Seeed Grove - Servo Series User manual

1
Grove - Servo
Version：1.0
Release date：9/20/2015
Wiki: http://www.seeedstudio.com/wiki/Grove_-_Servo
Bazaar: http://www.seeedstudio.com/depot/Grove-Servo-p-1241.html

2
Document Revision History
Revision
Date
Author
Description
1.0
Sep 21, 2015
Victor.He
Create file

3
Contents
Document Revision History··································································································· 2
1. Introduction ···················································································································2
2. Features··························································································································3
3. Specifications ·················································································································4
4. Usage······························································································································5
5. Support···························································································································6

1
Disclaimer
For physical injuries and possessions loss caused by those reasons which are not related to product quality,
such as operating without following manual guide, natural disasters or force majeure, we take no
responsibility for that.
Under the supervision of Seeed Technology Inc., this manual has been compiled and published which
covered the latest product description and specification. The content of this manual is subject to change
without notice.
Copyright
The design of this product (including software) and its accessories is under tutelage of laws. Any action to
violate relevant right of our product will be penalized through law. Please consciously observe relevant local
laws in the use of this product.

2
1. Introduction
Grove - Servo is DC motor with gearing and feedback system. It is used in driving mechanism of robots. The
module is a bonus product for Grove lovers. We regulated the three-wire servo into a Grove standard
connector. You can plug and play it as a typical Grove module now, without jumper wires clutter. But if you
feel more like a proto servo, check out EMAX 9g ES08A High Sensitive Mini Servo. They are the same model,
both of good quality and burden-free price.

3
2. Features
Small module
Grove Compatible Interface
Easy to use

4
3. Specifications
Item
Min
Typical
Max
Unit
Working Voltage
4.8
5.0
6.0
V
Torque
1.5/1.8
Kg.cm
Speed
0.12/0.16
s/60°
Size
32X11.5X24
mm
Weight
8.5
Gram

5
4. Usage
The Servo has three wires: power, ground, and signal. The power wire is typically red, and should be
connected to the 5V pin on the Arduino/Seeeduino board. The ground wire is typically black or brown and
should be connected to a ground pin on the Arduino board. The signal pin is typically yellow, orange or
white and should be connected to Digital 9 on the Arduino board.You can change to the digital port as you
like. But don't forget to change the port number in the definition of the demo code at the same time.
Next sweeps the shaft of a servo back and forth across 180 degrees.This example makes use of the
Arduino servo library.
Connect the Servo to Seeeduino and connect Seeeduino to PC using a USB cable.
Restart the Arduino IDE, open one demo code you like, for example Sweep directly by the
path:File -> Example ->Servo->Sweep.
Upload the code.Please click here if you do not know how to upload.

6
5. Support
If you have questions or other better design ideas, you can go to our forum or wish to discuss.
