Seeed Grove - LoRa-E5 User manual

Grove - LoRa-E5
Grove LoRa-E5 embedded with LoRa-E5 STM32WLE5JC, powered by
ARM Cortex M4 ultra-low-power MCU core and LoRa SX126x, is a
wireless radio module supporting LoRa and LoRaWAN protocol on the
EU868 & US915 frequency and (G)FSK, BPSK, (G)MSK, LoRa
modulations. Grove - LoRa-E5 can endow your development boards'
strong features of ultra-long transmitting range by easily plug and play
with Grove connector on board.
As an upgrade of our old version - Grove - LoRa Radio - powered
by RFM95 ultra-long-range Transceiver Module, Grove LoRa-E5
embedded with LoRa-E5 STM32WLE5JC Module is a high-performance
and easy-to-use wireless radio LoRa module supporting LoRaWAN
protocol.

LoRa-E5 LoRaWAN STM32WLE5JC module is the major functional part
integrated into Grove - LoRa-E5. It is a LoRaWAN module that
embedded with ARM Cortex M4 ultra-low-power MCU core and LoRa
SX126x, as the world-first combo of LoRa RF and MCU chip into one
single tiny module, it supports (G)FSK, BPSK, (G)MSK, and LoRa
modulations, and is FCC, CE certified. (Learn more about LoRa-E5
from LoRa-E5 wiki)
More comparison between the LoRa-E5 and RFM95
chip:
By connecting Grove - LoRa-E5 to your development boards, your
devices are able to communicate with and control LoRa-E5 conveniently
by AT command through UART connection. Grove LoRa-E5 will be a
superior choice for IoT device development, testing, and long-distance,
ultra-low power consumption IoT scenarios like smart agriculture, smart
office, and smart industry. It is designed with industrial standards with a
wide working temperature at -40℃~ 85℃, high sensitivity between -
116.5 dBm and -136 dBm, and power output between 10 dBm and 22
dBm.

Features
•LoRa-E5 (STM32WLE5JC) embedded
•Support LoRaWAN protocol on EU868/US915 frequency band
•Ultra-long transmitting range up to 10km (Ideal value in open space)
•Easy control by AT command via UART connection
•Rapid prototyping with plug-and-play Grove interfaces
•Ultra-low power consumption and high performance
Harware Overview
1. LoRa-E5 STM32WLE5JC (Datasheet)
2. MHF IPEX Connector
3. Wire Antenna
4. Grove Connector
5. LED Indicators

Platform Supported
Arduino
Raspberry Pi
Specification
General Parameters
Voltage Supply:
3.3V - 5V
Power Output:
Up to +20 dBm at 3.3V
Working Frequency
868/915MHz
Protocol
LoRaWAN
Sensitivity
-116.5dBm ~ -136dBm
Modulation
LoRa, (G)FSK, (G)MSK and BPSK
Current
Only 60uA in sleep mode
Size
20*40mm
Working Temperature
-40℃~ 85℃
Part List:
Grove - LoRa-E5 PCBA *1
Grove Universal Cable *1

Application
•Works for LoRaWAN sensor nodes and any wireless communication
application
•IoT device testing and development
Getting Started
Preparations
Here is a demo showing you how to connect TTN (The Things Network)
and Seeeduino XIAO module via Grove - LoRa-E5 module. These
modules are able to collect temperature and humidity parameters from
the environment and send them back to TTN. The flashing LED lights on
the Seeeduino Xiao indicate the status of the temperature and humidity
sensor as connecting to TTN cloud.
Attention
Please ensure the consistent of the frequency band among the end nodes, gateway,
and TTN configuration you are using by following this instruction. The frequency plan
this demo applied is for EU868.
Hardware Required
Seeeduino XIAO
Grove - LoRa-E5
Seeeduino XIAO
Expansion Board
Grove - Temperature &
Humidity Sensor (DHT11)

Notes
If this is your first time using Seeeduino XIAO, please refer to Seeeduino XIAO's wiki. If
this is your first time to use Arduino, Arduino’s website is a great resource for you to
start your Arduino journey.
Hardware Connection
•Step 1. Connect the LoRa-E5 module directly to the "UART" slot.
•Step 2. Put DH11 into the "A0/D0" socket. As shown below.
•Step 3. Download the code, please refer to the software part.
Software Preparation
Notes
If this is the first time you work with Arduino, we strongly recommend you to see Getting
Started with Arduino before the start. Click to learn about detail about how to install an
Arduino Library
Download Library
•Step 1. Install the u8g2 library
•Step 2. Install the DHT sensor library

