Seeed Base Shield V2 User manual
Arduino Uno is the most popular Arduino board so far, however it is sometimes frustrating
when your project requires a lot of sensors or Leds and your jumper wires are in a mess. The
purpose of creating the Base Shield is to help you get rid of bread board and jumper wires.
With the rich grove connectors on the base board, you can add all the grove modules to the
Arduino Uno conveniently! The pinout of Base Shield V2 is the same as Arduino Uno R3.
Parameter Value/Range
Operating voltage 3.⅗V
Operation Temperature -25℃ to +85℃
Analog Ports 4
Digital Ports 7
UART Ports 1
I2C Ports 1
Size 69mm x53mm
Compatible Boards
The Base Shield is tested and fully compatible with following boards:
Arduino Uno(all revisions)/Seeeduino(V4&V4.2)
Arduino Mega/Seeeduino Mega
Arduino Zero(M0)/Seeeduino Lorawan
Arduino Leonardo/Seeeduino Lite
Arduino 101
1-Analog Ports: include 4 anlog ports, A0, A1, A2 and A3.
2-Digital Ports: include 7 digital ports, D2, D3, D4, D5, D6, D7 and D8.
3-UART Port: 1 UART port.
4-I2C Ports: 4 I2C ports.
5-Power Switch: when using Arduino UNO with Base Shield v2, please turn the switch to
5v position; While using Seeeduino Arch with Base Shield v2, please turn the switch to
3.3v.
6-Reset Buton: reset the arduino board.
7-PWR LED：The Green LED turns on when power on.
8-P1, P2：please solder the pads P1 and P2， if use Base Shield v2 with Seeeduino V3.
Dimension: 2.1 * 2.7 inch
Getting Started
Hardware
Step 1. Prepare the below stuffs:
Seeeduino V4.2 Base Shield Grove - Buzzer Grove - Button
Get ONE Now Get ONE Now Get ONE Now Get ONE Now
Step 2. Connect Grove - Buzzer to port D3 of Base Shield.
Step 3. Connect Grove - Button to port D2 of Base Shield.
Step 4. Plug Base Shield into Seeeduino.
Step 5. Connect Seeeduino to PC through a USB cable.
Software
Step 1. Copy below code to Arduino IDE and upload to Seeeduino.
- Step 2. Press the button and we will hear the buzzer.
FAQ
Please click here to see all Base Shield V2 FAQs.
Schematic Online Viewer
1const int button = 2; // connect a button
2const int buzzer = 3; // connect a buzzer
3void setup()
4{
5 pinMode(button, INPUT); //set button as an INPUT device
6 pinMode(buzzer, OUTPUT); //set LED as an OUTPUT device
7}
8void loop()
9{
10 int btn = digitalRead(button); //read the status of the button
11 digitalWrite(buzzer, btn);
12 delay(10);
13 }
