SEB INTERNATIONAL SERVICE Edition Avril 2014
1
SEB INTERNATIONAL SERVICE

SEB INTERNATIONAL SERVICE Edition Avril 2014
2
Table of content
1. General Data ........................................................................ 3
2. Technical Data...................................................................... 3
2.2. Reference values: ................................................................................3
3. Hydraulic and wiring diagrams ............................................ 4
3.1. Wiring diagram ....................................................................................4
3.2. Hydraulic diagram:...............................................................................5
4. Dismantling .......................................................................... 6
4.1. General dismantling.............................................................................6
4.2. Grinder ..............................................................................................10
4.3. Subassembly switch ejection ............................................................. 14
4.4. Switch ejection disassembly ..............................................................17
5. ASS Modes ......................................................................... 20
5.1. ASS Mode 1 :......................................................................................20
5.2. ASS Mode 2 :......................................................................................22
6. ASS defect description ....................................................... 23

SEB INTERNATIONAL SERVICE Edition Avril 2014
3
1. General Data
2. Technical Data
2.2.Reference values:
Expresso temperature (50ml –strong coffee) 1st coffee : 68°C mini
Temperature increase by steam with 125ml of water after 45s : 42°C
Cake thickness : 12-14mm
Front
plastique
Ind G/H
EA8200
EA8240
EA8245
EA8271
EA8255
Front
plastique
Ind G/H
EA8250
EA8251
EA8258
EA8268
Front die
caste
Ind H/I
EA8260
EA8261
EA826E
EA828E

SEB INTERNATIONAL SERVICE Edition Avril 2014
4
3. Hydraulic and wiring diagrams
3.1.Wiring diagram

SEB INTERNATIONAL SERVICE Edition Avril 2014
5
3.2.Hydraulic diagram:

SEB INTERNATIONAL SERVICE Edition Avril 2014
6
4. Dismantling
4.1.General dismantling
Tools : Torx screwdriver (T15)
Remove the grinding fineness
setting button
Unscrew the screws from the
coffee bean container
Unscrew the 3 screws from the
cover of top

SEB INTERNATIONAL SERVICE Edition Avril 2014
7
Remove the cover by pulling
upward with your hand in place of
cleaning tablet pipe
Remove the front cover
Remove the 2 clips with a
screwdriver
Disconnect the plug

SEB INTERNATIONAL SERVICE Edition Avril 2014
8
Unscrew the 2 screws of the front
Unscrew the 2 screws of from the
rear and remove the protection.
Unscrew the 4 screws in the
bottom and the 2 screws of
bottom right and bottom left
Take away the coffee pipe
Unscrew the 2 screws on top of
front cover

SEB INTERNATIONAL SERVICE Edition Avril 2014
9
Open the panel on the rigth

SEB INTERNATIONAL SERVICE Edition Avril 2014
10
4.2.Grinder
Tools : torx screwdriver (T15)
Remove the protection
Remove the crown who is on
the grinder as the picture.
A screwdriver can help
Unscrew the 2 screw of the
grinder
Disconnect the plug of
grinder (it’s black wires)

SEB INTERNATIONAL SERVICE Edition Avril 2014
11
Change the grinder
BECARFUL: the spring of the
brewing unit must be in the
good position.
Thread breaks mound
NOK
OK

SEB INTERNATIONAL SERVICE Edition Avril 2014
12
Check if the little ball is in the
green line (as the picture)
Before to put back the crown of
grinder, check if the axis to
adjust the coffee grinding on
the good position like the
NOK
OK
NO
K
OK

SEB INTERNATIONAL SERVICE Edition Avril 2014
13
Connect the new grinder.
The cables must be in good
position (see the picture in the
“instruction to put the wires)
Put back all protections

SEB INTERNATIONAL SERVICE Edition Avril 2014
14
4.3.Subassembly switch ejection
Tools: torx screwdriver (T15)
Remove the protection
Disconnected all wires of the
power board
Removed the subset grinder

SEB INTERNATIONAL SERVICE Edition Avril 2014
15
Unscrew the 3 screws of
thermobloc and tip up in back
Unscrew the 2 screws of
switch

SEB INTERNATIONAL SERVICE Edition Avril 2014
16
Slide up the switch
Change the switch and make
the same actions to
reassemble all the parts
Perform calibration

SEB INTERNATIONAL SERVICE Edition Avril 2014
17
4.4.Switch ejection disassembly
Tools: torx screwdriver (T15 & T10)
Remove the protection
Disconnected all wires of the
power board
Removed the subset grinder

SEB INTERNATIONAL SERVICE Edition Avril 2014
18
Unscrew the screw with the
T10
Tip over on the right the right
side of swich bracket

SEB INTERNATIONAL SERVICE Edition Avril 2014
19
Removed the switch (help you
of a screwdriver)
Make the same actions to
reassemble all the parts
BE CARFULL : put the switch
in the good position (wire in
the down)
OK

SEB INTERNATIONAL SERVICE Edition Avril 2014
20
5. ASS Modes
5.1.ASS Mode 1 :
Remove cake tank + Put tray + Put water tank + Press OK + Plug the appliance
1 - Information : On this mode, you’ll find the information listed on the table below.
Turn the OK button for changing the page.
NO
