Secure ThermoPlus AS1 Operation instructions

ThermoPlus AS1
User Operating Instructions
The ThermoPlus AS1 - Programmable Room
Thermostat Offers a number of pre-installed heating profiles
which are simple to set-up by the installer or user to provide
maximum comfort. Once complete, user operations are kept
to a minimum by using the +/ - and Warm/Cool buttons on the
front of the unit.
PLEASE NOTE: The ThermoPlus contains a selection of five
pre-set and one adjustable profile options, one of these profiles
should have been set by the Installer to meet your heating
requirements. Care should be taken to ensure the correct
profile is selected that most suits your lifestyle. Details on
how to change the selected profile are located on page 9 of
this guide.
1

What is a programmable room thermostat?
...an explanation for householders.
A programmable room thermostat is both a programmer and a
room thermostat. A programmer allows you to set 'ON and OFF'
time periods to suit your own lifestyle. A room thermostat works
by sensing the air temperature, switching on the heating when
the air temperature falls below the thermostat setting and
switching it off once the set temperature has been reached.
So, a programmable room thermostat lets you choose what
times you want the heating to be on, and what temperature it
should reach while it is on. It will allow you to select different
temperatures in your home at different times of the day (and
days of the week) to meet your particular needs.
Turning a programmable room thermostat to a higher setting
will not make the room heat up any faster. How quickly the room
heats up depends on the design of the heating system, for
example, the size of the boiler and radiators. Neither does the
setting affect how quickly the room cools down. Turning a
programmable room thermostat to a lower setting will result in
the room being controlled at a lower temperature, and saves
energy.
The way to set and use your programmable room thermostat is
to find the lowest temperature settings that you are comfortable
with at the different times you have chosen, and then leave it
alone to do its job. The best way to do this is to set low
temperatures first, say 18ºC and then turn them up by one
degree each day until you are comfortable with the
temperatures. You won't have to adjust the thermostat further.
Any adjustments above these settings will waste energy and
cost you more money.
2

contd...
What is a programmable room thermostat?
If your heating system is a boiler with radiators, there will usually
be only one programmable room thermostat to control the
whole house. But you can have different temperatures in
individual rooms by installing thermostatic radiator valves
(TRVs) on individual radiators. If you don't have TRVs, you
should choose a temperature that is reasonable for the whole
house. If you do have TRVs, you can chose a slightly higher
setting to make sure that even the coldest room is comfortable,
then prevent any overheating in other rooms by adjusting the
TRVs. The time on the programmer must be correct. Some
types have to be adjusted in spring and autumn at the changes
between Greenwich Mean Time and British Summer Time. You
may be able to temporarily adjust the heating programme, for
example, 'Override', 'Advance' or 'Boost'. These are explained
in the manufacturer's instructions.
Programmable room thermostats need a free flow of air to
sense the temperature, so they must not be covered by curtains
or blocked by furniture. Nearby electric fires, televisions, wall or
table lamps may prevent the thermostat from working properly.
3

Warm and Cool Temperature Adjustments
The ThermoPlus has two preset temperature levels, these are
known as 'Warm', higher level temperature(21 °C) and 'Cool',
lower or set back temperature(15 °C). The preset temperatures
have been selected to give a comfortable, safe, yet efficient
temperature level in the home.
In certain installations it may be necessary to adjust either
the 'Warm' and / or 'Cool' temperatures to meet the specific
needs of the user. This can be achieved by following the
simple steps below; (Additional information is also contained
within the General Information section of this guide)
6
1
2
3 5 4 8 7
4

Warm and Cool Temperature Adjustments
Thermoplus Programming Mode
The ThermoPlus AS1 has been designed for minimal user
intervention, however should any changes be required please
press buttons 4 and 8 simultaneously to enter the programming
mode, this will allow you to;
- Check the current time/date/year
- Check the current profile
- Set a new pre-set profile or
- Set a user defined profile
PLEASE NOTE; Upon completion of
the instructions above, please
ensure that you exit the programming
mode by pressing button 4 and 8 simultaneously.
Time and Date Check
The ThermoPlus thermostat has been pre-set with the current
time and date during manufacture. No alteration should be
required to the time and date, however if any modification
is required please refer to the flowchart below.
Open
Cover
Select warm
or cool
temperature
by pressing
“WARM /
COOL”button
Adjust the
temperature
by using UP /
DOWN
buttons
Once
adjustment
is complete
close the
cover
4
8
5

