Seiko 6M25 User manual

INSTRUCTIONS (P. 3)
INSTRUCTIONS (P. 30)
INSTRUCCIONES (P. 58)
BEDIENUNGSANLEITUNG (S. 86)
ISTRUZIONI (P. 114)
INSTRUÇÕES (P. 143)
用法説明 (171 頁)
Cal. 6M25, 6M26

English
2
You are now the proud owner of a SEIKO Analogue Quartz Watch Cal. 6M25/6M26. For best
results, please read the instructions in this booklet carefully before using your SEIKO Analogue
Quartz Watch. Please keep this manual handy for ready reference.
Vous voici l’heureux propriétaire d’une montre quartz analogique SEIKO Cal. 6M25/6M26. Pour
obtenir d’excellentes performances de cet article SEIKO, veuillez lire attentivement cette brochure
que vous conserverez pour toute référence ultérieure.
Enhorabuena por su adquisición de un reloj SEIKO analógico de cuarzo Cal. 6M25/6M26. Para
óptimo resultado, lea detenidamente las instrucciones de este folleto antes de usar el reloj. Guarde
este manual para consulta posterior.
Sie sind jetzt Besitzer einer SEIKO Analog-Quarzuhr Kal. 6M25/6M26. Bitte lesen Sie diese Bedie-
nungsanleitung vor Verwendung der Uhr sorgfältig durch und heben Sie sie gut auf.
Siete ora in possesso di un orologio SEIKO Analogico al Quarzo Cal. 6M25/6M26. Per ottenere i
migliori possibili risultati dal Vostro orologio, leggere attentamente le istruzioni di questo manuale
prima di utilizzare il Vostro orologio SEIKO analogico al quarzo. Conservare poi il manuale stesso
per ogni qualsiasi eventuale futuro riferimento.
Você pode sentir-se orgulhoso de possuir um Relógio SEIKO Quartz Análogo Cal. 6M25/6M26.
Para obter os melhores resultados, leia atentamente as instruções contidas neste opúsculo antes
de usar o seu Relógio SEIKO Quartz Análogo. Queira conservar este manual para referências
futuras.
6M25/6M26

English
3
ENGLISH
CONTENTS
Page
FEATURES .................................................................................................................. 4
MODES AND DISPLAYS ............................................................................................ 5
ADJUSTING THE HAND AND DATE POSITIONS ....................................................... 7
TIME SETTING ............................................................................................................ 9
CALENDAR ................................................................................................................. 10
ALARM ....................................................................................................................... 11
TIMER ......................................................................................................................... 13
STOPWATCH .............................................................................................................. 15
TACHYMETER ............................................................................................................ 18
NECESSARY PROCEDURE AFTER BATTERY CHANGE ............................................ 20
NOTES ON OPERATING THE WATCH ....................................................................... 22
BATTERY LIFE INDICATOR ........................................................................................ 24
BATTERY CHANGE ..................................................................................................... 24
TO PRESERVE THE QUALITY OF YOUR WATCH ...................................................... 26
SPECIFICATIONS ........................................................................................................ 29

English
4
SEIKO ANALOGUE QUARTZ
Cal. 6M25, 6M26
FEATURES
TIME TIMER
● Hour, minute & second hands
● Up to 60 minutes can be set in
minute increments.
CALENDAR
● Date displayed in numerals
● Month indicated by hands
● Calendar adjusts automatically
except February of leap years.
ALARM
● Can be set to ring on a 12-hour
basis.
STOPWATCH
● Measures up to 60 minutes in 1/10
second increments.
TACHYMETER
● For models with tachymeter scale

English
5
MODES AND DISPLAYS
[Cal. 6M26]
There are two buttons and a crown.
a: Normal position b: Extended position
Date Date
CROWN
B
A
a b
Hour hand Minute hand Hour hand Minute hand
Second hand
MODE INDICATOR MODE INDICATOR
5
A
B
a b
Second hand
5
[Cal. 6M25]
CROWN

English
6
MODE CHANGE
CROWN Turn at normal position clockwise or counterclockwise.
Time
setting
➡
Pull out
CROWN.
➡
Adjusting
hand & date
positions
Pull out
CROWN.
➡
Pull out
CROWN.
➡Time
setting
Pull out
CROWN.
Calendar
setting
TIME mode
(Alarm disengaged)
TIME mode
(Alarm engaged)
STOPWATCH mode ALARM SETTING mode
CALENDAR mode TIMER mode

