Security Brands Edge 27-210 Owner's manual

DIRECT PROGRAMMING MANUAL
27-210, 27-220HID/SK, 27-225HID/SK,
27-230HID/SK, 27-235HID/SK, 27-240

Edge SMART KEYPADs and Card Readers
Direct Programming Manual
Applicable Models
27-210, 27-220HID, 27-220SK, 27-225HID, 27-225SK, 27-230HID, 27-230SK, 27-235HID, 27-235SK, 27-240
© 2021 Security Brands, Inc. All rights reserved.

Edge Smart Keypads and Card Readers Direct Programming Manual
If you need help, please email [e-mail] or call [phone].
Table of Contents
Introduction _____________________________________________________________________________3
Overview__________________________________________________________________________________________________ 3
Glossary___________________________________________________________________________________________________ 3
Programming ____________________________________________________________________________ 4
Direct Programming Input Format____________________________________________________________________ 4
Sub Modes Overview____________________________________________________________________________________ 4
Default Configuration __________________________________________________________________________________ 5
Audible Tone Feedback _________________________________________________________________________________ 6
Programming Procedures ______________________________________________________________________________ 6
Add Access Code(s) to Relay A ___________________________________________________________________6
Delete Code______________________________________________________________________________________6
Change Master Code ____________________________________________________________________________7
Enable/Disable Relays ___________________________________________________________________________7
Add Latch Code to Relay B _______________________________________________________________________7
Change Sleep Code ______________________________________________________________________________7
Change Code Length_____________________________________________________________________________8
Change Relay Trigger Time ______________________________________________________________________8
Enable/Disable Timers and Schedules ___________________________________________________________8
Enable/Disable “3 Strikes, You’re Out” ___________________________________________________________9
Configure Event Input 1__________________________________________________________________________9
Add Latch Code to Relay A _____________________________________________________________________ 12
Add Access Code(s) to Relay A on Both Wiegand Inputs _______________________________________ 12
Add Access Code(s) to Relay A on Wiegand Input 1 ____________________________________________ 15
Add Access Code(s) to Relay A on Wiegand Input 2 ____________________________________________ 17
Add Manager Access Code(s) to Relay A on Both Wiegand Inputs _____________________________ 19
Add Manager Access Code(s) to Relay A on Wiegand Input 1 __________________________________ 21
Add Manager Access Code(s) to Relay A on Wiegand Input 2 __________________________________ 23
Add Sleep Code(s) on Both Wiegand Inputs____________________________________________________ 26
Add Sleep Code(s) on Wiegand Input 1 ________________________________________________________ 28
Add Sleep Code(s) on Wiegand Input 2 ________________________________________________________ 30

Direct Programming Manual Edge Smart Keypads and Card Readers
If you need help, please email [e-mail] or call [phone].
Add Latch Code(s) to Relay A on Both Wiegand Inputs_________________________________________ 32
Add Latch Code(s) to Relay A on Wiegand Input 1 _____________________________________________ 35
Add Latch Code(s) to Relay A on Wiegand Input 2 _____________________________________________ 37
Add Access Code(s) to Relay B on Both Wiegand Inputs _______________________________________ 39
Add Access Code(s) to Relay B on Wiegand Input 1 ____________________________________________ 41
Add Access Code(s) to Relay B on Wiegand Input 2 ____________________________________________ 44
Add Latch Code(s) to Relay B on Both Wiegand Inputs_________________________________________ 46
Add Latch Code(s) to Relay B on Wiegand Input 1 _____________________________________________ 48
Add Latch Code(s) to Relay B on Wiegand Input 2 _____________________________________________ 50
Change Default Facility Code __________________________________________________________________ 53
Add Split-Relay Access Code on Wiegand Inputs _______________________________________________ 53
Add Split-Relay Latch Code on Wiegand Inputs ________________________________________________ 55
Delete Code(s) on Both Wiegand Inputs _______________________________________________________ 57
Delete Code(s) on Wiegand Input 1 ____________________________________________________________ 59
Delete Code(s) on Wiegand Input 2 ____________________________________________________________ 61
Set Unit Clock Time ____________________________________________________________________________ 64
Set Unit Clock Date ____________________________________________________________________________ 64
Configure Split-Relay Function _________________________________________________________________ 64
Toggle Silent Mode ____________________________________________________________________________ 66
Configure Anti-Passback _______________________________________________________________________ 66
Configure Wiegand Inputs _____________________________________________________________________ 69
Configure Wiegand Bit Format_________________________________________________________________ 70
Configure Wiegand Code Scheme _____________________________________________________________ 71
Configure Wiegand Validation Method ________________________________________________________ 72
Change Wiegand Code Length _________________________________________________________________ 72
Add Access Code(s) to Relay B _________________________________________________________________ 73
Add Limited-Use Code _________________________________________________________________________ 73
Enter Pairing Mode ____________________________________________________________________________ 74
Delete All Codes and Timers ___________________________________________________________________ 74
Master Code Reset_____________________________________________________________________________ 74
Unit Reset______________________________________________________________________________________ 75
Technical Support _____________________________________________________________________ 75