Software Code
Download the example; copy the code stick onto the Aruino IDE and
then upload it.
#include <Arduino.h>
#include <U8x8lib.h>
#include "DHT.h"
#define DHTPIN 0 // what pin we're connected to
// Uncomment whatever type you're using!
#define DHTTYPE DHT11 // DHT 11
// #define DHTTYPE DHT22 // DHT 22 (AM2302)
//#define DHTTYPE DHT21 // DHT 21 (AM2301)
DHT dht(DHTPIN, DHTTYPE);
U8X8_SSD1306_128X64_NONAME_HW_I2C u8x8(/* reset=*/U8X8_PIN_NONE);
// U8X8_SSD1306_128X64_NONAME_SW_I2C u8x8(/* clock=*/ SCL, /* data=*/ SDA, /*
reset=*/ U8X8_PIN_NONE); // OLEDs without Reset of the Display
static char recv_buf[512];
static bool is_exist = false;
static bool is_join = false;
static int led = 0;
static int at_send_check_response(char *p_ack, int timeout_ms, char *p_cmd, ...)
{
int ch;
int num = 0;
int index = 0;
int startMillis = 0;
va_list args;
memset(recv_buf, 0, sizeof(recv_buf));
va_start(args, p_cmd);
Serial1.printf(p_cmd, args);
Serial.printf(p_cmd, args);
va_end(args);
delay(200);
startMillis = millis();
if (p_ack == NULL)
{
return 0;
}
do
{
while (Serial1.available() > 0)
{
ch = Serial1.read();
recv_buf[index++] = ch;
Serial.print((char)ch);

delay(2);
}
if (strstr(recv_buf, p_ack) != NULL)
{
return 1;
}
} while (millis() - startMillis < timeout_ms);
return 0;
}
static void recv_prase(char *p_msg)
{
if (p_msg == NULL)
{
return;
}
char *p_start = NULL;
int data = 0;
int rssi = 0;
int snr = 0;
p_start = strstr(p_msg, "RX");
if (p_start && (1== sscanf(p_start, "RX: \"%d\"\r\n", &data)))
{
Serial.println(data);
u8x8.setCursor(2, 4);
u8x8.print("led :");
led = !!data;
u8x8.print(led);
if (led)
{
digitalWrite(LED_BUILTIN, LOW);
}
else
{
digitalWrite(LED_BUILTIN, HIGH);
}
}
p_start = strstr(p_msg, "RSSI");
if (p_start && (1== sscanf(p_start, "RSSI %d,", &rssi)))
{
u8x8.setCursor(0, 6);
u8x8.print(" ");
u8x8.setCursor(2, 6);
u8x8.print("rssi:");
u8x8.print(rssi);
}
p_start = strstr(p_msg, "SNR");

if (p_start && (1== sscanf(p_start, "SNR %d", &snr)))
{
u8x8.setCursor(0, 7);
u8x8.print(" ");
u8x8.setCursor(2, 7);
u8x8.print("snr :");
u8x8.print(snr);
}
}
void setup(void)
{
u8x8.begin();
u8x8.setFlipMode(1);
u8x8.setFont(u8x8_font_chroma48medium8_r);
Serial.begin(115200);
pinMode(LED_BUILTIN, OUTPUT);
digitalWrite(LED_BUILTIN, HIGH);
Serial1.begin(9600);
Serial.print("E5 LORAWAN TEST\r\n");
u8x8.setCursor(0, 0);
if (at_send_check_response("+AT: OK", 100, "AT\r\n"))
{
is_exist = true;
at_send_check_response("+ID: AppEui", 1000, "AT+ID\r\n");
at_send_check_response("+MODE: LWOTAA", 1000, "AT+MODE=LWOTAA\r\n");
at_send_check_response("+DR: EU868", 1000, "AT+DR=EU868\r\n");
at_send_check_response("+CH: NUM", 1000, "AT+CH=NUM,0-2\r\n");
at_send_check_response("+KEY: APPKEY", 1000,
"AT+KEY=APPKEY,\"2B7E151628AED2A6ABF7158809CF4F3C\"\r\n");
at_send_check_response("+CLASS: C", 1000, "AT+CLASS=A\r\n");
at_send_check_response("+PORT: 8", 1000, "AT+PORT=8\r\n");
delay(200);
u8x8.setCursor(5, 0);
u8x8.print("LoRaWAN");
is_join = true;
}
else
{
is_exist = false;
Serial.print("No E5 module found.\r\n");
u8x8.setCursor(0, 1);
u8x8.print("unfound E5 !");
}
dht.begin();
u8x8.setCursor(0, 2);
u8x8.setCursor(2, 2);

