Vulcan-Hart HD12C Programming manual

INSTALLATION AND OPERATION
MANUAL FOR HOT DOG GRILL
MODELS: HD12C&S, HD27C&S,
HDM18C&S, HDM42C&S, HD45C&S, AND
HD75C&S (FORMERLY VHT-221S&T, VHT-227S&T,
VHTM-1718S&T, VHTM-2242S&T, VHT-3445S&T, &
VHT-3475S&T)
VULCAN-HART CORPORATION, PO. BOX696 LOUISVILLE, KY40201-0696,TEL.[phone] TECHNICAL
ASSISTANCE FORM 30527 (1-SO) (Formerly F-20406)

IMPORTANT
OPERATING, INSTALLING AND SERVICE PERSONNEL
Operating information for this equipment has been prepared for use by qualified and/authorized
operating personnel.
All installation and service on this equipment is to be performed by qualified, certified, licensed and/
authorized installation or service personnel, with the exception of any part marked with a D in front
of the part number.
Service may be obtained by contacting the Factory Service Department, Factory Representative or
Local Service Agency.
DEFINITIONS QUALIFIED AND/OR AUTHORIZED OPERATING
PERSONNEL
Qualified or authorized operating personnel are those who have carefully read the information in this
manual and are familiar with the equipment's functions or have had previous experience with the
operation of the equipment covered in this manual.
QUALIFIED INSTALLATION PERSONNEL
Qualified installation personnel are individuals, a firm, corporation or company which either in
person or through a representative are engaged in, and are responsible for:
1. The installation of gas piping from the outlet side of the gas meter, or the service regulator when
the meter is not provided, and the connection and installation of the gas appliance. Qualified
installation personnel must be experienced in such work, be familiar with all precautions required,
and have complied with all requirements of state or local authorities having jurisdiction.
Reference in the United States of America -National Fuel Gas Code ANSI Z223.1 (Latest
Edition). In Canada -Canadian Standard CAN/CGA-B149.1 NAT. GAS (Latest Edition) or
CAN/CGA-B149.2 PROPANE GAS (Latest Edition).
2. The installation of electrical wiring from the electric meter, main control box or service outlet to the
electric appliance. Qualified installation personnel must be experienced in such work, be familiar
with all precautions required, and have complied with all requirements of state or local authorities
having jurisdiction. Reference: In the United States of America -National Electrical Code ANSI
NFPA No. 70 (Latest Edition). In Canada -Canadian Electric Code Part 1 CSA-C22.1 (Latest
Edition).
3. The installation of steam piping from the source of supply to the service inlet of the appliance.
Qualified installation personnel must be experienced in such work, be familiar with all precautions
required, and have complied with all requirements of state or local authorities having jurisdiction.
QUALIFIED SERVICE PERSONNEL
Qualified service personnel are those who are familiar with Vulcan equipment who have been
endorsed by the Vulcan-Hart Corporation. All authorized service personnel are required to be
equipped with a complete set of service and parts manuals and stock a minimum amount of parts
for Vulcan equipment.

INSTALLATION AND OPERATION OF
MODELS HD12C&S, HD27C&S, HDM18C&S,
HD42C&S, HD45C&S, AND HD75C&S HOT DOG GRILL
PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE
The manufacturer suggests that you thoroughly read
this entire manual and carefully follow all of the
instructions provided.
Your Vulcan Hot Dog Grill is produced with quality
workmanship and material. It has been designed for
countertop operation. Models HD12C&S have 5 rollers
in one group. Models HD27C&S, HDM18C&S,
HD42C&S, and HD45C&S have 10 rollers in two
independently controlled groups for maximum flexibility
under any conditions. Models HD75C&S
INSTALLATION
UNCRATING
This hot dog grill was inspected before leaving the
factory. The transportation company assumes full
responsibility for safe delivery upon acceptance of the
shipment. Immediately after unpacking, check for
possible shipping damage. If the grill is found to be
damaged after unpacking, save the packaging material
and contact the carrier within 15 days of delivery.
CAUTION: Remove all shipping material from
between the rollers and the grease pan.
LOCATION
THE UNIT SHOULD NOT BE ACCESSIBLE TO THE
CUSTOMER.
Position the hot dog grill on a flat horizontal surface at
the desired location.
ASSEMBLY OF OPTIONAL SNEEZE GUARD
If you have purchased the optional sneeze guard,
assemble the guard to the grill as shown in Fig. 1.
have 16 rollers in two groups. Each group has a choice
of low, medium, and high temperature settings.
A sneeze guard is available as an option on Models
HD27C&S, HD45C&S, and HD75C&S.
Proper installation, usage and maintenance of your hot
dog grill will result in many years of satisfactory
performance.