English
7
ADJUSTING THE HAND AND DATE POSITIONS
●Before setting the time and calendar, be sure to use STOPWATCH mode to check
the positions of Hour, Minute and Second hands and the date numeral.
CROWN Turn to set MODE INDICATOR to “CHRONO.”.
* If the stopwatch is counting, first press Button B
to stop measurement and then press Button A to
reset the hands.
HOW TO RESET THE HAND AND DATE POSITIONS
●If the hands do not return to the 12 o’clock position or the date numeral does not
appear at the center of the calendar frame, reset them following the procedure
below. If they do not need resetting, go on to the next section (“TIME SETTING”).
CROWN Pull out.
▼
➠
CROWN
➡
10

English
8
Minute hand
BPress to select what is to be ad-
justed (hands or date) in the fol-
lowing order
(See *1 on page 22) :
▲
Second hand
Hour handDate
▲
▲
▲
A
CROWN
▼
Push back in to normal position .
▼
CROWN
Calendar
frame
➡
▼
Press to reset the selected hand
to the 12 o’clock position or put
the date to the center of the cal-
endar frame.
(See *2 on page 22)
B
A
➠
10
10

English
9
TIME SETTING
CROWN Turn to set MODE INDICATOR to “TIME” or
“ALM.ON”.
CROWN Pull out.
Second
hand
Minute hand
Hour hand
➡
B
A
CROWN Push back in to
normal position
in accordance with a time signal.
▼
▼
▼
B
A
CROWN
➠
➠
5
5
Press to set Minute hand. (See *2
and *3 on page 22)
Press to set Hour hand. (See *2
and *4 on page 22)
* Second hand automatically
returns to the 12 o’clock
position.
CROWN

English
10
CALENDAR
●Themonthisindicatedbythehourmarker that all three hands pointto.
●Thedate is indicated by thenumeral shown in the calendarframe.
●Thecalendar automatically adjusts for oddand even months except Februaryof leap years.
CROWN Turn to set MODE INDICATOR to “DATE”.
CALENDAR SETTING
CROWN Pull out.
▼
B
▼
A
5
B
➠
CROWN
▼
A
10
➠
Month
[Ex.: December]
CROWN
Date
CROWN Push back in to
normal position .
Press to set the month (Ex. De-
cember).
(See *2 on page 22)
Press to set the date (Ex. 10th).
(See *2 on page 22)
➡

English
11
ALARM
ALARM SETTING
●The alarm can be set to ring on a 12-hour basis.
CROWN
B
B
A
➡
Hour hand
Minute hand
10 A
▼
▼
CROWN Turn to set MODE INDICATOR to
“ALM.ON” or “TIME” to engage
or disengage the alarm. (See the
following section)
Turn to set MODE INDICATOR to “ALM.SET”.
(See
*5 on page 22)
Press to set Minute hand. (See *2
and *3 on page 22)
Press to set Hour hand. (See *2 on
page 22)
CROWN

English
12
ALARM ENGAGEMENT/DISENGAGEMENT
• Alarm engagement • Alarm disengagement
CROWN Turn to set MODE INDI-
CATOR to “ALM.ON”.
(See also *6 on page 22)
CROWN Turn to set MODE INDI-
CATOR to “TIME”.
MODE INDICATOR
10 10
[TIME mode with alarm engaged] [TIME mode with alarm disengaged]
● Alarm rings at the designated time for 20 seconds.
* To stop it manually, press Button A or B.
● To check the designated alarm time, set MODE INDICATOR to “ALM.SET”.
Current time

English
13
●The timer can be set to count down up to 60 minutes in minute increments.
TIMER
CROWN Turn to set MODE INDICATOR to “TIMER”.
●Before setting the timer, check that the three hands are at “0” position.
TIMER SETTING
APress to set the desired amount
of time in minutes.
(See *2 on
page 22)
Minute hand
Second hand
A
10
* To set the timer for 60
minutes, set Minute hand
at “0” position.

