Seiko CREDOR 7R06 User manual

7R06
BG7R06-2301

Thank you very much for choosing a CREDOR watch.
Only the unique melding of traditional Japanese sensitivity and state-of-
the-art technology can bring you a watch of this quality and character.
Doing so is our passion. The CREDOR name is your guarantee.
From the French “crête d’or” or “crest of gold” it signifies our commitment
to always being the very best.
We hope this CREDOR watch will be your favorite personal timepiece for
many years to come.
Please read carefully the instructions in this booklet for proper and safe use
of your CREDOR watch before start using it.
Keep this manual handy for easy reference.
If your watch has a protective film for preventing scratches, make sure to peel it off before using
the watch. If the watch is used with the film on it, dirt, sweat, dust, or moisture may be attached
to the film and may cause rust.
1
English

CONTENTS
■ HANDLING CAUTIONS ....................................................................................... 3
■ PERFORMANCE AND TYPE ............................................................................... 4
■ WATER RESISTANCE ......................................................................................... 5
■ CHARACTERISTICS ........................................................................................... 6
■ NAMES OF THE PARTS ...................................................................................... 7
■ HOW TO USE ....................................................................................................... 8
• How to wind the mainspring .............................................................................. 8
• Power reserve indicator ..................................................................................... 9
• How to use ...................................................................................................... 12
■ TO PRESERVE THE QUALITY OF YOUR WATCH .......................................... 17
• After-sale service ............................................................................................. 17
• Daily care ........................................................................................................ 18
• Remarks on 18-karat gold ............................................................................... 18
• Watch body / metal bracelet ............................................................................ 18
• Band ................................................................................................................ 19
• Magnetic resistance (Magnetic influence) ....................................................... 20
• Shock .............................................................................................................. 20
• Troubleshooting .............................................................................................. 21
■ SPECIFICATIONS (Movement) ........................................................................ 22
2
■ HANDLING CAUTIONS
bWARNING
To indicate the risks of serious consequences such as severe injuries
unless the following safety regulations are strictly observed.
Immediately stop wearing the watch in the following cases.
○
If the watch body or band becomes edged by corrosion etc.
○
If the pins protrude from the band.
* Immediately consult the retailer from whom the watch was purchased or SEIKO CUSTOMER
SERVICE CENTER.
Keep the watch and accessories out of the reach of babies
and children.
Care should be taken to prevent a baby or a child accidentally swallowing the accessories.
If a baby or child swallows the battery or accessories, immediately consult a doctor, as it will be
harmful to the health of the baby or child.
bCAUTION
To indicate the risks of light injuries or material damages unless the
following safety regulations are strictly observed.
Avoid wearing or storing the watch in the following places.
○
Places where volatile agents (cosmetics such as polish remover, bug repellent, thinners, etc.)
are vaporizing
○
Places where the temperature drops below 5°C
or rises above 35°C for a long time
○
Places affected by strong magnetism or
static electricity
○
Places affected by strong vibrations
○
Places of high humidity
○
Dusty places
Do not shock or magnetize
○
The watch is a precision device. Avoid shocks by dropping, spins or tumbles. Do not wear the
watch when you play active sports.
○
The watch may temporarily stop operating when affected by strong magnetism.
“Magnetic resistance (Magnetic influence)”→ P. 20
If you observe any allergic symptoms or skin irritation
Stop wearing the watch immediately and consult a specialist such as a dermatologist or an
allergist.
Other cautions
○
Do not disassemble or tamper with the watch.
○
Please follow local government directions when disposing of the watch body.
○
Keep the watch out of the reach of babies and children. Extra care should be taken to avoid
risks of any injury or allergic rash or itching that may be caused when they touch the watch.
○
If your watch is of the fob or pendant type, the strap or chain attached to the watch may damage
your clothes, or injure the hand, neck, or other parts of your body.