ELECTRICAL CONNECTIONS
WARNING: ELECTRICAL AND GROUNDING
CONNECTIONS MUST COMPLY WITH THE APPLICABLE
PORTIONS OF THE NATIONAL ELECTRICAL CODE
AND/OR OTHER LOCAL ELECTRICAL CODES.
WARNING: APPLIANCES EQUIPPED WITH A FLEXIBLE
ELECTRIC SUPPLY CORD ARE PROVIDED WITH A
THREE-PRONG GROUNDING PLUG. IT IS IMPERATIVE
THAT THIS PLUG BE CONNECTED INTO A PROPERLY
GROUNDED THREE-PRONG RECEPTACLE. IF THE
RECEPTACLE IS NOT THE PROPER GROUNDING TYPE,
CONTACT AN ELECTRICIAN. DO NOT REMOVE THE
GROUNDING PRONG FROM THIS PLUG.
Plug the power cord into a 120 volt receptacle.
OPERATION
WARNING: HOT PARTS CAN CAUSE BURNS. USE CARE
WHEN OPERATING AND SERVICING THE HOT DOG
GRILL.
WARNING: DO NOT OPERATE THE GRILL WITHOUT
THE GREASE PAN IN PLACE.
BEFORE FIRST USE
Clean the grill with warm soapy water. Rinse well
and dry with a soft clean cloth.
Set the control switches to HIGH and allow the
unit to operate for one-half hour. This will burn off
oil and hand grease acquired during the
manufacturing process.
USING THE GRILL
NOTE: The MEDIUM setting is designed for the
alternate rollers not to be heated.
Use hot dogs, or any sausage, etc., that will lie straight
and not curl. Commercial pack hot dogs, etc., grill
better than retail pack.
Set the controls for the desired mode of operation. The
left-hand switch controls the first five rollers (nearest
the operator). The right-hand switch controls the
remaining five rollers (or 8 rollers on Models
HD75C&S). Each switch has four modes:
OFF, LOW, MEDIUM, and HIGH.
RECOMMENDED PUSH BUTTON SETTINGS FOR
EFFICIENT OPERATION
SLOW PERIODS: Set the front rollers on HIGH and
the back rollers (away from the operator) on LOW.
Preheat the franks in the rear five (or eight) rows, then
transfer as needed to the front rows. Franks will be
customer ready in a short period of time.
BUSY PERIODS: Set the front rollers on HIGH and
the rear rollers on MEDIUM. Fill all rows. Use franks
from front rows first, transferring franks from the back
rows to the front rows as needed.
VERY BUSY PERIODS: Set the front rollers on HIGH
and the back rollers on HIGH. Fill all rows.
Cooking time will vary according to the ambient
temperature, hot dog temperature, and the quality of
the product. Frankfurters should be kept refrigerated
until ready to use. When cooking, do not transfer
franks from HIGH to LOW as they may shrivel.
CAUTION: Proper food handling requires that hot
dogs be kept at an internal temperature of 140° F
or above during display and serving. Accordingly,
the operator of this grill should not keep franks on
the LOW or MEDIUM heat setting for more than
two hours. After that time, they must be
transferred to the HIGH setting for cooking and
serving.

CLEANING
CAUTION: Never use steel wool or abrasive
cleaners to clean the rollers as this will damage the
finish and possibly damage the bearings.
Remove all franks. Push the HIGH buttons and allow
the rollers to get hot. Clean the rollers with a CLEAN
WET CLOTH. Wipe from the outside ends towards
the center of the rollers to prevent grease from being
forced into the bearings. For stubborn deposits, club
soda or ice cubes have been found effective.
When the unit is cool, remove and clean the grease
pan in a sink.
