Seiko W620 User manual

INSTRUCTIONS (P. 3)
BEDIENUNGSANLEITUNG (S. 25)
INSTRUCTIONS (P. 48)
ISTRUZIONI (P. 70)
INSTRUCCIONES (P. 93)
INSTRUÇÕES (P. 115)
用法説明 (137 頁)
Cal. W620

2
English
You are now the proud owner of a SEIKO Digital Quartz Watch Cal. W620. For best results, please
read the instructions in this booklet carefully before using your SEIKO Digital Quartz Watch.
Please keep this manual handy for ready reference.
Sie sind jetzt Besitzer einer SEIKO Digital-Quarzuhr Kal. W620. Bitte lesen Sie diese Bedienungsan-
leitung vor Verwendung der Uhr sorgfältig durch und heben Sie sie gut auf.
Vous voici l’heureux propriétaire d’une montre numérique SEIKO quartz Cal. W620. Pour obtenir
d’excellentes performances de cet article SEIKO, veuillez lire attentivement cette brochure que
vous conserverez pour toute référence ultérieure.
Siete ora in possesso di un orologio SEIKO digitale al quarzo Cal. W620. Per ottenere i migliori
possibili risultati dal Vostro orologio, leggere attentamente le istruzioni di questo manuale prima
di utilizzare il Vostro orologio SEIKO digitale al quarzo. Conservare poi il manuale stesso per ogni
qualsiasi eventuale futuro riferimento.
Enhorabuena por su adquisición de un reloj SEIKO digital de cuarzo Cal. W620. Para óptimo
resultado, lea detenidamente las instrucciones de este folleto antes de usar el reloj. Guarde este
manual para consulta posterior.
Você pode sentir-se orgulhoso de possuir um Relógio SEIKO Quartz Digital Cal. W620. Para obter
os melhores resultados, leia atentamente as instruções contidas neste opúsculo antes de usar o
seu Relógio SEIKO Quartz Digital. Queira conservar este manual para referências futuras.

3
English
ENGLISH
CONTENTS
Page
MODE CHANGE ...................................................................................................... 5
TIME/CALENDAR MODE ........................................................................................ 6
STOPWATCH MODE ............................................................................................... 7
STROKE MODE ....................................................................................................... 9
TIMER MODE .......................................................................................................... 10
ALARM MODE ........................................................................................................ 12
ILLUMINATING LIGHT ............................................................................................. 14
NOTES ON USING THE WATCH ............................................................................. 15
BATTERY CHANGE .................................................................................................. 17
TO PRESERVE THE QUALITY OF YOUR WATCH................................................... 19
SPECIFICATIONS ..................................................................................................... 23

4
English
CAL. W620
TIME/CALENDAR
STOPWATCH
●The stopwatch measures up to 10 hours in 1/100 second increments.
●Memory recall function: Up to 8 lap times can be stored in memory.
STROKE FUNCTION
●The number of strokes per minute is automatically calculated by measuring the time
required to make three strokes.
TIMER
●Preset timer function: 9 different lengths of time have been preset.
●Adjustable timer function: Can be set for up to 9 hours and 59 minutes in one-minute
increments.
DAILY ALARM
ILLUMINATING LIGHT (ELECTROLUMINESCENT PANEL)

5
English
MODE CHANGE
AWith each press, the mode changes in the following order:
TIME/
CALENDAR
mode
STOPWATCH
mode ➡TIMER mode ➡ALARM mode
➡
➡➡
STROKE
mode
CHRO
B
A
C
D
E
Mode mark
(No mode mark in TIME/
CALENDAR mode)

6
English
TIME/CALENDAR MODE
TIME/CALENDAR SETTING
B
▼
C
▼
D
▼
▼
BReturn to TIME/CALENDAR mode.
Set the flashing digits.
▼
APress to show TIME/CALENDAR mode.
Press for 2 to 3 seconds.
Select the digits to be adjusted.
▲
Minutes
Seconds
▲
Hour
▲
Date
▲
Month
12-/24-hour
indication Year
▲
▲
▲
B
A
C
D

7
English
STOPWATCH MODE
●The stopwatch measures up to 10 hours in 1/100 second increments.
●The first 8 lap times are automatically stored in memory.
APress to show STOPWATCH mode.
STOPWATCH OPERATION
Standard measurement
C
START
C
STOP RESET
D
▼
▼
CHRO
A
C
D
Current time
Time measured

