SEH IH-304 User manual

USB Hub
IH-304
User Manual
MHAB-UM-IH304
Version: 1.2 | 2018-11

Overview
This 'User Manual' provides a description of the hardware
installation and initial setup of the IH-304.
Table of contents 1.
Do you need assistance? Contact us!
Überblick
Dieses 'User Manual' (Benutzerhandbuch) beschreibt die
Hardware-Installation und die Inbetriebnahme des IH-304.
Inhaltsverzeichnis 19.
Benötigen Sie Hilfe? Kontaktieren Sie uns!
Monday to Thursday
Friday 8:00 a.m. to 4:45 p.m. and 8:00 a.m. to 3:15 p.m. (CET)
[phone]
[email protected]
www.seh-technology.com
Montag–Donnerstag
Freitag 8:00–16:45 Uhr 8:00–15:15Uhr
[phone]
[email protected]
www.seh.de

User Manual [en] 1
Contents
Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Associated Products ........................................................................2
Scope of Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Device Overview ...............................................................................5
Dimensions & Weight......................................................................6
Connectors..........................................................................................6
Type Plate ............................................................................................8
LED Display .........................................................................................9
Safety Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Initial Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Regulatory Compliance Information . . . . . . . . . . . . . . . . . . 15
EC Declaration of Conformity.................................................... 15
Federal Communication Commission (FCC) Notice.......... 17

2 [en] User Manual
Purpose
The industrial solution IH-304 is a USB hub. The device has
four USB 3.0 ports. They can be used to charge USB devices.
The IH-304 is connected to a client via the USB interface.
Alternatively, the IH-304 can be connected to an industrial
USB Deviceserver 'INU-100' by SEH Computertechnik GmbH.
This way, the USB devices which are connected to the IH-304
can be accessed via a TCP/IP network or the Internet. More
details can be found in the chapter ’Associated Products’
2.
The IH-304 has been developed for industrial environments. It
is mounted on a top-hat rail, e.g. in a control cabinet. The
integrated overvoltage protection guards the connected USB
devices against too high voltages (e.g. from faulty power
supplies or lightning strikes).
Associated Products
Industrial solution 'INU-100 USB Deviceserver'
The INU-100 allows you to access non-network-ready USB
devices such as the IH-304 in the network (virtual USB cable
extension). To do this, the IH-304 is connected to a USB port
of the INU-100. The access is controlled via the software tool
‘SEH UTN Manager‘.
The INU-100 must be purchased separately. Detailed
information:
http://www.seh-technology.com/products/
industrial-solutions/inu-100.html

User Manual [en] 3
Industrial Solution 'SU-302 Serial to USB Converter
The industrial solution SU-302 is a serial to USB converter. It
can be connected to the INU server via USB and allows for the
use of two serial devices via its interfaces RS-232 (for plug
type D-Sub, DE-9) and RS-485 (also known as EIA-485;
compatible with RS-422/EIA-422).
By combining the INU server and SU-302 you make your serial
devices available via network (TCP/IP, Internet)!
http://www.seh-technology.com/products/
industrial-solutions/su-302.html
Industrial Solutions 'Top-Hat Rail Power Supplies'
All Industrial Solutions are mounted on a top-hat rail in a
control cabinet. The USB Deviceserver INU-100 and the USB
Hub IH-304 are to be connected to a power supply. You either
use your existing power supply or—if there is none or no
vacancy—you can buy a new one.
Spare yourself the search and use the top-hat rail power
supplies DRP-20 and DRP-75 which are specifically selected to
perfectly match the industrial solutions!
http://www.seh-technology.com/products/
industrial-solutions/accessories.html

4 [en] User Manual
Scope of Supply
Please check the package content before getting started:
USB hub 'IH-304'
User
Manual The User Manual gives information on the installation
and initial setup of the IH-304.
(This document)
USB cable USB 3.0, connector A on type B
connector

User Manual [en] 5
Technical Data
Device Overview
Properties Values
Operating
environment – ambient temperature: 5–40 °C
– relative humidity: 20–80%
Safeguard Overvoltage protection
USB ports 1–4
(type A;
device connection)
USB port
(type B)
power LED
power connectors
snap lock
LEDs for
USB ports 1–4
host connection LED

6 [en] User Manual
Dimensions & Weight
Connectors
USB
Properties Values
Device connection – 4 × USB 3.0 SuperSpeed
– USB port type A
– can be used for charging:
1.5 A per port
Host connection – 1 × USB 2.0 Hi-Speed
– USB port type B
140 g
111 mm
114 mm
111 mm
22.5 mm
105.5 mm

User Manual [en] 7
Power supply
The IH-304 can be fed by 2 power supplies. While one power
supply is actively supplying, the other serves as backup.
(You also find this circuit diagram printed on the side of the
IH-304 housing.)
WARNING
The device and the power supply or power
supplies must be installed in the same control
cabinet. The low-voltage cable between the
power supply and the device must not be longer
than 3 m.
Power supply 1:
2:
connection:
connectors 1 + 2
connectors 3 + 4
via screw terminals
Supply voltage: – 12 V – 48 V direct current
– power consumption max. 45 W
– redundant
power supply 1
power supply 2

