SEDONA L2500 Configuration guide

sedona by lynx™
mom friendly. dad ready.™
™
Exclusive Sedona Island Packages are complete,
including the island

Mom Friendly. Dad Ready. All Sedona by Lynx™ products are
designed with the family in mind.
Quality materials. Fine craftsmanship. Innovative features and
technology. These attributes have earned Lynx products a reputation
for excellence among outdoor-dining enthusiasts.
Created by a team with decades of experience meeting the
demanding requirements of the commercial restaurant industry, Lynx
products have always been designed to combine high performance
and luxurious appearance with long-term durability for reliable year-
round grilling.
The Lynx commitment to continuous innovation has introduced
numerous industry firsts. Including a hood assist kit that makes raising
and lowering the grill hood effortless. And ProSear™ infrared burners
that allow unprecedented variable temperature control. Advances
such as these have made the Lynx name synonymous with the best in
outdoor cooking. And they make Sedona by Lynx an exceptional value
for those in search of much more than an ordinary grill.

The true value of a grill is in the cooking performance, ease of use and enduring beauty it
brings to your outdoor kitchen. By every measure, Sedona by Lynx™ clearly stands apart.
As you’ll see throughout the following pages, Sedona Grills and related accessories
are designed in every detail to exceed your expectations and enhance your outdoor
entertaining pleasure.
Crafted by the Lynx Grill specialists at our factory in Southern California, each Sedona
Grill displays the meticulous fit and finish and high-quality materials that have made Lynx
products favorites of grilling enthusiasts.
Sedona Grills are available in a wide variety of configurations. Endowed with innovative
Lynx features, they set a higher standard for luxurious outdoor dining. By making it easier
than ever to prepare great meals, cooked to perfection.
sedona by lynx™–
WelCome To a HiGHer sTandard

TeCHnoloGy and QUaliTy HiGHliGHTs
Prosear™Variable searinG TeCHnoloGy
• Unlike many grills with infrared searing burners that only offer two settings – hi or off – the Lynx ProSear™ infrared
burner is variable
• You can sear a baseball-cut filet mignon restaurant style, then throttle back to cook delicate seafood like scallops
• This is the acclaimed ProSear™ burner for which Lynx has been known for years

feaTUres and benefiTs
sUPerior fiT and finisH
All stainless steel construction
Continuously welded joints for quality, strength
and beauty
Finished seams with finely polished edges
sTainless sTeel bUrners
Durable stainless steel tube burners with briquettes
ensure instant ignition with steady and even heat
distribution
Twelve Year Warranty
inTernal HaloGen
Grill sUrfaCe liGHT
Effectively illuminates the entire grilling surface
using a heavy-duty ceramic glass lens directly over
the grilling surface
12 volt halogen light
ConTrol Knobs illUminaTed
WiTH blUe led liGHTs
Each knob features dedicated LED lighting
Knob markings can easily be viewed at night
Single switch activation
The innovative features, unparalleled performance and superior craftsmanship of Sedona by Lynx™Grills are available
in 24”, 30” and 36” configurations for built-in or freestanding applications.

feaTUres and benefiTs
CeramiC radianT briQUeTTes
Specially designed high-density ceramic
Even heat across the entire grilling surface
Briquettes are clipped in place to facilitate easy
cleaning
Enhances food’s flavor as drippings hit the
briquettes and turn to smoke
sParK iGniTion sysTem
Reliable spark ignition
Activated by burner control knobs
Battery back-up in event of a power failure
TemPeraTUre GaUGe
Indicates when your grill is ready for cooking
Large and easy to read
Temperature gauge indicates internal temperature
for indirect cooking
sTainless sTeel GraTes
Heavy-duty electro-polished stainless steel grates

feaTUres and benefiTs
rear infrared bUrner
Rotisserie models feature a rear infrared burner
L600 36” Grills - 14,000 BTU
L500 30” Grills - 12,500 BTU
L400 24” Grills - 12,500 BTU
roTisserie sysTem
Compact motor, easy to remove and store when
not in use
Includes spit rod with two spit forks
amPle GrillinG sUrfaCe
24” Grills - 575 square inches (398 primary / 177 secondary)
30” Grills - 733 square inches (508 primary / 225 secondary)
36” Grills - 891 square inches (618 primary / 273 secondary)
Hood assisT KiT
Heat treated stainless steel spring system
Makes hood operation effortless and safe
Easy to remove for those who appreciate the heft

