Seiko C-20 User manual

8B92 BSJ8B92-2202 C-20
8B92
INSTRUCTIONSRadio Sync Solar World Time Chronograph
https://www.seikowatches.com/
日本語 ..................................................
English ................................................
1
JA
1
EN
䬁Ổᶮ㔈 /䷂橕ᶮ㔈
そのほかの言語の取扱説明書は、パソコンや
スマートフォンから当社ホームページ内の
「カスタマーサービス」>「取扱説明書ダウンロード」
にアクセスいただき、ご覧ください。
Please refer to the Instruction Manuals
of other languages by accessing
"Customer Service"→ "Instruction"
on our Website from PC or Smartphone.

Thank you very much for choosing a SEIKO watch.
For proper and safe use of your SEIKO watch,
please read carefully the instructions in this
booklet before using it.
Keep this manual handy for easy reference.
* Length adjustment service for metallic bands is available at the retailer from
whom the watch was purchased. If you cannot have your watch repaired by
the retailer from whom the watch was purchased because you received the
watch as a gift, or you moved to a distant place, please contact SEIKO
CUSTOMER SERVICE CENTER. The service may also be available on a
chargeable basis at other retailers, however, some retailers may not undertake
the service.
* If your watch has a protective film for preventing scratches, make sure to peel
it off before using the watch. If the watch is used with the film on it, dirt, sweat,
dust, or moisture may be attached to the film and may cause rust.
EN 1
CONTENTS
1 HOW TO USE
Handling cautions ............................................ 5
Before use ....................................................... 9
Make sure to keep the watch sufficiently
charged ....................................................... 9
To receive radio signals ............................... 9
Characteristics .............................................. 10
Names of the parts and their functions .......... 12
How to use the button .................................... 14
Crown ............................................................ 15
2 BEFORE USE
Before Use .................................................... 16
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)
Setting the time and date by receiving a radio
signal ............................................................. 18
Mechanism of radio signal reception ......... 18
Automatic reception and manual reception
...... 19
Reception environment ................................. 20
Radio signal reception range indication ..... 20
Radio signal reception range: Japan (JJY)
....... 21
Radio signal reception range: China (BPC)
...... 22
Radio signal reception range: U.S.A. (WWVB)
..... 23
Radio signal reception range: Germany
(DCF77) ..................................................... 24
To improve radio signal reception .............. 25
Environments in which it is difficult to
receive a radio signal ................................. 26
How to check the reception status ................. 28
How to display the reception results .......... 28
EN 2
4 WORLD TIME FUNCTION
How to use the world time function ................ 30
World time function .................................... 30
How to select the time zone (How to display
the local time around the world) ..................... 32
Time zone display and time difference table
..... 34
What is a time zone? ................................. 36
Q&A for the world time function ................. 37
5 HOW TO USE THE STOPWATCH
Stopwatch Function ....................................... 38
The names of the parts and functions of the
stopwatch .................................................. 39
Before using the stopwatch ....................... 40
How to use the stopwatch ............................. 42
How to use the tachymeter ............................ 46
6 SOLAR CHARGING FUNCTION
Charging the battery ...................................... 48
How to charge the battery .......................... 48
Guide to charging times ............................. 49
About energy ................................................. 50
Energy depletion forewarning function (Two-
second interval movement and Five-second
interval movement) .................................... 50
Power save function .................................. 51
7
TO PRESERVE THE QUALITY OF YOUR WATCH
Power Source ................................................ 52
Daily care ...................................................... 54
Performance and type ................................... 55
Lumibrite ....................................................... 56
Water resistant performance ......................... 57
Magnetic resistant performance .................... 58
EN 3

Band .............................................................. 60
How to use tri-fold type clasp for leather band
(Special clasps) ............................................. 63
How to use an adjustable three-fold clasp
(Pointed tip diving type) ................................. 69
How to use an easy adjust type clasp ............ 73
After sales service ......................................... 76
8 TROUBLESHOOTING
How to conduct manual reception (Receive
a radio signal manually)
............................... 78
When a radio signal cannot be received ........ 81
How to manually set the time ..................... 82
How to manually set the date ..................... 84
Preliminary position ....................................... 86
Automatic hand position adjustment function
(Adjustment of preliminary positions of hour,
minute and seconds hands)
......................... 86
Setting the Preliminary Position of the
Date/Stopwatch Hands
............................ 86
How to set the preliminary position ................ 87
Set the preliminary position for the date,
and the hour and minute hands. ................ 87
Setting the Preliminary Position of the
Stopwatch Second and Minute Hands ....... 91
Troubleshooting ............................................ 95
In case of an abnormal movement .............. 102
Reset the system ..................................... 102
Set the stopwatch hands to “0” ................ 104
Set the date to “1” (1st) ............................ 107
How to set the time zone .......................... 109
Set the time and date ............................... 112
9 SPECIFICATIONS
Specifications .............................................. 113
EN 4
Handling cautions
bWARNING
Please note that there is a risk of serious consequences such as severe injury if the following
safety regulations are not strictly observed.
Immediately stop wearing the watch in following cases:
○ If the watch body or band becomes edged by corrosion etc.
○ If the pins protrude from the band.
* Immediately consult the retailer from whom the watch was purchased or SEIKO CUSTOMER SERVICE
CENTER.
Keep the watch and accessories out of the reach of babies and children.
Care should be taken to prevent a baby or a child accidentally swallowing the accessories.
If a baby or child swallows the battery or accessories, immediately consult a doctor, as it will be
harmful to the health of the baby or child.
Do not remove the secondary battery from the watch.
* About the secondary battery → Power Source → P.52
Replacement of the secondary battery requires professional knowledge and skill. Please ask the retailer
from whom the watch was purchased for replacement of the secondary battery.
Installation of an ordinary silver oxide battery can generate heat that can cause bursting and ignition.
EN 5
1
HOW TO USE
bCAUTION
Please note that there is a risk of minor injury or material damage if the following safety
regulations are not strictly observed.
Avoid the following places for wearing or keeping the watch:
○Places where volatile agents (cosmetics such as polish remover, bug repellent, thinners etc.) are
vaporizing
○ Places where the temperature drops below
5°C or rises above 35°C for a long time
○ Places affected by strong magnetism or static
electricity
○ Places affected by strong vibrations
○ Places of high humidity
○ Dusty places
If you observe any allergic symptoms or skin irritation
Stop wearing the watch immediately and consult a specialist such as a dermatologist or an allergist.
Other cautions
○ For adjusting the length of the metallic band, specialized knowledge and expertise are necessary.
Therefore, in such a case, contact the retailer from whom the watch was purchased. If you attempt
to adjust the metallic band, injury may occur to your hand or fingers, or parts of the band may be
lost.
○ Do not disassemble or tamper with the watch.
○ Keep the watch out of the reach of babies and children. Extra care should be taken to avoid risks
of any injury or allergic rash or itching that may be caused when you touch the watch.
○ When disposing of used batteries, follow the instructions of your local authorities.
○ If your watch is of the fob or pendant type, the strap or chain attached to the watch may damage
your clothes, or injure the hand, neck, or other parts of your body.
EN 6
1
HOW TO USE
bWARNING
Do not use the watch in scuba diving or saturation diving.
The various tightened inspections under simulated harsh environment, which are
usually required for watches designed for scuba diving or saturation diving, have
not been conducted on the water resistant watch with the BAR (barometric
pressure) display. For diving, use watches specifically designed for diving.
bCAUTION
Do not pour running water directly from faucet.
The water pressure of tap water from a faucet is high enough to degrade the water
resistant performance of a water resistant watch for everyday life.
EN 7
1
HOW TO USE

