iBLUON BT-HS02-HQ User manual

BLUETOOTH STEREO HEADSET
iBLUON BT-HS02-HQ
USER GUIDE

TABLE OF CONTENTS
1. Introduction
2. Package Contents
3. Features
4. Charging
5. Pairing with Bluetooth Devices
6. Re-connecting with the paired device
7. Headset Controls
8. What the lights mean
9. Product Specification
10. Troubleshooting
11. Warning
12. Warranty
13. Need more help?
1. Introduction
Thank you for choosing the iBLUON BT-HS02-HQ Bluetooth Stereo Headset
with Bluetooth technology. iBLUON BT-HS02-HQ Bluetooth Stereo Headset
makes connectivity invisible and reliable, besides will provide you with wireless
control over many of today’s audio and mobile devices.

What is Bluetooth?
Bluetooth wireless technology is a short-range communications technology
intended to replace the cables connecting portable and/or fixed devices while
maintaining high levels of security. It is designed to communicate data/voice
within short-range distance of 10m to 100m. Bluetooth technology has achieved
global acceptance such that any Bluetooth enabled device, almost everywhere
in the world, can connect to other Bluetooth enabled devices in proximity.
A fundamental Bluetooth wireless technology strength is the ability to
simultaneously handle both data and voice transmissions. This enables users to
enjoy variety of innovative solutions such as a hands-free headset for voice
calls, printing and fax capabilities, and synchronizing PDA, laptop, and mobile
phone applications to name a few.
2. Package Contents
iBLUON BT-HS02-HQ Headset USB Charging cable User Manual

3. Feature
4. Charging
iBLUON BT-HS02-HQ Stereo Headset uses the rechargeable Lithium-Polymer
battery. Make sure your iBLUON BT-HS02-HQ is fully charged for two hours
before you start using.

How to charge;
1) Plug the USB cable into the USB port on your computer.
2) The LED indicator is red when charging the headset.
3) The LED indicator turns blue when the battery is fully charged.
4) Remove the battery charger from the headset.
5. Paring with Bluetooth Devices
Before you can use your headset with a Bluetooth enabled product, you must
pair it with that product.
How to pair;
iBluon
1
2
iBluon_□□□

6. Re-connecting with a paired device
Although you disconnect your headset from the paired device, you don’t need to
re-pair with the same device that was already paired before in order to
reconnect your headset to that device. You can only turn the power-switch on
and wait for a couple of seconds to reconnect your headset to that device.
7. Headset Control
Key Definition
Action Key Press Time
Sound
Effect
Power On Slide S/W On Don’t care Start-Up Sound
Pairing Mode - Enter Very Long Warning Sound
Pairing Mode - Exit Short Tick Sound
Wake Up the Headset Long Tick Sound
Reconnect Short or Long Tick Sound
Battery Check +/- & << >> Pressed No Sound
Play/Pause Short No Sound
Play stop Long Tick Sound
Backward Search << Short Tick Sound
Forward Search >> Short Tick Sound
Volume Up Short
Volume-up (Repeat)
+
Continuous
Tick Sound on
Volume Limit
Volume-down Short
Volume-down (Repeat)
_
Continuous
Tick Sound on
Volume Limit
Accept Call Short Tick Sound
Mic Mute On/Off << or >> Short Tick Sound
Voice Dial Short Tick Sound
Call Transfer Long Tick Sound
Reject Call Long Tick Sound
Hang Up Call Short Tick Sound
Last Call Long Tick Sound
Cancel Call Short Tick Sound
* Short key : 0.5~2 seconds, Long key : 2~5 seconds,
Very long key : Over 5 seconds