○
Please keep in mind that if a watch is taken off and placed down as it is, the case back, the band
and the clasp will rub against each other possibly causing scratches on the case back. We
recommend placing a soft cloth between the case back, the band and the clasp after taking off
your watch.
3
HANDLING CAUTIONS
English

■ PERFORMANCE AND TYPE
The case back shows the performance and type of your watch.
1
8
K
T
M
A
D
E
I
N
J
A
P
A
N
7
R
0
6
-
0
0
0
0
000000
7R06-0000 :
Serial number
Case Number
Caliber Number
○Case number
The number to identify the type of your watch
○Serial number
The number to identify your watch
* The above illustrations are examples and may differ from the case back of the watch you
purchased.
4PERFORMANCE AND TYPE
■ WATER RESISTANCE
This watch is not water-resistant.
Do not allow water or water vapor to enter the watch.
○ In order to achieve the complete purity of the chime sound, the watch has a non-water
resistant design so that absolute silence of the whole movement is realized.
○ Refrain from using the watch in a condition that the watch is exposed to high humidity, for
example, at times of heavy sweating or when wearing gloves.
○ Store the watch in a dry place.
○ If the inner surface of the glass is clouded with condensation for a long time, consult the
retailer from whom the watch was purchased or SEIKO CUSTOMER SERVICE CENTER.
bWARNING
Do not use the watch in scuba diving or
saturation diving.
The various tightened inspections under simulated harsh environment,
which are usually required for watches designed for scuba diving or
saturation diving, have not been conducted. For diving, use watches
specifically designed for diving.
bCAUTION
Do not turn or pull out the crown when the
watch is wet.
Water may get inside of the watch.
Do not leave moisture, sweat and dirt on the
watch for a long time.
Keep your watch clean. Wipe off moisture and sweat with a soft cloth.
5
WATER RESISTANCE
English

■ CHARACTERISTICS
“Sonnerie” mechanism
○ This watch features the “sonnerie” mechanism, which is powered by its own separate
mainspring. The mechanism has an hour striking function that automatically announces
the current time by chiming the preset number of times on the hour.
○ The mechanism has been constructed based on a typical Japanese hanging bell sound
that produces a lingering sound, which creates a feeling of a natural flow of time and space.
○ The hour striking function can be set to one of three different modes; the “SONNERIE”
mode which strikes the number of hours every hour on the hour, the “ORIGINAL” mode
which strikes three times every three hours at 12:00, 3:00, 6:00 and 9:00, and the
“SILENCE” mode which mutes the chime sound when it is inappropriate.
○ The hour repeating function which announces the current hour by chiming the number of
hours can be activated at any time you wish to hear the delightful bell sound.
bCAUTION
The automatic chiming of the hour striking function is powered by mechanical movement.
It may start chiming slightly ahead or behind the correct time.
Characteristics of spring drive
○ This watch features“ Spring drive”, the unique mechanism made available only by SEIKO
technology.
○ The Spring Drive watch ensures quartz accuracy while using the mainspring as its sole
power source.
○ The glide-motion seconds hand moves in a perfectly smooth movement.
bCAUTION
○ Spring Drive works by the power provided by the mainspring. Remember to check the
power reserve indicator and keep the mainspring of the watch sufficiently wound while
using the watch.
“Power reserve indicator”→ P. 9
○ Under a low-temperature condition (below 0°C), the watch may stop when the power
reserve indicator shows less than one-fourth of the power reserve.
In such a case, turn the crown to wind the mainspring.
6CHARACTERISTICS
■ NAMES OF THE PARTS
7R06
1Hour hand
2Power reserve indicator for the
watch mechanism
→ P. 10
3Seconds hand
4Button
5Hour striking mode indicator
→ P. 15
6Mainspring for the hour
striking function
7Minute hand
8Power reserve indicator for the
hour striking function
→ P. 11
9Crown
7
8
6
9
1
2
3
4
5
How to wind the mainspring→ P. 8
How to use→ P. 12
7
NAMES OF THE PARTS
English

■ HOW TO USE
How to wind the mainspring
This watch is equipped with two separate mainsprings: one exclusive to the watch mechanism
and the other exclusive to the hour striking function.