English
14
TIMER OPERATION
B
➡
START
B
STOP
➡
B
RESTART
➡
B
STOP
➡
A
RESET
* Restart and stop of timer can be repeated by pressing Button B.
B
A
10
● When the set time is up, a warning sound beeps for approximately 5 seconds.
* To stop it manually, press Button A or B.
* See also *7 on page 22.

English
15
●Stopwatch measures up to 60 minutes in 1/10 second increments.
STOPWATCH
CROWN Turn to set MODE INDICATOR to “CHRONO.”.
Second hand
Minute hand
Hour hand
1/10 seconds
Seconds
Minutes
➡
➡
➡
● In the following cases, the stopwatch operations cannot be made:
1) While the timer warning sound is beeping (for about 5 seconds).
2) While the hands are moving quickly to catch up with the
accumulated elapsed time after the split time is released (less
than 5 seconds).
* See also *8 on page 23.
In other modes In STOPWATCH mode
HOW TO READ THE HANDS
●In STOPWATCH mode, each hand indicates the elapsed time as follows:

English
16
• For the first 1 minute
Ex.: 20 and 7/10 seconds
• After the first 1 minute
Ex.: during measurement Ex.: when measurement is
stopped or split time is
measured
Minute hand
Second hand
1/10 second
hand**
Minute hand
10
10
1/10 second
hand***
Minute hand
Second hand
* 1/10 second hand moves
from 0 to 9 (minute markers)
repeatedly.
**1/10 second hand stays at
“0” position while the
stopwatch is counting.
*** When the measurement is
stopped or split time is
measured, 1/10 second
hand indicates the 1/10
seconds measured.
When the measurement is
restarted or split time is
released, it returns to “0”
position.
1/10 second
hand*
10

English
17
BA A B
START SPLIT
RELEASE
STOP
SPLIT
* Measurement and release of split time can be repeated by pressing Button A.
○○
A
RESET
3 Split time measurement
BB B B
START RESTART STOP
STOP
○○
A
RESET
2 Accumulated elapsed time measurement
* Restart and stop of stopwatch can be repeated by pressing Button B.
STOPWATCH OPERATION
●Before using the stopwatch, be sure to reset the hands to “0” position.
B
START
B
STOP
A
RESET
1 Standard measurement
10
A
B

English
18
TACHYMETER
(for models with tachymeter scale on the dial)
To measure the hourly average speed of a vehicle
Use the stopwatch to determine
how many seconds it takes to go
1 km or 1 mile.
1
Tachymeter scale indicated by
Second hand gives the average
speed per hour.
2
Ex. 1Ex. 1
Second hand:
40 seconds
“90” (tachymeter scale figure) x 1 (km or mile)
= 90 km/h or mph
Ex. 2: If the measuring distance is extended to 2 km or miles or shortened to 0.5 km or miles
and Second hand indicates “90” on tachymeter scale:
“90” (tachymeter scale figure) x 2 (km or mile) = 180 km/h or mph
“90” (tachymeter scale figure) x 0.5 (km or mile) = 45 km/h or mph
Tachymeter scale: “90”
* Tachymeter scale can be used only when the time required is less than 60 seconds.

English
19
To measure the hourly rate of operation
Use the stopwatch to measure
the time required to complete 1
job.
1
Tachymeter scale indicated by
Second hand gives the average
number of jobs accomplished per
hour.
2
“180” (tachymeter scale figure) x 1 job
= 180 jobs/hour
Ex. 1Ex. 1
Ex. 2: If 15 jobs are completed in 20 seconds:
“180” (tachymeter scale figure) x 15 jobs = 2700 jobs/hour
Second hand:
20 seconds
Tachymeter scale:
“180”

English
20
NECESSARY PROCEDURE AFTER BATTERY CHANGE
●When the battery is replaced, the information stored in the IC does not correspond
with the time and date actually displayed. Before using the watch, therefore, be sure
to reset the hands and date, following the procedure below.
CROWN Turn to set MODE INDICATOR to “CHRONO.”.
* If the stopwatch is counting, first press Button B
to stop measurement and then press Button A to
reset the hands.
➡
CROWN
▼
Pull out.
B
A
CROWN
➡
AB
OR
▼
▼
➠
7
AB
AND Press and hold at the same time
for 2 seconds.
* A beep sounds when the
buttons are released, and the
hands start to show
demonstration movement.
Press to stop the hands.