8. What the lights mean
LED-Blue LED-Red
Action
Status
ON
Time
(sec)
OFF
Time
(sec)
Status
ON
Time
(sec)
OFF
Time
(sec)
Note
Pairing Blink
Mode 1
0.2 0.2 Blink
Mode 1
0.2 0.2
A2DP
Streaming
Blink
Mode 1
0.05 2.0 Off
0.05Waiting
Connection
Blink
Mode 2
0.05
1.0
Off
0.05Ring Blink
Mode 3
0.05
1.0
Off
Active Call Blink
Mode 1
0.05 2.0 Off
Charging Off On
Full charged On Off
Very
Low
Off Blink
Mode 1
0.2 0.2
Low Off On
Normal On Off
Battery
Check
Mode
Full On Off
* Blink Mode 1 : On - Off - On - Off …
Blink Mode 2 : On1 - Off1 - On1 - Off2 …
Blink Mode 3 : On1 - Off1 - 17 times - Off2 - On1 …

9. Products Specification
Bluetooth Version Version 2.0, Class II
Bluetooth Support Profile A2DP, AVRCP, HSP, HFP
RF Frequency 2,4GHz / 79 Channel / AFH
Coverage Range* Bluetooth standard 33 feet (10 meters)
Music Playback Time* Up to 8 hours
(The maximum playback time depends on the usage
frequency and environmental factors. A long distance
wireless connection and high volume level will increase the
power consumption and may decrease the playback time.)
Talk Time* Up to 10 hours
Standby Time* Approximately 300 hours
Charging Time Approximately 2.5 hours
Charging Methods Mini USB cable, DC Adapter(5V, 300mA)
Battery 290mAh, Lithium-Poymer
Headset Speaker
Diameter: < 15mm
Frequency Response: 20Hz ~ 20KHz
SPL (Sound Pressure Level): 93dB @ 1KHz
Impedance: 16Ω@ 1V, 1KHz
Power Rating: 5mW (Maximum)
Mic. Typical : ECM unit (40dB)
S/N Ratio Up to 90dB
Size and Weight 45.5(W) x 23.5(L) x 11.8(H) , About 40g
Supports Bluetooth Hands-Free and Headset Profiles (HFP/HSP), Advanced
Audio Distribution Profile (A2DP), and Audio/Video Remote Control Profile
(AVRCP)
*Performance may vary by device.
10. Troubleshooting
1) If you hear crackling noises, - Bluetooth is a radio technology, which
means it is sensitive to objects between the headset and the connected
device. It is designed for the headset and the connected device to be used

within 100 meters (33 feet) of each other, with no major object in the way.
2) If you have no light on the indicator LED, - Please make sure if the headset
is switched on or you also check the battery if it is too low for power on.
3) If you have pairing problems, - You may have deleted the pairing
connection in you Bluetooth mobile phone, MP3, and other Audio devices.
Please follow the pairing instruction in section 5.
4) If you can not hear anything, - Please increase the volume in the headset,
and ensure that the headset is paired to a device that is playing.
5) If you are facing the other problems, - Please contact with the seller.
11. Warning
Use of a headset that covers both ears will impair your ability to hear other
sounds. Use of such a headset while operating a motor vehicle or riding a
bicycle may create a serious hazard to you and/or others, and is prohibited by
law in some regions.
12. Warranty
zThis warranty lasts for one year from the date of purchase of the
products.
zThis warranty extends to you only if you are the end users with the
original purchase receipt.
zWe will, at our option, repair or replace the products that do not conform
to the warranty.
zThe manufacturer or the seller shall not be liable for any incidental
consequence or damages by the end users.
zThis warranty gives you specific legal right. You may also have other
rights which vary from state to state.

FCC compliance Information
This device complies with part 15 of FCC Rules.
Operation is subject to the following two conditions;
1. This device may not cause harmful interference, and
2. This device must accept any interference received.
Including interence that may cause undesired operation.
FCC WARNING
This equipment may qenerate or use radio frequency energy. Changes
or modifications to this equipment may cause harmful interference
unless the modifications are expressly in the instruction
manual. The user could lose the authority to operate this equipment
if an unauthorized change or modification is made.
13. Need more help?
