Seehot SBS-030C User manual
Two-link function:
This function means 2 Bluetooth mobile Phones
connected with Bluetooth headset “SBS-030C” at the
same time.
When the Phone A & Phone B are neither paired, the two
link operation as below:
1)Pairing with Phone A: In off mode, press and hold MFB
until indicator light flashes red and blue alternately, use
phone A to search the Bluetooth headset “SBS-030C”,
enter the pin code”0000” and confirm on the phones A, to
pair and connect with phone A, and the headset will enter
into standby mode.
2)Turn off the Bluetooth function of phone A or turn off the
phone A, the headset will back to unconnected mode.
3)Pairing with Phone B: press and hold MFB until
indicator light flashes red and blue alternately, use phone
B to search the Bluetooth headset “SBS-030C”, enter the
pin code”0000” and confirm on the phones B, to pair and
connect with phone B, and the headset will enter into
standby mode.
4). Connecting the Phone A&B at the same time:
Method 1: Activate the Bluetooth function of Phone A,
select the Bluetooth device “SBS-030C” on the Phone A,
and connect with the “SBS-030C”, at that time the 2
Phones are connected with the headset already.
Method 2: Turn on the Bluetooth function on the phone
A/B, or turn on the phone A/B, and restart the headset,
the headset will automatically connect with the two
mobile phones within one minute.
Note:
Note 1: For the difference technology of Phones, it
doesn’t guarantee compatibility of all functions on every
Bluetooth enabled device.
Note 2: Redial the last phone number after connected
with two Phones, the headset will choose the Phone
which is connected first(not the one pairing first) to call.
The other phone does not respond for calling.
Note 3: For voice dialing after connected with two
Phones, the headset will choose the Phone which is
connected first(not the one pairing first) to call. The other
phone does not respond for calling.
Switching Between Two Calls
•Connected with one phone and operate with two calls
1).When answering the call A, there is a call B coming,
you could press the MFB shortly to answer the call B, the
call A is under the status of waiting. Re-press the MFB
shortly, you could switch the two calls each other.
2).When answering the call A, there is a call B coming,
you can press and hold MFB for 2 seconds to end the call
A, and answer the call B.
•After two-link functions switching between two calls
If phone A is answering the call, there have a call
coming from phone B; Press MFB shortly to answer the
call on phone B.
V4.1+EDR
HSP, HFP , A2DP,AVRCP
Class 2
Up to 10 Meters
2.402~2.480GHz
Built-in Rechargeable
3.7V/70mAH Li-polymer Battery
DC4.75-5.25V
About 2 hours
3.5 hours
4 hours
150 hours
L49 x W15 x H10
About 13.5g
Basic Operations
Charging Your Headset
Prior to use the headset for the first time or has not
been used for a long time, please fully charge the
headset.
Approximately 2 hours are required to fully charge
the headset.
The indicator light turns red while being charged, and
will turn blue automatically after being fully charged.
When the headset is running out of battery, the
indicator light will flash red (the headset will switch
off automatically when the battery is drained). Please
charge the headset as above steps in time to prolong
the battery's using life (Charging indication will be
delayed for a few minutes if the headset has not been
used for a long time or the battery is drained).
Note:
Please check if the charging device whether suitable for the headset or
not before charging
Please use the supplied battery and charging device, if use other
accessories ,it may go against the approval or warranty terms of the
product, and could be dangerous.
There have built-in and non-removable Lithium Battery, please do not
attempt to force open the battery as this could damage the headset.
If left unused, a fully charged headset will loose its power
automatically. It is recommended to charge the headset every three
months.
Do not leave the headset in a too hot or too cold condition (best
between -10℃and 50℃) which may affect the headset's operations.
Do not dispose of the headset into a fire and water.
Turning On The Headset
In OFF MODE, press and hold MFB for 5 seconds until
you hear “Power on”, and the indicator light flashes
blue for 3 times, then the headset will enter into ON
MODE.
Turning Off The Headset
In ON MODE, press and hold MFB for 4 seconds until
you hear “Power off”, and the indicator light flashes red
for 3 times, then the headset will enter into OFF MODE.
Pairing Your Headset With A Bluetooth
Mobile Phone
Ensure the headset is off, and the distance between
your headset and phone is within 1 meter.
Press and hold MFB for about 8 seconds until you
hear “Pairing”, the indicator light flashes blue and
red alternately, then the headset will enter into
PAIRING MODE.
Activate the Bluetooth function on the phone,
search Bluetooth devices (See the user guide of
your phone for instructions).
Select headset “SBS-030C” from the found devices
list of the phone.
Enter the passkey “0000”, confirm to pair the
headset with your phone. If successfully paired, you
with your phone. If successfully paired, you will hear
“Connected”, and the indicator light will flash blue
every 8 seconds. The headset enters into the
STANDBY MODE.(If the pairing cannot be completed
within 5 minutes after the PAIRING MODE has been
activated, the headset will enter into the STANDBY
MODE. Repeat above steps to do the pairing again).