Edge Smart Keypads and Card Readers Direct Programming Manual
If you need help, please email [e-mail] or call [phone]. 3
Introduction
Overview
This manual covers in detail how to carry out all programing functions on all Edge Smart Keypad and
Card Reader systems directly via the onboard keypad.
Glossary
Access Card/Code
A card/code used to trigger a relay for a configurable trigger time and open a gate or door.
Anti-Passback
An access control scheme designed to prevent access for individuals to whom access has not been
properly granted.
Latch Card/Code
A card/code used to latch a relay and hold a gate or door open if the relay is off and unlatch a relay
allowing a gate or door to close if the relay is on. It toggles the current relay state.
Manager Card/Code
A card/code that remains functional even when the unit is in Sleep Mode.
Master Code
A four-digit code used for programming.
Programming Mode
An operation mode on the Edge unit that allows the unit to be programmed, allowing access control
administration and management as well as configuration of features and connected devices.
Silent Mode
An operation mode on the Edge unit that disables all audible tones.
Sleep Card/Code
A card/code used to enable/disable Sleep Mode.
Sleep Mode
An operation mode on the Edge unit that disables acceptance of all access and latch cards and
codes, event inputs, and tones. Only manager cards/codes are functional while Sleep Mode is active.
Wiegand
A communications protocol used in access control, which allows keypads, proximity card readers,
remotes, and vehicle tag readers connected to a primary controller to be managed by the controller.

Direct Programming Manual Edge Smart Keypads and Card Readers
4 If you need help, please email [e-mail] or call [phone].
Programming
Direct Programming Input Format
All direct programming procedures involve entering the Master Code at the Edge unit to enter
Programming Mode, entering the Sub Mode, entering additional Sub Modes (depending on feature),
entering the parameter value(s), and pressing the pound key (#) to exit programming.
Sub Modes Overview
Sub Mode
Sub Mode 2
Programming Feature
1
-
Add Access Code(s) to Relay A
2
-
Delete Code
3 - Change Master Code
4 2 Enable/Disable Relays
4 3 Add Latch Code to Relay B
4
4
Change Sleep Code
4
5
Change Code Length
4
6
Change Relay Trigger Time
4 7 Enable/Disable Timers and Schedules
4 8 Enable/Disable “3 Strikes, You’re Out”
4 9 Configure Event Input 1
5
-
Add Latch Code to Relay A
6
100
Add Wiegand Access Code(s) to Relay A
6
101
Add Wiegand Manager Code(s) to Relay A
6 102 Add Wiegand Sleep Code(s)
6 103 Add Wiegand Latch Code(s) to Relay A
6 104 Add Wiegand Access Code(s) to Relay B
6
105
Add Wiegand Latch Code(s) to Relay B
6
106
Change Default Facility Code
6
107
Add Wiegand Split-Relay Access or Latch Code(s)
6
200
Delete Wiegand Code(s)
6 302 Set Unit Clock Time
6 303 Set Unit Clock Date
6
307
Configure Split-Relay Function
6
309
Toggle Silent Mode
6
310
Configure Anti-Passback
6
500
Configure Wiegand Inputs
6 501 Configure Wiegand Bit Format on Both Wiegand Inputs

