SECO-LARM ENFORCER HL-951R1-SQ User manual

ENFORCER One- and Two-Channel 917MHz RF Receivers
4 SECO-LARM U.S.A., Inc.
Sample Applications
:
WARRANTY:
This SECO
-
LARM product is warranted against defects in material
and workmanship while used in normal ser ice for
one (1) year from the date of sale to the original customer. SECO-LARM’s obligation is limited to the repair or replacement of any
defecti e part if the unit is returned, transportation prepaid, to SECO-LARM. This Warranty is oid if damage is caused by or attributed
to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration, improper or abnormal usage, or faulty installation,
or if for any other reason SECO-LARM determines that such equipment is not operating properly as a result of causes other than
defects in material and workmanship. The sole obligation of SECO-LARM and the purchaser’s exclusi e remedy, shall be limited to
the replacement or repair only, at SECO-LARM’s option. In no e ent shall SECO-LARM be liable for any special, collateral, incidental,
or consequential personal or property damage of any kind to the purchaser or anyone else.
NOTICE: The SECO-LARM policy is one of continual de elopment and impro ement. For that reason, SECO-LARM reser es the
right to change specifications without notice. SECO LARM is also not responsible for misprints. All trademarks are the property of
SECO-LARM U.S.A., Inc. or their respecti e owners. Copyright © 2020 SECO-LARM U.S.A., Inc. All rights reser ed.
SECO-LARM
®
U.S.A., Inc.
16842 Millikan A enue, Ir ine, CA 92606
Website:
www.seco
-
larm.com
Phone: (949) 261
-
2999 | (800) 662
-
0800
Email: sales@seco
-
larm.com
®
PITSW1
MI_HL
-
951xx
-
SQ_191220.docx
Indi idual control each channel Disable Controller
FCC/IC
COMPLIANCE
STATEMENTS
FCC ID:
K4E951T4
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
Notice: The changes or modifications not expressly appro ed by the party responsible for compliance could oid the user’s authority
to operate the equipment.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the de ice is
permitted. Any change to the antenna or the de ice could result in the de ice exceeding the RF exposure requirements and oid
user’s authority to operate the de ice.
Model
HL-951R1-SQ HL-951R2-SQ HL-951R1-LQ HL-951R2-LQ
Operating
frequency
9
17
MHz
Memory capacity
99
transm
itter button codes
per channel
Operating oltage
10
~24 VAC
, 9~48
VDC
3.2~6 VDC
l
ow
-
oltage
Operating
current
Standby
7mA@12
VDC
(typical)
Acti e
68
mA@12VDC per channel
Relay
Output
Type
Independent,
sequence, access control
Modes
1~99 sec momentary
(default
, 1s)
, 1~99 min momentary, toggle, latch, alidity (follow)
Relay
contacts
N
umber
1
2
1
2
R
ating
Form C
10A@1
4VDC
Digital Display
Signal strength, programming
functions, etc.
Connectors
Screw terminals, +,
-
, with NO/NC/COM per
relay
Operating temperature
-
40°~167° F (
-
40°~75° C)
Dimensions
3
7
/
8
"
x2
7
/
16
"
x1
3
/
16
"
(
99
x6
2
x
30
mm)
Specifications
:
Forward/Re erse, 2 Relays
•
Flexible operating oltage: 10~24 VAC, 9~48 VDC
(3.2~6 VDC low- oltage ersion also a ailable)
•Independently programmable channels
•Compatible with all SECO-LARM transmitters
of the same frequency
•5 Relay output functions
NOTE: Operating range will ary greatly depending on the installation and operating en ironment.
Installation Manual
One
-
and
Two
-
Channel
917MHz RF Recei ers
The ENFORCER 917
MHz HL
-
951
series RF
transmitters and re
cei er
s
use digital modulation for impro ed
immunity to interference, better signal penetration in en ironments with hea y obstructions, and significantly
longer range of up to 1,800ft (550m) line of sight. The ultra-low transmission power gi es you longer battery life
with easy to obtain coin-type batteries.
1.
Mount the recei er out of sight in a location where it is not exposed to weather or moisture, and where it is
not surrounded by metal. Metal will block the RF signal, resulting in a reduced range.