Ensure the distance between your headset and phone
is within 10 meters, and without any obstacles. You
can use the headset freely.
If the headset has paired with your phone but
disconnected, it will pair automatically again when
turns on within operation range.
Answering/Ending A Call
Press MFB once.
Rejecting A Call
Press and hold MFB for one second.
Voice Dialing
In STANDBY MODE, press MFB twice and say the voice
tag as soon as you hear the short beep(ensure your
phone supports voice dialing function, and you have
recorded the voice tag into your phone. See the user
guide of your phone for instructions)
Last Number Redialing
Press and hold MFB for one second.
Adjusting Volume
Press V+ or V- to adjust the volume to meet your need.
Power Saving
The headset will turn off automatically if it can not be
paired or disconnected with any devices within 20
minutes.
Audio Remote-control Functions
Specifications
Bluetooth Specification
Bluetooth Profiles Supported
Transmission Power
Operation Range
Frequency Range
Battery
Charging Voltage
Charging Time
Music Playing Time*
Talk Time *
Standby Time *
Dimensions(mm)
Weight
SBS-030C
Bluetooth Stereo Headset
User Manual
*May vary due to user’s operation mode and device settings.
Structure Sketch
Bluetooth headset should be used with the compatible
devices which support Bluetooth wireless technology.
This allows you the freedom to make any calls and
enjoy the music streaming any time.
Please read this user manual carefully before using the
headset, and also read your device’s user manual
regarding the Bluetooth function, and pay attention to
those important safety and maintenance information.
Please keep the headset away from children.
(1)Microphone
(2)Audio Jack/Charging Socket
(3)Earhook
(4)Multifunction Button (MFB)
(5)Volume Key+(V+)
(6)Volume Key-(V-)
(7)Earpiece
Two-link Function
Note: The two Phones mentioned below will be called Phone A and B.
Play/Pause
Press MFB once for music playing or press again to
pause.
Backward
Press and hold V+ to backward the last song.
Forward
Press and hold V- to forward the next song.
Note: Ensure your paired devices support AVRCP Bluetooth Profile to
realize remote-control use.
Disconnecting
To disconnect the paired headset from your phone,
please turn off the headset or disconnect the headset
from the Bluetooth menu of your phone.
Care and Maintenance
Do not use abrasive cleaning solvents to clean the
headset.
Do not allow the headset to touch with any sharp
objects since this will cause scratching and damage.
Be sure to store the headset in a dry place, free from
extreme temperatures, humidity and dust in normal
use.
Additional Statements
The headset is unable to pair with the non-smart
phones.
The headset is compliant with the specified Bluetooth
version. It does not guarantee compatibility of all
functions on every Bluetooth enabled device. Please
check your device’s user manual for compatibility and
functionality.
Charge the headset under any status to a reset.
The headset will turn off automatically if it can not be
paired with any devices within 20 minutes.
The headset will beep when operates successfully but
this maybe too low to hear, and all belong to normal
phenomenon.
The above operations may vary due to different
devices.
Manufacturer reserves the rights to final explanation of
all the above statements.
Two-link function:
This function means 2 Bluetooth mobile Phones
connected with Bluetooth headset “SBS-030C” at the
same time.
When the Phone A & Phone B are neither paired, the two
link operation as below:
1)Pairing with Phone A: In off mode, press and hold MFB
until indicator light flashes red and blue alternately, use
phone A to search the Bluetooth headset “SBS-030C”,
enter the pin code”0000” and confirm on the phones A, to
pair and connect with phone A, and the headset will enter
into standby mode.
2)Turn off the Bluetooth function of phone A or turn off the
phone A, the headset will back to unconnected mode.
3)Pairing with Phone B: press and hold MFB until
indicator light flashes red and blue alternately, use phone
B to search the Bluetooth headset “SBS-030C”, enter the
pin code”0000” and confirm on the phones B, to pair and
connect with phone B, and the headset will enter into
standby mode.
4). Connecting the Phone A&B at the same time:
Method 1: Activate the Bluetooth function of Phone A,
select the Bluetooth device “SBS-030C” on the Phone A,
and connect with the “SBS-030C”, at that time the 2
Phones are connected with the headset already.
Method 2: Turn on the Bluetooth function on the phone
A/B, or turn on the phone A/B, and restart the headset,
the headset will automatically connect with the two
mobile phones within one minute.
Note:
Note 1: For the difference technology of Phones, it
doesn’t guarantee compatibility of all functions on every
Bluetooth enabled device.
Note 2: Redial the last phone number after connected
with two Phones, the headset will choose the Phone
which is connected first(not the one pairing first) to call.
The other phone does not respond for calling.
Note 3: For voice dialing after connected with two
Phones, the headset will choose the Phone which is
connected first(not the one pairing first) to call. The other
phone does not respond for calling.
Switching Between Two Calls
•Connected with one phone and operate with two calls
1).When answering the call A, there is a call B coming,
you could press the MFB shortly to answer the call B, the
call A is under the status of waiting. Re-press the MFB
shortly, you could switch the two calls each other.