It is necessary to wind them separately.
How to wind the mainspring for the watch mechanism
2Wind the mainspring until the power reserve indicator for the watch mechanism shows a
fully wound state.
“Power reserve indicator for the watch mechanism”→ P. 10
3Make sure that the seconds hand is moving.
bCAUTION
The crown cannot be turned further when the mainspring is fully wound to prevent
overwinding of the mainspring. Do not try to forcefully turn the crown as this may damage
the watch.
1Turn the crown at the normal position
clockwise (12 o’clock direction)
slowly.
How to wind the mainspring for the hour striking
function
2Wind the mainspring until the power reserve indicator for the hour striking function shows
a fully wound state.
“Power reserve indicator for the hour striking function”→ P. 11
bCAUTION
The crown cannot be turned further when the mainspring is fully wound to prevent
overwinding of the mainspring. Do not try to forcefully turn the crown as this may damage
the watch.
1Turn the crown at the normal position
counterclockwise (6 o’clock
direction) slowly.
8HOW TO USE
Power reserve indicator
This watch is equipped with two separate mainsprings: one exclusive to the watch
mechanism and the other exclusive to the hour striking function. The power reserve of
each mainspring is shown by its own power reserve indicator.
The power reserve indicator for the hour striking function is located at the 2 o’clock position
(SONNERIE) and the power reserve indicator for the watch mechanism is located at the 10
o’clock position (MARCHE).
Power reserve indicator for the watch
mechanism
Power reserve indicator for the hour striking
function
9
HOW TO USE
Power reserve indicator
English

Power reserve indicator for the watch mechanism
The power reserve indicator for the watch mechanism lets you know the winding state
of the mainspring for the watch mechanism.
Before removing the watch from your wrist, observe the power reserve indicator to check if
the watch has enough power stored to keep running until the next time you wear it. If
necessary, wind the mainspring.
(To prevent the watch from stopping, wind the mainspring to store the excess power that will
allow the watch to run for extra time.)
Power reserve
indicator for the watch
mechanism
Winding state of the
mainspring Fully wound Half wound Unwound
Number of hours the
watch can run
Approximately
48 hours (2 days)
Approximately
24 hours (1 day)
The watch either
stops or is running
down.
The hour striking function is activated by the power generated by the mainspring for the watch
mechanism. When the power reserve for the watch mechanism becomes low, the hour
striking function is automatically disengaged as the watch mechanism takes precedence.
bCAUTION The hour striking function can be activated within approximately 36
hours since the mainspring for the watch mechanism is fully wound.
Power reserve
indicator for the watch
mechanism
Winding state of the
mainspring About 1/4 wound
Number of hours the
watch can run Approximately 12 hours (0.5 day)
○ When the power reserve indicator for the watch mechanism points anywhere below the
point (・) on the dial, the hour striking function cannot be activated. In such a case, wind
the mainspring.
10 HOW TO USE
Power reserve indicator
Power reserve indicator for the hour striking function
The power reserve indicator for the hour striking function lets you know the winding
state of the mainspring of the hour striking function.
○It has approximately 60 hours of power reserve in the “SONNERIE” mode, or approximately
200 hours of power reserve in the “ORIGINAL” mode.
The hour striking function is activated by the power generated by the mainspring for the
watch mechanism. When the power reserve for the watch mechanism becomes low, the
hour striking function is automatically disengaged as the watch mechanism takes
precedence.
○ The hour striking function can be activated within approximately 36 hours since the
mainspring for the watch mechanism is fully wound.
“Power reserve indicator for the watch mechanism”→ P. 10
○The hour repeating function is also powered by the mainspring for the hour striking function.