Time and Date Check
Open Cover
Enter programming mode
(Details given on the previous page)
Press TIME
Press SET
MINUTE flashes,
adjust using UP/
DOWN buttons Press SET HOURS flashes,
adjust using UP/
DOWN buttons Press SET
HOURS flashes,
adjust using UP/
DOWN buttons
Press SET
MONTH flashes,
adjust using UP/
DOWN buttons
Press SET
Press EXIT
Exit Programming mode Press EXIT
6

Warm and Cool Temperature Adjustment
The Warm and Cool target
temperature settings on the
ThermoPlus AS1 are fully
adjustable. To change a
target temperature it is first
necessary to press the the
centre button to bring up the
'Warm' or 'Cool' setting
(Indicated by the red or blue
LED indicators). By using the
up/down keys under the flap
the 'Warm/Cool' temperature
can be increased or
decreased to the desired
temperature setting
PLEASE NOTE - it is not possible to set the warm setting to
below that of the cool setting or vice versa.
Once a new temperature has been set on either the Warm or
Cool setting the AS1 will continue to use this setting until the
next manual adjustment.
PLEASE NOTE - The AS1 will display any temporary
change the user has made by pressing the + or - buttons, this
does not indicate a permanent change in either the Warm or
Cool settings, the temperature will return to the pre-set levels
at the next switching period. During an override the 'Warm'
or 'Cool' setting will not be displayed on the LCD.
Press here to select Warm or Cool
7

To increase
Press
To decrease
Press
Warm and Cool Temperature Adjustment
8

Setting Heating Profiles
The ThermoPlus AS1 contains a selection of five preset and one
user definable profile options, one of these will have been set by
the Installer. Care should be taken to ensure a profile is selected
that suits your lifestyle the best. Profiles one to five are detailed on
pages 8 and 9. If none of the preset profiles meet your
requirements it is possible to set a user defined profile, full details
are given on page 10. Open Cover
Enter programming mode by pressing
buttons 4 & 8 simultaneously
Press PROG
Press SET
Select the required profile by using the UP / DOWN buttons
Press SET
Press EXIT
Exit PROGRAMMING mode
Profiles one to five have fixed programmes, they can be reviewed by
pressing the set button once the selection process detailed above has
been completed. To set a custom profile please refer to the instructions
on page 12. 9

The ThermoPlus has six heating profiles, five are fixed and one is adjustable.‘ONE’
has been set as the default and is detailed below. During installation a heating
profile should have been set to best match your requirements; illustrations of the
preset below shown are profiles.
Heating Profiles
24 HOUR
ONE – DEFAULT START STATUS
EVERY DAY 06:00 WARM
22:00 COOL
PROFILE TWO START STATUS
EVERY DAY 06:00 WARM
08:00 COOL
17:00 WARM
22:30 COOL
PROFILE THREE START STATUS
EVERY DAY 06:00 WARM
08:00 COOL
11:30 WARM
13:30 COOL
17:00 WARM
22:30 COOL
1
PROFILE
24 HOUR
2
PROFILE
24 HOUR
3
PROFILE
1
1
TIME
TIME
TIME
PROFILE
PROFILE
PROFILE
WARM
WARM
WARM
COOL
COOL
COOL
2
2
2
3
3
3
4
4
4
5
5
5
6
6
6
7
7
7
8
8
8
9
9
9
10
10
10
11
11
11
12
12
12
13
13
13
14
14
14
15
15
15
16
16
16
17
17
17
18
18
18
19
19
19
20
20
20
21
21
21
22
22
22
23
23
23
00
00
00
TIME PROFILE
TIME PROFILE
TIME PROFILE
TEMPERATURE PROFILE
TEMPERATURE PROFILE
TEMPERATURE PROFILE
Profiles One To Three
24 Hour - Same Profile Each Day
10

Profiles one to five have fixed periods, no alteration to the Warm / Cool
times can be made, if it is necessary to make any alterations then
profile six must be used. Profile six will allow you to set up a profile to
your exact requirements. Please refer to the flowchart on page 10.
Profiles Four and Five
5 Day/ 2 Day - Different Weekday / Weekend Profile
START STATUS START STATUS
MON - FRI 06:00 WARM SAT/SUN 07:00 WARM
08:00 COOL 22:00 COOL
11:30 WARM
13:30 COOL
17:00 WARM
22:30 COOL
PROFILE FIVE START STATUS START STATUS
MON - FRI 06:00 WARM SAT/SUN 07:00 WARM
08:00 COOL 22:00 COOL
17:00 WARM
22:30 COOL
4
PROFILE
5/2 DAY
5
PROFILE
5/2 DAY
1
TIME
TIME
MON - FRI
MON - FRI
SAT/SUN
SAT/SUN
WARM
WARM
WARM
WARM
COOL
COOL
COOL
COOL
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
18
18
19
19
20
20
21
21
22
22
23
23
00
00
TIME PROFILE
TIME PROFILE
TEMPERATURE PROFILE
TEMPERATURE PROFILE
MON - FRI
MON - FRI
SAT/SUN
SAT/SUN
1
11

