Securitytronix ST-HD-BT3.6-1MP User manual

ST-HD-BT3.6-1MP
IR Color HD-CVI Camera
V1.0 12/29/14 1

PACKAGE CONTENTS
This package contains:
One (1) ST-HD-BT3.6-1MP infrared bullet color HD camera
One (1) installation manual
Note: The ST-HD-BT3.6-1MP requires a 12VDC 500mA power supply such as the
ST-PS12VDC1A.
PRODUCT DESCRIPTION
The ST-HD-BT3.6-1MP is a high-definition camera designed around a 1/3” Color 1 megapixel
CMOS, 24 IR LEDs providing infrared capability up to 65 feet, and a 3.6mm lens. The ability to
send HD video over coaxial cable makes the ST-HD-BT3.6-1MP a cost effective high-definition
surveillance solution for any budget.
SPECIFICATIONS
ST-HD-BT3.6-1MP
Specifications (Typical)
1.
Image Sensor
1/3” 1MP CMOS
2.
Maximum Resolution
1280(H) x 720(V)
3.
Scanning System
NTSC
4.
Synchronization
Internal
5.
Minimum Illumination
0.01Lux, 0Lux with IR on
6.
Scanning System
Progressive
7.
Electronic Shutter
1/60s~1/100,000s
8. Lens
3.6mm fixed
9.
Auto Gain Control
Auto
10. IR LED
φ5x24PCS
11.
IR Viewing Distance
Up to 65 feet
12.
Video Output
HD-CVI
13.
Operation Temperature
14- 113F
14.
Relative Humidity
95% maximum
15.
Dimensions
Ø2.5”x6.1”
16.
Weight
0.85 lbs.
17. Required Power Supply
DC12V 500mA
V1.0 12/29/14
2

INSTALLATION AND OPERATION
1. UNPACKING and HANDLING
Each unit is shipped assembled and factory tested.
Ensure that all accessories are removed from the container before discarding packing material
2. MECHANICAL INSPECTION
Inspect the front and rear of the equipment for shipping damage. Make sure the equipment is
clean, and no connectors are broken, damaged, or loose. If equipment appears to be
damaged or defective please contact your distributor or SecurityTronix at 1-800-688-9282
(option 3, then option 2) for assistance.
3. SPECIAL ATTENTION
a. The installer must comply with electrical safety standards. There must be sufficient
space between the camera’s power supply and video line and any high voltage
equipment and/or cables.
b. To help ensure the camera’s life and proper operation do not point the camera
towards the sun or strong light.
c. Do not install the camera in an environment where the temperature is above 113F.
The camera should be installed in a cool and spacious environment.
d. Do not install the camera near a magnetic field or a high-power motor.
e. Only use a dry cloth to clean the camera. If there is dirt that is difficult to remove wipe
gently with a mild detergent. Never use strong or abrasive detergents.
f. A 12VDC 500mA power supply must be used. AC power cannot be applied. AC
power will damage the camera and void warranty.
g. Only qualified installers are allowed to install, test and disassemble the camera.
h. The IR LED angle and lens viewing range are adjusted at the factory. Any change to
the camera’s lens will affect image quality.
i. The camera is a low voltage product. If installed outdoors proper safety and
lightening grounding are required.
4. WIRING CONNECTIONS
a. Connect the power supply’s DC plug to the camera’s power outlet.
b. Connect the camera to the CVR with a 75Ωcoaxial video cable.
c. Connect power supply’s AC plug to a suitable AC power outlet.
d. Adjust the lens direction according to the required surveillance area and environment.
V1.0 12/29/14 3

5. TROUBLESHOOTING
a. No picture after applying power –(i) check all plugs and cables are securely
connected to the proper connectors; (ii) ensure your power supply is providing the
correct voltage and current.
b. The picture has ripples –(i) check to see if the power supply is experiencing AC
ripple, if so a filter may be required; (ii) determine if the monitor is faulty; (iii)
determine if other peripheral equipment is causing ripple and if so make the
necessary adjustments.
c. The picture background continuously changes color –a fluorescent lamp’s magnetic
field may cause color roll, therefore, reduce the number of fluorescent lamps or
increase the distance between the camera and the lamps.
d. The picture appears smeared –(i) the power supply voltage level may be unstable,
therefore, try another power supply; (ii) ensure the cables are correctly connected
and/or the cables are of the correct impedance.
e. Other interference may require a SecurityTronix ground loop isolation filter.
f. Additional troubleshooting assistance can be found on-line at www.securitytronix.com
in addition to support from SecurityTronix sales engineers at 1-800-688-9282, option
3, then option 2.
V1.0 12/29/14 4