8
English
Accumulated elapsed time measurement
C
START
C
STOP RESTART
▼
▼
C
STOP RESET
D
▼
C
○○○○
▼
BPress to activate the memory recall func-
tion.
▼
DWith each press, the stored data are re-
called from the oldest to the newest.
▼
BReturn to STOPWATCH mode.
* Restart and stop of the stopwatch can be repeated by pressing button C.
Lap time measurement
C
START LAP 1 LAP 2
▼
▼
C
STOP RESET
D
▼
○○○○
▼
DD
* Measurement of lap time can be repeated by pressing button D.
●MEMORY RECALL FUNCTION
The stored data can be recalled either during or after the measurement.
CHRO
RCL
D
B
Recall
mark

9
English
STROKE MODE
●The number of strokes per minute is automatically calculated by measuring the time
required to make three strokes.
APress to show STROKE mode.
A
C
C
▼
CPress to start measurement.
Press to stop measurement when the third
stroke is made.
* The number of strokes per minute will be
displayed.
PACE

10
English
TIMER MODE
●Two types of timers are available: preset timer and adjustable timer.
PRESET TIMER SETTING
APress to show TIMER mode.
D
▲
3 minutes 5 minutes
▲
10 minutes
▲
15 minutes
▲
T M R
B
A
C
D
Set time
Current time
Number of times
the countdown is repeated
Select the preset time.
▲
20 minutes
45 minutes 40 minutes 35 minutes 30 minutes
▲
▲
▲
▲

11
English
ADJUSTABLE TIMER SETTING
C
▼
Select the digits to be adjusted.
B
▼
DSet the flashing digits.
▼
▼
BReturn to TIMER mode.
TIMER OPERATION
C
START
C
STOP RESTART
▼
▼
C
STOP RESET
D
▼
C
○○○○
▼
Press for 2 to 3 seconds.
▲
Minutes
Hour
▲
* When the set time is up, a warning sound beeps for 5 seconds. To stop it manually, press any one
of the buttons.

12
English
A L M
ALARM MODE
●The alarm can be set to ring on a 24-hour basis.
ALARM TIME SETTING
Set alarm time
B
▼
CSelect the digits to be adjusted.
▼
▼
APress to show ALARM mode.
▲
Minutes
Hour
▲
▼
D
▼
Set the flashing digits.
BReturn to ALARM mode.
* The alarm is automatically engaged.
“on”/“– –”
(alarm engagement/
disengagement) mark
Press for 2 to 3 seconds.
B
A
C
D
Current time

13
English
●ALARM ENGAGEMENT/DISENGAGEMENT
CWith each press in ALARM mode, the
alarm is alternately engaged and disen-
gaged.
A L M
C
“on”/“– –” (alarm engagement/disengagement) mark
Alarm mark
●TURNING ON/OFF OF HOURLY TIME SIGNAL AND BUTTON OPERATION
CONFIRMATION SOUND
CWith each press in TIME/CALENDAR
mode, hourly time signal and confirma-
tion sound are turned on and off alter-
nately.
* At the designated time the alarm rings for 20
seconds, and the display is illuminated as the
alarm rings. To stop them manually, press any
of the buttons.
C
* When the hourly time signal mark is displayed,
the hourly time signal rings every hour on the
hour and the confirmation sound beeps with
each press of the buttons.
Hourly time
signal mark

14
English
ILLUMINATING LIGHT (Electroluminescent panel)
Turn on the illuminating light.
E
* The display panel is illuminated for 3
seconds.
E

15
English
NOTES ON USING THE WATCH
MODE CHANGE
●If the stopwatch is not reset to “00” and button A is pressed to change the mode from the
STOPWATCH, the TIMER mode appears, skipping the STROKE mode.
TIME/CALENDAR MODE
●In setting the seconds, when the seconds read any number from “30” to “59” and button D is pressed,
one minute is added and the seconds are reset to “00”.
●Note on unusual display:
While setting the time/calendar, all the segments of the display will light up if both buttons C and D
are pressed at the same time. This is not a malfunction. Press any one of the buttons to return to the
TIME/CALENDAR mode, and then set the time/calendar again.
STOPWATCH MODE
●The lap number counts up to “99”. After that, it is displayed in 2
digits such as “00” for 100, “01” for 101, and so on.
●Even if the digits are reset to “00” in the stopwatch measurement,
stored data is not erased and can be recalled unless a new
measurement is started.
CHRO
Lap No.
Lap time
●Even if the STOPWATCH mode is changed to another while the measurement is in progress, it
continues counting properly and the flashing STOPWATCH mode mark indicates that the stopwatch
is in use.
●In memory recall after measurement, the oldest measurement in memory is displayed first.
In memory recall during measurement, the newest one is displayed first.