2).When answering the call A, there is a call B coming,
you can press and hold MFB for 2 seconds to end the call
A, and answer the call B.
•After two-link functions switching between two calls
If phone A is answering the call, there have a call
coming from phone B; Press MFB shortly to answer the
call on phone B.
V4.1+EDR
HSP, HFP , A2DP,AVRCP
Class 2
Up to 10 Meters
2.402~2.480GHz
Built-in Rechargeable
3.7V/70mAH Li-polymer Battery
DC4.75-5.25V
About 2 hours
3.5 hours
4 hours
150 hours
L49 x W15 x H10
About 13.5g
Basic Operations
Charging Your Headset
Prior to use the headset for the first time or has not
been used for a long time, please fully charge the
headset.
Approximately 2 hours are required to fully charge
the headset.
The indicator light turns red while being charged, and
will turn blue automatically after being fully charged.
When the headset is running out of battery, the
indicator light will flash red (the headset will switch
off automatically when the battery is drained). Please
charge the headset as above steps in time to prolong
the battery's using life (Charging indication will be
delayed for a few minutes if the headset has not been
used for a long time or the battery is drained).
Note:
Please check if the charging device whether suitable for the headset or
not before charging
Please use the supplied battery and charging device, if use other
accessories ,it may go against the approval or warranty terms of the
product, and could be dangerous.
There have built-in and non-removable Lithium Battery, please do not
attempt to force open the battery as this could damage the headset.
If left unused, a fully charged headset will loose its power
automatically. It is recommended to charge the headset every three
months.
Do not leave the headset in a too hot or too cold condition (best
between -10℃and 50℃) which may affect the headset's operations.
Do not dispose of the headset into a fire and water.
Turning On The Headset
In OFF MODE, press and hold MFB for 5 seconds until
you hear “Power on”, and the indicator light flashes
blue for 3 times, then the headset will enter into ON
MODE.
Turning Off The Headset
In ON MODE, press and hold MFB for 4 seconds until
you hear “Power off”, and the indicator light flashes red
for 3 times, then the headset will enter into OFF MODE.
Pairing Your Headset With A Bluetooth
Mobile Phone
Ensure the headset is off, and the distance between
your headset and phone is within 1 meter.
Press and hold MFB for about 8 seconds until you
hear “Pairing”, the indicator light flashes blue and
red alternately, then the headset will enter into
PAIRING MODE.
Activate the Bluetooth function on the phone,
search Bluetooth devices (See the user guide of
your phone for instructions).
Select headset “SBS-030C” from the found devices
list of the phone.
Enter the passkey “0000”, confirm to pair the
headset with your phone. If successfully paired, you
with your phone. If successfully paired, you will hear
“Connected”, and the indicator light will flash blue
every 8 seconds. The headset enters into the
STANDBY MODE.(If the pairing cannot be completed
within 5 minutes after the PAIRING MODE has been
activated, the headset will enter into the STANDBY
MODE. Repeat above steps to do the pairing again).
Ensure the distance between your headset and phone
is within 10 meters, and without any obstacles. You
can use the headset freely.
If the headset has paired with your phone but
disconnected, it will pair automatically again when
turns on within operation range.
Answering/Ending A Call
Press MFB once.
Rejecting A Call
Press and hold MFB for one second.
Voice Dialing
In STANDBY MODE, press MFB twice and say the voice
tag as soon as you hear the short beep(ensure your
phone supports voice dialing function, and you have
recorded the voice tag into your phone. See the user
guide of your phone for instructions)
Last Number Redialing
Press and hold MFB for one second.
Adjusting Volume
Press V+ or V- to adjust the volume to meet your need.
Power Saving
The headset will turn off automatically if it can not be
paired or disconnected with any devices within 20
minutes.
Audio Remote-control Functions
Specifications
Bluetooth Specification
Bluetooth Profiles Supported
Transmission Power
Operation Range
Frequency Range
Battery
Charging Voltage
Charging Time
Music Playing Time*
Talk Time *
Standby Time *
Dimensions(mm)
Weight
SBS-030C
Bluetooth Stereo Headset
User Manual
*May vary due to user’s operation mode and device settings.
Structure Sketch
Bluetooth headset should be used with the compatible
devices which support Bluetooth wireless technology.
This allows you the freedom to make any calls and
enjoy the music streaming any time.
Please read this user manual carefully before using the
headset, and also read your device’s user manual
regarding the Bluetooth function, and pay attention to
those important safety and maintenance information.
Please keep the headset away from children.
(1)Microphone
(2)Audio Jack/Charging Socket
(3)Earhook
(4)Multifunction Button (MFB)
(5)Volume Key+(V+)
(6)Volume Key-(V-)
(7)Earpiece
Two-link Function
Note: The two Phones mentioned below will be called Phone A and B.
Play/Pause
Press MFB once for music playing or press again to
pause.
Backward
Press and hold V+ to backward the last song.
Forward
Press and hold V- to forward the next song.
