SecureStart SS103A User manual

7 0
Mini Max 900
Portable Jump Starter
With Fuel-Gauge Indicator
SS103A User’s Manual

3
When to Recharge Your SecureStart™
It is mandatory to recharge SecureStart™ immediately after used. SecureStart™ is
incorporated with smart charging system as to prevent overcharging. Therefore permanent
(float/trickle) plugged-in charging is highly recommended.
Simply press and hold the fuel-gauge switch to observe the LED color on the fuel-gauge
indicator.
GREEN : Ready to jump-start
ORANGE/RED/ : Immediately recharge your SecureStart™ and replace 13 pieces ofAA
Audible “Beep” GP UltraAlkaline batteries at the same time
To ensure successful instant jump-starting, check the fuel-gauge indicator monthly.
Recharge your SecureStart™ immediately when the Orange or Red light is on.
Recharging of SecureStart™ is required monthly and is more frequently during summer
when temperature exceeds 29°C (85°F). It is recommended to store your SecureStart™
in a cool, dry location to maximize its performance.
Failure to follow the charging instructions may shorten your unit’s service life.
Jump-Starting Your Vehicle
1. Turn vehicle ignition switch to OFF before accessing battery in vehicle or connecting
cable clamps to vehicle battery.
2. Open hood of vehicle and position SecureStart™ away from fan blades, belts, pulleys or
any other moving parts.
3. Connect the Red positive (+) cable clamp first to the vehicle battery’s positive (+)
terminal. Rotate clamp slightly to ensure a good connection.
4. Connect the Black negative (-) cable clamp last to vehicle chassis, engine block,
hanging hook or other unpainted, non-moving metal surface that is away from the vehicle
battery. Rotate clamp slightly to ensure a good connection.
NOTE: Use SecureStart™ only on gasoline-powered engines with a 12-volt
cranking system. Read all instructions and safety warnings before use.
4
5. Turn vehicle ignition switch ON and start the engine.
6. After engine is started, leave the cable clamps of SecureStart connected for 3 minutes to
allow a top up charge of the SecureStart™ in case of reuse within short time.
7. Disconnect the Black negative (-) cable clamp first and place it to its storage position in
your SecureStart™.
8. ONLY after removing and storing the Black negative (-) cable clamp, disconnect the Red
positive (+) cable clamp last from the vehicle battery positive (+) terminal and place it to
its storage position in your SecureStart™.
9. It is mandatory to recharge your SecureStart™ immediately with wall adaptor (not
provided) or car adaptor for at least 2 cumulative hours. Permanent (float/trickle)
plugged-in charging is highly recommended.
10.SecureStartTM is allowed to crank for maximum 5 times between full charges with car
adaptor or wall adaptor (not provided).
Warranty Terms and Conditions
Your SecureStart is covered by a conditional, limited warranty to the original purchaser.
Your SecureStart is warranted to be free from defects in material and workmanship for a
limited period (as stated on card) from the date of sale. If your jumpstart unit malfunctions
or fails within the warranty period because of a defect in material or workmanship, we will
repair or replace it, at our discretion, without charge. You must present a sales invoice or
receipt to prove the date of purchase. If the warranty seal sticker is damaged, the warranty
shall be voided. This product warranty does not apply to the AA alkaline primary batteries.
Returned units determined to have been subjected to misuse shall not be covered under
warranty. This warranty does not cover defects or failures of your SecureStart due to any
cause other than defective manufacturer’s material or workmanship, including without
limitation any malfunctions or failures caused by repairs made by an unauthorized person
mishandling, modifications, normal wear, unreasonable use or damage. IN NO EVENT
SHALL THE MANUFACTURER BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES.
EXCEPT FOR THIS LIMITED WARRANTY, THE MANUFACTURER HAS NOT MADE, AND
SPECIFICALLY DISCLAIMS, ANY WARRANTY OR REPRESENTATION OF ANY KIND,
EXPRESS OR IMPLIED, DIRECT OR INDIRECT, OF PRODUCT FITNESS FOR A
PARTICULAR PURPOSE. THIS LIMITED, CONDITIONAL WARRANTY PROVIDES THE
EXCLUSIVE REMEDY FOR ANY CLAIM OR DAMAGE EXCEPT AS OTHERWISE
REQUIRED BY LAW.
NOTE: Use SecureStartTM only on 3-litre or smaller gasoline-powered engines if without car battery.