bCAUTION
Do not turn or pull out the crown when the watch is wet.
Water may get inside of the watch.
* If the inner surface of the glass is clouded with condensation or water droplets appear
inside of the watch for a long time, the water resistant performance of the watch is
deteriorated. Immediately consult the retailer from whom the watch was purchased or
SEIKO CUSTOMER SERVICE CENTER.
Do not leave moisture, sweat and dirt on the watch for a long time.
Be aware of a risk that a water resistant watch may lessen its water resistant
performance because of deterioration of the adhesive on the glass or gasket, or
the development of rust on stainless steel.
Do not wear the watch while taking a bath or a sauna.
Steam, soap or some components of a hot spring may accelerate the
deterioration of water resistant performance of the watch.
EN 8
1
HOW TO USE
Before use
■ Make sure to keep the watch sufficiently charged
The watch operates while charging electricity by converting light received on the dial to electrical energy.
It cannot properly operate unless the remaining energy is sufficient.
Place or store in a location receiving light, etc., to sufficiently charge electricity.
■ The amount of energy stored in the watch can be checked by the
movement of the small seconds hand.
“Checking the Charging Status” → P.16
■ Charging the solar battery
“How to charge the battery” → P.48
“Guide to charging times” → P.49
■ To receive radio signals
The watch automatically receives radio signals to adjust the time every day.
Automatic radio signal reception is carried out before 2:00 AM, 3:00 AM and 4:00 AM.
During this period of time, place the watch in a location that easily receives radio signals without wearing
it and do not move it.
“To improve radio signal reception” → P.25
EN 9
1
HOW TO USE
Characteristics
This solar-drive and radio-controlled watch is equipped with a world time function.
• The time in each region of the world can be displayed by selecting the time zone.
• This watch displays the precise time by receiving radio signals conveying time information.
• It can receive official standard frequencies from Japan (from either of two transmitting stations), the
People’s Republic of China, the United States of America and Germany.
■ World Time Function................
→ P.30
The time in each region of the world can be displayed by selecting
the time zone.
■ Radio Signal Receiving
Function....................................
→ P.18
This watch adjusts the time and the date precisely by automatically
receiving radio signals daily.
In addition, radio signals can be forcibly received with manual operation.
This watch can receive official standard radio signals from Japan (from 2
transmitting stations), China, U.S.A. and Germany (the transmitting station
for receiving radio signals can be selected using world time function).
■ Reception Level Indication
Function....................................
→ P.80
The movement of the small seconds hand indicates the radio signal
reception level during radio signal reception attempts.
(Only manual reception)
■ Display Function of Radio
Signal Reception Results........
→ P.28
The movement of the small seconds hand indicates radio signal
reception results (Yes/No).
EN 10
1
HOW TO USE
■ Stopwatch function..................
→ P.38
The stopwatch can carry out measurements up to 60 minutes in
increments of 1/5 of a second.
When the measurement reaches 6 hours, the stopwatch
automatically stops counting.
■ Solar Charging Function..........
→ P.48
A solar cell underneath the dial converts any form of light into
“electrical energy” to charge it. Once fully charged, the watch
continues to run for approximately six months.
■
Energy Depletion
Forewarning Function...........
→ P.50
The movement of the small seconds hand indicates that the battery
should be charged.
■ Power Save Function...............
→ P.51
This watch is equipped with a function which can suppress energy
consumption when it is left without receiving an adequate light
source for a certain length of time.
■ Automatic Hand Position
Alignment Function..................
→ P.86
When the hand positions display an incorrect time as a result of
external influences such as magnetism, the watch automatically
corrects the hand misalignment.
EN 11
1
HOW TO USE

Names of the parts and their functions
1
Stopwatch
second hand
2
Hour hand
3
Button B
4
Small seconds
hand
5
Button A
6
Tachymeter
7
Stopwatch minute
hand
8
Minute hand
9
Button C
0
24-hour hand
a
Crown
•
Normal position:
How to select the
time zone → P.32,
Checking the
reception result
→ P.28, Manual
reception → P.78,
Stopwatch function
→ P.28
•
First click position :
Manual date setting
→ P.84
•
Second click
position:
Manual time setting
→ P.82,
Reset the system
→ P.102
b
Button D
c
Date
* The operation method of the button varies with the functions being used. Follow the instructions of each section
of this manual.
* The position and design of the display may vary depending on the model.
* Some models may not have a tachymeter.
1
0
8
a
b
c
9
2
4
6
7
5
3
EN 12
1
HOW TO USE
●
Reception level display
[Manual reception]
H
:
High reception level (50-second
position)
L
:
Low reception level (40-second
position)
N
:
Unable to receive radio signals
(20-second position)
* Reception level display → P.80
●
Reception result
display
[Check of reception result]
Y
:
Reception successful
(10-second position)
N
:
Reception failed (20-second
position)
* How to display the reception results
→ P.28
●Standard radio signal display
Display (Country with radio
signal transmitting station) Display position
J / JJY (Japan)
23-second position
B / BPC (China) 21-second position
W / WWVB (U.S.A.) 43-second position
D / DCF77 (Germany) 3-second position
* World time function → P.30
●Time zone display
[Time zone selection]
City names:25 regions around the world
* How to select the time zone (How to display the local
time around the world) → P.32
* Time zone display and time difference table → P.34
* Indication on the bezel or positions of each item on the
dial may vary depending on the model (design).
EN 13
1
HOW TO USE
How to use the button
Some models may have a button which is recessed in the watch case to prevent accidental input.
Shape of the button differs depending on the design of the watch.
Normal Button Upper half of the
Button B is covered.
Button B has an outer
ring.
Button B is covered
except the hollow in the
middle of the button.
Button B is embedded
in the watchcase.
Button ring
Press the button with
your finger
Use an object with a
long tapered tip.
* You can also press the
lower half of the button
with your finger.
1. Turn the outer ring
counterclockwise
(to a downward
direction) to loosen
it.
2. Press the button
with your finger.
* After finishing the
operation, make sure
to relock the outer ring
by turning it clockwise.
Press the button using an object with a long
tapered tip.
EN 14
1
HOW TO USE
Crown
There are two types of crowns, a normal crown and a screw down crown.
Please check the type of the crown of your watch.
While
pressing the
crown in, turn it
in the direction
indicated by
the arrow.
The
crown
turns.
The crown
does not
turn.
Normal crown
Pull out the crown and operate it.
Screw down crown
Unlock the crown before
operating it.
After operating the crown,
lock it.
Unscrew
Rotate while
pressing
the crown in.
* By locking the crown by screw, a screw down crown can prevent malfunction and increase water resistance.
* Be careful not to screw the crown in by force as it may damage the slots of the crown.
EN 15
1
HOW TO USE

Before Use
1Checking the Charging Status
When the movement of the seconds hand shows an energy depletion state, the battery requires
charging.
The seconds hand moves
at one-second intervals.
The seconds hand moves
at two-second intervals.
The seconds hand moves
at five-second intervals.
The seconds
hand is stopped.
The watch is
sufficiently charged.
The charged energy is depleted.
→ P.50
The power save function is activated. → P.
51
Check the movements of the seconds hand
after releasing the Power Save mode.
The energy stored in the watch runs low.
Charge the
battery
sufficiently.
How to charge
the battery
→ P.48
* If the seconds hand does not move at one-second intervals even after fully charging the battery, refer to
“Charging the solar battery” in Troubleshooting on P.98
EN 16
2
BEFORE USE
2Checking the time and date
* The hands of this watch cannot be moved by turning the crown.
* When adjusting the time or date, refer to the following regarding the procedures.
When the time and
date are correct
Use the watch without
adjustment.
When the time
and date are
incorrect
Time zone
confirmation
→ P.32
When the radio
signal can be
received
Setting the time and date
by receiving a radio
signal → P.78
Radio signal reception range indication → P.
20
Environments in which it is difficult to receive a radio signal → P.
26
When a radio
signal cannot
be received
Manually set the time
→ P.82
Manually set the date
→ P.84
* When the watch does not display the correct time and date even after successfully receiving a radio signal, refer
to Troubleshooting.→ Misalignment of the time and hand positions P.98, and Misalignment of the date P.100
EN 17
2
BEFORE USE
Setting the time and date by receiving a radio signal
■ Mechanism of radio signal reception
The radio-controlled watch displays the precise Time and Date by automatically receiving and
synchronizing itself with the radio signal of an official standard frequency.
Transmitting
Station
Cesium
Atomic
Clock
Official standard
frequency
Radio-controlled watch
Receive radio signals through
the antenna inside the watch
Analyze time information
Display the current Time and
Date
Time signal transmitted by a standard frequency is based on a super accurate “Cesium Atomic Clock” that
may have a 1 second loss or gain per one hundred thousand years.
EN 18
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)
■ Automatic reception and manual reception
●Automatic reception
This watch sets the time and date by automatically receiving a radio signal at a fixed time.
It automatically receives a radio signal before 2:00 AM, 3:00 AM and 4:00 AM.
* When the reception is successful, the watch finishes the automatic reception.
* If the stopwatch hands are not reset to the 0-position, the watch will not receive a radio signal to set the time.
Make sure that the stopwatch hands are reset to the 0-position. “How to Reset the Stopwatch” → P.40
• Place the watch in a place where it can easily receive a radio signal (by the window, etc.).
• Do not move the watch during the radio signal reception.
“To improve radio signal reception” → P.25
●Manual reception
This watch can receive a radio signal arbitrarily at any time other than the automatic reception mode.
“How to conduct manual reception” → P.78
* Radio signal reception results depend on the receiving environment. “Environments in which it is difficult to receive
a radio signal” → P.26
* The watch cannot receive a radio signal outside the radio signal reception range. “Radio signal reception range
indication” → P.20
* When the time zone is set for a region other than the radio signal reception range, radio signals cannot be received.
Check the selection of time zone. “Time zone display and time difference table” → P.34
*
When the watch does not display the correct time and date even after successfully receiving a radio signal, refer to
Troubleshooting. “Misalignment of the time and hand positions” → P.98, “Misalignment of the date” → P.100
EN 19
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)

Reception environment
■ Radio signal reception range indication
This watch receives standard radio signals from Japan (2 stations), China, U.S.A. and Germany.
When you set the watch to a time zone in Japan, China, U.S.A. or Germany, the official standard frequencies
the watch receives will be automatically changed accordingly to the selected time zone.
“How to select the time zone (How to display the local time around the world)” → P.32
Germany (DCF77)
P.24
China (BPC)
P.22
Japan (JJY)
P.21
U.S.A.
(WWVB)
P.23
EN 20
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)
■ Radio signal reception range: Japan (JJY)
The reception range from the transmitting station is approximately 1,000 km (1,000 km radius of the
transmitting station).
Hagane-yama
transmitting
station (60 kHz)
Ohtakadoya-
yama
transmitting
station (40 kHz)
1,000 km
1,000 km
JJY is operated by the National Institute of
Information and Communications Technology
(NICT).
JJY is transmitted from two stations in Japan. Each
station transmits JJY in a different frequency.
Fukushima : Ohtakadoya-yama transmitting
station
Frequency: 40 KHz
Kyushu : Hagane-yama transmitting station
Frequency: 60 KHz
* NICT: National Institute of Information and
Communications Technology
* Even within the reception range, weather conditions,
terrain, buildings, and orientation may mean that
reception is not possible.
“Environments in which it is difficult to receive a radio
signal” → P.26
EN 21
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)
■ Radio signal reception range: China (BPC)
The reception range from the transmitting station is approximately 1,500 km (1,500 km radius of the
transmitting station).
Shangqiu
National Time
Service Center
(68.5 kHz)
1,500 km
BPC is operated by NTSC.
Shangqiu National Time Service Center
Frequency: 68.5 kHz
* NTSC: National Time Service Center
* The watch may be able to receive radio signals outside
a reception range if the receiving conditions are
favorable.
* Even within the reception range, weather conditions,
terrain, buildings, and orientation may mean that
reception is not possible.
“Environments in which it is difficult to receive a radio
signal” → P.26
EN 22
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)
■ Radio signal reception range: U.S.A. (WWVB)
The reception range from the transmitting station is approximately 3,000km
(3,000 km radius of the transmitting station). There are four time zones within the reception range.
Fort Collins
transmitting station
Frequency (60 KHz)
3,000 km
WWVB is operated by NIST.
Fort Collins transmitting station
Frequency: 60 kHz
* NIST: National Institute of Standards and Technology
* The watch may be able to receive radio signals outside
a reception range if the receiving conditions are
favorable.
* Even within the reception range, weather conditions,
terrain, buildings, and orientation may mean that
reception is not possible.
“Environments in which it is difficult to receive a radio
signal” → P.26
* Use of automatic reception is recommended, as this
time frame is optimal for automatic reception.
EN 23
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)

■ Radio signal reception range: Germany (DCF77)
The reception range from the transmitting station is approximately 1,000km (1,000 km radius of the
transmitting station).
There are three time zones within the reception range.
Mainflingen
transmitting station
(77.5 kHz)
1,000 km
DCF77 is operated by PTB.
Southeastern Frankfurt
Mainflingen transmitting station (77.5 kHz)
* PTB: Physikalisch-Technische Bundesanstalt
* Even within the reception range, weather conditions,
terrain, buildings, and orientation may mean that
reception is not possible.
“Environments in which it is difficult to receive a radio
signal” → P.26
* Use of automatic reception is recommended, as this
time frame is optimal for automatic reception.
EN 24
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)
■ To improve radio signal reception
●Place the watch in a place where it can easily receive a radio signal
such as near a window.
The antenna is embedded at the 9 o’clock position of the watch.
Turning the antenna toward the outside of a window or the
direction facing transmitting stations helps improve radio signal
reception.
* Locations of transmitting stations
“Radio signal reception range indication” → P.20
●Do not move the watch while it is
receiving radio signals.
To enhance the reception of radio signals, do not move the
watch or do not change the orientation of the watch while it is
receiving radio signals.
* If the button or crown is operated while the watch is receiving a
radio signal, the reception will be cancelled.
●The place where the watch is put before going to bed
Place the watch next to a window facing in the direction of a transmitting station before bedtime because
automatic reception is performed late at night.
The standard radio signal is influenced by the distance from the transmitting station, as well as by terrain
(including buildings) and weather conditions.
Also, please search for a place to easily receive radio signals when attempting reception.
Antenna
EN 25
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)
■Environments in which it is difficult to receive a radio signal
Avoid putting the watch in such places when it receives radio signals.
•Close to home electrical
appliances such as TV’s,
refrigerators or air conditioners
•Close to OA equipment such as
mobile phones, personal
computers or fax machines
•Close to steel desks or other
furniture made of metal
•In places generating radio
interference, such as construction
sites or places with heavy traffic
•Close to overhead power lines, TV
stations, train cables
•Inside a building, between tall
buildings, underground
•Inside a vehicle, train, or airplane
EN 26
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)
bCAUTION
• The watch may display the wrong time if it fails to receive radio signals properly
because of interference.
The watch may also fail to receive radio signals properly depending on the location or
radio wave receiving conditions.
In this case, move the watch to another place where it can receive radio signals.
• When the watch is out of reception range, its accurate quartz movement (loss / gain:
±15 seconds per month on average) will continue to keep the time.
• The time signal transmission may be stopped during maintenance of the facilities of
the (each) transmitting station or because of a lightning strike.
In such a case, see the (each) station’s website for further information or contact
SEIKO CUSTOMER SERVICE CENTER.
• Websites of transmission stations (As of August 2020)
Japan : National Institute of Information and Communications Technology (Japan
Standard Time Project) http://jjy.nict.go.jp/
China : NTSC http://www.ntsc.cas.cn/
U.S.A. : NIST https://www.nist.gov/pml/time-and-frequency-division/radio-
stations/wwvb
Germany : PTB https://www.ptb.de/cms/en.html
EN 27
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)

How to check the reception status
■ How to display the reception results
The small seconds hand indicates the latest reception results (Yes/No) of a radio signal for five seconds.
1Press Button B once and then
release it.
The small seconds hand indicates the
reception results.
Button B
Press
once and
release it
* When Button B is kept pressed, the watch starts
manual reception.
2Check if the reception was
successful (within 5 seconds).
If a reception was
successful: The seconds
hand points to Y
(Yes: the 10-second
position)
If a reception has failed: The
seconds hand points to N
(No: the 20-second
position)
* If Button B is pressed after five seconds or while
the small seconds hand is moving to display the
reception results, the reception results display
function is cancelled and the small seconds hand
resumes its normal movement.
EN 28
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)
If a reception was successful: The seconds hand points to Y
• A radio signal has been received successfully. Use the watch without any adjustments.
* When the watch does not display the correct time and date even after successfully receiving a radio signal, refer
to Troubleshooting.→ Misalignment of the time and hand positions P.98, and Misalignment of the date P.100
If reception has failed: The seconds hand points to N
•Place the watch in a place where it can easily receive a radio signal, or change its direction.
Even within the radio signal reception range, this watch may fail to receive a radio signal depending on
the condition (due to the influence of weather, terrain, buildings, or direction). “Environments in which it
is difficult to receive a radio signal” → P.26
This watch is unable to receive radio signals outside the reception range. “Radio signal reception range
indication” → P.20
•Make sure that the time zone is correctly selected before attempting radio signal reception.
When the time zone is set to a region other than the radio signal reception range, radio signals cannot
be received. Check the selection of time zone.
“How to select the time zone (How to display the local time around the world)” → P.32
“Time zone display and time difference table” → P.34
•Attempt to receive a radio signal in a different time period. (In the case of manual reception)
Receiving environments differ according to time periods even at the same place. Due to radio signal
characteristics, the watch is able to easily receive radio signals during nighttime hours.
• If you use the watch in a place or region outside the radio signal reception range or when the watch
cannot successfully receive radio signals, manually set the time and date.
“How to manually set the time” → P.82
“How to manually set the date” → P.84
EN 29
3
HOW TO SET THE TIME (RADIO SIGNAL RECEPTION)
How to use the world time function
■ World time function
•The time in each region of the world can be displayed by selecting the time zone (25 regions around the
world).
•In the Time Zone Setting mode, the stopwatch second
hand indicates the selected time zone.
•When the time zone is set to a region within the radio signal reception range, radio signals can be
received. When the watch is within the radio signal reception range, radio signals are received during
automatic reception or manual reception and the exact time and date are displayed.
* The watch is unable to receive radio signals outside the reception range. “Radio signal reception range
indication” → P.20
“How to select the time zone (How to display the local time around the world)” → P.32
“Time zone display and time difference table” → P.34
Time zone indication
EN 30
4
WORLD TIME FUNCTION
Example : Display Honolulu time (Set time zone to HNL (Honolulu))
When the time zone is selected, the date is automatically adjusted in conjunction with the hour hand.
<Before time zone setting>
Local time in Japan:
6th.,10 o’clock 8 minutes and 42
seconds
5
<After time zone setting>
Local time in Honolulu:
5th.,15 o’clock 8 minutes and 42
seconds
EN 31
4
WORLD TIME FUNCTION

How to select the time zone (How to display the local time around the world)
Press Button A for
3 seconds and
then release it.
Press Button B
to advance 1
time zone
Press Button A
to set back 1
time zone
1
Continue to press Button A (for 3 seconds),
and when the stopwatch second hand starts
to move counterclockwise, release it.
The watch switches to the time zone adjustment mode
and stops by the time zone set currently.
*
Within 10 seconds after procedure 1. is completed, start the
operation of procedure 2.
If the watch is left untouched for 10 seconds after the
seconds hand stops, the watch automatically returns to the
TIME display mode.
If this happens, restart the operation from procedure 1.
*
If the stopwatch hands are not reset to the 0-position, it is
not possible to set the time zone (the stopwatch second
hand does not stop). Reset the stopwatch and re-attempt
procedure 1. → P.40
2
Within 10 seconds after carrying out
procedure 1, press Button A or Button B to
set the stopwatch second hand to the local
time zone of a desired area.
With each pressing of the button, the stopwatch seconds
hand moves to the adjacent time zone index.
The position of stopwatch second hand indicates the time
zone. Please set it by referring to P.34.
EN 32
4
WORLD TIME FUNCTION
The radio signal transmitting station can be changed by selecting the time zone. When
selecting a time zone for regions other than the radio signal reception ranges, the radio
signal reception function will not work.
* When setting the daylight saving time (DST), add one hour to the time zone of the target area.
In Japan In China In the other countries
Set the seconds hand to
the 23-second position.
Set the seconds hand to
the 21-second position.
“Time zone display
and time difference
table” → P.34
3
Wait for ten seconds after the movement of the hour and minute hands stop. (The time
zone adjustment mode is finished.)
After ten seconds, the stopwatch second hand automatically switches to the 0-position.
* In case the date changes, the watch adjusts automatically after the stopwatch second hand switches to the 0-position.
EN 33
4
WORLD TIME FUNCTION
Time zone display and time difference table
In the Time Zone Setting mode, set the stopwatch second hand to point at the target time zone index referring to the
table below.
When setting daylight saving time (DST), add a time difference of +1 hour to the time zone of the target area.
Time zone
display
Time
difference
display
Seconds hand positions
Names of
representative
cities (Time zone)
Time
difference
from UTC
Receivable radio
signals
LON UTC 0-second position London ±0 hours DCF77
PAR/BER 1 3-second position Paris/Berlin +1 hours DCF77
CAI 2 6-second position Cairo +2 hours DCF77 △
JED 3 8-second position Jeddah +3 hours -
DXB 4 11-second position Dubai +4 hours -
KHI 5 13-second position Karachi +5 hours -
DAC 6 15-second position Dhaka +6 hours -
BKK 7 18-second position Bangkok +7 hours -
BJS/HKG 8 21-second position Beijing/Hongkong +8 hours BPC
TYO 9 23-second position Tokyo +9 hours JJY
SYD 10 25-second position Sydney +10 hours JJY △
NOU 11 28-second position Nouméa +11 hours -
EN 34
4
WORLD TIME FUNCTION
* Time zones marked with a △ in “Receivable radio signals” are selected when the time zone one hour earlier is set to daylight
saving time (DST).
* Each indication may differ depending on the model (design) of the watch.
(As of August 2020)
Time zone
display
Time
difference
display
Seconds hand positions
Names of
representative
cities (Time zone)
Time
difference
from UTC
Receivable radio
signals
WLG 12 30-second position Wellington +12 hours -
TBU 13 32-second position Nuku’alofa +13 hours -
MDY -11 34-second position Midway Islands -11 hours -
HNL -10 36-second position Honolulu -10 hours -
ANC -9 38-second position Anchorage -9 hours -
LAX -8 41-second position Los Angels -8 hours WWVB
DEN -7 43-second position Denver -7 hours WWVB
CHI -6 45-second position Chicago -6 hours WWVB
NYC -5 48-second position New York -5 hours WWVB
SDQ -4 50-second position Santo Domingo -4 hours WWVB △
RIO -3 53-second position Rio de Janeiro -3 hours -
FEN -2 55-second position Fernando de
Noronha -2 hours -
PDL -1 57-second position Azores -1 hour -
EN 35
4
WORLD TIME FUNCTION

■ What is a time zone?
Based on Coordinated Universal Time (UTC), the standard time commonly used is adopted by
countries and regions around the world.
The standard time is determined by each country or region, and the region where the same
standard time is adopted is referred to as the time zone.
Further, Daylight Saving Time (DST) is individually adopted in countries and regions.
[What is UTC (Coordinated Universal Time)?]
UTC is the universal standard time coordinated through international agreement. It is used as the official
time around the world. UTC is a time coordinated by adding leap seconds to the “International Atomic
Time (TAI)” determined from atomic clocks in the world, in order to correct the deviation from the
astronomically defined universal time (UT).
[What is summer time (DST)?]
Summer time is Daylight Saving Time (DST).
Advance the watch one hour to prolong daytime during longer daylight hours in summer.
The adoption and duration of Daylight Saving Time (DST) vary depending on the country.
* Time differences between regions and daylight saving time may change due to circumstances of a country or
region.
* In some regions, time zones that differ from UTC by half- or quarter-hour time differences are established. (For
example, some parts of India)
EN 36
4
WORLD TIME FUNCTION
■ Q&A for the world time function
Q
:
Will the watch be automatically set to the local time when it is moved to a place outside Japan in a different time zone?
A
:
The watch will not be automatically set to the local time if it is just moved to a place outside Japan in a different time
zone.
When traveling abroad, select the time zone for that area.
The watch automatically displays the local time when the time zone is selected. (The time difference can be adjusted
in one-hour increments.)
After selecting the time zone, radio signals within the radio signal reception range are received and a more accurate
local time can be set. (The transmitting station from which to receive radio signals is changed by selecting the time
zone.)
Q
:
When returning to Japan from overseas, is the time automatically set to Japan time?
A
:
Just moving does not adjust your watch to Japanese local time.
When wearing a watch in Japan, set to Japan time by use of the world time function.
Q
:
The hands stop during operation of time zone selection setting, therefore, does time lag occur?
A
:
The internal circuit stores the time, therefore, no time lag occurs.
Q
:
When a time zone for a region other than the radio signal reception range is set, the watch will not receive a radio signal.
How is the accuracy of the watch at that time?
A
:
The watch has an accuracy of a normal quartz watch in that case. (Monthly rate: ±15 seconds)
Q
:
How is adjustment made to a local time with a time zone of 15 minutes or 30 minutes?
A
:
The time can be adjusted on a 1 hour basis by use of the time difference adjustment function. When adjusting to a local
time with a time difference of 15 minutes or 30 minutes, refer to “How to manually set the time” → P.82
EN 37
4
WORLD TIME FUNCTION
Stopwatch Function
The stopwatch can carry out measurements for up to 60 minutes in increments of 1/5 of a second.
When the measurement reaches 6 hours, the stopwatch hands are automatically reset to the 0-
second position.
* When the measurement reaches 60 minutes, the stopwatch second hand automatically stops at the 0-second
position.
When starting the stopwatch again and then the buttons are operated to stop the stopwatch or to measure a split
time, the stopwatch second hand displays the measured time from the restart.
After the stopwatch is restarted or a split time measurement is released, the stopwatch second hand advances for
60 minutes at the longest.
EN 38
5
HOW TO USE THE STOPWATCH
■ The names of the parts and functions of the stopwatch
1Stopwatch second hand
moves in 1/5-second increments
2Button C
Start/Stop
3Button D
Split/Reset
4Stopwatch minute hand
moves in one-minute increments
5Tachymeter
→ P.46
* The position and design of the display may vary depending on the model.
* Some models may not have a tachymeter.
1
3
4
5
2
EN 39
5
HOW TO USE THE STOPWATCH

■ Before using the stopwatch
Before using the stopwatch, reset it and check that the stopwatch hands (second hand, minute
hand) are stopped at “0 seconds and 0 minutes”.
Refer to the following procedure for resetting the stopwatch.
•How to reset the stopwatch
* The stopwatch can be operated when the crown is at the normal position.
Button C
Button D
Current status
The stopwatch has
stopped.
The stopwatch is
operating.
Press Button C and Button D
to make the stopwatch
hands move.
EN 40
5
HOW TO USE THE STOPWATCH
If any of the stopwatch hands do not return to 0 minute 0 second when the stopwatch is reset, set
the stopwatch hands to the preliminary hand position.
→ “Setting the Preliminary Position of the Stopwatch Second and Minute Hands” P. 91
Press Button C, and then
press Button D
•Before pressing the buttons, make
sure that the stopwatch hands are
moving.
Checking the position of the stopwatch hands after
resetting the stopwatch
The stopwatch hands have
stopped at the “0 seconds
and 0 minutes” position
The stopwatch is
reset.
The stopwatch hands have
stopped at a position other
than the “0 seconds and 0
minutes” position
Adjust the stopwatch
hands to the
preliminary position
→ P.91
EN 41
5
HOW TO USE THE STOPWATCH
How to use the stopwatch
•Standard measurement Ex. 5,000 meters running
C C D
Start Stop Reset
Start the measurement Goal Reset the stopwatch to
0minute 0 second.
Example of measurement:
20 minutes 41 seconds
Button C Button C
Button D
EN 42
5
HOW TO USE THE STOPWATCH
•Accumulated elapsed time measurement Ex. Measuring the time for a soccer match
C C C C D
Start Stop Start Stop Reset
Start match. Stop match. Start again. The match ends. Reset the stopwatch
to 0 minute
0second.
Button C Button C Button C Button C
Button D
•Restart and stop of the stopwatch can be repeated.
EN 43
5
HOW TO USE THE STOPWATCH

•Split time (intermediate elapsed time) measurement Ex. 5,000 meters running
* “Split time” is the time that has elapsed from the start of an activity to any given stage.
C D C D D
Start Split StopStop Reset
Start The runner passed
the P point.
The intermediate elapsed time
is displayed.
Goal (Display of goal
time)
Reset the stopwatch
to 0 minute
0second.
Example of the
intermediate
elapsed time
Start P point Goal
Button C
Button D
Button C
Button D Button D
EN 44
5
HOW TO USE THE STOPWATCH
•Measurement of two competitors
C D C D D
Start (Split) (Stop)
(Split release)
Reset
Start First runner finishes.
Displays finishing time
of first runner
Second runner
finishes.
(Still displaying finishing
time of first runner)
Check time of
second runner.
Displays finishing time
of second runner
Reset the
stopwatch to
0minute 0 second.
Ex. Measurement of two
competitors
Start First runner finishes. Second runner finishes.
Button C
Button D
Button C
Button D Button D
EN 45
5
HOW TO USE THE STOPWATCH
How to use the tachymeter
The numbers on the tachymeter scale can be read to determine how many seconds it takes to run
1 km or to measure the time required to complete 1 job.
•How to measure kilometers / hour
1Measure the time (within 1 minute) it takes to run 1 km.
2Check the numerals on the tachymeter
scale to which the stopwatch second
hand is pointing.
Ex. :
If it takes 45 seconds to run 1 km...80 km/h
EN 46
5
HOW TO USE THE STOPWATCH
•How to measure the hourly rate of operation
1Measure the time (within 1 minute) required to complete 1 job.
2Check the numerals on the tachymeter
scale to which the stopwatch second
hand is pointing.
Ex. : If it takes 20 seconds to complete one
product...180 products/hour
EN 47
5
HOW TO USE THE STOPWATCH

Charging the battery
■ How to charge the battery
Expose the dial to light to charge the watch.
To ensure optimal performance of the watch, make
sure that the watch is kept sufficiently charged at all
times.
Under the following situations, the energy of the
watch is likely to be depleted, resulting in stoppage
of the watch:
• The watch is concealed under a sleeve.
•
The watch is used or stored under conditions where
it cannot be exposed to light for a long time.
* Be careful to make sure that the watch does not get hot when it is charging. (The operating temperature range is
-10°C to +60°C.)
* When you first start using the watch or starting it after it stopped due to a lack of charge, charge the watch sufficiently
using the table on P.49 as a guide.
EN 48
6
SOLAR CHARGING FUNCTION
■ Guide to charging times
Charge the watch using the times below as a guide.
Illuminance
lx (LUX) Light source Condition (Example)
From the state where the watch is
stopped (Not charged)
In the state where
the hand moves (The
watch is charged)
Time required for
fully charging the
watch
Time required for
charging the watch
to start moving at
one-second
intervals
Time required for
charging the watch
to last for 1 day
700 Fluorescent
light General offices - - 4 hours
3,000 Fluorescent
light 30 W 20 cm 230 hours 6 hours 1 hour
10,000
Fluorescent
light 30 W 5 cm 60 hours 1.5 hours 15 minutes
Sunlight Cloudy day
100,000 Sunlight
Sunny day (Under the
direct sunlight on a
summer day)
30 hours 30 minutes 3 minutes
The figures of “Time required for charging the watch to start moving at one-second intervals” are estimations of
time required to charge the stopped watch by exposing it to light until it moves at steady one-second intervals.
Even if the watch is partially charged for a shorter period, the watch will resume one-second interval movement.
However, it may shortly return to two-second interval movement. Use the charging time in this column as a rough
guide for sufficient charging time.
* The seconds hand movement indicates the remaining amount of energy. “Checking the Charging Status” → P.16
* The required charging time slightly varies depending on the model of the watch.
EN 49
6
SOLAR CHARGING FUNCTION
About energy
■ Energy depletion forewarning function (Two-second
interval movement and Five-second interval movement)
The energy depletion forewarning function is activated when the energy stored in the watch runs low.
In such a case, the small seconds hand moves at two-second intervals.
If the watch continues to be in the state of two-second interval movement, the watch switches to five-second
interval movement, followed by a completely stopped state.
If the energy depletion forewarning function is activated, charge the watch sufficiently.
“How to charge the battery” → P.48
“Guide to charging times” → P.49
* Neither the button nor the crown can be operated while the seconds hand moves at two-second or five-second
intervals. (This is not a malfunction.)
* While the seconds hand moves at five-second intervals, the hour and minute hands, as well as the date, stop
operating.
* While the seconds hand moves at five-second intervals, the automatic reception function and manual reception
function will not work. After the watch is charged sufficiently and the seconds hand returns to normal one-second
interval movement, conduct the manual reception of radio signals to set the watch to the correct time. (“Automatic
reception and manual reception” → P.19)
EN 50
6
SOLAR CHARGING FUNCTION
■ Power save function
This watch is equipped with a power save function which can suppress energy consumption when it is left without receiving
an adequate light source for a certain length of time.
* There are two types of power save mode.
Power Save 1 Power Save 2
Condition The watch is exposed to a state without receiving an
adequate light source for 72 hours or longer.
The watch is in an insufficient charging state for a long
time.
Situation
The small seconds
hand stops pointing at
the 15-second
position, and the hour
and minute hands also
stop.
The watch conducts
automatic radio signal
receiving.
The small seconds
hand stops pointing at
the 45-second
position, and the hour
and minute hands also
stop.
The watch does not
conduct automatic
radio signal receiving.
How to
handle the
situation
When the watch is exposed to an adequate light source
for five seconds or longer, it displays the current time
again after the seconds hand is rapidly advanced.
After sufficiently charging the battery, set the watch for
the current time, if necessary.
Power Save 2
* While the watch is being charged, the seconds hand moves at “Five-second Intervals.” During the “Five-second Interval Movement,”
neither the button nor the crown can be operated.
* If the “Power Save 2” mode is prolonged, the stored power amount drops and the internal current time information stored will be lost.
When the watch returns to its normal movement of one-second interval after sufficiently charging the battery, set the current time by
receiving a radio signal. (“Automatic reception and manual reception” → P.19)
EN 51
6
SOLAR CHARGING FUNCTION

Power Source
The battery used in this watch is a special secondary battery, which is different from ordinary
batteries.
Unlike an ordinary silver oxide battery, the secondary battery does not require periodic
replacement.
The capacity or charging efficiency may gradually lower due to long-term use or operating
environment.
In addition, long-term use may shorten the charge duration due to wear, contamination, lubricant
deterioration of mechanical parts, etc. Request repair when the performance lowers.
bWARNING
■ Notes on replacing the secondary battery
• Do not remove the secondary battery from the watch.
Replacement of the secondary battery requires professional knowledge and skill.
Please ask the retailer from whom the watch was purchased for replacement of the
secondary battery.
• Installation of an ordinary silver oxide battery can generate heat that can cause
bursting and ignition.
EN 52
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
* Overcharge prevention function
When the secondary battery is fully charged, the overcharge prevention function is automatically
activated to avoid further charging.
There is no need to worry about damage caused by overcharging no matter how much the
secondary battery is charged in excess of the “time required for fully charging the watch.”
* For the required time to fully charge the battery, see “Guide to charging times” → P.49.
bWARNING
■ Notes on charging the watch
•When charging the watch, do not place the watch in close proximity to an intense light
source such as lighting equipment for photography, spotlights or incandescent lights,
as the watch may be excessively heated resulting in damage to its internal parts.
•When charging the watch by exposure to direct sunlight, avoid places that easily reach
high temperatures, such as a car dashboard.
• Always keep the watch temperature under 60°C.
EN 53
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
Daily care
●The watch requires good daily care
• Do not wash the watch when its crown is in the extended position.
• Wipe away moisture, sweat or dirt with a soft cloth.
• After soaking the watch in seawater, be sure to wash the watch in clean pure water and wipe it dry
carefully.
Do not pour running water directly from a faucet onto the watch. Put some water into a bowl first, and
then soak the watch in the water to wash it.
* If your watch is rated as “Non-water resistant” or “water resistant for daily use,” please do not wash the watch.
“Performance and type” → P.55
“Water resistant performance” → P.57
●Turn the crown from time to time
• In order to prevent corrosion of the crown, turn the crown from time to time.
• The same practice should be applied to a screw down crown.
“Crown” → P.15
●Press the button once in a while
• Press the button once in a while to prevent corrosion of the button.
* If the display is changed by pressing any button, wait and leave it as is.
EN 54
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
Performance and type
The case back shows the caliber and performance of your watch
8B92-0000
8
B
9
2
-
0
0
0
0
0
0
0
0
0
0
M
A
D
E
I
N
J
A
P
A
N
W
A
T
E
R
R
E
S
I
S
T
A
N
T
1
0
B
A
R
S
T
A
I
N
L
E
S
S
S
T
E
E
L
Water resistant
performance
Case Number
Magnetic resistant
performance
•Water resistant performance
Please refer to P.57.
•Case Number
The number to identify the type of your watch.
•Magnetic resistant performance
Please refer to P.58 and P.59.
* The above illustration is provided as an example, therefore it may not be exactly the same as your watch.
EN 55
7
TO PRESERVE THE QUALITY OF YOUR
WATCH

Lumibrite
If your watch has Lumibrite
Lumibrite is a luminous paint that absorbs the light energy of sunlight and lighting apparatuses in a short
time and stores it to emit light in the dark. For example, if exposed to a light of more than 500 lux for
approximately 10 minutes, Lumibrite can emit light for 3 to 5 hours. Please note, however, that, as Lumibrite
emits the light it stores, the luminance level of the light decreases gradually over time. The duration of the
emitted light may also differ slightly depending on such factors as the brightness of the place where the
watch is exposed to light and the distance from the light source to the watch.
* In general, when coming from a place that is bright to a place that is dark, it takes human eyes some time to adapt
to the darkness making it difficult to see objects initially. (Dark adaptation)
* Lumibrite is luminous paint that stores and emits light, which is harmless to human beings and the environment,
containing no toxic materials such as radioactive substances.
<Brightness levels>
Condition Illumination
Sunlight Fine weather 100,000 lux
Cloudy weather 10,000 lux
Indoor (Window-side during
daytime)
Fine weather More than 3,000 lux
Cloudy weather 1,000 to 3,000 lux
Rainy weather Less than 1,000 lux
Lighting apparatus (40-watt daylight
fluorescent light)
Distance to the watch: 1 m 1,000 lux
Distance to the watch: 3 m 500 lux (Average room luminance)
Distance to the watch: 4 m 250 lux
EN 56
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
Water resistant performance
Refer the table below for the description of water resistant performance of your watch before using.
(Please look at P.55.)
Indication on the
case back
Water resistant
performance Conditions of Use
No indication Non-water resistance Avoid drops of water or sweat
WATER
RESISTANT
Water resistance for
everyday life
The watch withstands
accidental contact with
water in everyday life.
bWARNING
Please do not use it for
swimming.
WATER
RESISTANT
5 BAR
Water resistance for
everyday life at 5-BAR
water resistant
The watch is suitable for sports such as swimming.
WATER
RESISTANT
10（20）BAR
Water resistance for
everyday life at 10 (20)-BAR
water resistant
The watch is suitable for diving not using an air cylinder.
EN 57
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
Magnetic resistant performance
Affected by nearby magnetism,
a watch may temporarily gain or lose time or stop operating.
* When the hand positions deviate to display incorrect time as a result of influence of magnetism, this watch
automatically corrects the hand alignment itself. (P.86)
bDANGER
Indication on the case back Condition of use
No indication Keep the watch more than 10 cm away from magnetic products.
Keep the watch more than 5 cm away from magnetic products.
(JIS level-1 standard)
Keep the watch more than 1 cm away from magnetic products.
(JIS level-2 standard)
If the watch becomes magnetized and its accuracy deteriorates to an extent exceeding the specified rate
under normal use, the watch needs to be demagnetized. In this case, you will be charged for
demagnetization and accuracy readjustment even if it happens within the guarantee period.
The reason why a watch is affected by magnetism
The built-in motor is provided with a magnet, which may be influenced by a strong external magnetic field.
EN 58
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
Examples of common magnetic products that may affect watches
Smartphone, cellular phone, tablet terminal
(Speaker, magnet of cover)
AC adapter Bag
(With magnet
buckle)
AC-powered
shaver
Magnetic
cooking device
Portable radio
(Speaker)
Magnetic
necklace
Magnetic health
pillow
EN 59
7
TO PRESERVE THE QUALITY OF YOUR
WATCH