Note: Ensure your paired devices support AVRCP Bluetooth Profile to
realize remote-control use.
Disconnecting
To disconnect the paired headset from your phone,
please turn off the headset or disconnect the headset
from the Bluetooth menu of your phone.
Care and Maintenance
Do not use abrasive cleaning solvents to clean the
headset.
Do not allow the headset to touch with any sharp
objects since this will cause scratching and damage.
Be sure to store the headset in a dry place, free from
extreme temperatures, humidity and dust in normal
use.
Additional Statements
The headset is unable to pair with the non-smart
phones.
The headset is compliant with the specified Bluetooth
version. It does not guarantee compatibility of all
functions on every Bluetooth enabled device. Please
check your device’s user manual for compatibility and
functionality.
Charge the headset under any status to a reset.
The headset will turn off automatically if it can not be
paired with any devices within 20 minutes.
The headset will beep when operates successfully but
this maybe too low to hear, and all belong to normal
phenomenon.
The above operations may vary due to different
devices.
Manufacturer reserves the rights to final explanation of
all the above statements.
Two-link function:
This function means 2 Bluetooth mobile Phones
connected with Bluetooth headset “SBS-030C” at the
same time.
When the Phone A & Phone B are neither paired, the two
link operation as below:
1)Pairing with Phone A: In off mode, press and hold MFB
until indicator light flashes red and blue alternately, use
phone A to search the Bluetooth headset “SBS-030C”,
enter the pin code”0000” and confirm on the phones A, to
pair and connect with phone A, and the headset will enter
into standby mode.
2)Turn off the Bluetooth function of phone A or turn off the
phone A, the headset will back to unconnected mode.
3)Pairing with Phone B: press and hold MFB until
indicator light flashes red and blue alternately, use phone
B to search the Bluetooth headset “SBS-030C”, enter the
pin code”0000” and confirm on the phones B, to pair and
connect with phone B, and the headset will enter into
standby mode.
4). Connecting the Phone A&B at the same time:
Method 1: Activate the Bluetooth function of Phone A,
select the Bluetooth device “SBS-030C” on the Phone A,
and connect with the “SBS-030C”, at that time the 2
Phones are connected with the headset already.
Method 2: Turn on the Bluetooth function on the phone
A/B, or turn on the phone A/B, and restart the headset,
the headset will automatically connect with the two
mobile phones within one minute.
Note:
Note 1: For the difference technology of Phones, it
doesn’t guarantee compatibility of all functions on every
Bluetooth enabled device.
Note 2: Redial the last phone number after connected
with two Phones, the headset will choose the Phone
which is connected first(not the one pairing first) to call.
The other phone does not respond for calling.
Note 3: For voice dialing after connected with two
Phones, the headset will choose the Phone which is
connected first(not the one pairing first) to call. The other
phone does not respond for calling.
Switching Between Two Calls
•Connected with one phone and operate with two calls
1).When answering the call A, there is a call B coming,
you could press the MFB shortly to answer the call B, the
call A is under the status of waiting. Re-press the MFB
shortly, you could switch the two calls each other.
2).When answering the call A, there is a call B coming,
you can press and hold MFB for 2 seconds to end the call
A, and answer the call B.
•After two-link functions switching between two calls
If phone A is answering the call, there have a call
coming from phone B; Press MFB shortly to answer the
call on phone B.
V4.1+EDR
HSP, HFP , A2DP,AVRCP
Class 2
Up to 10 Meters
2.402~2.480GHz
Built-in Rechargeable
3.7V/70mAH Li-polymer Battery
DC4.75-5.25V
About 2 hours
3.5 hours
4 hours
150 hours
L49 x W15 x H10
About 13.5g
Basic Operations
Charging Your Headset
Prior to use the headset for the first time or has not
been used for a long time, please fully charge the
headset.
Approximately 2 hours are required to fully charge
the headset.
The indicator light turns red while being charged, and
will turn blue automatically after being fully charged.
When the headset is running out of battery, the
indicator light will flash red (the headset will switch
off automatically when the battery is drained). Please
charge the headset as above steps in time to prolong
the battery's using life (Charging indication will be
delayed for a few minutes if the headset has not been
used for a long time or the battery is drained).
Note:
Please check if the charging device whether suitable for the headset or
not before charging
Please use the supplied battery and charging device, if use other
accessories ,it may go against the approval or warranty terms of the
product, and could be dangerous.
There have built-in and non-removable Lithium Battery, please do not
attempt to force open the battery as this could damage the headset.
If left unused, a fully charged headset will loose its power
automatically. It is recommended to charge the headset every three
months.
Do not leave the headset in a too hot or too cold condition (best
between -10℃and 50℃) which may affect the headset's operations.
Do not dispose of the headset into a fire and water.
Turning On The Headset
In OFF MODE, press and hold MFB for 5 seconds until
you hear “Power on”, and the indicator light flashes
blue for 3 times, then the headset will enter into ON
MODE.
Turning Off The Headset
In ON MODE, press and hold MFB for 4 seconds until
you hear “Power off”, and the indicator light flashes red
for 3 times, then the headset will enter into OFF MODE.