Edge Smart Keypads and Card Readers Direct Programming Manual
If you need help, please email [e-mail] or call [phone]. 5
6
502
Configure Wiegand Bit Format on Wiegand Input 1
6 503 Configure Wiegand Bit Format on Wiegand Input 2
6 504 Configure Wiegand Code Scheme
6 505 Configure Wiegand Validation Method
6
506
Configure Wiegand Code Length
7
-
Add Access Code(s) to Relay B
8
-
Add Limited-Use Code
9 - Enter Pairing Mode
0 - Delete All Codes
Default Configuration
Feature/Parameter
Value
Master Code 1251
Sleep Code 1985
Relay A Manager Access Code
1366
Relay A Manager Latch Code
1273
Relay A Manager Unlatch Code
1381
Relay B Manager Access Code
1752
Relay B Manager Latch Code
1678
Relay B Manager Unlatch Code
1387
Access/Latch Code Length
4 digits
Relay Trigger Time
5 seconds
Keypad Press-to-Press Timeout
5 seconds
Programming Timeout
15 seconds
Timers and Schedules
Enabled
“3 Strikes, You’re Out”
Disabled
Event and Digital Inputs Disabled
Wiegand Inputs Disabled
Split-Relay Function Disabled
Anti-Passback Disabled
Silent Mode Disabled

Direct Programming Manual Edge Smart Keypads and Card Readers
6 If you need help, please email [e-mail] or call [phone].
Audible Tone Feedback
All Edge units produce audible tone feedback for key presses, correct entries, incorrect entries, and
to confirm a cleared entry as detailed below. Audible feedback is also used for feature status/mode.
Good Tone: sounds when a correct control or programming entry is received by the Edge unit.
Bad Tone: sounds when an incorrect control or programming entry is received by the Edge unit.
The tone is reminiscent of a buzzer.
Key Tone: sounds every time a key is pressed on the Edge unit keypad.
Clear Tone: sounds to confirm the entry has been cleared when the star (*) key is pressed on
the keypad to clear an unwanted or mistaken entry.
Programming Procedures
All procedures must be entered using the keypad on the Edge unit. Make sure the unit sounds tones
with every key press. Otherwise the unit may be powered off, in Sleep Mode, or having an issue.
Add Access Code(s) to Relay A
This procedure will add one or more access codes to Relay A.
Note: By default, the following codes are reserved for other functions and cannot be used:
1251, 1273, 1366, 1381, 1387, 1678, 1752, and 1985.
1251 $1 $XXXX$#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 1 and listen for good tone.
Enter code (4 digits by default; numbers only) to be added and listen for good tone.
Repeat above step to add additional codes.
Enter # key to exit Programming Mode.
Delete Code
This procedure will delete a specified code (access and latch codes only; no Wiegand codes).
1251 $2 $XXXX $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 2 and listen for good tone.
Enter code to be deleted and listen for good tone.
Enter # key to exit Programming Mode.