Create a fully featured outdoor kitchen in no time at all with a premium Sedona Island Package. Available in two color
schemes, and offered with a choice of 30” or 36” grills, these Islands also include an outdoor-rated refrigerator, double-
burner side burner and a combination storage system with two fully enclosed pull-out drawers. A 15” overhang along the
rear of the island accommodates seating and a circular end counter extension adds extra space for entertaining.
sedona l2500/l2600 island PaCKaGes
15” counter over hang
accommodates seating along the rear
Beautiful detailing throughout Each island includes two USB
charging stations
l2500s island WiTH 30” Grill
AVAILABLE IN BOTH COLORS
Shown
L2500S - Sandalwood*

l2600 island WiTH 36” Grill - available in both colors
Model No. L2600G (shown above) / L2600S
boTH islands inClUde
L500REF - 20” outdoor rated refrigerator, 4.1 cu ft.
capacity. Includes 3 wire shelves plus door storage and
can dispenser in the door. Interior light.
LSB502 - Side burner with two 12,500 BTU sealed
burners with Blue LED’s illuminating the gas control
knobs.
l2600 islands inClUde
L600 PSR Grill - 36” Grill with 2 SS Tube burners and
1 ProSearTM Burner
LSA636 - Combination storage system with one door
and two pull out drawers
l2500 islands inClUde
L500PSR Grill - 30” Grill with 1 SS Tube burners and 1
ProSearTM Burner
LSA530 - Combination storage system with one door
and two pull out drawers
island dimensions
L2600 - 92 1/8“ long x 47 3/16” deep x 38” high
L2500 - 92 1/8“ long x 47 3/16” deep x 38” high
both colors are available in sldvowoow......
all sedona islands
assemble in minUTes.
Sedona Islands are designed for easy delivery
and quick setup. Delivered in a flat package
sized to fit through typical backyard gates, they
can be assembled within 30 minutes by two to
three people using just a few tools.
island PaCKaGes - feaTUrinG 30” & 36” Grills
ALL ISLANDS ARE AVAILABLE
IN EITHER COLOR SCHEME
Beige stucco base with
oxy-iron (beige with orange
highlights) tile countertop
*sandalWood
Light gray stucco base with
oyx-chrome (dark green with
brown highlights) tile countertop
*falCon Gray
92” x 47” half oval shape with a 47” diameter circular entertainment area feature on the right
15” counter overhang which runs along the back of the island and sweeps around the circular right end to accommodate
additional seating
Has two diamond shaped tile features on the back side with a tile kick plate
Welded frame is 1” square tubing with galvanized protection
Premium grade outdoor rated concrete board substrate
Pre-wired with GFI protection for grill and refrigerator connections along with convenient electrical receptacle for rotisserie motor
Two USB charging ports standard
Island comes ready for gas connections and includes required venting
Leveling feet are standard
Tough acrylic stucco which is waterproof, UV resistant and long lasting
Sealed porcelain 6”x 6” tile is unglazed, frost proof, designed for outdoor use
Beautiful cross hatch tile pattern with a 3” border around the counter edges which include a bull nose and 3” vertical lip
Includes a tile border which frames the front of the grill and base on three sides
boTH islands feaTUre

Shown - L1500G - Falcon Gray*
The convenience of an outdoor kitchen is easy to achieve with the essentials
built into a classic Sedona Island. Choose from 30” or 36” grill sizes. Your
island also includes an outdoor-rated refrigerator and a side burner, as well
as doors for extra storage space and a 10” overhang along the rear of the
island for seating, so guests can gather around the grill.
l1500 island WiTH 30” Grill
available in both colors
Model No. L1500S
sedona l1500/l1600 island PaCKaGes
feaTUrinG 30” & 36” Grills
10” counter over hang
accommodates seating along the rear
boTH islands inClUde
L500REF - 20” outdoor rated refrigerator, 4.1 cu ft.
capacity. Includes 3 wire shelves plus door storage
and can dispenser in the door. Interior light.
LSB501 - Side burner with a 12,500 BTU sealed
burner with blue LED illuminating the gas control
knob. Standard with stainless steel cover and gas
and electrical connections to grill.
l1600 islands inClUde
76” x 40” rectangular shape with a 10” counter
over hang to accommodate seating along the rear.
L600PS Grill - 36” grill with 2 stainless steel tube
burners and 1 ProSearTM burner, grill includes
internal halogen hood light, blue LED lights over
each gas control knob and many other features.
LDR636 - 36” double access doors allow access to
utility connections below the grill and extra storage.
l1500 islands inClUde
71” x 40” rectangular shape with a 10” counter
over-hang to accommodate seating along the rear.
L500PS Grill - 30” grill with 1 stainless steel tube
burner and 1 ProSearTM burner, grill includes
internal halogen hood light, blue LED lights over
each gas control knob and many other features.
LDR530 - 30” double access doors allow access to
utility connections below the grill and extra storage.
island dimensions
L1600 - 76 1/8“ long x 40 5/8” deep x 38” high
L1500 - 71 3/4“ long x 40 5/8” deep x 38” high
l1600 island WiTH 36”
Grill - available in both colors
Model No. L1600G
Beige stucco base with
oxy-iron (beige with orange
highlights) tile countertop
*sandalWood
Light gray stucco base with
oyx-chrome (dark green
with brown highlights) tile
countertop
*falCon Gray