Pairing Your Headset With A Bluetooth
Mobile Phone
Ensure the headset is off, and the distance between
your headset and phone is within 1 meter.
Press and hold MFB for about 8 seconds until you
hear “Pairing”, the indicator light flashes blue and
red alternately, then the headset will enter into
PAIRING MODE.
Activate the Bluetooth function on the phone,
search Bluetooth devices (See the user guide of
your phone for instructions).
Select headset “SBS-030C” from the found devices
list of the phone.
Enter the passkey “0000”, confirm to pair the
headset with your phone. If successfully paired, you
with your phone. If successfully paired, you will hear
“Connected”, and the indicator light will flash blue
every 8 seconds. The headset enters into the
STANDBY MODE.(If the pairing cannot be completed
within 5 minutes after the PAIRING MODE has been
activated, the headset will enter into the STANDBY
MODE. Repeat above steps to do the pairing again).
Ensure the distance between your headset and phone
is within 10 meters, and without any obstacles. You
can use the headset freely.
If the headset has paired with your phone but
disconnected, it will pair automatically again when
turns on within operation range.
Answering/Ending A Call
Press MFB once.
Rejecting A Call
Press and hold MFB for one second.
Voice Dialing
In STANDBY MODE, press MFB twice and say the voice
tag as soon as you hear the short beep(ensure your
phone supports voice dialing function, and you have
recorded the voice tag into your phone. See the user
guide of your phone for instructions)
Last Number Redialing
Press and hold MFB for one second.
Adjusting Volume
Press V+ or V- to adjust the volume to meet your need.
Power Saving
The headset will turn off automatically if it can not be
paired or disconnected with any devices within 20
minutes.
Audio Remote-control Functions
Specifications
Bluetooth Specification
Bluetooth Profiles Supported
Transmission Power
Operation Range
Frequency Range
Battery
Charging Voltage
Charging Time
Music Playing Time*
Talk Time *
Standby Time *
Dimensions(mm)
Weight
SBS-030C
Bluetooth Stereo Headset
User Manual
*May vary due to user’s operation mode and device settings.
Structure Sketch
Bluetooth headset should be used with the compatible
devices which support Bluetooth wireless technology.
This allows you the freedom to make any calls and
enjoy the music streaming any time.
Please read this user manual carefully before using the
headset, and also read your device’s user manual
regarding the Bluetooth function, and pay attention to
those important safety and maintenance information.
Please keep the headset away from children.
(1)Microphone
(2)Audio Jack/Charging Socket
(3)Earhook
(4)Multifunction Button (MFB)
(5)Volume Key+(V+)
(6)Volume Key-(V-)
(7)Earpiece
Two-link Function
Note: The two Phones mentioned below will be called Phone A and B.
Play/Pause
Press MFB once for music playing or press again to
pause.
Backward
Press and hold V+ to backward the last song.
Forward
Press and hold V- to forward the next song.
Note: Ensure your paired devices support AVRCP Bluetooth Profile to
realize remote-control use.
Disconnecting
To disconnect the paired headset from your phone,
please turn off the headset or disconnect the headset
from the Bluetooth menu of your phone.
Care and Maintenance
Do not use abrasive cleaning solvents to clean the
headset.
Do not allow the headset to touch with any sharp
objects since this will cause scratching and damage.
Be sure to store the headset in a dry place, free from
extreme temperatures, humidity and dust in normal
use.
Additional Statements
The headset is unable to pair with the non-smart
phones.
The headset is compliant with the specified Bluetooth
version. It does not guarantee compatibility of all
functions on every Bluetooth enabled device. Please
check your device’s user manual for compatibility and
functionality.
Charge the headset under any status to a reset.
The headset will turn off automatically if it can not be
paired with any devices within 20 minutes.
The headset will beep when operates successfully but
this maybe too low to hear, and all belong to normal
phenomenon.
The above operations may vary due to different
devices.
Manufacturer reserves the rights to final explanation of
all the above statements.
Two-link function:
This function means 2 Bluetooth mobile Phones
connected with Bluetooth headset “SBS-030C” at the
same time.
When the Phone A & Phone B are neither paired, the two
link operation as below:
1)Pairing with Phone A: In off mode, press and hold MFB
until indicator light flashes red and blue alternately, use
phone A to search the Bluetooth headset “SBS-030C”,
enter the pin code”0000” and confirm on the phones A, to
pair and connect with phone A, and the headset will enter
into standby mode.
2)Turn off the Bluetooth function of phone A or turn off the
phone A, the headset will back to unconnected mode.
3)Pairing with Phone B: press and hold MFB until
indicator light flashes red and blue alternately, use phone
B to search the Bluetooth headset “SBS-030C”, enter the
pin code”0000” and confirm on the phones B, to pair and
connect with phone B, and the headset will enter into
standby mode.
4). Connecting the Phone A&B at the same time:
Method 1: Activate the Bluetooth function of Phone A,
select the Bluetooth device “SBS-030C” on the Phone A,
and connect with the “SBS-030C”, at that time the 2
Phones are connected with the headset already.
