Seiko R-Wave User manual






HR012-1

HOW DOES IT WORK?
This clock receives a time signal transmitted by the National Institute of Standard
and Technology (NIST). Located in Fort Collins, Colorado, the transmitter is linked
to a cesium atomic clock, the most accurate time keeping device in the world,
with a time deviation less than one second in one million years.
Your SEIKO clock is specially programmed to interpret the signal and set itself to
the correct local time.

COVERAGE
Continental United States, parts of Southern Canada and Northern Mexico.
Geographic features, weather disturbances and structural characteristics may
affect reception. Signal reception is strongest during night time.

LOCATION OF CLOCK
Place your clock near a window and in an area in your home or office where you
receive good radio reception.
Avoid placing the clock near electrical devices such as personal computers,
radios, TV's, satellite dishes, air conditioners, etc. Also, avoid light dimmer
switches and appliances with electric motors such as dishwashers, refrigerators
and washing machines. These devices may interfere with the reception of the
signal.

OTHER SPECIFICATIONS
* Solar powered / No external battery needed
* Calendar with day-of-the-week from 1 January 2000 to 31 December 2069
* Thermometer (Fahrenheit Only)

Important
* Do not expose the clock to extreme temperatures, direct sunlight, water or
severe shock.
* Avoid contact with any corrosive materials such as perfume, alcohol or
cleaning agents.
* Do not subject the clock to excessive force, shock, dust, temperature or
humidity. Any of these conditions may shorten the life of the clock.
* Do not tamper with any of the internal components of this clock. This will
invalidate the warranty and may cause damage.
HOW DOES IT WORK?
This clock receives a time signal transmitted by the National Institute of Standard and Technology (NIST). Located in Fort Collins,
Colorado, the transmitter is linked to a cesium atomic clock, the most accurate time keeping device in the world, with a time deviation
less than one second in one million years.
Your SEIKO clock is specially programmed to interpret the signal and set itself to the correct local time.

COVERAGE
Continental United States, parts of Southern Canada and Northern Mexico. Geographic features, weather disturbances and structural
characteristics may affect reception. Signal reception is strongest during night time.

LOCATION OF CLOCK
Place your clock near a window and in an area in your home or office where you receive good radio reception.
Avoid placing the clock near electrical devices such as personal computers, radios, TV's, satellite dishes, air conditioners, etc. Also,
avoid light dimmer switches and appliances with electric motors such as dishwashers, refrigerators and washing machines. These
devices may interfere with the reception of the signal.

OTHER SPECIFICATIONS
• Solar powered / No external battery needed
• Calendar with day-of-the-week from 1 January 2000 to 31 December 2069
• Thermometer (Fahrenheit Only)

Important
• Do not expose the clock to extreme temperatures, direct sunlight, water or severe shock.
• Avoid contact with any corrosive materials such as perfume, alcohol or cleaning agents.
• Do not subject the clock to excessive force, shock, dust, temperature or humidity. Any of these conditions may shorten the life of the 
 clock.
• Do not tamper with any of the internal components of this clock. This will invalidate the warranty and may cause damage.
HR012-1

HOW TO START YOUR CLOCK
• Slide the "POWER ON / OFF" switch to "ON" on the bottom of the clock. If there is sufficient light source, the display will show a full
 segment and the time and calendar are displayed as AM 12:00 (Mountain Time) 1-1 SAT. The temperature will show "---.-˚F" after 
 the full segment is displayed and the temperature reading will be shown in a few seconds.
• If the clock doesn't show the time, calendar, or temperature as above, simply slide the "POWER ON / OFF" switch to "OFF" and
 then set it back to "ON" position.
 NOTE: Remove the clear film label over the display before the clock is used.

AUTOMATIC TIME SETTING
First reception after power-up
• The clock initializes at AM 12:00 (Mountain Time) 1-1 SAT
• The clock will search for the signal automatically after powered on. The " " tower and wave icon at the lower-right portion of the 
 display will start flashing to indicate the receiving status.
• If the signal is received, synchronization will take 3-15 minutes and the clock will show the received time.
• Successful reception is indicated by the " ", 3 solid waves of the tower and wave icon.

Selecting the appropriate time zone
• The " " map for the four time zones in US will be shown at the right portion of the display.
• To set the appropriate time zone, press and hold the "WAVE/SET" button until the year value flashes.
• Press the "WAVE/SET" button twice, the " " map will flash. Press "UP" or "DOWN" button to set the appropriate time zone.
• To end the time zone setting, press and hold the "WAVE/SET" button until the " " map stops flashing.

Automatic time update
• The clock will automatically start reception when it is showing the time between 2:00 ~ 6:00 am.

Manual time update
• Reception can be started any time by pressing the "WAVE/SET" button on the bottom of clock.

STANDARD TIME / DAYLIGHT SAVINGS TIME
The clock will change to standard time/daylight savings time automatically when the time signal is received. When time is changed to
daylight savings time, the "D.S.T" icon will be shown and time is adjusted automatically.

POOR RECEPTION
• If for some reason your clock does not set itself automatically within 24 hours, it is probably due to poor reception. This is normally 
 a temporary condition. Try another location in the room or move to another room. If possible, locate the clock near a window. If you 
 would like to set the clock manually while waiting for the automatic time setting, follow the manual time setting steps.

MANUAL SETTING INSTRUCTION
• Press and hold the "WAVE/SET" button until the year digits flash. Press "UP" or "DOWN" button to increase or decrease the year 
 value. Press and hold "UP" or "DOWN" button to respectively increase or decrease quickly.
• Press the "SET / WAVE" button once, the month and date digits will flash. Press "UP" or "DOWN" button to set date. The month
 value will be changed automatically when start or end of the month is run through. The day will synchronize with the date  
 automatically.
• Press the "WAVE/SET" button twice, the hour and minute digits will flash. Press "UP" or "DOWN" button to set minute value. The 
 hour value will be changed automatically when "00" minute is run through.
• After setting, press the "SET / WAVE" button once to end the setting.

NON-RADIO OPERATION
• If you live in an area where the signal is not received (Alaska, Hawaii, etc) you can still use your clock by following the manual 
 setting instructions. It will function as a standard quartz clock.

POWER SAVING MODE
• The clock is equipped with "Power-Saving Mode" to minimize power consumption. When the clock is placed in the dark, the digital 
 display will be blanked automatically and only "POWER SAVE" will be shown on display. The clock itself is still running to keep 
 the time accurate. When the light becomes normal, the digital display will be shown again.

SPECIFICATION
• Solar Powered : No need of external battery