a bUilT-in of yoUr oWn
36” bUilT- in Grill
Model No. L600PSR (shown)
ProSear™ infrared technology delivers intense
and controllable infrared heat
891-sq. in. cooking surface (618 primary, 273
secondary)
Stainless steel tube burner for extremely even
cooking temperature
Superior fit and finish - continuously welded joints
Spark ignition system with battery back-up
Control illumination with blue LED lights
Internal halogen grill surface light
Specially designed high-density ceramic radiant
briquettes
Large and easy-to-read temperature gauge
Hood Assist Kit
Rotisserie models include; Rear infrared burner,
compact rotisserie motor, spit rod and two spit forks.
Stainless steel grilling grates
Dimensions - 36“W x 25”D x 25”H
30” bUilT- in Grill
Model No. L500PSR (shown)
24” bUilT- in Grill
Model No. L400PS (shown)
ProSear™ infrared technology delivers intense
and controllable infrared heat
733-sq. in. cooking surface 508 primary, 225
secondary)
Stainless steel tube burner for extremely even
cooking temperature
Superior fit and finish - continuously welded joints
Spark ignition system with battery back-up
Control illumination with blue LED lights
Internal halogen grill surface light
Specially designed high-density ceramic radiant
briquettes
Large and easy-to-read temperature gauge
Hood Assist Kit
Rotisserie models include; Rear infrared burner,
compact rotisserie motor, spit rod and two spit forks.
Stainless steel grilling grates
Dimensions - 30“W x 25”D x 25”H
ProSear™ infrared technology delivers intense
and controllable infrared heat
575-sq. in. cooking surface (398 primary, 177
secondary)
Stainless steel tube burner for extremely even
cooking temperature
Superior fit and finish - continuously welded joints
Spark ignition system with battery back-up
Control illumination with blue LED lights
Internal halogen grill surface light
Specially designed high-density ceramic radiant
briquettes
Large and easy-to-read temperature gauge
Hood Assist Kit
Rotisserie models include; Rear infrared burner,
compact rotisserie motor, spit rod and two spit
forks.
Stainless steel grilling grates
Dimensions - 24“W x 25”D x 25”H

freesTandinG models for mobile ConVenienCe
Enjoy the advanced grilling technology and superior craftsmanship of Sedona by Lynx™in a form that’s at home in any
outdoor area—even small patios. Sedona Freestanding models offer a full range of grill sizes and convenience features.
And they roll easily on heavy-duty castors, so you can quickly reposition your grill, or store it when you’re not entertaining.
36” Grill
Model No. L600PSR (shown)
with Model No. L600CART
30” Grill
Model No. L500PSR (shown)
with Model No. L500CART
24” Grill
Model No. L400PS (shown)
shown with Model No. L400CART

Elegant and Functional Lighting Optional Rotisserie SystemSuperior Craftsmanship
Doors with rigid liners
Internal storage shelf
LP tank restraint system
THe sedona by lynx™ ColleCTion
sHiPPinG WeiGHT/dimensions
L600 Cart: 106 lbs. / 38”W x 34” D x 12”H
L500 Cart: 86 lbs. / 34”W x 30”D x 12”H
L400 Cart: 72 lbs. / 34”W x 24”D x 12”H
All Sedona by Lynx™Grill Heads can be easily assembled to a matching cart. Cart arrives in a flat package and can
be quickly assembled by two people in less than 20 minutes. Unique keyhole slot design provides simple assembly
procedure only requiring a screwdriver.
sedona by lynx™CarTs feaTUre
ComPlemenTary ProdUCTs
Sedona offers a complete line of complementary products to allow you to fully equip your Outdoor Kitchen. This includes a variety of
access doors, combination storage systems, side burners, a refrigerator, an insulating jacket and vinyl covers. Sedona adaptor kits
allow Sedona to fit into a variety of existing island cutouts.
doUble doors
Model No. LDR636/LDR530
Doors with rigid liners
Easily Installed
Stainless steel handles
Sized to grill width
sToraGe door & fUlly
enClosed doUble draWers
Model No. LSA636/ LSA530
Fully enclosed drawers for secure storage
Slides keep drawers solidly in closed position
Stainless steel handles
Sized to match grill
Door has a rigid liner
Easily Installed
Stainless Steel handles
Sized to grill width or for additional storage
24” sinGle door
Model No. LDR424