Method 2: Turn on the Bluetooth function on the phone
A/B, or turn on the phone A/B, and restart the headset,
the headset will automatically connect with the two
mobile phones within one minute.
Note:
Note 1: For the difference technology of Phones, it
doesn’t guarantee compatibility of all functions on every
Bluetooth enabled device.
Note 2: Redial the last phone number after connected
with two Phones, the headset will choose the Phone
which is connected first(not the one pairing first) to call.
The other phone does not respond for calling.
Note 3: For voice dialing after connected with two
Phones, the headset will choose the Phone which is
connected first(not the one pairing first) to call. The other
phone does not respond for calling.
Switching Between Two Calls
•Connected with one phone and operate with two calls
1).When answering the call A, there is a call B coming,
you could press the MFB shortly to answer the call B, the
call A is under the status of waiting. Re-press the MFB
shortly, you could switch the two calls each other.
2).When answering the call A, there is a call B coming,
you can press and hold MFB for 2 seconds to end the call
A, and answer the call B.
•After two-link functions switching between two calls
If phone A is answering the call, there have a call
coming from phone B; Press MFB shortly to answer the
call on phone B.
V4.1+EDR
HSP, HFP , A2DP,AVRCP
Class 2
Up to 10 Meters
2.402~2.480GHz
Built-in Rechargeable
3.7V/70mAH Li-polymer Battery
DC4.75-5.25V
About 2 hours
3.5 hours
4 hours
150 hours
L49 x W15 x H10
About 13.5g
Basic Operations
Charging Your Headset
Prior to use the headset for the first time or has not
been used for a long time, please fully charge the
headset.
Approximately 2 hours are required to fully charge
the headset.
The indicator light turns red while being charged, and
will turn blue automatically after being fully charged.
When the headset is running out of battery, the
indicator light will flash red (the headset will switch
off automatically when the battery is drained). Please
charge the headset as above steps in time to prolong
the battery's using life (Charging indication will be
delayed for a few minutes if the headset has not been
used for a long time or the battery is drained).
Note:
Please check if the charging device whether suitable for the headset or
not before charging
Please use the supplied battery and charging device, if use other
accessories ,it may go against the approval or warranty terms of the
product, and could be dangerous.
There have built-in and non-removable Lithium Battery, please do not
attempt to force open the battery as this could damage the headset.
If left unused, a fully charged headset will loose its power
automatically. It is recommended to charge the headset every three
months.
Do not leave the headset in a too hot or too cold condition (best
between -10℃and 50℃) which may affect the headset's operations.
Do not dispose of the headset into a fire and water.
Turning On The Headset
In OFF MODE, press and hold MFB for 5 seconds until
you hear “Power on”, and the indicator light flashes
blue for 3 times, then the headset will enter into ON
MODE.
Turning Off The Headset
In ON MODE, press and hold MFB for 4 seconds until
you hear “Power off”, and the indicator light flashes red
for 3 times, then the headset will enter into OFF MODE.
Pairing Your Headset With A Bluetooth
Mobile Phone
Ensure the headset is off, and the distance between
your headset and phone is within 1 meter.
Press and hold MFB for about 8 seconds until you
hear “Pairing”, the indicator light flashes blue and
red alternately, then the headset will enter into
PAIRING MODE.
Activate the Bluetooth function on the phone,
search Bluetooth devices (See the user guide of
your phone for instructions).
Select headset “SBS-030C” from the found devices
list of the phone.
Enter the passkey “0000”, confirm to pair the
headset with your phone. If successfully paired, you
with your phone. If successfully paired, you will hear
“Connected”, and the indicator light will flash blue
every 8 seconds. The headset enters into the
STANDBY MODE.(If the pairing cannot be completed
within 5 minutes after the PAIRING MODE has been
activated, the headset will enter into the STANDBY
MODE. Repeat above steps to do the pairing again).
Ensure the distance between your headset and phone
is within 10 meters, and without any obstacles. You
can use the headset freely.
If the headset has paired with your phone but
disconnected, it will pair automatically again when
turns on within operation range.
Answering/Ending A Call
Press MFB once.
Rejecting A Call
Press and hold MFB for one second.
Voice Dialing
In STANDBY MODE, press MFB twice and say the voice
tag as soon as you hear the short beep(ensure your
phone supports voice dialing function, and you have
recorded the voice tag into your phone. See the user
guide of your phone for instructions)
Last Number Redialing
Press and hold MFB for one second.
Adjusting Volume
Press V+ or V- to adjust the volume to meet your need.
Power Saving
The headset will turn off automatically if it can not be
paired or disconnected with any devices within 20
minutes.
Audio Remote-control Functions
Specifications
Bluetooth Specification
Bluetooth Profiles Supported
Transmission Power
Operation Range
Frequency Range
Battery
Charging Voltage
Charging Time
Music Playing Time*
Talk Time *
Standby Time *
Dimensions(mm)
Weight
SBS-030C
Bluetooth Stereo Headset
User Manual
*May vary due to user’s operation mode and device settings.