Therefore, using the hour repeating function will consume the power reserve of the
mainspring for the hour striking function.
○When the power reserve indicator for the hour striking function shows that no power reserve
is left, the hour striking function is disengaged and the watch will stop chiming.
○The hour repeating function can be activated by pressing the button located at the 8 o’clock
position even if the power reserve indicator for the hour striking function shows less than
0, but it chimes with longer intervals.
bCAUTION Do not leave the power reserve indicator for the hour striking function
showing less than 0 for a long time while you are wearing the watch,
as this can cause malfunctions. Keep in mind that the power reserve
should always be above 0.
Power reserve
indicator for the hour
striking function
Winding state of the
mainspring Fully wound Half wound Unwound
11
HOW TO USE
Power reserve indicator
English

How to use
How to set the time
While you are setting the time if you turn the minute hand clockwise passing the 12 o’clock
marker, the watch automatically strikes the hour.
If this happens, stop setting the time while the chime is sounding and resume the setting
procedures after the chiming finishes.
bCAUTION
Friction may occur between the parts used while the watch is chiming and the parts used in
connection with time setting procedure. The watch is equipped with a protective device to
guard against serious failures caused by this, however, to enjoy optimal performance of the
watch for a long time, it is recommended that you follow the time setting procedures instructed
below.
The following time setting method disengages the chiming at the passing of the every hour,
offering a time saving manner of setting the time.
Time setting method after changing the hour striking
mode to the “SILENCE” mode
* If you set the time while the minute hand is pointing to any of the minute markers between 50
and 59, the watch may fail to correctly chime the first hour on the hour after it is adjusted.
1Make sure that the watch is operating.
To carry out the procedure, please make sure that the watch is in working state.
Please wind the mainspring when the watch is not working.
“How to wind the mainspring”→ P. 8
2Pull out the crown to the first click.
3Turn the crown either clockwise or
counterclockwise to set the hour
striking mode indicator to
“SILENCE”.
“How to change the hour striking
mode”→ P. 15
12 HOW TO USE
How to use
6Push the crown back into the normal position in accordance with a time signal.
4Pull out the crown to the second click
when the seconds hand is at the
12 o’clock position. (The seconds
hand stops.)
5Turn the crown counterclockwise
(6 o’clock direction) to advance the
hands to set the time.
Set the minute hand about ten
minutes behind and then slowly
advance the minute hand to the
desired time.
Time setting method without changing the hour striking
mode to the“SILENCE” mode
1Make sure that the watch is operating.
To carry out the procedure, please make sure that the watch is in working state.
Please wind the mainspring when the watch is not working.
“How to wind the mainspring”→ P. 8
2Pull out the crown to the second click
when the seconds hand is at the
12 o’clock position. (The seconds
hand stops.)
13
HOW TO USE
How to use
English

5Push the crown back into the normal position in accordance with a time signal.
* You can push the crown back to the original position while the watch is chiming.
3Turn the crown clockwise (12 o’clock
direction) to slowly turn the minute
hand counterclockwise, until it
passes the nearest 6 o’clock position
(30 minutes) before the time you
wish to set, and then slowly advance
it to the nearest 6 o’clock position (30
minutes) before the time you wish to
set.
【Ex.】If you wish to set the time
to 10:10, set the minute
hand to 9:30 temporarily.
4Turn the crown counterclockwise (6
o’clock direction) to slowly advance
the minute hand to the time you wish
to set.
【Ex.】If you wish to set the time
to 10:10, advance the
minute hand from 9:30 to
10:10.
When the minute hand
passes 10:00, the watch
starts to chime, but you
can continue to advance
the minute hand to 10:10.
Tips for more accurate time setting
To ensure effective operation of the Spring Drive mechanism, observe the following
instructions when you set the time.
1Before setting the time, make sure to wind the mainspring sufficiently.
