Secura CBG-018 User manual

USER MANUAL
AUTOMATIC CONICAL BURR COFFEE GRINDER
www.thesecura.com
MODEL: CBG-018

4
SECURA AUTOMATIC CONICAL BURR COFFEE GRINDER
Copyright © 2016 – Secura Inc. - All rights are reserved. http://www.thesecura.com
A. Coffee Bean Container Lid (removable)
B. Coffee Bean Container (removable)
C. Ground Coffee Container Lid (removable)
D. Ground Coffee Container (removable)
E. Cord
F. Base
G. Cup Selector
H. ON / OFF Button
PARTS IDENTIFICATION

5
Before using the appliance for the fi rst time, or following periods of prolonged storage, it
is necessary to clean the appliance thoroughly. See the Cleaning section.
Before use make sure the voltage on the appliance rating plate matches your electrical
supply.
1.Make sure the unit is clean as per the steps mentioned in “ Cleaning and preparing
conical coffee grinder for use”
2.Place the conical grinder on a fl at, level surface such as a countertop.
3.Make sure the Ground coffee container (D) with Lid (C ) and Coffee bean container (B)
and Lid ( A) are completely inserted into the machine before grinding.
4.Plug the grinder into an outlet.
5.Fill the Coffee bean container (B) with coffee beans and replace the lid. The bean
container can hold up to 8oz of coffee beans. Note: Only fi ll the container with coffee beans.
Never fi ll the container with any of the following: sugar-coated beans, syrups or other
coatings, and instant coffee. Never fi ll the container with water or any other liquid.
6.Rotate the Coffee bean container (B) until the arrow on the container points to the
desired grind setting. There are a total of 18 settings. 1 is the fi nest setting and 18 is the
coarsest setting.
Note: Grind size settings will change the output volume of grounds. Fine settings will
produce less grounds and coarse settings will produce more grounds when the same cup
BEFORE USE
USING YOUR COFFEE GRINDER
Copyright © 2016 – Secura Inc. - All rights are reserved. http://www.thesecura.com
1.Check the bean container for the presence of foreign objects before using.
2.Make sure the bean container and ground coffee container are completely clean and
dry before using.
3.Do not place your hand in or near the grinder burr.
4.Any servicing, other than cleaning and user maintenance, should be performed by an
authorized service representative.

6
Copyright © 2016 – Secura Inc. - All rights are reserved. http://www.thesecura.com
setting is used. Caution: Never change the grind setting while the grinder is running!
7.Use the Cup selector dial (G) to pick the number of cups of coffee you will be brewing
(from 2 to 10). The amount of ground coffee yielded varies quite a bit, depending on how
coarse or fi ne you grind and whether you use light, dry beans or dark, oily beans. After
grinding a few times, you will fi nd the correct cup selector setting for the amount of coffee
you want to grind.
8.Push the On/Off Button (H) to start your grinder. The grinder will begin grinding the
coffee directly into the Ground Coffee container (D). It will stop automatically after reaching
the amount of ground coffee associated with the cup setting chosen. Note: If you need to
turn the grinder off before the grinding cycle is fi nished, press the On/ Off Button once.
9.During grinding, if either the Coffee Bean container (B) or Ground Coffee container (D)
is removed, the grinder will stop operating.
10.To avoid the unit jamming with grounds, NEVER turn the unit on if the Ground Coffee
container (D) has fi lled to the “MAX” level.
11.To avoid overheating the motor, do not grind more than 2 full, 10 cup cycles, without a
break. Allow the motor to cool at least 5 Minutes between cycles.
CLEANING/ REMOVING THE UPPER GRINDER BURR
Remove the coffee bean container & lid from the top housing by rotating it•
counterclockwise until the arrow on the side of the container reaches the OPEN
position, and then lift it straight up.
Remove the ground coffee container & lid by pulling it directly out of the base.•
Turn the upper grinder cone counterclockwise until it is loose and lift it out.•
Clean both the upper and lower grinder cones with a small brush.•
Replace the upper grinder cone into the grinder and turn it clockwise until it fi xes into position. •
SECURA AUTOMATIC CONICAL BURR COFFEE GRINDER