Edge Smart Keypads and Card Readers Direct Programming Manual
If you need help, please email [e-mail] or call [phone]. 7
Change Master Code
This procedure will change the current Master Code.
Note: By default, the following codes are reserved for other functions and cannot be used:
1251, 1273, 1366, 1381, 1387, 1678, 1752, and 1985.
1251 $3 $XXXX$#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 3 and listen for good tone.
Enter new Master Code (4 digits; numbers only) and listen for good tone.
Enter # key to exit Programming Mode.
Enable/Disable Relays
This procedure will enable or disable Relay A or B.
1251 $4 $2 $X $X $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 2 and listen for good tone.
Enter 1 (for Relay A) or 2 (for Relay B).
Enter 1 (to enable) or 2 (to disable).
Enter # key to exit Programming Mode.
Add Latch Code to Relay B
This procedure will add a latch code to Relay B.
Note: By default, the following codes are reserved for other functions and cannot be used:
1251, 1273, 1366, 1381, 1387, 1678, 1752, and 1985.
1251 $4$3 $XXXX$#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 3 and listen for good tone.
Enter code (4 digits by default; numbers only) to be added and listen for good tone.
Enter # key to exit Programming Mode.
Change Sleep Code
This procedure will change the sleep code.
Note: By default, the following codes are reserved for other functions and cannot be used:

Direct Programming Manual Edge Smart Keypads and Card Readers
8 If you need help, please email [e-mail] or call [phone].
1251, 1273, 1366, 1381, 1387, 1678, 1752, and 1985.
1251 $4 $4 $XXXX$#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 4 and listen for good tone.
Enter new sleep code (4 digits; numbers only) and listen for good tone.
Enter # key to exit Programming Mode.
Change Code Length
This procedure will change the code length for non-Wiegand codes from 4 to 11 digits.
IMPORTANT! COMPLETING THIS PROCEDURE WILL DELETE ALL ACCESS AND LATCH CODES!
1251 $4 $5 $XX $1251$#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 5 and listen for good tone.
Enter code length (04 to 11) and listen for good tone.
Enter Master Code and listen for good tone.
Enter # key to exit Programming Mode.
Change Relay Trigger Time
This procedure will change the relay trigger time for Relay A or B from 1 to 999 seconds.
1251 $4 $6 $X $XXX $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 6 and listen for good tone.
Enter 1 (for Relay A) or 2 (for Relay B) and listen for good tone.
Enter trigger time in seconds (001 to 999) and listen for good tone.
(e.g., 10 seconds would be entered as 010.)
Enter # key to exit Programming Mode.
Enable/Disable Timers and Schedules
This procedure will enable or disable timers and schedules.
1251 $4 $7 $1 $#

Edge Smart Keypads and Card Readers Direct Programming Manual
If you need help, please email [e-mail] or call [phone]. 9
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 7 and listen for audible feedback.
Single tone means feature is enabled.
Double tone means feature is disabled.
Enter 1 (for no change) or 2 (to change current state) and listen for good tone.
Enter # key to exit Programming Mode.
Enable/Disable “3 Strikes, You’re Out”
This procedure will enable or disable “3 Strikes, You’re Out” security. When enabled, the Edge unit
will sound an alarm and go into a 90-second period of lockdown when an incorrect code is entered
three times on the keypad.
1251$4 $8 $1 $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 8 and listen for status tones.
One tone: feature is enabled.
Two tones: feature is disabled.
Enter 1 (for no change) or 2 (to change current state) and listen for good tone.
Enter # key to exit Programming Mode.
Configure Event Input 1
This procedure will enable and configure Event Input 1.
Note: To configure other inputs, use the Edge Smart Keypad app.
Mode 0
When this mode is active, Event Input 1 is disabled.
1251 $4 $9 $0 $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 9 and listen for status tones:
Good tone: Event Input 1 is disabled (Mode 0).
One tone: Mode 1 enabled.
Two tones: Mode 2 enabled.
Three tones: Mode 3 enabled.

