 Cleaning rules
Even slight soiling can cause faults. Following the following rules
for cleanliness when working on the fuel supply system and in‐
jection system or on the turbocharger:
♦ Carefully clean connection points and the surrounding area
with engine cleaner or brake cleaner and dry thoroughly before
opening.
♦ Seal off open pipes/lines and connections immediately with
clean plugs, e.g. from engine sealing cap set - VAS 6122- .
♦ Place removed parts on a clean surface. Cover with lint-free
cloths only.
♦ Carefully cover opened components or seal them if repairs
cannot be carried out immediately.
♦ Only install clean components: Only unpack replacement
parts immediately prior to installation. Do not fit parts that have
been stored unpackaged (e.g. in tool boxes etc.).
♦ When the system is open, avoid working with compressed air
and moving vehicle.
♦ Make sure that no fuel runs onto the fuel hoses. Should this
occur, the fuel hoses must be cleaned again immediately.
♦ Protect disconnected electrical connectors from dirt and water,
and reconnect them only when dry.
3.2 Foreign particles in engine
♦ Before working on the engine, all open inlet and exhaust ports
must be sealed with suitable plugs (from engine bung set -
VAS 6122- ) to prevent foreign particles from entering the
engine.
3.3 Contact corrosion
Contact corrosion can occur if unsuitable fasteners are used (e.g.
bolts, nuts, washers, etc.).
For this reason, only fasteners with a special surface coating are
installed in the vehicle.
Furthermore, rubber and plastic components as well as adhe‐
sives are made of non-conductive materials.
If there is any doubt about the suitability of parts, a general rule
is to use new parts ⇒ Electronic Parts Catalogue .
3.4 Routing and attachment of pipes, hoses
and wiring
♦ Mark fuel lines, vacuum lines, pipes/hoses for activated char‐
coal filter system and electrical wiring etc. before removal so
they can be re-installed in the original positions and correctly
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
3. Repair instructions 9

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
connected. Where necessary, make sketches or take photo‐
graphs.
♦ To prevent damaging pipes, hoses and wiring, ensure suffi‐
cient clearance from all moving or hot components in engine
compartment (little space in engine compartment).
3.5 Installing radiators and condensers
Even if installed correctly, the radiator, the condenser and the
charge air cooler may have small dents in their fins. This does not
mean that the components are damaged. It is not permissible to
renew radiators, charge air coolers or condensers only because
of such minor dents.
3.6 Vacuum system: checking
Special tools and workshop equipment required
♦ Hand vacuum pump - VAS 6213-
Operation process
– Check all vacuum lines in the complete vacuum system for:
♦ Cracks
♦ Traces of animal bites
♦ Kinked or crushed lines
♦ Lines porous or leaking
– Check vacuum line to solenoid valve and from solenoid valve
to corresponding component.
– If a fault is stored in the event memory, check all vacuum lines
leading to the corresponding component, and also check the
remaining vacuum lines leading to other components.
– If it is not possible to build up pressure with the hand vacuum
pump - VAS 6213- or if the pressure drops again immediately,
check the hand vacuum pump and connecting hoses for leaks.
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
10 Rep. gr.00 - Technical data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
10 – Removing and installing engine
1 Removing and installing the engine
⇒ “1.1 Engine removal”, page 11
⇒ “1.2 Separating engine and gearbox”, page 29
⇒ “1.4 Securing engine to engine and gearbox support”,
page 37
⇒ “1.5 Installing engine”, page 39
1.1 Engine removal
Special tools and workshop equipment required
♦ Hydraulic column jack - VAS 6931-
♦ Support bridge - T10323- for vehicles with all-wheel drive
♦ Engine bracket - T10359 A-
♦ Pins - T10359/2-
♦ Adapters - T10359/3-
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
1. Removing and installing the engine 11

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
♦ Securing element from gearbox support - 3282-
♦ Pressing-off lever - 80 - 200-
♦ Protective glasses
♦ Protective gloves
♦ Double ladder
Removing
Note
♦ The engine is removed downwards with gearbox. To do this,
the subframe needs to be removed.
♦ After removing of coolant or fuel lines, these must be sealed
using the engine sealing cap set - VAS 6122- to prevent dirt
from entering or coolant or fuel from running out.
♦ Fit cable ties in the original positions when installing.
♦ All cable ties which are opened or cut through when engine is
removed must be replaced in the same position when engine
is installed.
CAUTION
On a warm motor, the cooling system is under high pressure.
Hot steam/hot coolant can escape - risk of scalding.
Risk of scalding to skin and body parts.
– Wear protection gloves.
– Wear safety goggles.
– Reduce excess pressure by covering cap of coolant expan‐
sion tank with cloths and opening it carefully.
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
12 Rep. gr.10 - Removing and installing engine