6
PROFILE
User Definable - 7 Day Programming
Profile Six
Open Cover
Enter programming mode
(Details on page..)
Press PROG
Press SET
Adjust the warm start time by
using the UP/DOWN bttuons
and confirming with the SET
button
Adjust the cool start time by
using the UP/DOWN bttuons
and confirming with the SET
button
Once a day has been
completed press either; SET -
continue to next day COPY -
apply altered setting to the
next day Or exit
Press EXIT
Exit Programming mode
Repeat until
each required
period is set
Repeat until
each required
period is set
COPY FEATURE
The copy feature can be used to
apply changes made from one
days programming to the next.
This is achieved by pressing the
down arrow button when 'SET'
is displayed on the screen.
'SET' is displayed after the last
cool period is confirmed on each
day.
12

Resetting the ThermoPlus AS1
Electronic equipment can in some circumstances be affected by electrical
interference. If the display becomes frozen or scrambled; or if you wish to
revert back to the default settings please use the following procedure.
To reset press
Reset Procedure
PLEASE NOTE; Using this procedure will restore the ThermoPlus to
the original factory programme settings, the time setting will also
default to 1st January 2005.
RESETTING THE THERMOPLUS AS1
On the ThermoPlus AS1 press the 'UP' and 'DOWN'
arrow buttons together:
Then release the buttons and the thermostat will return to preset
factory settings.
13

General Information
Frost Protection
The Blue button situated under the flap will initiate the frost
protection mode when pressed, the word 'STANDBY' will
appear on the display, the thermostat has been pre-
programmed with a frost protection temperature level of 7oC,
this can be adjusted by using the up and down arrow buttons.
Battery
The programmer is fitted with a non-rechargeable, long life
battery, which will maintain the programmed time settings for a
minimum of 12 months with the supply disconnected. THIS
SHOULD BE SUFFICIENT TO COVER POWER
INTERRUPTIONS DURING THE LIFE OF THE UNIT. During
power interruptions the LCD display and LED indicators will not
function.
Service and Repair
The ThermoPlus AS1 is NOT user serviceable. Please do not
dismantle the unit. In the unlikely event of a fault developing
please refer to the RESETTING THE THERMOSTAT section of
this user guide located on page 9. If this fails to resolve the
problem please contact a local heating engineer or a qualified
electrician.
14

Specification ThermoPlus AS1
Contact type: Micro dis-connection
(Voltage Free)
Contact rating: 3(1)Amps 230-240V
AC Power supply: 230-240V AC 50Hz
Operating temperature range 0 °C to 40 °C
Temperature control range 5 °C to 30 °C
Standby temperature 5 °C to 30 °C
Double insulated.
Dirt protection Normal situations
Enclosure protection IP30
Purpose of control Electronic thermostat
Reserve Battery Type Lithium
Case material Thermoplastic, flame retardant
Dimensions 120mm x 90mm x 32mm
Display
User LED
Programming Liquid crystal, Backlit
Clock 24 hour
Display time adjustment: 1 Minute steps
Switched time adjustment: 15 Minute steps
Programme selection Auto,
Standby operating periods per day (Warm) 3
Override Instant Warm/Cool
Backplate
Standard(s) Industry Standard Backplate
15
BS EN 60730-1, BS EN
60730-2-9, EN 60730-1, EN
60730-2-9

www.securemeters.com
Secure Meters (UK) Ltd
Secure House, Lulworth Close,
t: +44 1962 840048 f: +44 1962 841046
Eastleigh, SO53 3TL, UK
Chandlers Ford,
Part Number P82312 Issue 5
INDEX
Introduction and operating guide 2
Warm/Cool temperature adjustment 3
Programming mode 4
Time and date check 5
Setting profiles 8
Heating profiles 1-5 9
Profile 6 - User adjustable 10
Reset procedure 12
General information 13
Specification 14
NP008231200 0
Table of contents
Other Secure Thermostat manuals

Secure
Secure STP328 User manual

Secure
Secure SEC_SRT321 Instruction manual

Secure
Secure SRT321 User manual

Secure
Secure radbot 1 User manual

Secure
Secure C1727 User manual

Secure
Secure Beanbag User manual

Secure
Secure H3747 User manual

Secure
Secure SCS317 User manual

Secure
Secure SCP318 Operation instructions

Secure
Secure SRT321 Operating instructions