Installation Notes
:
Introduction:
Compatible
T
ransmitters
:
HL-951R2-SQ and HL-951T4-SQ shown
HL
-
951T1
-
SQ
..................
1
-
Button pocket
-
sized pendant, CR
-
2032 coin
-
type
battery
HL-951T2-SQ .................. 2-Button pocket-sized pendant, CR-2032 coin-type battery
HL-951T3-SQ .................. 3-Button pocket-sized pendant, CR-2032 coin-type battery
HL-951T4-SQ .................. 4-Button pocket-sized pendant, CR-2032 coin-type battery
Model
Channels
Output
Frequency
Operating
Voltage
HL
-
951R1
-
SQ
1
10A Form “C” relay
91
7
MHz
1
0~
24 VAC
,
9
~48 VDC
HL
-
951R2
-
SQ
2
10A Form “C”
relay
91
7
MHz
10~
24 VAC
,
9
~48 VDC
HL
-
951R1
-
LQ
1
10A Form “C” relay
91
7
MHz
3.2
~
6
VDC
battery
HL
-
951R2
-
LQ
2
10A Form “C” relay
91
7
MHz
3.2
~
6
VDC
battery
®
®
1.
Press the
selector
button
of for 3 seconds or more. The channel’s LED will flash L1, indicating channel 1.
To select channel 2, press the selector button again.
2. After 2 seconds, the LED will slow flash with the display showing the number of codes already in storage
and enter programming mode.
NOTE: The LED will flash a maximum of 15 seconds. If the selector button or no transmitter button is
pressed during this time, the recei er will exit programming mode, and the LED will turn off.
Entering Programming Mode
:

ENFORCER One- and Two-Channel 917MHz RF Receivers
2 SECO-LARM U.S.A., Inc.
Each c
hannel
relay
can be programmed to
one of fi e
output
modes
.
(
HL
-
9
5
1R2
-
x
Q
only:
E
ach
channel
can be
independently programmed to operate in a different output mode, depending on the user’s application.) The fi e modes are:
1. P1 – 1~99 Second Timed Pulse Output (default, 1 second) – When the transmitter button is pressed, the relay will turn
ON for the programmed number of seconds.
2. P2 – Toggle Output – Works much like a toggle switch to turn a de ice ON & OFF alternately. Press the transmitter
button once, and the relay turns ON. Press the transmitter button again, and the relay turns OFF.
3. P3 – Latch Output – Press the transmitter button once, and the relay turns ON and stays ON. The channel relay will
remain ON regardless of whether a compatible transmitter button is pressed again or not. To turn the relay OFF, press
the selector switch on the recei er once to reset.
4. P4 – Validity Output – The channel will turn the relay ON for as long as the transmitter button is pressed.
NOTE: Due to possible interference or drops in transmitter battery power while the transmitter button is continuously
pressed (e en for short periods of time), the recei er may lose the transmitter’s signal and turn the relay OFF.
5. P5 – 1~99 Minute Timed Pulse Output – When the transmitter button is pressed, the relay will turn ON for 1 second.
Clear Channel Memory:
1.
Enter programming mode and select the desired channel as described on pg.
1.
2. While the LED is flashing, press the selector button again for at least 3 seconds or until the channel indicator LED
flashes 3 times. This will clear all codes for that channel.
3. To clear codes from the other channel, enter programming mode for the other channel and repeat the abo e steps.
Display Channel Memory:
1.
To see how many codes ha e been learned
by
a channel, enter programming mode and select the desired channel as
described on pg. 1.
2. The LED will flash for 15 seconds showing number of codes stored in that channel’s memory.
Programming Channel Relay Output
Mode
:
Selecting the relay output
mode
:
•Enter programming mode and select the desired
channel as described on pg. 1.
•Press the selection button again. The LED will
display the current output mode (default P1).
•To change a channel’s output mode, press the
selector button repeatedly to scroll through the 5
output modes until the desire mode appears. Each
press mo es to the next mode in the sequence as
shown in the diagram to the right.
•In modes P1 and P5, long press the selector button
to choose the number of seconds or minutes,
respecti ely
•When complete, wait 15 seconds for the recei er to
automatically exit programming mode.