(Ensure that the power reserve indicator for the watch mechanism is showing a fully wound
state.)
2When starting to use a watch after it stops, wind the mainspring sufficiently. To set the
time after that, wait for approximately 30 seconds after the seconds hand starts moving,
then pull the crown out to the first click.
3The seconds hand will stop moving when the crown is pulled out to the first click. Do not
stop the movement of the seconds hand for longer than 30 minutes. If the stoppage of the
seconds hand movement exceeds 30 minutes, push the crown back in, and wait for
approximately 30 seconds after the seconds hand restarts moving, and then set the time.
14 HOW TO USE
How to use
Hour striking mode
The hour striking function offers three different modes. These modes can be selected simply
by changing the mode indicator located at the 6 o’clock position on the dial.
Hour striking
mode indicator
Mode SONNERIE SILENCE ORIGINAL
Function
The number of hours is
automatically counted
by chiming every hour
on the hour.
The chime is
disengaged.
The time is announced
by a three-strike chime
at the passing of every
three hours: 12:00,
3:00, 6:00 and 9:00.
How to change the hour striking mode
Turn the crown clockwise (12 o’clock direction):
The indicator will move from “ORIGINAL” to “SILENCE” to “SONNERIE”.
If you turn the crown further in the same direction, the hour striking mode indicator will not
move any further.
Turn the crown counterclockwise (6 o’clock direction):
The indicator will move from “SONNERIE” to “SILENCE” to “ORIGINAL”.
If you turn the crown further in the same direction, the hour striking mode indicator will not
move any further.
* Set the hour striking mode indicator pointing exactly to the marker (･) below the mode
name.
* If you change the hour striking mode from “SILENCE” to “SONNERIE” or “ORIGINAL”
while the minute hand is pointing to any of the minute markers between 50 and 59, the
watch may fail to correctly chime the first hour on the hour after it is adjusted.
1Pull out the crown to the first click.
2Turn the crown either clockwise or
counterclockwise to move the
striking mode indicator.
15
HOW TO USE
How to use
English

Hour repeating function and silent function
The two functions can be used by operating the button located at the 8 o’clock position.
To use the hour repeating function
Firmly push the button to the second click
and release.
The hour repeating function is now
activated.
To use the silent function
Press the button halfway down to the first
click.
Doing this can activate the silent function so
that chiming can be muted as long as the
button is pressed.
Hour repeating function
The hour repeating function lets you know the current hour(s) by chiming the number of hours.
○ The number of hours that the watch chimes changes at 50 minutes every hour.
【Ex.】The watch chimes twice if you activate this function between 1:50 and 2:50.
* The hour repeating function can be activated at anytime you press the button located at
the 8 o’clock position, regardless of the hour striking mode.
Silent function
The silent function can immediately prevent the chime from sounding as long as the button
is pressed halfway down to the first click, which controls the movement of the hammer.
○ Keep pressing the button halfway down until the chime stops.
○ The hammer movement passes through the button, so that you will easily recognize by
finger feel when the chime finishes. Also, you will know when the chime finishes by viewing
the movement of the gears near the hammer and slow governor.
○ Release the button when the chime finishes.
Hammer
Slow
governor
Button
16 HOW TO USE
How to use
■
TO PRESERVE THE QUALITY OF YOUR
WATCH
After-sale service
Notes on guarantee and repair
○Contact the retailer from whom the watch was purchased or SEIKO CUSTOMER SERVICE
CENTER for repair or overhaul.
○Within the guarantee period, present the certificate of guarantee to receive repair services.
○ Guarantee coverage is provided in the certificate of guarantee. Read carefully and retain
it.
○For repair services after the guarantee period has expired, if the functions of the watch can
be restored by repair work, we will undertake repair services upon request and payment.
Replacement parts
○ Please keep in mind that if original parts are not available, they may be replaced with
substitutes whose outward appearance may differ from the originals.
Inspection and adjustment by disassembly and
cleaning (overhaul)
○ Periodic inspection and adjustment by disassembly and cleaning (overhaul) is
recommended approximately once every 2 years in order to maintain optimal performance
of the watch for a long time.
○ The movement of this watch comprises over 600 individual parts. To ensure that this
mechanism works properly all the time, washing parts, changing oil, adjusting accuracy,
checking functions and replacing consumable parts on a regular basis are important. The
first overhaul after the purchase of your watch is particularly important for preserving long-
time use of your watch. According to use conditions, the oil retaining condition of your watch
mechanical parts may deteriorate, abrasion of the parts may occur due to contamination
of oil, which may ultimately lead the watch itself to stop.
Please contact the retailer from whom the watch was purchased for inspection and
adjustment by disassembly and cleaning (overhaul). For replacement of parts, please
specify “SEIKO GENUINE PARTS”. When asking for inspection and adjustment by
disassembly and cleaning (overhaul), make sure that the gasket and push pin are also
replaced with new ones.
17
TO PRESERVE THE QUALITY OF YOUR WATCH
English

Daily care
The watch requires good daily care
○ The watch body and band touch the skin directly just as underwear.
Keep the watch body and band clean in order to avoid stain on the sleeve edge or rash or
itch.
After removing the watch from your wrist, wipe perspiration or moisture with a soft cloth as
soon as possible.
○ Do not use any chemical agent such as cleaner to clean the watch.
Turn the crown from time to time. (Only several turns in
slow movement will be enough.)
○ This prevents corrosion of the crown and helps to extend the life of the gasket in use.
○ Stainless steel is a highly rust-resistant metal. However, rust will form if contaminants are
left on it for a long time.
Remarks on 18-karat gold
○ 18-karat gold (18KT) is an alloy comprised of 75% of gold and 25% of other metals.
Depending on the proportion of the other metals mixed with the gold, the 18-karat gold is
classified into three colors such as yellow gold (YG), white gold (WG) and pink gold (PG).
Decoloration of 18-karat gold
○ While gold can maintain its glittering quality, other metal components in the alloy may
discolor to look like reddish or blackish due to various reasons.
○ Daily care helps to prevent discoloration of the alloy, however, if the discoloration or stain
of the alloy persists even after wiping the watch off, take your watch to the retailer from
whom the watch was purchased for refinishing. (Refinishing will be done at a cost.)
Watch body / metal bracelet
Length adjustment service
○ For the length adjustment service of the 18-karat gold or platinum bracelet, ask the retailer
from whom the watch was purchased.
The watch will be submitted to CREDOR SERVICE STUDIO for the length adjustment.
It may take two to three weeks depending on the model to adjust the length of the bracelet.
○
The length adjustment service of the 18-karat gold, platinum or stainless steel mesh bracelet
will not be charged only for the first time. However, the cost for materials or parts necessary
for the length adjustment and repair cost other than the length adjustment will be charged.
○ The length adjustment service of stainless-steel band is available from the retailer from
whom the watch was purchased or SEIKO CUSTOMER SERVICE CENTER. Some other
retailers may charge you for the length adjustment or may not undertake such treatments.
Periodic cleaning
○ Periodic cleaning is highly recommended to enjoy the best quality of the watch for a long
time.
Ask the retailer from whom the watch was purchased or the CREDOR SERVICE STUDIO
through your nearby CREDOR retailers. (Cleaning may be done at a cost.)
18 TO PRESERVE THE QUALITY OF YOUR WATCH
Band
The band touches the skin directly and becomes dirty from sweat or dust. Therefore,
lack of care may accelerate deterioration of the band or cause skin irritation or stain
on the sleeve edge. The watch requires a lot of attention for long usage.
Metallic band
○Moisture, sweat or soil will cause rust even on a stainless steel band if they are left for a
long time.