16
English
STROKE MODE
●The time required to make each stroke is measured up to 9 seconds and 99 in 1/100 second
increments.
●The measurable number of strokes per minute is between 18 and 240.
●The stroke and stopwatch functions cannot be used simultaneously.
●If the measurement is stopped within 0.75 seconds after it is started, “- - -” is displayed.
If the measurement is not stopped after more than 10 seconds have elapsed, “Err” will automatically
appear. Even if “- - -” or “Err” is shown, the measurement can be started by pressing button C.
PACE
PACE
TIMER MODE
●The adjustable timer can be set up to 9 hours and 59 minutes in minute increments.
●If button D is pressed while the time set for the adjustable timer is displayed, the set time will be
canceled and the preset time of 3 minutes will be shown.
●Restart and stop of the timer can be repeated by pressing button C.
●After the countdown is repeated 99 times, the number of times the countdown is repeated is displayed
in 2 digits such as “00” for 100, “01” for 101, and so on.
ALARM MODE
●Alarm test: The alarm can be tested by keeping buttons C and D pressed in the TIME/CALENDAR
mode.

17
English
ILLUMINATING LIGHT (Electroluminescent panel)
●The electroluminescent panel loses its luminance as the battery voltage decreases. Also, its
luminance level decreases gradually with use.
●When the illuminating light becomes dim, replace the battery with a new one. If the illuminating light
remains dim after the battery is replaced, have the electroluminescent panel replaced with a new one
by the retailer from whom the watch was purchased, or an AUTHORIZED SEIKO DEALER. It will be
replaced at cost.
●While the illuminating light is used, the watch gives out a slight noise. However, this is not a
malfunction.
BATTERY CHANGE
The miniature battery which powers your watch should last approximately
2 years. However, because the battery is inserted at the factory to check
the function and performance of the watch, its actual life once in your
possession may be less than the specified period. When the battery expires,
be sure to replace it as soon as possible to prevent any malfunction. For
battery replacement, we recommend that you contact an AUTHORIZED
SEIKO DEALER and request SEIKO CR2025 battery.
2
Years
* The battery life may be less than 2 years if the alarm is used for more than 20 seconds
a day and/or the illuminating light more than 3 times a day.
●Battery life indicator
When all the digits start flashing, have the battery replaced with a new one as soon
as possible.

18
English
●Necessary procedure after battery change
After the battery is replaced with a new one, or if an abnormal display (broken digits,
etc.) appears, follow the procedure below to reset the IC.
Press and hold buttons A, B, C and D at the same time for 2 to
3 seconds. The display shown at right appears.
* Before using the watch, set the time/calendar and alarm.
●Never short-circuit, heat or otherwise tamper with the battery, and never
expose it to fire. The battery may burst, become very hot or catch fire.
●The battery is not rechargeable. Never attempt to recharge it, as this may cause
battery leakage or damage to the battery.
CAUTION
●Do not remove the battery from the watch.
●If it is necessary to take out the battery, keep it out of the reach of children. If
a child swallows it, consult a doctor immediately.
WARNING

19
English
TO PRESERVE THE QUALITY OF YOUR WATCH
Condition
of use
WATER
RESISTANT
5 BAR
WATER
RESISTANT
No indication
Indication on
case back
Non-water
resistant
Degree
of water
resistance*
Accidental
contact with
water such
as rain and
splashes
Swimming,
yachting and
taking a
shower
No No No No
Yes No No No
Yes Yes No No
Yes Yes Yes No
WATER
RESISTANT
10/15/20 BAR
Scuba
diving**
and
saturation
diving
Taking a bath
and shallow
diving
3 bar
5 bar
10/15/20 bar
■WATER RESISTANCE

20
English
• If the watch becomes wet, have it
checked by an AUTHORIZED
SEIKO DEALER or SERVICE
CENTER.
5 bar WR
Your watch works with stable
accuracy within a temperature
range of 5°C and 35°C (41°F
and 95°F).
10/15/20
bar WR
Temperatures over 50°C (122°F) or below
–10°C (+14°F) may cause a slight time loss
or gain or battery leakage or shorten the
battery life.
However, the above conditions will be
corrected when the watch returns to normal
temperature.
●Non-water resistant
●Water resistant 5/10/15/20 bar
• Do not operate the buttons when
the watch is wet or in water.
If used in sea water, rinse the
watch in fresh water and dry it
completely.
• When taking a shower with a water
resistant 5 bar watch, or taking a
bath with a water resistant 10, 15
or 20 bar watch, be sure to observe the
following:
* Do not operate the buttons when the watch
is wet with soapy water or shampoo.
* If the watch is left in warm water, a slight
time loss or gain may be caused. This
condition, however, will be corrected when
the watch returns to normal temperature.
* Pressure in bar is a test pressure and
should not be considered as
corresponding to actual diving depth
since swimming movement tends to
increase the pressure at a given
depth. Care should also be taken on
diving into water.
** We recommend that you wear a
SEIKO Diver’s Watch for scuba
diving.
■TEMPERATURES
+50°C
-10°C