Direct Programming Manual Edge Smart Keypads and Card Readers
10 If you need help, please email [e-mail] or call [phone].
Four tones: Mode 4 enabled.
Five tones: Mode 5 enabled.
Enter 0 and listen for good tone.
Enter # key to exit Programming Mode.
Mode 1
When this mode is active, the selected relay will be triggered when the state of Event Input 1
changes from normally open (N/O) to normally closed (N/C).
1251 $4 $9 $1 $X $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 9 and listen for status tones:
Good tone: Event Input 1 is disabled (Mode 0).
One tone: Mode 1 enabled.
Two tones: Mode 2 enabled.
Three tones: Mode 3 enabled.
Four tones: Mode 4 enabled.
Five tones: Mode 5 enabled.
Enter 1 for Mode 1 and listen for good tone.
Enter 1 (for Relay A) or 2 (for Relay B) and listen for good tone.
Enter # key to exit Programming Mode.
Mode 2
When this mode is active, a log entry of the event input state will be made when the state of
Event Input 1 changes from normally open (N/O) to normally closed (N/C).
1251 $4 $9 $2 $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 9 and listen for status tones:
Good tone: Event Input 1 is disabled (Mode 0).
One tone: Mode 1 enabled.
Two tones: Mode 2 enabled.
Three tones: Mode 3 enabled.
Four tones: Mode 4 enabled.
Five tones: Mode 5 enabled.
Enter 2 for Mode 2 and listen for good tone.
Enter # key to exit Programming Mode.

Edge Smart Keypads and Card Readers Direct Programming Manual
If you need help, please email [e-mail] or call [phone]. 11
Mode 3
This mode is a combination of Modes 1 and 2.
1251 $4 $9 $3 $X $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 9 and listen for status tones:
Good tone: Event Input 1 is disabled (Mode 0).
One tone: Mode 1 enabled.
Two tones: Mode 2 enabled.
Three tones: Mode 3 enabled.
Four tones: Mode 4 enabled.
Five tones: Mode 5 enabled.
Enter 3 for Mode 3 and listen for good tone.
Enter 1 (for Relay A) or 2 (for Relay B) and listen for good tone.
Enter # key to exit Programming Mode.
Mode 4
When this mode is active, the selected relay will be enabled when the state of Event Input 1
changes from normally open (N/O) to normally closed (N/C). Otherwise the relay is disabled.
1251 $4 $9 $4 $X $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 9 and listen for status tones:
Good tone: Event Input 1 is disabled (Mode 0).
One tone: Mode 1 enabled.
Two tones: Mode 2 enabled.
Three tones: Mode 3 enabled.
Four tones: Mode 4 enabled.
Five tones: Mode 5 enabled.
Enter 4 for Mode 4 and listen for good tone.
Enter 1 (for Relay A) or 2 (for Relay B) and listen for good tone.
Enter # key to exit Programming Mode.
Mode 5
When this mode is active, the selected relay will be triggered or latched when the state of Event
Input 1 changes from normally closed (N/C) to normally open (N/O).

Direct Programming Manual Edge Smart Keypads and Card Readers
12 If you need help, please email [e-mail] or call [phone].
(The default configuration is Relay B trigger.)
1251 $4 $9 $5 $X $X $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 4 and listen for good tone.
Enter secondary sub mode 9 and listen for status tones:
Good tone: Event Input 1 is disabled (Mode 0).
One tone: Mode 1 enabled.
Two tones: Mode 2 enabled.
Three tones: Mode 3 enabled.
Four tones: Mode 4 enabled.
Five tones: Mode 5 enabled.
Enter 5 for Mode 5 and listen for good tone.
Enter 1 (for relay selection) or 2 (for relay operation selection) and listen for good tone.
Relay Selection: Enter 0 (for Relay A) or 1 (for Relay B) and listen for good tone.
Relay Operation Selection: Enter 0 (for trigger) and 1 (for latch) and listen for good tone.
Enter # key to exit Programming Mode.
Add Latch Code to Relay A
This procedure will add a latch code to Relay A.
Note: By default, the following codes are reserved for other functions and cannot be used:
1251, 1273, 1366, 1381, 1387, 1678, 1752, and 1985.
1251 $5 $XXXX $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 5 and listen for good tone.
Enter code (4 digits by default; numbers only) to be added and listen for good tone.
Enter # key to exit Programming Mode.
Add Access Code(s) to Relay A on Both Wiegand Inputs
These procedures will add an access code or codes to Relay A for Wiegand keypads, card readers,
remotes, and vehicle tag readers on both Wiegand inputs.
Quick Entry for Wiegand Keypad (uses default facility code)
This procedure will add one or more access codes with the default facility code for a Wiegand
keypad. Both the 26-bit and SBI Flex 64-bit formats can be used.
1251 $6 $100 $1 $XXXXX $#
Enter Master Code (default 1251) and listen for good tone.