7Copyright © 2016 – Secura Inc. - All rights are reserved. http://www.thesecura.com
There are a total of 18 grind settings, with 1 being the fi nest grind setting and 18 being
the coarsest grind setting.
Our general recommendations are:
COARSE:
French Press Coffee Makers.•
Percolators.•
MEDIUM:
Steam Boiler Espresso Machines.•
Drip Coffee Makers. When using GoldTone Filters use a somewhat•
coarser setting; when using Filter Paper try a fi ner setting.
FINE:
Espresso pump machines.•
Fully Automatic Coffee Centers (when using ground coffee).•
Stovetop Mocha Machines.•
Manual fi lters with manual brewing.•
Manual preparation of Turkish coffee (two fi nest settings).•
Helpful Hints:
For espresso pump machines and automatic coffee centers: If your coffee or espresso•
brews too fast, try fi ner settings. If your espresso brews too slow, try coarser settings.
For French Press: Please follow the instructions of your French Press coffee maker•
(after pouring water over the ground coffee, stir thoroughly to prevent the ground coffee
from clogging).
Dark, oily beans: Grind dark oily beans one or two steps coarser than medium or light •
brown beans. On the fi nest settings it is possible that oil residue from dark, oily beans
could clog the feeder channel.
Clogging and Overfl ow: If your coffee making equipment cannot process the water •
through the grounds, overfl ow or clogging might occur. Choose a coarser grind setting.
GRIND SETTINGS

8
Before using the conical coffee grinder for the fi rst time, clean it according to the
following instructions. Then, to ensure optimal grinder function and durability, clean it
regularly following these simple steps.
Carefully unpack the coffee grinder and remove all packaging material.•
Remove any dust that may have accumulated on the removable parts during•
packaging. Remove any dust that may have accumulated on the removable parts
during packaging.
Make sure your grinder is unplugged before cleaning.•
Remove the coffee bean container & lid from the top housing by rotating it•
counterclockwise until the arrow on the side of the container reaches the OPEN
position, and then lift it straight up.
Remove the ground coffee container & lid by pulling it directly out of the base.•
Wash the coffee bean container & lid and ground coffee container & lid with mild•
detergent and water. Do not use harsh or abrasive agents to clean these parts. You
may also wash them in your dishwasher’s top rack.
Remove ground coffee from the grinder spout with a small brush.•
The coffee grinder base and housing can be wiped clean with a damp cloth, do not •
immerse them in water.
Once the components are clean, make sure they are completely dry before reinstalling •
them in the grinder.
Coffee oils can deposit inside the grinding chamber and become rancid. It is•
recommended that you clean the grinding chamber after each daily use.
Check the feeder channel for coffee build up and use the small brush to push any build•
up into the ground coffee container .
Note: The removable bean container, bean container lid, ground coffee container and
ground coffee container lid are all dishwasher safe on the top rack only (away from the
heating element).
The removable upper grinder burr is not dishwasher safe.
Dark oily beans require you to clean the grinding chamber more often then medium
brown non-oily beans.
Caution: Do not immerse the grinder or the removable grinding cone in water. Do not
use harsh or abrasive materials to clean the coffee grinder.
CLEANING AND PREPARING CONICAL COFFEE GRINDER FOR USE
Copyright © 2016 – Secura Inc. - All rights are reserved. http://www.thesecura.com
SECURA AUTOMATIC CONICAL BURR COFFEE GRINDER

9
HELPFUL HINTS
Copyright © 2016 – Secura Inc. - All rights are reserved. http://www.thesecura.com
Never grind without the ground coffee container in place! Make sure that the ground coffee•
container is completely inserted into the machine before grinding. Otherwise ground coffee
can blow out of the grinder spout creating a mess on your countertop.
Make sure there are no beans in the bean container before removing it from the machine.•
If you need to empty the bean container proceed as follows:•
a) Unplug the grinder,
b) Remove the lid and turn the machine upside down,
c) Carefully pour the beans into another receptacle and then remove the bean container and
shake out any beans that are down in the grinder.
The fi ner the grind setting, the longer it takes to grind a certain amount of coffee. •
Finely ground coffee can sometimes cling to the inside of the spout due to static electricity.•
After grinding in the fi nest settings, tap the machine to make sure any grounds are dislodged
into the ground coffee container. We recommend cleaning the grinding chamber after using
the fi ne grind settings.
Please note: Never grind “in advance”. Only grind the amount of coffee you will use for•
preparing coffee within the next hour. Ground coffee loses aroma and fl avor very fast. Ground
coffee also attracts other odors.
Do not grind for more than three minutes in a row. All of the moving parts will get warm, which •
infl uences the taste and aroma of your coffee.
Important: Never let ground coffee exceed the Max - Line on the ground coffee container. Too •
much coffee in the ground coffee container can back-up into the feeder channel. If grinding
continues this can burn out the motor.
Before removing the ground coffee container, tap the machine a few times. This will relieve •
some of the static build-up which occurs when grinding.
CONICAL GRINDER SPECIFICATIONS
Bean Hopper Capacity
Grind Settings
Cup Settings
Bin Capacity
Noise level
8 oz. (226 g)
18 (1-18)
1-10 cups
5 oz. (140 g)
88 db.