8 [en] User Manual
Type Plate
The type plate gives important product information, such as
hardware and certification information as well as the serial
number. The serial number contains the production date:
nnn YYYY MM nnnnn.
You need this information for support requests.
Current inputat 12 V:
at 48 V:
– approx. 50 mA without load
– approx. 3.5 A with full load on the
USB ports
– approx. 20 mA without load
– approx. 0.9 A with full load on the
USB ports

User Manual [en] 9
LED Display
The LEDs of the IH-304 provide information about its status.
LED Action Color Description
USB ports
1–4 permanently on
permanently
on
green
red
The USB port is
functional.
The USB port was
deactivated for safety
reasons or an error
occurred.
Please contact the
support 3.
Host
connection permanently off
permanently
on
–
green
There is no
connection to the
host.
There is a connection
to the host.
If the power LED is on
at the same time, the
IH-304 is operational.
Power permanently
off
permanently
on
–
yellow
The IH-304 is not
functional (it is not
supplied with power
and/or there is no
connection to the
host).
If the host connection
LED is on at the same
time, the IH-304 is
supplied with power
by at least one of the
two power supplies.

10 [en] User Manual
Safety Regulations
The IH-304 is a USB hub for use in industrial environments.
The IH-304 expands the number of USB ports.
• Read the documentation and make sure that your system
meets the requirements listed therein.
• Avoid contact with humidity or liquids.
• The device must only be connected and operated if it is in
perfect condition.
• Do not open the housing. Unauthorized modifications to
the device can affect the product certification and are for-
bidden.
• The device must not be directly connected to outdoor
lines.
• Warning! This is a Class A product. In a domestic environ-
ment this product may cause radio interference in which
case the user may be required to take adequate measures.
• Only use a certified USB cable (< 3 m) listed at
www.usb.org.
• Electrostatic discharges (ESD) may impair device perfor-
mance.
• An interruption of the supply voltage may impair device
performance or cause malfunctions.
• Choose and use a power supply for the IH-304, which
meets the power supply requirements stated in this docu-
ment.
• The device and the power supply or power supplies must
be installed in the same control cabinet.
• The low-voltage cable between the power supply and the

User Manual [en] 11
device must not be longer than 3 m.
• Choose cables with a suitable wire-cross section for the
connection to power supplies.

12 [en] User Manual
Hardware Installation
Install the IH-304 on a top-hat rail (DIN rail according to DIN
EN 60715, 35 mm wide), e.g. in a control cabinet.
You can directly connect up to four USB devices to the USB
ports 1–4 (type A). The IH-304 is connected to a host (client or
industrial USB Deviceserver INU-100) via the USB port host
connection (type B).
To supply the IH-304 with power, you have to connect it to
one or two power supplies of your control cabinet.
Required tools:
• Phillips screwdriver
1. Install the IH-304 on a top-hat rail:

User Manual [en] 13
2. Connect the USB devices to the USB ports 1–4 of the IH-
304:
3. Use the USB cable included in delivery to connect the IH-
304 via the USB port host connection (type B) to a client or
industrial USB Deviceserver INU-100.
4. Connect the power supply/supplies (7) of your control
cabinet to the IH-304:

14 [en] User Manual
Initial Setup
The IH-304 is automatically recognized as hub by your client.
Further installation steps are not required.
If you connect the IH-304 to an industrial USB Deviceserver
INU-100, you have to establish a connection via the
corresponding software tool 'SEH UTN Manager'. For more
information read the INU-100 documentation, available at
http://www.seh-technology.com/products/
industrial-solutions/inu-100.html

User Manual [en] 15
Regulatory Compliance Information
EC Declaration of Conformity
Manufacturer's name and address:
SEH Computertechnik GmbH
Suedring 11, 33647 Bielefeld, Germany
Phone: [phone]
Herewith SEH Computertechnik GmbH declares that
Product: Industrial Solution
Type designation: IH-304
Serial no.: 291 yyyy mm nnnnn (yyyy = year, mm =
month, nnnnn = seq. no.)
is in conformity with the provision of the
DIRECTIVE 2014/30/EU OF THE EUROPEAN PARLIAMENT
AND OF THE COUNCIL of 26 February 2014
on the harmonisation of the laws of the Member States
relating to electromagnetic compatibility (recast)
DIRECTIVE 2011/65/EU OF THE EUROPEAN PARLIAMENT
AND OF THE COUNCIL of 8 June 2011
on the restriction of the use of certain hazardous substances
in electrical and electronic equipment (recast)
Standards applied:
EN 55032:2012 Class A
EN 61000-6-2:2005
EN 50581:2012
To meet the above specifications, the user has to comply with
all instructions defined in the enclosed manual User Manual.
Bielefeld, Germany (Friday, November 10, 2017)
Dipl.-Ing. Rainer Ellerbrake, General Manager

16 [en] User Manual
Important:
The latest version of the EC declaration of
conformity can be downloaded from the website
of SEH Computertechnik GmbH:
http://www.seh-technology.com/services/
ce-notifications.html