5
IMPORTANT
Read All Instructions And Safety Warnings
Before Using SecureStart™
Warning / Safety Information
1. Read and follow all instructions in this manual before using the SecureStart™.
2. Follow all instructions published by the automobile and car battery manufacturers,
especially the procedure of jump-starting of a car.
3. KEEP OUT OF THE REACH OF CHILDREN.
4. NEVER ALLOW cable clamps (“+” & “-“) to TOUCH each other. Cable clamps are
“live” at all times, and will spark once they touch, SecureStart™ will generate heat too.
Always ensure clamps are stowed securely in clamp holders when not connected for
jump-starting.
5. ALWAYS VERIFY car battery positive terminal (RED “+”) before connecting cable
clamps to battery. Be aware of connecting sequence.
6. Handle SecureStart™ and car battery with care while jump-starting a car. Car batteries
generate hydrogen gas during normal battery operation, such gas may cause explosion
with a spark. Care should be taken to ensure sparks are not generated near the car
battery. Sparks occur when connecting or disconnecting leads. Keep sparks and
flames away from batteries.
7. Keep hands and cables clear of fan blades, belts pulleys and other moving parts when
working near a running engine. Remove jewelry, watch and loose clothing when near
the engine compartment. Take extra care to protect eyes during jump-starting.
8. Do not charge the SecureStart™ in wet or moist locations through the DC charging jack.
Severe electrical shock may result.
9. Do not charge the SecureStart™ in an airtight container, provide adequate ventilation
during charging.
10. Do not attempt to disassemble the SecureStart™. Do not cut any cables or wires on
this product. The TMF®power pack contained within your unit is capable of generating
very high current. This current may cause severe burns or personal injury.
11. Use your SecureStart™ to jump-start cars that run with lead-acid battery only. Do not
jump-start a car that with frozen car battery or attempt to charge it with a SecureStart™.
12. Never immerse SecureStart™ into water or seawater.
13. Keep SecureStart™ away from sunlight, hot and high humidity environment. Do not
store with metal parts such as tools and wires etc.
14. SecureStart™ contains non-spill-able sealed lead-acid batteries. Under normal and
appropriate use, the product is safe and there is no exposure to lead.
//IMSS103A-E, 20080814//
2
STEP 3: Replace 13 pieces of AA alkaline batteries.
- locate battery cover on back of the SecureStart and push cover slightly in
direction of arrow. Remove cover.
- remove 13 pieces of AA batteries and replace with the fresh AA Ultra
Alkaline batteries. Orientate batteries according to directions indicated in
bottom of battery compartment.
- slide battery cover over battery compartment until cover locks in place.
STEP 4: Charge your SecureStart™ by using car adaptor or wall adaptor (not provided)
immediately.
By Car Adaptor - 6 hours accumulatively or permanently plugged-in:
Plug the car adaptor into the cigarette lighter socket of your vehicle. Plug the
other end of the car adaptor cable jack into the DC charging socket on
SecureStart™.
Charging will start only when the engine is ignited.
During charging your SecureStart with the car adaptor, the green LED on the car adaptor will remain on
showing that there is power from the cigarette lighter socket. To maximize SecureStart™ performance,
permanent plugged-in charging is recommended.
On-Charge Display with car adaptor may change color randomly due to
fluctuation of alternator voltage. Please ignore the color changes.
By Wall Adaptor (not provided) - minimum 4 hours or permanently plugged-in charging:
Plug the DC jack of the adaptor into the DC charging socket on SecureStart™.
Your SecureStart™ will begin charging upon switching the AC outlet to “ON”.
To maximize SecureStart™ performance, permanent plugged-in charging is recommended.
On-Charge Display With Wall Adaptor Only:
Steady GREEN Indication - Unit is fully charged and ready to GO.
Steady RED Indication - Unit is on charge.
Plug into the jack here
Plug into the cigarette
Lighter socket of vehicle
Plug into the jack here
Plug into the wall socket

1
Getting to Know Your SecureStart™
Prepare Your SecureStart™ Before First Use
STEP 1: Upon purchase, disconnect the external 13-cell AA alkaline battery pack that
is connected with a wire connector to the SecureStart by pulling the connecting wire out.
Discard this 13-cell alkaline battery pack.
STEP 2: Depress the fuel gauge switch, if the fuel gauge shows green light, just
recharge the SecureStart™ (skip to Step-4). If fuel gauge shows orange or red light,
complete Step-3 and 4 as follows.
STEP 1: STEP 3:
WARNING: DO NOT allow the cable clamps to TOUCH each other! The
cable clamps carry electrical current at all times. If they touch each other, severe
sparks may cause personal injury and battery explosion. Use only the car
adaptor or wall adaptor supplied with your SecureStart™ for charging. To avoid
dama
g
e, do not use an
y
other char
g
ers or a
pp
l
y
an
y
other char
g
in
g
methods.
!
AA Ultra Alkaline Battery
Compartment 13 pieces of
AA Ultra Alkaline Batteries
Battery orientation shown here
Green LED
FRONT
OR
Red Negative (+)
Cable Clamp
Black Negative (-)
Cable Clamp
Fuel-Gaugein
Indicator Fuel-Gauge SwitchDC Charging Jack
13 cells AA ultra Alkaline Battery Pack
with connector wire
12V DC
Car Adaptor
15VDC minimum 1Amp
Wall Adaptor
(Not provided)
REAR
6
WARRANTY CARD
Product Type SecureStart SS103A
Serial No.
Date of
Purchase Warranty Period: 1 year from date of
purchase
Name:
Address:
Customer’s
Contact
Tel No.:
Retailer
Under normal usage according to the user
manual, if product defects happen within 1
year after purchase please contact the
sales agent or retail shop for warranty
claim.
If faults found due to abuse, repair charge
will be applicable. If this warranty card is
lost or there are no records of purchase
date and name of retailer, the warranty will
be void. Please retain this warranty
document with proper record.
Please refer to page 4 for details.
Agent:
