seeed studio Base Shield V2 User manual

Base Shield V2
Arduino Uno is the most popular Arduino board so far, how ever it is sometimes frustrating w hen your project requires a lot of sensors or Leds and your jumper
w ires are in a mess. The purpose of creating the Base Shield is to help you get rid of bread board and jumper w ires. With the rich grove connectors on the base
board, you can add all the grove modules to the Arduino Uno conveniently! The pinout of Base Shield V2 is the same as Arduino Uno R3, how ever Arduino Uno is
not the board one that the Base Shield V2 is compatible w ith plenty of boards.
Version
Product Version Changes Released Date
Base Shield V1.2 Initial Oct 2011
Base Shield V1.3 Change the Grove connector layout and quantity Aug 2012
Base Shield V2.0 Change the Grove connector layout and quantity, as w ell as a pow er sw itch to enable both 3.3V and 5V. Mar 2014
Compatible Boards
The Base Shield is tested and fully compatible w ith follow ing boards:
Arduino Uno(all revisions)/Seeeduino(V4&V4.2)
Arduino Mega/Seeeduino Mega
Arduino Zero(M0)/Seeeduino Loraw an
Arduino Leonardo/Seeeduino Lite
Arduino 101
Arduino Due 3.3V
Intel Edison 5V
Linkit One
!!!Note
The boards are not listed above mean that it might have chance to w ork w ith the platform board how ever requires extra w ork such as jump w ires or rew riting the

code. If you are interested in digging more, w elcome to contact [e-mail].
Hardware Overview
1-Analog Ports: include 4 anlog ports, A0, A1, A2 and A3.
2-Digital Ports: include 7 digital ports, D2, D3, D4, D5, D6, D7 and D8.
3-UART Port: 1 UART port.
4-I2C Ports: 4 I2C ports.
5-Pow er Sw itch: w hen using Arduino UNO w ith Base Shield v2, please turn the sw itch to 5v position; While using Seeeduino Arch w ith Base Shield v2,
please turn the sw itch to 3.3v.
6-Re se t Buton: reset the arduino board.
7-PWR LED：The Green LED turns on w hen pow er on.
8-P1, P2：please solder the pads, P1 and P2 if use Base Shield v2 w ith Seeeduino V3.
Dim e ns ion: 2.1 * 2.7 inch
Getting Started
Hardware
Step 1. Prepare the below stuffs:
Seeeduino V4.2 Base Shield Grove - Buzze r Grove - Button
Get ONE Now Get ONE Now Get ONE Now Get ONE Now

Step 2. Connect Grove - Buzzer to port D3 of Base Shield.
Step 3. Connect Grove - Button to port D2 of Base Shield.
Step 4. Plug Base Shield into Seeeduino.
Step 5. Connect Seeeduino to PC through a USB cable.
Software
Step 1. Copy below code to Arduino IDE and upload to Seeeduino.
const int button = 2; // connect a button
const int buzzer = 3; // connect a buzzer
void setup()
{
pinMode(button, INPUT); //set button as an INPUT device
pinMode(buzzer, OUTPUT); //set LED as an OUTPUT device
}
void loop()
{
int btn = digitalRead(button); //read the status of the button
digitalWrite(buzzer, btn);
delay(10);
}
Step 2. Press the button and w e w ill hear the buzzer.
FAQ
Please click here to see all Base Shield V2 FAQs.
Resources
[PDF] Dow nload Wiki PDF
[Eagle] Base Shiled V2 SCH

[Eagle] Base Shiled V2 PCB
[PDF] Base Shiled V2 SCH
[PDF] Base Shiled V2 PCB