○Lack of care may cause a yellowish or gold stain on the lower sleeve edge of shirts.
○ Wipe off moisture, sweat or soil with a soft cloth as soon as possible.
○ To clean the soil around the joint gaps of the band, wipe it out in water and then brush it off
with a soft toothbrush. (Protect the watch body from water splashes by wrapping it up in
plastic wrap etc.)
Wipe off the remaining moisture with a soft cloth.
○ Because some titanium bracelets use pins made of stainless steel, which has outstanding
strength, rust may form in the stainless steel parts.
○ If rust advances, pins may poke out or drop out, and the watch case may fall off the bracelet,
or the clasp may not open.
○ If a pin is poking out, personal injury may result. In such a case, refrain from using the watch
and request repair.
Leather band
○ A leather band is susceptible to discoloration and deterioration from moisture, sweat and
direct sunlight.
○ Wipe off moisture and sweat as soon as possible by gently blotting them up with a dry cloth.
○ Do not expose the watch to direct sunlight for a long time.
○ Please take care when wearing a watch with light-colored band, as dirt is likely to show up.
○ Refrain from wearing a leather band watch other than Aqua Free bands while swimming,
and when working with water even if the watch itself is water-resistant enforced for daily
use.
Notes on skin irritation and allergy
Skin irritation caused by a band has various reasons such as allergy to metals or leathers, or
skin reactions against friction on dust or the band itself.
Notes on the length of the band
Adjust the band to allow a little clearance with your wrist to ensure proper airflow.
When wearing the watch, leave enough room to insert a finger between the band
and your wrist.
19
TO PRESERVE THE QUALITY OF YOUR WATCH
English

Magnetic resistance (Magnetic influence)
Affected by nearby magnetism, a watch may temporarily gain or lose time or stop operating.
This watch is a magnetic resistant watch that is fully compliant with JIS level-1 standard.
Conditions of use
Keep the watch more than 5 cm away from magnetic products.
(JIS-1)
If the watch becomes magnetized and its accuracy deteriorates to an extent exceeding the specified
rate under normal use, the watch may need to be demagnetized. In this case, you will be charged
for demagnetization and accuracy readjustment even if it happens within the guarantee period.
Examples of common magnetic products that may affect watches
The reason why this watch is affected by magnetism
The built-in speed-regulating mechanism is provided with a magnet, which may be influenced by
a strong external magnetic field.
Shock
bCAUTION
This watch incorporates a complicated mechanism, comprising individual parts that exceed
the number that ordinary timepieces have.
Exercise caution so as not to subject the watch to excessive shock or vibration.
Smartphone, cellular phone, tablet terminal
(speaker, magnet of cover)
AC adapter Bag
(with magnet
buckle)
AC-powered
shaver
Magnetic
cooking device
Portable radio
(speaker)
Magnetic
necklace
Magnetic health
pillow
20 TO PRESERVE THE QUALITY OF YOUR WATCH
Troubleshooting
Troubles Possible causes Solutions
The watch stops operating. The mainspring has not been
wound.
Turn the crown to wind the mainspring
and reset the time. While you are wearing
the watch or when you take it off, check
the remaining power shown by the power
reserve indicator and wind the
mainspring if necessary.
The watch stops even though
the power reserve indicator is
not showing “0”.
The watch has been left at a
low temperature (below 0°C).
Turn the crown to wind the mainspring.
Under a low-temperature condition
(below 0°C), the watch may stop when
the power reserve indicator shows less
than one-fourth of the power reserve.
The watch goes to the
checkup mode when the
crown is pulled out twice within
3 seconds. (The checkup
mode is for delivery
inspection.)
In order to return to the normal mode,
push the crown back to its normal
position, and pull it out to the second
click, and then push it back again to its
normal position. Even if the watch is left
untouched while it is in the checkup
mode, it will automatically return to the
normal mode after a few minutes.
* Wait until the watch starts moving
normally to set the time.