Band
The band touches the skin directly and becomes dirty with sweat or dust. Therefore, lack of care
may accelerate deterioration of the band or cause skin irritation or stain on the sleeve edge.
The watch requires a lot of attention for long usage.
●Metallic band
•Moisture, sweat or soil will cause rust even on a stainless steel band if they are left for a long time.
•Lack of care may result in a rash or cause a yellowish or gold stain on the lower sleeve edge of shirts.
• Wipe off moisture, sweat or soil with a soft cloth as soon as possible.
• To clean the soil around the joint gaps of the band, wipe it out in water and then brush it off with a soft
toothbrush.
(Protect the watch body from water splashes by wrapping it up in plastic wrap etc.)
Clean it off with a soft cloth.
• Because some titan bands use pins made of stainless steel, which has outstanding strength, rust may
form in the stainless steel parts.
• If rust advances, pins may poke out or drop out, and the watch case may fall off the band, or the clasp
may not open.
• If a pin is poking out, personal injury may result. In such a case, refrain from using the watch and request
repair.
EN 60
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
●Leather band
•A leather band is susceptible to discoloration and deterioration from moisture, sweat and direct sunlight.
• Wipe off moisture and sweat as soon as possible by gently blotting them up with a dry cloth.
• Do not expose the watch to direct sunlight for a long time.
• Please take care when wearing a watch with light-colored band, as dirt is likely to show up.
•
Refrain from wearing a leather band watch other than Aqua Free bands while bathing, swimming, and
when working with water even if the watch itself is water resistant enforced for daily use (10-BAR/20-BAR
water resistant).
●Polyurethane band
• A polyurethane band is susceptible to discoloration from light, and may be deteriorated by solvent or
atmospheric humidity.
•Especially a translucent, white, or pale colored band easily adsorbs other colors, resulting in color smears
or discoloration.
• Wash out dirt in water and clean it off with a dry cloth.
(Protect the watch body from water splashes by wrapping it up in plastic wrap etc.)
• When the band becomes less flexible, have the band replaced with a new one. If you continue to use
the band as it is, the band may develop cracks or become brittle over time.
EN 61
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
●Silicone band
• As for material characteristics, the band is easily dirtied, and may be stained and discolored.
Wipe off dirt with a wet cloth or cleaning tissue.
• Unlike bands of other materials, cracks may result in the band being cut. Take care not to damage the
band with an edged tool.
Notes on skin
irritation and
allergy
Skin irritation caused by a band may result from various factors such as allergy to
metals or leathers, or skin reactions against friction on dust or the band itself.
Notes on the
length of the band
Adjust the band to allow a little clearance with your wrist to ensure proper
airflow.
When wearing the watch, leave enough room to insert a finger between
the band and your wrist.
EN 62
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
How to use tri-fold type clasp for leather band (Special clasps)
There are 3 types of special clasps as described below;
If the clasp of the watch you purchased is one of them, please refer to the indications.
AA Type → P.64
BB Type → P.65
CC Type → P.66
EN 63
7
TO PRESERVE THE QUALITY OF YOUR
WATCH

AA Type
1Lift up the clasp to release the buckle.
Fixed loop
Movable loop
Buckle
Flap
2Open the flap.
3
Remove the pin from the adjustment hole. Slide the
band left and right, and reinsert the pin into the
adjustment hole at an appropriate length.
Pin
Adjustment hole
4Fasten the flap.
* Do not push the flap in too hard.
* When fastening the clasp, insert the tip of the band
into the movable loop and fixed loop, and then,
securely tighten the clasp.
EN 64
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
BB Type
1While pressing the push buttons on both sides
of the flap, lift to open the clasp.
Push button
2Remove the pin from the adjustment hole.
Slide the band left and right, and insert the pin
into the adjustment hole at an appropriate
length. Push the buckle and fasten the clasp.
Buckle
Pin
Adjustment hole
EN 65
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
CC Type
●How to wear or take off the watch
1While pressing the push buttons on both sides
of the flap, pull the band out of the movable
loop and fixed loop. Then open the clasp.
Fixed loop
Movable loop
Buckle
Flap
Push button
2Place the tip of the band into the movable loop
and fixed loop, and fasten the clasp by
pressing the frame of the buckle.
EN 66
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
●How to adjust the length of the band
1While pressing the push buttons on both sides
of the flap, pull the band out of the movable
loop and fixed loop. Then open the clasp.
Fixed loop
Movable loop
Buckle
Flap
Push button
2Press the push buttons again to unfasten the
flap.
EN 67
7
TO PRESERVE THE QUALITY OF YOUR
WATCH

3Pull the pin out of an adjustment hole of the
band. Slide the band to adjust its length and
find an appropriate hole. Place the pin into the
hole.
Pin
Adjustment hole
Pin
Adjustment hole
4Fasten the flap.
EN 68
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
How to use an adjustable three-fold clasp (Pointed
tip diving type)
The rubber bands and some leather bands are provided with an adjustable three-fold clasp
(Pointed tip diving type) of the type where the pointed tip of the band dives downward as shown
in the figure.
If the clasp of the watch you purchased is as follows, please refer to the following instructions.
EN 69
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
●How to wear or take off the watch
Buckle
Push button
Band
1. Open the clasp and pull upward by
pressing the push buttons on both sides of
the buckle.
2. Fasten the clasp by pressing the frame of
the buckle.
EN 70
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
●How to adjust the length of the band
Buckle
Push button
Band
Pin
Pin
Adjustment hole
1. Open the band clasp by pushing the
buttons on both sides of the clasp.
2. Pull the pins out of the adjustment holes at
both locations.
EN 71
7
TO PRESERVE THE QUALITY OF YOUR
WATCH

3. Slide the band to the right and left and at an
appropriate length, push the pins firmly into
the adjustment holes again at those 2
locations.
* The above illustrations are provided as examples. Some details may differ depending on the model.
EN 72
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
How to use an easy adjust type clasp
Some bands are provided with an easy adjust type clasp for fine adjustment of the band’s length.
If the clasp of the watch you purchased is as follows, please refer to the following instructions.
* The band can be lengthened by up to about 5 mm.
This is useful if the band feels too tight or is uncomfortable for some reason.
EN 73
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
●How to wear the band (Opening and closing the clasp)
Push button Buckle
1. Lightly press the push buttons to open the
clasp.
* Note that pressing the push buttons too
firmly (deeply) actuates the adjuster, which
lengthens the band.
2. Fasten the clasp by pressing the frame of
the buckle.
EN 74
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
●How to adjust the length of the band
1. You can lengthen the band by up to about 5 mm
(2 stages) by firmly pressing the push buttons
from both sides to actuate the adjuster.
2. Fasten the clasp by pressing the frame of the
buckle.
* Even while the clasp is closed, you can still retract
the length of band extended by the adjuster.
* The above illustrations are provided as examples. Some details may differ depending on the model.
EN 75
7
TO PRESERVE THE QUALITY OF YOUR
WATCH