u8x8.print("temp:");
u8x8.setCursor(2, 3);
u8x8.print("humi:");
u8x8.setCursor(2, 4);
u8x8.print("led :");
u8x8.print(led);
}
void loop(void)
{
float temp = 0;
float humi = 0;
temp = dht.readTemperature();
humi = dht.readHumidity();
Serial.print("Humidity: ");
Serial.print(humi);
Serial.print(" %\t");
Serial.print("Temperature: ");
Serial.print(temp);
Serial.println(" *C");
u8x8.setCursor(0, 2);
u8x8.print(" ");
u8x8.setCursor(2, 2);
u8x8.print("temp:");
u8x8.print(temp);
u8x8.setCursor(2, 3);
u8x8.print("humi:");
u8x8.print(humi);
if (is_exist)
{
int ret = 0;
if (is_join)
{
ret = at_send_check_response("+JOIN: Network joined", 12000, "AT+JOIN\r\n");
if (ret)
{
is_join = false;
}
else
{
at_send_check_response("+ID: AppEui", 1000, "AT+ID\r\n");
Serial.print("JOIN failed!\r\n\r\n");
delay(5000);
}
}
else
{

char cmd[128];
sprintf(cmd, "AT+CMSGHEX=\"%04X%04X\"\r\n", (int)temp, (int)humi);
ret = at_send_check_response("Done", 5000, cmd);
if (ret)
{
recv_prase(recv_buf);
}
else
{
Serial.print("Send failed!\r\n\r\n");
}
delay(5000);
}
}
else
{
delay(1000);
}
}
TTN Console Configuration Setup
•Step 1: Load into TTN
website: https://www.thethingsnetwork.org and create your account,
then access “Console” and first click on "APPLICATIONS".
•Step 2: Add an Application:
•Application ID: Enter a unique name.

•Description: Enter a description.
•Handler registration: select the same handler as the gateway router.
•Select Add Application to continue.
•Step 3: Add a decoding script to the application and save.

function Decoder(bytes, port) {
var decoded = {};
if (port === 8) {
decoded.temp = bytes[0] <<8| bytes[1];
decoded.humi = bytes[2] <<8| bytes[3];
}
return decoded;
}
•Step 4: Add Grove - LoRa-E5 device to the TTN Console
•Run the downloaded program module, view the DEVEUI and APP
EUI of the LoRa-E5 module through the serial port.
1. Add these two EUIs to the application.

•Step 5: Register Device: enter the registered device page
1. Device ID: Enter a unique name.
2. Device EUI: Select the E5 dev EUI.
3. APP KEY: Use this APPkey
2B7E151628AED2A6ABF7158809CF4F3C
4. App EUI: Select the E5 App EUI.
•Step 6: Gateway Registration on TTN Console

Please refer to the instruction shown in The Things Indoor Gateway wiki
page: The Things Indoor Gateway Get Started with SenseCAP
•Step 7: Review Result
you can check the readings via the Serial Monitor.

Temperature and Humidity Parameters
•Step 1: Enter the APPLICATION created in TTN, click on the data
page to view the reported data

•Step 2: LED control
Enter the current device control page. Send the specified data in the
“DOWNLINK” window.
Send "01" to turn on LED light; Send "00" to turn off:

Resources
Datasheet:
•Grove LoRa-E5 v1.0.brd
•Grove LoRa-E5 v1.0.pdf
•Grove LoRa-E5 v1.0.sch
•LoRa-E5 datasheet and specifications
•LoRa-E5 AT Command Specification
•STM32WLE5JC Datasheet
Certifications:
•LoRa-E5-HF Certification CE-VOC-RED
•LoRa-E5-HF FCC Certification -DSS
•LoRa-E5-HF FCC Certification -DTS
Relevant SDK:
•STM32Cube MCU Package for STM32WL series
Tech Support
Please submit any technical issue into our forum.