Structure Sketch
Bluetooth headset should be used with the compatible
devices which support Bluetooth wireless technology.
This allows you the freedom to make any calls and
enjoy the music streaming any time.
Please read this user manual carefully before using the
headset, and also read your device’s user manual
regarding the Bluetooth function, and pay attention to
those important safety and maintenance information.
Please keep the headset away from children.
(1)Microphone
(2)Audio Jack/Charging Socket
(3)Earhook
(4)Multifunction Button (MFB)
(5)Volume Key+(V+)
(6)Volume Key-(V-)
(7)Earpiece
Two-link Function
Note: The two Phones mentioned below will be called Phone A and B.
Play/Pause
Press MFB once for music playing or press again to
pause.
Backward
Press and hold V+ to backward the last song.
Forward
Press and hold V- to forward the next song.
Note: Ensure your paired devices support AVRCP Bluetooth Profile to
realize remote-control use.
Disconnecting
To disconnect the paired headset from your phone,
please turn off the headset or disconnect the headset
from the Bluetooth menu of your phone.
Care and Maintenance
Do not use abrasive cleaning solvents to clean the
headset.
Do not allow the headset to touch with any sharp
objects since this will cause scratching and damage.
Be sure to store the headset in a dry place, free from
extreme temperatures, humidity and dust in normal
use.
Additional Statements
The headset is unable to pair with the non-smart
phones.
The headset is compliant with the specified Bluetooth
version. It does not guarantee compatibility of all
functions on every Bluetooth enabled device. Please
check your device’s user manual for compatibility and
functionality.
Charge the headset under any status to a reset.
The headset will turn off automatically if it can not be
paired with any devices within 20 minutes.
The headset will beep when operates successfully but
this maybe too low to hear, and all belong to normal
phenomenon.
The above operations may vary due to different
devices.
Manufacturer reserves the rights to final explanation of
all the above statements.
Two-link function:
This function means 2 Bluetooth mobile Phones
connected with Bluetooth headset “SBS-030C” at the
same time.
When the Phone A & Phone B are neither paired, the two
link operation as below:
1)Pairing with Phone A: In off mode, press and hold MFB
until indicator light flashes red and blue alternately, use
phone A to search the Bluetooth headset “SBS-030C”,
enter the pin code”0000” and confirm on the phones A, to
pair and connect with phone A, and the headset will enter
into standby mode.
2)Turn off the Bluetooth function of phone A or turn off the
phone A, the headset will back to unconnected mode.
3)Pairing with Phone B: press and hold MFB until
indicator light flashes red and blue alternately, use phone
B to search the Bluetooth headset “SBS-030C”, enter the
pin code”0000” and confirm on the phones B, to pair and
connect with phone B, and the headset will enter into
standby mode.
4). Connecting the Phone A&B at the same time:
Method 1: Activate the Bluetooth function of Phone A,
select the Bluetooth device “SBS-030C” on the Phone A,
and connect with the “SBS-030C”, at that time the 2
Phones are connected with the headset already.
Method 2: Turn on the Bluetooth function on the phone
A/B, or turn on the phone A/B, and restart the headset,
the headset will automatically connect with the two
mobile phones within one minute.
Note:
Note 1: For the difference technology of Phones, it
doesn’t guarantee compatibility of all functions on every
Bluetooth enabled device.
Note 2: Redial the last phone number after connected
with two Phones, the headset will choose the Phone
which is connected first(not the one pairing first) to call.
The other phone does not respond for calling.
Note 3: For voice dialing after connected with two
Phones, the headset will choose the Phone which is
connected first(not the one pairing first) to call. The other
phone does not respond for calling.
Switching Between Two Calls
•Connected with one phone and operate with two calls
1).When answering the call A, there is a call B coming,
you could press the MFB shortly to answer the call B, the
call A is under the status of waiting. Re-press the MFB
shortly, you could switch the two calls each other.
2).When answering the call A, there is a call B coming,
you can press and hold MFB for 2 seconds to end the call
A, and answer the call B.
•After two-link functions switching between two calls
If phone A is answering the call, there have a call
coming from phone B; Press MFB shortly to answer the
call on phone B.
V4.1+EDR
HSP, HFP , A2DP,AVRCP
Class 2
Up to 10 Meters
2.402~2.480GHz
Built-in Rechargeable
3.7V/70mAH Li-polymer Battery
DC4.75-5.25V
About 2 hours
3.5 hours
4 hours
150 hours
L49 x W15 x H10
About 13.5g
Basic Operations
Charging Your Headset
Prior to use the headset for the first time or has not
been used for a long time, please fully charge the
headset.
Approximately 2 hours are required to fully charge
the headset.
The indicator light turns red while being charged, and
will turn blue automatically after being fully charged.
When the headset is running out of battery, the
indicator light will flash red (the headset will switch
off automatically when the battery is drained). Please
charge the headset as above steps in time to prolong
the battery's using life (Charging indication will be
delayed for a few minutes if the headset has not been
used for a long time or the battery is drained).
