Securitytronix ST-D420IR6-B User manual

1
INSTALLATION MANUAL
ST-D420IR6-B or -W
Dome Infra Red CCD Camera

2
PACKAGE CONTENTS
This package contains:
One ST-D420IR6 Dome Infra Red CCD camera
One installation manual
Note: The ST-D420IR6 requires a 12VDC 500mA-1,000mA power supply such as the
ST-PS12VDC1A or ST-PS12VDC2A.
PRODUCT DESCRIPTION
The ST-D420IR6 is an indoor infrared camera designed around a 1/3” Color SONY Super HAD
CCD with 420TVL of resolution, 24 infrared LEDs providing infrared capability up to 80 feet. The
ball style dome camera provides the installer with the ability to easily adjust the camera’s viewing
area. The ST-420IR6 is cost effective indoor surveillance solution for any budget.
SPECIFICATIONS
ST-D420IR6
Specifications (Typical)
1. Image Sensor
1/3” SONY Super HAD CCD
2. Pixels (HxV)
500x582
3. Scanning System
NTSC
4. Horizontal Resolution
420TV Lines
5. Synchronization
Internal
6. Minimum Illumination
0Lux/F1.2 (IR LED on)
7. Backlight Compensation
ON/OFF Switchable
8. Electronic Shutter
1/50~100,000 Seconds
9. White Balance
Automatic
10. Lens
6mm
11. S/N Ratio
≥48dB
12. IR LED
φ5x24PCS
13. IR Viewing Distance
49 –65 feet
14. Gamma Correction
0.45
15. Video Output
1.0Vp-p/75Ω
16. Operation Temperature
14°- 122°F
17. Power Supply
DC12V 500mA –1,000mA
18. Dimensions
3.7”x3.3”x3.3”
19. Weight
1.8 oz
20. Protection Grade
No

3
INSTALLATION AND OPERATION
1. UNPACKING and HANDLING
Each unit is shipped assembled and factory tested.
Ensure that all accessories are removed from the container before discarding packing material
2. MECHANICAL INSPECTION
Inspect the front and rear of the equipment for shipping damage. Make sure the equipment is
clean, and no connectors are broken, damaged, or loose. If equipment appears to be
damaged or defective please contact your distributor or SecurityTronix at 1-610-429-1511 for
assistance.
3. SPECIAL ATTENTION
a. The installer must comply with electrical safety standards. There must be sufficient
space between the camera’s power supply and video line and any high voltage
equipment and/or cables.
b. To help ensure the camera’s life and proper operation do not point the camera
towards the sun or strong light.
c. Do not install the camera in an environment where the temperature is above 122°F.
The camera should be installed in a cool and spacious environment.
d. Do not install the camera near a magnetic field or a high-power motor.
e. Only use a dry cloth to clean the camera. If there is dirt that is difficult to remove wipe
gently with a mild detergent. Never use strong or abrasive detergents.
f. A 12VDC 500mA –1,000mA power supply must be used. AC power cannot be
applied. Using a power supply other than 12VDC 500mA –1,000mA will damage the
camera.
g. Only qualified installers are allowed to install, test and disassemble the camera.
h. The IR LED angle and lens viewing range are adjusted at the factory. Any change to
the camera’s lens will affect image quality.
i. The camera is a low voltage product. If installed outdoors proper safety and lightening
grounding are required.
4. WIRING CONNECTIONS
a. Connect the power supply’s DC plug to the camera’s power outlet.
b. Connect the camera to the monitor with a 75Ωcoaxial video cable.
c. Connect power supply’s AC plug to a suitable AC power outlet.
d. Adjust the lens direction according to the required surveillance area and environment.

4
Troubleshooting assistance can be found on-line at www.securitytronix.com in addition to support
from SecurityTronix sales engineers at 1-610-429-1511.