The watch temporarily loses/
gains time.
The watch has been left in
extremely high or low
temperatures for a long time.
Return the watch to a normal temperature
so that it works accurately as usual, and
then reset the time. The watch has been
adjusted so that it works accurately when
it is worn on your wrist under a normal
temperature range between 5°C and
35°C.
The watch was brought into
close contact with a magnetic
object.
Correct this condition by moving and
keeping the watch away from the
magnetic source, and reset the time. If
this action does not correct the condition,
contact the retailer from whom the watch
was purchased.
The watch was dropped, worn
while playing active sports, hit
against hard surfaces, or
exposed to strong vibrations.
Reset the time. If the watch does not
return to its normal accuracy after
resetting the time, contact the retailer
from whom the watch was purchased.
Right after starting the watch,
it seems that the seconds
hand moves more quickly than
usual when setting the time.
When the watch starts moving,
it takes a little time before the
speed-regulating unit starts
operating. (This is not a
malfunction.)
It takes several seconds before the
speed-regulating unit starts operating.
To set the time correctly, wait for
approximately 30 seconds after the
seconds hand starts to move, and set the
time.
Blur in the display persists.
This condensation temporarily
occurs due to a temperature
difference between the inside
of the watch and the outside
environment.
Condensation will clear when the
temperature difference is reduced. No
repair is needed.
Moisture has entered the
watch.
Consult the retailer from whom the watch
was purchased.
21
TO PRESERVE THE QUALITY OF YOUR WATCH
English

Troubles Possible causes Solutions
The hour striking function does
not work.
The power supplied by the
mainspring for the hour
striking function has been
consumed.
Refer to “How to wind the mainspring for
the hour striking function”→ P. 8 to wind
the mainspring for the hour striking
function and reset the time.
The power reserve indicator
for the watch mechanism
shows less than one quarter.
Refer to “How to wind the mainspring for
the watch mechanism”→ P. 8 to wind the
mainspring for the watch mechanism and
reset the time.
The hour striking mode is set
to the “SILENCE” or
“ORIGINAL” mode.
Refer to “How to change the hour striking
mode”→ P. 15 to change the mode to the
“SONNERIE” mode.
You have changed the hour
striking mode to either
“SILENCE” or “ORIGINAL”
mode while the minute hand is
pointing to any of the minute
markers between 50 and 59.
In this case, the watch may fail to correctly
chime the first hour on the hour (0
minute). From the next hour, the watch
will correctly chime on the hour.
The hour repeating function
chimes with longer intervals.
The power reserve indicator
for the hour striking function is
showing less than “0.”
Refer to “How to wind the mainspring for
the hour striking function”→ P. 8 to wind
the mainspring for the hour striking
function and reset the time.
* For the solution of troubles other than above, contact the retailer from whom the watch was
purchased.
■ SPECIFICATIONS (Movement)
Cal. NO 7R06
Features Hour, minute and seconds hands, hour striking mode indicator, power reserve
indicator (for the watch mechanism and for the hour striking function)
Frequency of
crystal oscillator 32,768 Hz (Hz = Cycles per second)
Loss/Gain
Within 15 seconds per month (equivalent to 1 second per day)
(If the watch is worn on your wrist within normal temperature range between 5 °C
and 35 °C.)
Operational
temperature range
-10°C ~ +60°C
Under a low-temperature condition (below 0 °C), always keep at least one-fourth of
the watch power shown by the power reserve indicator.
Driving system Manual winding type
Duration Approx. 48 hours
Additional functions “SONNERIE” mechanism, Hour repeating function
IC (Integrated
Circuit) Oscillator, frequency divider, and spring drive control circuit (C-MOS-IC): 1 piece
Hand movement Glide motion
Jewels 88 jewels
* The specifications are subject to change without prior notice due to product improvement.
22 TO PRESERVE THE QUALITY OF YOUR WATCH