sinGle side bUrner
Model No. LSB501
doUble side bUrner
Model No. LSB502
17” enClosed doUble
draWers
Model No. LUD517
ComPlemenTary ProdUCTs
insUlaTed JaCKeT
Model No. LIJ600/LIJ500/LIJ400
Vinyl CoVer for
bUilT-in Grill
Model No. VC600/VC500/VC400
20” oUTdoor refriGeraTor
Model No. L500REF
QUiCK disConneCT WiTH
sHUToff & fiTTinGs
Model No. LQD
Vinyl CoVer for
freesTandinG Grill
Model No. VC600F/VC500F/VC400F
UL listed for outdoor use
Seamless stainless steel exterior
Interior light
4.1 cubic feet of usable capacity
3 wire shelves
Can dispenser in drawer for convenience
Additional door storage
Reversible door (kit included)
Two 6” deep fully enclosed drawers
Full extension drawer slides
Stainless steel handles
One @12,500 btu burner
Includes stainless steel cover
Blue LED light activated by grill switch
Easy to clean sealed burner base
Two burners @12,500 btu per burner
Includes stainless steel cover
Blue LED lights activated by grill switch
Easy to clean sealed burner base
Mandatory for grills installed in islands with
combustible materials
Attractive all welded, insulated construction
Simple solution for gas connections
3/4” ID hose ensures adequate gas supply
12’ hose includes 3/4” quick disconnect fitting at
one end and 3/4” male pipe thread on the other
Includes manual shut-off valve

sPeCifiCaTions & insTallaTion
THe sedona by lynx ColleCTion
BUILT-IN GRILL
Model A B C
L400 23.00 10.00 21.25
L500 29.00 10.00 21.25
L600 35.00 10.00 21.25
COMPLEMENTARY PRODUCTS
Model A B C
LSB501*11.00 4.00 16.00
LSB502*21.00 4.00 16.00
LDR424 22.00 19.00 –
LDR530 28.25 19.00 –
LDR636 33.75 19.00 –
LSA530 28.25 19.00 20.00
LSA636 33.75 19.00 20.00
LUD517 17.25 12.75 20.00
L500REF 21.50 34.00 24.50
Measurements in inches.
BUILT-IN GRILL WITH INSULATING JACKET
Model A B C
LIJ400 30.00 11.62 23.25
LIJ500 36.00 11.62 23.25
LIJ600 42.00 11.62 23.25
11/8” min. for model LUDE
31/2” min. for model LUDXL
21/2” min. for model LDR (access door)
* Cocktail Pro should have an open bottom for plumbing and drain access.
** 1” square hole must be located at rear of grill cutout. 120V GFI outlet must
be located within 6’ of the 1” hole.
GAS
NON-COMBUSTIBLE
CONSTRUCTION
3”
F
21
3/4
''
2”Ø or 2” square holes
for manifold connection
(rear or bottom access)
12” min.
Grill**
Cocktail Pro*
Warming Drawer/
Convenience Center
Utility
Drawer
Side
Burner
Access
Doors
19”
A
B
D
E
G
H
29” 21/4”
31/2”
31/4”min.
2”
H
3”min.
C
24”
Trash
Center
363/8”
min.
31/2”
81/4”
61/4”
Trash
Chute
5
5/8''
2
3/
16''
Single
Storage Drawer
16”
3”
min.
14
1/2
''
8 1/4''
Towel
Dispenser
NON-COMBUSTIBLE
CONSTRUCTION
The guides, measurements and dimensions detailed below are designated to assist you with planning your outdoor kitchen.
NOTE: Due to continuing product innovation, specifications are subject to change without notice.
IMPORTANT: Please reference the Care & Use / Installation manual for details on gas plumbing requirements, electrical specifications and the
proper installation of your Lynx outdoor kitchen equipment. This manual can be downloaded from the Lynx website at www.lynxgrills.com
COUNTER TOP NOTCH DETAIL
Only required if island counter top overhangs the face of the island
Insulating
Jacket A
4.5”
5”
3”
Note: Insulating jacket required for all grills installed into
a combustible enclosure.
Note: For Natural Gas grills, Lynx recommends using 3/4” gas lines.
Note: Side burners may be rotated 90 degrees.
See installation manuals for details.
C
B
A
A
Double
Drawers
(LUD)
Single
& Double
Side Burner
(LSB)
Outdoor
Refrigerator
(L500REF)
CUTOUT NOT
REQUIRED
WITH LIJs
Door & Drawer Options
(LDR, LSA)
1.50” min.
C
B
B
A
A
3.50”
3.50”
12.00”
2.00” 34.00”
2.25”
21.50”
0.56”
* When installing the LSB side burners
over the refrigerator; the counter top
must be at least 37-1/2” above the floor.