NOTE:
For a diagram of the PC board, including the location of
the function switch, please see Overview, pg. 3.
Toggle Output
(P2)
Validity Output
(P4)
1~99 sec (default, sec)
Timed Pulse Output
(P1)
Latch Output
(P3)
1~99 min
Timed
Pulse
Output
(
P5
)
Code Learning a New Transmitter Button:
1.
Enter programming mode and select the desired channel as described on pg.
1.
2. While the LED is flashing, press the desired transmitter button to be learned one time. The three horizontal bars of the
recei er’s LED indicator will flash three times to indicate the transmitter button has been successfully learned and will
automatically exit learning mode. To learn further codes, re-enter programming mode and repeat.
NOTES:
•Do not press the selection button again after entering programming mode as this will take you to output mode
programming.
•The indicator LED will flash a maximum of 15 seconds. If no transmitter button is pressed during this time, the recei er
will exit code programming mode, and the LED will turn off.
•If the code has already been learned, the indicator LED will slowly flash two dashes. The code will not be learned a
second time.
•One channel can learn the codes of a maximum of 99 transmitter buttons. If you attempt to learn an additional transmitter
code, the earliest code learned will be deleted and the new code will be learned.
ENFORCER One- and Two-Channel 917MHz RF Receivers
SECO-LARM U.S.A., Inc. 3
SK-910RB2Q shown. SK-910RBQ is the
same, but only has one each: mode
switch; function switch; indicator LED;
channel relay.
Selector Button
Operation
:
LED Indicat
or
:
O er iew:
HL-951R2-SQ PC board shown. Remo e the front co er of the recei er to access the function switch and terminal block.
Enter programming
mode
Press and hold
the selector button for three seconds or more
to enter programming mode.
Select channel for
programming
E
ntering progr
amming mode automatically takes you to channel 1. To select channel 2,
press the
selector button once more.
Learn code
After e
nter
ing
programming mode for the desired channel
, the recei er is ready to learn a code,
so the selector button is not used again. To learn a code press the desired button on the
transmitter.
Delete all codes
from a channel
After entering programming mode for the desired channel,
wait until the LED begins to flash a
number (the number of codes learned for that channel), then press and hold the selector button
for at least three seconds or until the LED flashes 3 stripes.
Memory display
After entering programming mode for the desi
red channel, after 2 seconds the LED will begin to
flash a number indicating the number of codes already stored for that channel.
Programming output
mode
After entering programming mode for the desired channel, press the selector button again. The
display will show the current mode (P1~P5). To change the mode, press again repeatedly until
the display shows the desired mode.
Programming timed
pulse duration
After following the abo e steps to program the output mode, when in mode P1 or P5, long press
the selector button to change the number of seconds or minutes, respecti ely.
8. 8.
Flashing e ery 3~5 seconds – recei er powered on and in operation
8. 8.
A alid RF signal has been recei ed
L.1.
Flashing – number shows current channel to be programmed
=. =.
Flash 2 times – new code has been learned or all codes for that channel ha e been deleted
-
.
-
.
Slow flashing – in programming mode, shows that the attempted code has pre iously been learned
Flash 2 times – exit programming mode
0. 0.
F
lashing
–
in programming
mode, shows the number of codes (0~99) already learned for the selected
channel
P.1.
In output programming mode – number indicates the current mode
0.1.
In output programming mode when either P1 or P5 has been selected
–
number indicates the output time
in
seconds or minutes, respecti ely
See "Selector Button Operation,"
below for a description of the
arious uses of this button
Selector
Button
Power input
Ch 1 relay
N.O.1
N.C.1
COM1
N.O.2
N.C.2
COM2
Ch 2 relay
– VAC1
+
VAC2
LED Display
(
HL
-
915
R2
-
x
Q
only
)
8. 8.
The LED indicator displays
:
•General status – the left dot will
flash e ery 3~5 when operating
•RF signal recei ed – the right dot
will light when an RF signal is
being recei ed
•TX Code enrollment and deletion
•Display number of codes
programmed
•Output mode programming
See "LED Indicator" below for details.