Edge Smart Keypads and Card Readers Direct Programming Manual
If you need help, please email [e-mail] or call [phone]. 13
Enter sub mode 6 and listen for good tone.
Enter next sub mode 100 and listen for good tone.
Enter next sub mode 1 and listen for good tone.
Enter code (26-bit: 5 digits; numbers only; max value 65535) and listen for good tone.
Repeat above step to add additional codes.
Enter # key to exit Programming Mode.
Note: This procedure will not work if any of the following are true:
One or both Wiegand inputs are disabled.
One or both Wiegand inputs are configured to share code list with non-Wiegand codes.
Each Wiegand input is configured to a different Wiegand bit format.
Split relay feature is enabled.
Quick Entry for Wiegand Card Readers, Remotes, and Vehicle Tag Readers
This procedure will add one or more access codes with a specified facility code for a Wiegand
card reader, remote, or vehicle tag reader. Only the 26-bit format can be used.
1251 $6 $100 $2 $XXX $XXXXX $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 6 and listen for good tone.
Enter next sub mode 100 and listen for good tone.
Enter next sub mode 2 and listen for good tone.
Enter 3-digit facility code and listen for good tone.
Enter 5-digit access code and listen for good tone.
Repeat above step to add additional codes.
Enter # key to exit Programming Mode.
Note: This procedure will not work if any of the following are true:
One or both Wiegand inputs are set to SBI Flex 64-bit format.
One or both Wiegand inputs are disabled.
One or both Wiegand inputs are configured to share code list with non-Wiegand codes.
Each Wiegand input is configured to a different Wiegand bit format.
Split relay feature is enabled.
Bulk Entry for Wiegand Card Readers, Remotes, and Vehicle Tag Readers
This procedure will add access codes with a specified facility code in bulk for a Wiegand card
reader, remote, or vehicle tag reader. Only the 26-bit format can be used.
1251 $6 $100 $3 $XXX $XXXXX $XXXXX $#

Direct Programming Manual Edge Smart Keypads and Card Readers
14 If you need help, please email [e-mail] or call [phone].
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 6 and listen for good tone.
Enter next sub mode 100 and listen for good tone.
Enter next sub mode 3 and listen for good tone.
Enter 3-digit facility code and listen for good tone.
Enter 5-digit starting access code and listen for good tone.
Enter 5-digit ending access code and listen for good tone (maximum of 100 codes).
Enter # key to exit Programming Mode.
Note: This procedure will not work if any of the following are true:
One or both Wiegand inputs are set to SBI Flex 64-bit format.
One or both Wiegand inputs are disabled.
One or both Wiegand inputs are configured to share code list with non-Wiegand codes.
Each Wiegand input is configured to a different Wiegand bit format.
Split relay feature is enabled.
Scan Entry for Wiegand Card Readers and Vehicle Tag Readers
This procedure will add one or more access codes with a specified facility code by scanning for a
Wiegand card reader or vehicle tag reader. Only the 26-bit format can be used.
1251 $6 $100 $4 $Scan First Card $... $Scan Last Card $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 6 and listen for good tone.
Enter next sub mode 100 and listen for good tone.
Enter next sub mode 4 and listen for good tone.
Scan card to be added twice at reader and listen for good tone.
Repeat above step to add additional codes.
Note: Card-to-card swipe timeout is 10 seconds.
Enter # key to exit Programming Mode.
Note: This procedure will not work if any of the following are true:
One or both Wiegand inputs are set to SBI Flex 64-bit format.
One or both Wiegand inputs are disabled.
One or both Wiegand inputs are configured to share code list with non-Wiegand codes.
Each Wiegand input is configured to a different Wiegand bit format.
Split relay feature is enabled.