Note:
Please check if the charging device whether suitable for the headset or
not before charging
Please use the supplied battery and charging device, if use other
accessories ,it may go against the approval or warranty terms of the
product, and could be dangerous.
There have built-in and non-removable Lithium Battery, please do not
attempt to force open the battery as this could damage the headset.
If left unused, a fully charged headset will loose its power
automatically. It is recommended to charge the headset every three
months.
Do not leave the headset in a too hot or too cold condition (best
between -10℃and 50℃) which may affect the headset's operations.
Do not dispose of the headset into a fire and water.
Turning On The Headset
In OFF MODE, press and hold MFB for 5 seconds until
you hear “Power on”, and the indicator light flashes
blue for 3 times, then the headset will enter into ON
MODE.
Turning Off The Headset
In ON MODE, press and hold MFB for 4 seconds until
you hear “Power off”, and the indicator light flashes red
for 3 times, then the headset will enter into OFF MODE.
Pairing Your Headset With A Bluetooth
Mobile Phone
Ensure the headset is off, and the distance between
your headset and phone is within 1 meter.
Press and hold MFB for about 8 seconds until you
hear “Pairing”, the indicator light flashes blue and
red alternately, then the headset will enter into
PAIRING MODE.
Activate the Bluetooth function on the phone,
search Bluetooth devices (See the user guide of
your phone for instructions).
Select headset “SBS-030C” from the found devices
list of the phone.
Enter the passkey “0000”, confirm to pair the
headset with your phone. If successfully paired, you
with your phone. If successfully paired, you will hear
“Connected”, and the indicator light will flash blue
every 8 seconds. The headset enters into the
STANDBY MODE.(If the pairing cannot be completed
within 5 minutes after the PAIRING MODE has been
activated, the headset will enter into the STANDBY
MODE. Repeat above steps to do the pairing again).
Ensure the distance between your headset and phone
is within 10 meters, and without any obstacles. You
can use the headset freely.
If the headset has paired with your phone but
disconnected, it will pair automatically again when
turns on within operation range.
Answering/Ending A Call
Press MFB once.
Rejecting A Call
Press and hold MFB for one second.
Voice Dialing
In STANDBY MODE, press MFB twice and say the voice
tag as soon as you hear the short beep(ensure your
phone supports voice dialing function, and you have
recorded the voice tag into your phone. See the user
guide of your phone for instructions)
Last Number Redialing
Press and hold MFB for one second.
Adjusting Volume
Press V+ or V- to adjust the volume to meet your need.
Power Saving
The headset will turn off automatically if it can not be
paired or disconnected with any devices within 20
minutes.
Audio Remote-control Functions
Specifications
Bluetooth Specification
Bluetooth Profiles Supported
Transmission Power
Operation Range
Frequency Range
Battery
Charging Voltage
Charging Time
Music Playing Time*
Talk Time *
Standby Time *
Dimensions(mm)
Weight
SBS-030C
Bluetooth Stereo Headset
User Manual
*May vary due to user’s operation mode and device settings.
Structure Sketch
Bluetooth headset should be used with the compatible
devices which support Bluetooth wireless technology.
This allows you the freedom to make any calls and
enjoy the music streaming any time.
Please read this user manual carefully before using the
headset, and also read your device’s user manual
regarding the Bluetooth function, and pay attention to
those important safety and maintenance information.
Please keep the headset away from children.
(1)Microphone
(2)Audio Jack/Charging Socket
(3)Earhook
(4)Multifunction Button (MFB)
(5)Volume Key+(V+)
(6)Volume Key-(V-)
(7)Earpiece
Two-link Function
Note: The two Phones mentioned below will be called Phone A and B.
Play/Pause
Press MFB once for music playing or press again to
pause.
Backward
Press and hold V+ to backward the last song.
Forward
Press and hold V- to forward the next song.
Note: Ensure your paired devices support AVRCP Bluetooth Profile to
realize remote-control use.
Disconnecting
To disconnect the paired headset from your phone,
please turn off the headset or disconnect the headset
from the Bluetooth menu of your phone.
Care and Maintenance
Do not use abrasive cleaning solvents to clean the
headset.
Do not allow the headset to touch with any sharp
objects since this will cause scratching and damage.
Be sure to store the headset in a dry place, free from
extreme temperatures, humidity and dust in normal
use.
Additional Statements
The headset is unable to pair with the non-smart
phones.
The headset is compliant with the specified Bluetooth
version. It does not guarantee compatibility of all
functions on every Bluetooth enabled device. Please
check your device’s user manual for compatibility and
functionality.
Charge the headset under any status to a reset.
The headset will turn off automatically if it can not be
paired with any devices within 20 minutes.
The headset will beep when operates successfully but
this maybe too low to hear, and all belong to normal
phenomenon.
The above operations may vary due to different
devices.
Manufacturer reserves the rights to final explanation of
all the above statements.
Table of contents
