Security Camera King NVR-ELT-8-POE4 User manual

8CH NVR’s - Manual
NVR-ELT-8
NVR-ELT-8-POE4
1080p
Resolution
3yr
Warranty
Embodied in a powdered white sleek small form casing, this unit can house one individual hard drive up to a 4TB. Our NVR oers you a variety of recording resolutions,
adjustable frame rates, interchangeable on all of our channels. Fitted with a dual-core embedded processor, two 2.0 USB ports, a Gigabit Ethernet port and three indicator
lights for quick analysis of unit operation makes this device a highly desirable design.
Rejoice as you traverse through familiar terrain with the GUI interface as it remains the same across our entire line. Customers new and old, nd navigating through the menu
functions easily with this user friendly OSD menus and options. Record and watch the footage with dual-stream and optional settings like regular record (24/7), motion and
alarm or utilize all methods based on a schedule per your choice.
Utilize additional features for preservation of your data footage. Our NVR is equipped with valuable network features like FTP uploads, NTP synchronization, self-contained
DDNS, and more. By setting up the FTP you can back-up your recordings to an osite location, ensuring your data is obtainable for review should your NVR be damaged,
stolen or destroyed.
We take great pride in our products and services and we’re sure you’ll be amazed with this unit. We even back it up with a 3 year warranty and lifetime 100% free technical
support with this device. Contact our support team with your questions, comments or problems and will be more than happy to assist you. Most of the time we can remotely
help you via a computer with our remote support software.