Edge Smart Keypads and Card Readers Direct Programming Manual
If you need help, please email [e-mail] or call [phone]. 15
Add Access Code(s) to Relay A on Wiegand Input 1
These procedures will add an access code or codes to Relay A for Wiegand keypads, card readers,
remotes, and vehicle tag readers on Wiegand Input 1 only.
Quick Entry for Wiegand Keypad (uses default facility code)
This procedure will add one or more access codes with the default facility code for a Wiegand
keypad. Both the 26-bit and SBI Flex 64-bit formats can be used.
1251 $6 $1 $100 $1 $XXXXX $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 6 and listen for good tone.
Enter 1 (for Wiegand Input 1). No tone will sound.
Enter next sub mode 100 and listen for good tone.
Enter next sub mode 1.
Enter code (26-bit: 5 digits; numbers only; max value 65535) and listen for good tone.
Repeat above step to add additional codes.
Enter # key to exit Programming Mode.
Note: This procedure will not work if any of the following are true:
Wiegand input is disabled.
Wiegand input is configured to share code list with non-Wiegand codes.
Split relay feature is enabled.
Quick Entry for Wiegand Card Readers, Remotes, and Vehicle Tag Readers
This procedure will add one or more access codes with a specified facility code for a Wiegand
card reader, remote, or vehicle tag reader. Only the 26-bit format can be used.
1251 $6 $1 $100 $2 $XXX $XXXXX $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 6 and listen for good tone.
Enter 1 (for Wiegand Input 1). No tone will sound.
Enter next sub mode 100 and listen for good tone.
Enter next sub mode 2 and listen for good tone.
Enter 3-digit facility code and listen for good tone.
Enter 5-digit access code and listen for good tone.
Repeat above step to add additional codes.
Enter # key to exit Programming Mode.

Direct Programming Manual Edge Smart Keypads and Card Readers
16 If you need help, please email [e-mail] or call [phone].
Note: This procedure will not work if any of the following are true:
Wiegand input is set to SBI Flex 64-bit format.
Wiegand input is disabled.
Wiegand input is configured to share code list with non-Wiegand codes.
Split relay feature is enabled.
Bulk Entry for Wiegand Card Readers, Remotes, and Vehicle Tag Readers
This procedure will add access codes with a specified facility code in bulk for a Wiegand card
reader, remote, or vehicle tag reader. Only the 26-bit format can be used.
1251 $6 $1 $100 $3 $XXX $XXXXX $XXXXX $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 6 and listen for good tone.
Enter 1 (for Wiegand Input 1). No tone will sound.
Enter next sub mode 100 and listen for good tone.
Enter next sub mode 3 and listen for good tone.
Enter 3-digit facility code and listen for good tone.
Enter 5-digit starting access code and listen for good tone.
Enter 5-digit ending access code and listen for good tone (maximum of 100 codes).
Enter # key to exit Programming Mode.
Note: This procedure will not work if any of the following are true:
Wiegand input is set to SBI Flex 64-bit format.
Wiegand input is disabled.
Wiegand input is configured to share code list with non-Wiegand codes.
Split relay feature is enabled.
Scan Entry for Wiegand Card Readers and Vehicle Tag Readers
This procedure will add one or more access codes with a specified facility code by scanning for a
Wiegand card reader or vehicle tag reader. Only the 26-bit format can be used.
1251 $6 $1 $100 $4 $Scan First Card $... $Scan Last Card $#
Enter Master Code (default 1251) and listen for good tone.
Enter sub mode 6 and listen for good tone.
Enter 1 (for Wiegand Input 1). No tone will sound.
Enter next sub mode 100 and listen for good tone.
Enter next sub mode 4 and listen for good tone.
Scan card to be added twice at reader and listen for good tone.
